Automatic Technology Axess Pro Series 3000 User manual

Axess® Pro Series 3000
Commercial Shutter Opener
Featuring TrioCode™Technology
INSTALLATION INSTRUCTIONS | OWNERS COPY
Part # 92647 (Manual) V1.00

2Axess® Pro Series 3000 Owner Installation Instructions
WARNING: It is vital for the safety of persons to follow all
instructions.Failuretocomplywiththeinstallationinstructions
and the safety warnings may result in serious personal injury
and/or property and remote control opener damage. Please
save these instructions for future reference.
Automatic Technology (Australia) Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all
conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of
an Automatic Technology (Australia) Pty Ltd commercial shutter opener. Automatic Technology (Australia) Pty Ltd hereby
further expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any
person as a result whether directly or indirectly from failure to install the Automatic Technology (Australia) commercial
shutter opener in accordance with these installation instructions.
NOTE: A Photo Electric Beam Sensor must be fitted with
this opener. Failure to comply will void the warranty and may
cause serious personal injury and/or property damage.

Owner Installation Instructions Axess® Pro Series 3000 3
Important Safety Instructions 4
Features 6
Package Contents 8
Controllers Input And Output 8
Operating Controls 9
Before Drive Unit Installation 11
Installation 12
EasyBeam™ Installation 13
Programming The Opener 14
Menu Structure 14
Viewing And Editing Parameters 15
Setting Limits 16
Setting Limits: Via Transmitter 17
Coding Transmitters 18
Transmitter Editing 19
Transmitter Management 21
Remotely Coding Transmitters 23
Setting Pedestrian Position 24
Reprofiling The Door Travel 24
Control Board Adjustments 25
Current Trips 25
Auto-Close Times 25
Light Times 26
Motor Settings 27
Time Clock 31
Diagnostic Tools 33
Memory Tools 35
Specifications 36
Troubleshooting 37
Maintenance 38
Warranty 40
Axess® Pro Series 3000
Commercial Shutter Door Opener

4Axess® Pro Series 3000 Owner Installation Instructions
For Safety protection, a Photo Electric Beam must be fitted with this opener. Failure to
comply will void the warranty and may result in serious personal injury and/or property
damage.
DO NOT operate the opener unless the door is in full view and free from objects such
as cars and children/people. Make sure that the door has finished moving before
entering or leaving the driveway.
DO NOT operate the opener when children/people are near the door. Children
must be supervised near the door at all times when the opener is in use.
Serious personal injury and/or property damage can result from failure to
follow this warning.
DO NOT allow children to operate the opener. Any device that can
operate the opener, make sure it is out of reach of children and that
the doorway is in full view at all times. Serious personal injury and/or
property damage can result from failure to follow this warning.
DO NOT wear rings, watches, or loose clothing while installing
or servicing Axess® pro series 3000 shutter opener.
The opener is not intended for use by young children or
infirm persons without adequate supervision. Children
should be supervised to ensure that they do not play with
the transmitters or the opener.
The opener is not showerproof - it should not be
immersed in water or sprayed directly by a hose or
other water carrying device.
WARNING: It is vital for the safety of people who
install, maintain or operate the door to follow all
instructions. Failure to comply with the following
Safety instructions may result in serious personal
injury and/or property damage.
Important Safety Instructions

Owner Installation Instructions Axess® Pro Series 3000 5
Connect the power supply cord to properly earthed mains. Electrical wiring must be
compliance with your local building and electrical codes.
The door must be well balanced and in good working order. Door springs, brackets and
their hardware are under extreme tension and can cause serious personal injury. Do
not attempt to adjust them. A faulty door must be repaired by a commercial door
professional prior to opener installation.
Remove or disengage all locks and mechanisms prior to installation of the
opener.
Keep hands and loose clothing clear of the door and opener at all times.
When using Auto-Close mode a photo electric beam must be fitted
correctly and tested for operation at regular intervals. Extreme caution
is recommended when using Auto-Close mode. All Safety Instructions
above must be followed.
Make sure that the door is fully open before driving into or out
of the driveway. And make sure the door is fully closed before
leaving the driveway.
Frequently examine the installation, in particular guides and
mountings for signs of wear, damage or imbalance. DO
NOT use if repair or adjustment is needed since a fault
in the installation or an incorrectly balanced door may
cause injury.
After installation a full function test of the system
and safety devices must be done.
Important Safety Instructions
Please read this installation instruction manual before
attempting to install, maintain or use the opener.
Failure to comply with the instructions may result
in serious injury and/or property damage.

6Axess® Pro Series 3000 Owner Installation Instructions
Thank you for purchasing the Axess® Pro Series 3000
Commercial Shutter Opener. This opener is designed to
suit commercial heavy duty Shutter doors. The components
and materials used in this opener are of the latest
technology and highest quality. Listed below are
some of the many features.
Operation
To operate the door opener, simply activate one of the integrated controller’s
inputs by using TrioCode™ handheld transmitter, keypad or other devices
including key switches, swipe cards, and loop detectors. In response, the door
will then open, stop or close as requested. The opener can also be configured to
close automatically using one of several Auto-Close modes.
Operator Console
Incorporated into the integrated controller is a simple to use operator console which
consists of several buttons and a display. The console offers a user friendly menu
system that greatly simplifies installation, adjustment and status indication. Features
include editing transmitter storage and names, setting various parameters, selecting
specialised operating modes and performing system diagnostics.
Status Indication
The status of the door opener can be determined at anytime by observing the console’s screen.
When the MAIN SCREEN is displayed, the current position of the door or the result of the last movement
can be found. The display will also show the count down progress of the Auto-Close timers. Any active
input will also be displayed along with the state of various features such as periodic service.
TrioCode™ Code Hopping Technology
Every time a TrioCode™ transmitter is used, a new security code is randomly generated from over 4.29 billion
possibilities. This greatly enhances the security of the system and makes “code grabbing” a thing of the
past.
These transmitters also overcome interference issues by simultaneously sending a signal over three slightly
different frequencies. Even if two of the three signals are jammed, the system will still work.
Features

Owner Installation Instructions Axess® Pro Series 3000 7
Security Code Store
The opener uses state of the art technology in storing your selected transmitter
codes. Up to 511 different transmitters can be stored in the opener’s memory
with the facility to assign a 11 character name to each transmitter.
Remote Limits Positioning
During installation, a hand held transmitter can be used when setting the door travel
limits. This allows the installer to closely observe and control the movement of the
door from any position rather than having to be within arms reach of the console.
Controlling Lights
The Auxiliary output can be programmed to operate a light relay module. The light relay
module can control the warning or courtesy light. The timing of these outputs can be adjusted
to suit your needs.
Extensive Operating Modes Via Control Inputs And Remote Control
The integrated controller can be configured to operate in many different ways via its 7 control and safety
inputs. These include P.E, FIRE, GPI, OPEN, STOP, CLOSE, and SWIPE. Remote control operation is provided
with each transmitter’s button being able to be configured to operate one of OSC, PEDESTRIAN, SWIPE,
CLOSE, OPEN, STOP, LIGHT or VACATION functions. The controllers functionality is further enhanced by
4 Auto-Close modes, 3 P.E response modes and 2 pedestrian response modes. For details refer to relevant
sections.
Automatic Manual Operation Clutch
The opener is equipped with automatic clutch. If power to the opener is disrupted for any reason, the User
can open or close the door manually by using the hand chain. When power is restored, simply press the
button on the console or press button on the transmitter to open or close the door.

8Axess® Pro Series 3000 Owner Installation Instructions
01
fig
Package Contents
Axess 3110v1 Power Drive Unit 1
Timing Assembly 1
Wall Control Unit 1
Network Cable 1
Output Drive Shaft Assembly 1
Chain 10B (0.625”) 1
Sprocket 14x0.625 assembly 1
Mounting Flange 1
Ax30 Fasterner Pack 1
TrioCode™ Keyring Transmitters 2
Installation Manual 1
EasyBeam™ with wires and brackets 1
Wall Control Unit
Transmitters
EasyBeam™
Network Cable
Timing assembly
Chain 10B
Mounting Flange
Output Drive Shaft
Sprocket
Fastner Pack

Owner Installation Instructions Axess® Pro Series 3000 9
Controller Input And Outputs
Motor identification harness connector
cluch interlock microswitch connector
Serial Interface Connector
Position Sensor Connector
10 Amps Slow Blow FuseStandby Battery
03
04
02
01
05
01
02
03
04
05
02
fig

10 Axess® Pro Series 3000 Owner Installation Instructions
09
08
13
07
06 14
12
11 10
Terminal Block ( From Left To Right )
V+ Three Wire PE Beams “ + “ Supply
IN3 Three Wire PE Beams Trigger Input
V- Common For Two Wire EasyBeam™ and Three
Wire PE Beams
IN2 Two Wire EasyBeam™ Input
AUX OUT Receiver’s Auxiliary Output
FIRE N/O , N/C Input Terminal
GPI N/O Input Terminal
OPN N/O , N/C Input Terminal
STP N/O , N/C Input Terminal
CLS N/O Input Terminal
SWP N/O Input Terminal
COM Terminal For Inputs
Programmer PG-3 Input
Console Previous Button
Liquid Crystal Display
Console Next Button
Console Open Button
Console Stop Button
Console Set Button
Console Close Button
06 07
08
09
10
11
12
13
14
03
fig
Operating Controls
