Automatic Technology HiRO GDO-12 User manual

GDO-12 Wiring and Installation Instructions
Safety Beam Kits
WPE-2V1 KIT -
SAP# ORDER NO. 86802
ITEM DESCRIPTION QTY
1WPB-04.02 TX ASSEMBLY 1
2WPB-04.02 RX ASSEMBLY 1
3 BASE STATION WPE2V1 ASSEMBLY 1
4 MOUNTING KIT 1
FLUSH MOUNTING KIT -
5 PEB4-W1 BRACKET 2
6 TAPTITE SCREW “P” M3 X 8 8
7 SELF TAPPING SCREW M6 X 25 4
8 PLASTIC WALL PLUG 6.7 X 25 4
9 TAPTITE SCREW “P” BLACK ZINC M3 X 12 8
Wireless WPE-2v1
Important Safety Instructions
WARNING! • When using Safety beams, the doorway must be clear of all obstructions and persons
a all times. The location of the beams and manner in which they are installed might not
give safety protection at all times.
• The sensors need to be 100mm above the floor level, however, the exact position must
be chosen in such a manner that it suits the application, the environmental conditions
and provides maximum safety protection.
• When using auto close mode, a Safety beam must be fitted correctly and tested for
operation at regular intervals. Extreme caution is recommended when using auto close
mode. All safety rules must be followed.
ELECTROCUTION! • Disconnect the power cord from mains power and battery backup (if installed) before
making any repairs or removing covers on openers.
CAUTION:
Fall from ladder • Ensure ladder is the correct type for job.
• Ensure ladder is on flat ground.
• Ensure user has 3 points of contact while on ladder.
Entrapment • Ensure the garage door is in good working order by undertaking regular servicing.
• Safety beams must be installed if the closing force at the bottom edge of the door exceeds
400N (40kg)
Doc # 160097_01
Part # 86806
Released 04/06/19
MOUNTING KIT
ITEM DESCRIPTION QTY
1 PE 2000TS BRACKET 2
2 ADJUSTMENT BRACKET 2
3 MOUNTING BRACKET 2
4 TAPTITE SCREW “B” PH M3 X 5 ZNC 8
5 PAN HEAD SCREW W/WASHER M5 X 10 4
4
15
2
3
5
Right side
bracket
WARNING! When using PE Beams, the doorway must be
clear of all obstructions and persons at all times. The location
of the beams and manner in which it is installed might not
give safety protection at all times. Check to make sure
that the height of the beam and type used give maximum
protection possible.
WARNING! PE beams must be installed
if the closing force at the bottom edge
of the door exceeds 400N (40kg force)
EASYBEAM P.E.-3V1 KIT
SAP# ORDER NO. 62626
ITEM DESCRIPTION QTY
14 EASYBEAM RX-TX SET 1
4 MOUNTING KIT 1
EasyBeamTM PE-3v1

6 - 8 Fiveways Boulevard, Keysborough, VIC, Australia 3173
P: 1300 133 944 E: [e-mail]
W: www.automatictechnology.com.au
Wireless Kit WPE-2v1
for GDO-12V1
Receiver
RESET LED
Apply pressure here Pull covers apart
Inserting batteries into receiver and transmitter
a. Insert two (2) C-Type batteries in the Receiver (WPB-4.02 RX) by removing
the front cover.
b. The LED on the receiver will light up and after the communication is
established between the receiver and base station the LED on the base
station and the receiver will turn off. This can take up to 60secs.
Mounting the Base Station to the Opener
a. Disconnect the power supply to the opener.
b. Remove the light diffuser cover via screw at the bottom.
c. Mount the base station board next to the control board as shown using the
screw supplied.
d. Plug the harness into the 4 pin connector on the base station board and
connect the harness to the ACC pin on the control board.
e. Refit the light diffuser.
ACC Pin
Assembling the Mounting Bracket
a. Attach the PE 2000TS Bracket 1 to the Receiver (WPB-4.02 RX) using four (4)
M3 x 5 Taptite screws 4 .
b. Connect the mounting bracket 3 to the adjustment bracket 2 with two (2) of
the M5 x 10 Pan Head Screws 5 .
c. Repeat steps (a) and (b) to assemble the Safety Beam Transmitter
(WPB-4.02TX).
d. Mount the receiver on the side of the doorway closest to the opener
and the transmitter on the other side in line with the receiver. The
mounting surface should be rigid. Affix with a minimum of four (4) screws
(not supplied).
e. ATA recommends the transmitter and receiver are placed in line of sight,
with the beam 100mm above the ground level (as per AS60335). This can be
achieved by ensuring the bottom of the receiver and transmitter are 65mm
above ground level. They should also be placed as close as possible to the
door opening.
4
1
5
2
3
5
Right side
bracket
Right side
bracket
assembled
Assemble Flush Mounting Kit (for minimum sideroom applications)
For applications which have limited space available or certain environmental
factors a flush mounting kit can be used.
a. Attached the transmitter (WPB-4.02TX) and receiver (WPB-4.02RX) to the
two (2) PEB4-W1 Bracket 5 with the eight (8) M3 x 8 Taptite screws “P” 6 .
b. Ensure to take note of the ATA recommendation in step (e) above and fix the
TX and RX to the wall or rigid surface using the two (2) 6.9 x 25 plastic wall
plugs 8 (if wall) and two (2) M6 x 25 self tapping screws 7 .
Aligning the Transmitter and Receiver
a. Make horizontal and/or vertical adjustment on the transmitter until the red
LED on the receiver stays on, this indicates alignment.
b. Make horizontal and/or vertical adjustment on the receiver until the red LED
on the transmitter stays on, this indicates alignment.
Setting the limits
After aligning the safety beams, refer to the openers
manual to set the travel limits. If Opener already
installed, install the safety beams then run the door
for 2 cycles for the opener to update details.
c. Repeat step (a) to insert batteries into the Transmitter (WPB-4.02 TX).
d. The LED on the transmitter will light up and after communication is established between the transmitter and base station the LED on
the transmitter and on the receiver will start to flash.
e. The flashing indicates the link is established between the transmitter and base station, receiver and base station, but receiver and
transmitter are not yet alligned.
f. Put cover back on Transmitter and Receiver and secure with eight (8) M3 x 12 taptite screws (black) 9.

Right side
bracket
assembled
NOTE: Mount the receiver on the side of the doorway closest to the
base station.
NOTE: Mount the receiver on the side of the doorway / gateway
closest to the opener / console.
Assembling the Mounting Bracket
Assemble the mounting bracket as per font page instructions.
NOTE: When using two (2) sets of Safety Beams within the
opening you must alternative the configuration. See diagram.
ATA recommends the transmitter and receiver are placed in
line of sight, with the beam 100mm above the ground level (as
per AS60335). This can be achieved by ensuring the bottom
of the receiver and transmitter are 65mm above ground level.
They should also be placed as close as possible to the door /
gate opening.In industrial applications it is recommended that
multiple Safety Beams are fitted.
TRANSMITTER RECEIVER
0V SB1 OR SB2
TX - 1RX - 1
TX - 2 RX - 2
65mm
Floor Level
100mm 65mm
WARNING! When using PE Beams, the doorway must be clear of all
obstructions and persons at all times. The location of the beams and
manner in which it is installed might not give safety protection at all
times. Check to make sure that the height of the beam and type used
give maximum protection possible.
TRANSMITTER
TRANSMITTER
TRANSMITTER RECEIVER
RECEIVER
0V SB1
0V SB2
One (1) set Two (2) sets
EasyBeamTM Kit PE-3v1
Wiring the EasyBeamTM PE-3v1
a. Connect the EasyBeamTM to the opener / console as per
the first wiring diagram for one (1) set of safety beams or
second wiring diagram for two (2) sets of safety beams.
Aligning the Transmitter and Receiver
a. Power up the opener with the safety beams connected. The green LED on the transmitter should turn ON to indicate power is present.
b. If the receiver is connected to power and the red LED is flashing while the green LED on the transmitter is on, the transmitter and
receiver are not aligned.
c. Make horizontal and/or vertical adjustment on the transmitter and/or receiver until the red LED on the receiver turns on, indicating
alignment.
Setting the limits
After aligning the safety beams, refer to the openers manual to set the travel limits. If Opener already installed, install the safety beams
then run the door for 2 cycles for the opener to update details.

© March 2019 Automatic Technology (Australia) Pty Ltd. All rights
reserved. No part of this document may be reproduced without prior
permission. In an ongoing commitment to product quality we reserve
the right to change specification without notice. E&OE.
Troubleshooting
Symptom Possible cause Remedy
Base station and receiver LED’s constantly on Receiver is not coded into base station Code the receiver into base station
Receiver LED constantly on but cannot close
the door
Receiver not coded into base station
Mains power is not switched on to the opener
Code the receiver into base station.
Switch on mains power
Receiver LED is blinking and can not close
the door
Receiver and transmitters not aligned
properly
Realign receiver and the transmitter
Beam is obstructed Remove obstruction from the path of the
beam.
During optical alignment transmitter LED
stopped working
Setup timed out Press reset button on the transmitter.
During optical alignment receiver LED
stopped working
Setup timed out Press reset button on the base station.
Wireless PE beam works ok but LED’s on
receiver and transmitter stopped working
To save battery power LED on transmitter
turns off after number of cycles
No remedy required.
LED on the receiver/transmitter started to
flash during operation of the door
The battery in the receiver/transmitter is
getting flat
Replace the batteries.
Specifications
Maintenance
To ensure a long and trouble free life for your Safety Beams, the following is recommended:
a. Periodically test the Safety Beam is operating efficiently by obstructing either the transmitter or receiver during the openers
operation to ensure the door stops.
b. If the Safety Beams are located in a very dusty / dirty environment make sure to clean transmitter and receiver lenses for
optimal performance.
c. Replace batteries in transmitter or receiver (Wireless WPE-2V1 only) when they start to flash during operation of the door.
Warranty
WPE-2V1 & PE-3V1
ACCESSORIES 1 year This warranty is to be read in conjunction with the owner’s copy of the opener installation instruction.
Technical Specifications EasyBeamTM Wireless
Infrared beam range 20m 6m
RF link range - 10m
RF link frequency - 2.4 Ghz ISM Band
Batteries for Wireless RX and TX - C-Type x 2
Battery Life - 3 years approx.
