AutoConnect PNT2001OBDHD24 User manual

12-24V
QUICK INSTALL GUIDE
8AM - 5PM Monday to Friday MT
CERTIFIED TRACKING SOLUTIONS
Thank-you for your purchase!
1.855.287.4477
You’ve made a smart decision. Please follow
5 QUICK STEPS shown in this guide.
REV061719
SERIES
PNT2001OBDHD
PNT2001OBDHD24
PNT2001OBDHD

PNT2001OBDHD
Depending upon the requirements, the device can be installed with
following options.
Type1: Device Only
Type2: PNT2001OBDHD with Starter Kill/input/output
Type3: PNT2001OBDHD with DRIVER ID
Type4: PNT2001OBDHD with Driver ID & PERF
Determine Installation Options
1
Red
White
Black
Green
Purple
Grey
Input 1( – )
Input 2( – )
Input 3( – )
Input 4( – )/PERF Switch Input
Buzzer Output
Yellow/Black
Yellow/Orange
Yellow/Green
Yellow/Red
Green/Blue
Grey/Black iButton Input
– GROUND MUST BE CONNECTED DIRECTLY TO CHASSIS WITH PAINT REMOVED –
Refer to the PNT2001OBDHD/JBUS Connections on the following page
Orange : Flashing Connected/Online
Green : 1Flash/Sec Valid GPS
Failure to adhere to these suggestions will result in a weak cellular
and/or GPS signal and will aect the performance of the device.
Secure in upper portion of dash in a hidden location with correct side
pointing skyward (label will indicate proper orientation). Example: Above
instrument cluster.
Do not cover with metal or position near any source of interference (Vehicle
Radio, BCM). Keep a safe distance of at least 24”.
Position the device in an Optimal Location
3
Connect OBD/JBUS(Optional)
4
Confirm LED Status
5
Type 1 : PNT2001 OBDHD
Type 2 : PNT2001OBDHD
with Starter kill/Inputs/Outputs (Optional)
Complete the wire connections according to
the required options
2
12-24 Volts ( + ) Constant
Ground
Starter kill ( – )
PERF Switch Ground
iButton Input
Ignition ( + ) (MUST be a true ignition source)
Black - GND
Red (12-24V+) - Constant
White-Key Ignition Source (+)
PNT2001OBDHD
Green - Starter Disable Out (-)
OPTIONAL
STARTER KILL
RELAY Vehicle Start
InteruptWire*
CUT
Red
White
87A
30
85
86
White-Key Ignition Source (+)
Red (12-24V+) - Constant
Yellow/Black - Input1 (-)
Yellow/Orange - Input2 (-)
Yellow/Green - Input3 (-)
Yellow/Red - Input4 (-)
Fuse
Black - GND
Black
Blue
PNT2001OBDHD
IMPORTANT: MUST BE TESTED
Please call 1855.287.4477 to test GPS device before closing up the dash.
Failure to follow these instructions may damage equipment and void its warranty.

PNT2001OBDHD
Type 3 : PNT2001OBDHD with Driver ID
White-Key Ignition Source (+)
Grey/Black - iButton Ground
Yellow/Black - Input1 (-)
Yellow/Orange - Input2 (-)
Yellow/Green- Input3 (-)
Yellow/Red- Input4 (-)
Green - Starter Disable Out (-)
Red (12-24V+) - Constant
Fuse
Black - GND
Grey - iButton Input
DRIVER iD PANEL
MOUNT SCANNER
DRIVER iD
FOB
1. Connect Red wire to Constant +12-24Vand fuse.
2. Connect Black wire to Ground.
3. Connect White wire to True Ignition (+).
4. Mount Driver iD Panel Mount Scanner.
1-2-3-4!
PNT2001OBDHD
Type 4 : PNT2001OBDHD
with Driver ID and PERF
White-Key Ignition Source (+)
Grey/Black - iButton Ground
Yellow/Red - Input4 (-)/PERF Switch Input
Yellow/Black - Input1 (-)
Yellow/Orange - Input2 (-)
Yellow/Green- Input3 (-)
Green - Starter Disable Out (-)
Red (12-24V+) - Constant
Fuse
Black - GND
G
Blue/White
rey - iButton Input
DRIVER iD PANEL
MOUNT SCANNER
DRIVER iD
FOB
ON OFF
Purple - PERF Switch Ground
SWITCH OPTION 1 SWITCH OPTION 2
Black
Purple Grey Red
PNT2001OBDHD

PNT2001OBDHD
OBD II Installation
PNT2001OBDHD
PNT2001OBDHD
1) Plug the 24-Pin Connector (1) into the device.
2) Connect the male end (2) of the direct connect cable to
the vehicle JBUS port.
3) Mount the device with the correct side facing up.
1) Unclip/unscrew vehicle JBUS port from the factory mounted position.
2) Plug the male end of the Y-Cable (1) to the unmounted
vehicle JBUS port.
3) Mount short (female JBUSI) end (2) of the Y-Cable to factory
mounting position.
4) Plug the 24-Pin Connector (3) into the device and position under
the top skin of the dash. Ensure correct side is facing up.
VEHICLE OBD PORT
VEHICLE OBD PORT
VEHICLE JBUS PORT
VEHICLE JBUS PORT
OPEN PORT
1) Unclip/unscrew vehicle OBD port from the factory mounted position.
2) Plug the male end of the Y-Cable (1) to the unmounted vehicle
OBDII port.
3) Mount short (female OBDII) end (2) of the Y-Cable to factory
mounting position.
4) Plug the 24-Pin Connector (3) into the device and position under the top
skin of the dash. Ensure correct side is facing up.
1
2
3
2
1PNT2001OBDHD
PNT2001OBDHD
OPEN PORT
1
2
3
2
1
1) Plug the 24-Pin Connector (1) into the device.
2) Connect the male end (2) of the direct connect cable to the
vehicle OBDII port.
3) Mount the device with the correct side facing up.
JBUS Installation
DIRECT DIRECT
INDIRECT
INDIRECT
IMPORTANT
DO NOT connect the red constant wire from step 2
IMPORTANT
DO NOT connect the red constant wire from step 2
