Tempo (ATS-2) Smart Hub Installation Instructions
Smart Phone Control Kit
NETWORK SMART HUB KIT - ORDER NO. 86953
ITEM DESCRIPTION QTY
1 WIRELESS HUB100 WT B&D 1
2 POWER SUPPLY AU 240V 1
3 WALL BRACKET HUB100 1
4 PLASTIC WALL PLUG 6.9 X 25 2
5 SELF TAPPING SCREW 6 X 25 2
6NETWORK TRANSCEIVER MODULE 1
7 HARNESS 4 CORE 275 ASSY 1
Garage Door Openers
Important Safety Instructions
WARNING! • DO NOT attempt to disassemble, repair or modify the product. This will invalidate
the warranty.
• DO NOT install product on openers that control J-Type or Single Piece Doors.
• Do not allow children to play with the Smart Hub or your smart phone if the ATA
phone app has been installed.
ELECTROCUTION! • Keep the device away from water and other liquids. In the event that water or
other liquids enter the device, power off he product immediately and clean the
device.
• To reduce the risk of fire or electric shock, do not expose this device to rain or
moisture. The device should not be exposed to dripping or splashing.
• DO NOT remove the cover as there are no user-serviceable parts inside.
CAUTION:
Fall from ladder • Ensure ladder is the correct type for job.
• Ensure ladder is on flat ground.
• Ensure user has 3 points of contact while on ladder.
Burns • DO NOT handle damaged or leaking batteries
• The battery backup kit contains sealed lead-acid batteries that must be disposed
of properly at the end of their useful life.
Doc # 160400_01
Part # 86954
Released 19/11/19
This device allows for operation of the door when not in line-of-sight of the door and
opener.
The door may operate unexpectedly, therefore do not allow anything to stay in or near the path of the
door. When the door is not operating automatically, watch the door when it is moving and keep people
away until the door is completely opened or closed. Contact with the moving door can cause serious
personal injury or damage to property.
It is our strong recommendation that your opener be fitted with SAFETY BEAMS.Safety
Beams detect any obstructions in the doors path and override automatic operation if one
presents. These must be installed as in accordance with AS/NZS 60335-2-95:2012.
This is in addition to regular professional servicing, and monthly obstruction tests as detailed in your
opener’s Home Owners Manual.
This device must be connected to power at all
times. DO NOT disconnect power after setup.

Smart Hub Set Up
Mounting the Hub
a. Determine whether you are going to wall mount the
hub.
i. If hub is to be placed on bench, simply connect to
power supply 2, turn on and proceed to installing
the Transceiver.
ii. If hub is to be wall mounted follow steps below.
b. To wall mount - Use wall bracket 3as template to
mark where to drill holes. Pre-drill holes.
i. For plaster walls - insert (2) two Plastic wall plugs 4
into holes, place wall bracket over holes and affix
with (2) two self tapping screws 5.
ii. For brick walls - place wall bracket 3over holes and
affix with (2) two self tapping screws 5.
c. Slide the hub over the bracket.
d. Connect the power supply 2and turn on.
1
3
5
This device must be connected to power at all times.
DO NOT disconnect power after setup.
Mounting the Transceiver to the Opener
a. Disconnect the power supply to the opener and open
the main cover.
b. Connect the harness 7to ACC on the control board,
before attaching to the network transceiver module 6
as shown.
c. Close cover.
d. Download the ATA App and follow the instructions in
the App to setup new smart hub.
e. Use a programmed remote and run the door through a
few cycles which will update the unit with the details of
the transceiver module.
6
7
Warranty
Refer to our websites for full warranty details;
www.automatictechnology.com.au
WARRANTY
ACCESSORIES 1 year
If you are a consumer under the Australian Consumer Law, our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
This warranty certificate and other statements contained in this document or other ATA documents given to you do not exclude, restrict or modify the
application of all or any of the provisions of the Australian Consumer Law.
Subject to your non-excludable rights under the Australian Consumer Law, ATA expressly excludes any liability for consequential loss, incidental or indirect
damages (including but not limited to damages for loss of business profits, business interruption and loss of business information) due to a defect of the
Product. In particular, any loss or damage caused to other equipment or accessories used with the product or any loss resulting from a delay in repair is
excluded to the extent permitted by law.
