1Modbus RTU protocol
© Copyright Reserved Autonics Co., Ltd. 11
1Modbus RTU protocol
1.1 Read Coil Status(Func01–01H)
Reads the output (OX reference, Coil) ON/OFF status in the Slave device.
(1) Query(Master)
Slave Address Function
(Command)
Starting Address No. of Points (Number of data) Error Check(CRC16)
High Low High Low Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
(2) Response(Slave)
Slave Address Function
(Command)
Byte Count
(Number of
data byte)
Data Data Data
Error Check(CRC16)
Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
The below example is to read the output status (ON: 1, OFF: 0) of 10EA within coil 00001(0000
H) to 00010(0009 H) on the Slave(Address 17) from the Master.
Query(Master)
Slave Address Function
(Command)
Starting Address No. of Points(Number of data) Error Check(CRC16)
High Low High Low Low High
11 H 01 H 00 H 00 H 00 H 0A H ## H ## H
The below example is when coil 00008(0007 H) to 00001(0000 H) value on the Slave is “ON-
ON-OFF-OFF-ON-ON-OFF-ON” and 00010(0009 H) to 00009(0008 H) value is “OFF-ON”.
Response(Slave)
Slave Address Function
(Command)
Byte Count
(Number of
data byte)
Data
(00008 to 00001)
Data
(00010 to 00009)
Error Check(CRC16)
Low High
11 H 01 H 02 H CD H 01 H ## H ## H
CRC16
CRC16

1 Modbus RTU protocol
12 © Copyright Reserved Autonics Co., Ltd.
1.2 Read Input Status(Func02–02H)
Reads the input (1X reference) ON/OFF status in the Slave device.
(1) Query(Master)
Slave Address Function
(Command)
Starting Address No. of Points(Number of data) Error Check(CRC16)
High Low High Low Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
(2) Response(Slave)
Slave Address Function
(Command)
Byte Count
(Number of
data byte)
Data Data Data
Error Check(CRC16)
Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
The below example is to read the input status (ON: 1, OFF: 0) of 10EA within 10001(0000 H) to
10010(0009 H) on the Slave(Address 17) from the Master.
Query(Master)
Slave Address Function
(Command)
Starting Address No. of Points(Number of data) Error Check(CRC16)
High Low High Low Low High
11 H 02 H 00 H 00 H 00 H 0A H ## H ## H
The below example is when 10008(0007 H) to 10001(0000 H) value on the Slave is “ON-ON-
OFF-OFF-ON-ON-OFF-ON” and 10010(0009 H) to 10009(0008 H) value is “OFF-ON”.
Response(Slave)
Slave Address Function
(Command)
Byte Count
(Number of
data byte)
Data
(00008 to 00001)
Data
(00010 to 00009)
Error Check(CRC16)
Low High
11 H 02 H 02 H CD H 01 H ## H ## H
CRC16
CRC16

1Modbus RTU protocol
© Copyright Reserved Autonics Co., Ltd. 13
1.3 Read Holding Registers(Func03–03H)
Reads the binary data of Holding Registers(4X reference) in the Slave device.
(1) Query(Master)
Slave Address Function
(Command)
Starting Address No. of Points(Number of data) Error Check(CRC16)
High Low High Low Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
(2) Response(Slave)
Slave Address Function
(Command)
Byte Count
(Number of
data byte)
Data Data Data Error Check(CRC16)
High Low High Low High Low Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
The below example is to read 2EA value within Holding Register 40001(0000 H) to 40002(0001
H) on the Slave(Address 17) from the Master.
Query(Master)
Slave Address Function
(Command)
Starting Address No. of Points(Number of data) Error Check(CRC16)
High Low High Low Low High
11 H 03 H 00 H 00 H 00 H 02 H ## H ## H
The below example is when 40001(0000 H) value on the Slave is “555(22B H)” and 40002(0001
H) value is “100 (64 H)”.
Response(Slave)
Slave Address Function
(Command)
Byte Count
(Number of
data byte)
Data Data Error Check(CRC16)
High Low High Low Low High
11 H 03 H 04 H 02 H 2B H 00 H 64 H ## H ## H
CRC16
CRC16

1 Modbus RTU protocol
14 © Copyright Reserved Autonics Co., Ltd.
1.4 Read Input Registers(Func04–04H)
Reads the binary data of Input Registers(3X reference) in the Slave device.
(1) Query(Master)
Slave Address Function
(Command)
Starting Address No. of Points(Number of data) Error Check(CRC16)
High Low High Low Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
(2) Response(Slave)
Slave Address Function
(Command)
Byte Count
(Number of
data byte)
Data Data Data
Error Check(CRC16)
Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
The below is to read 2EA value within Input Register 30001(0000 H) to 30002(0001 H) on the
Slave(Address 17) from the Master.
Query(Master)
Slave Address Function
(Command)
Starting Address No. of Points(Number of data) Error Check(CRC16)
High Low High Low Low High
11 H 04 H 00 H 00 H 00 H 02 H ## H ## H
The below example is when 30001(0000 H) value on the Slave is “10(A H)” and 30002(0001 H)
value is “20(14 H)”.
Response(Slave)
Slave Address Function
(Command)
Byte Count
(Number of
data byte)
Data Data Error Check(CRC16)
High Low High Low Low High
11 H 04 H 04 H 00 H 0A H 00 H 14 H ## H ## H
CRC16
CRC16

1Modbus RTU protocol
© Copyright Reserved Autonics Co., Ltd. 15
1.5 Preset Single Registers(Func06–06H)
Writes the binary data of single Holding Registers (4X reference) in the Slave device.
(1) Query(Master)
Slave Address Function
(Command)
Register Address Preset Data(Data) Error Check(CRC16)
High Low High Low Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
(2) Response(Slave)
Slave Address Function
(Command)
Register Address Preset Data(Data) Error Check(CRC16)
High Low High Low Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
The below example is to write “10(A H)” at Holding Register 40001(0000 H) of Slave(Address
17) from the Master.
Query(Master)
Slave Address Function
(Command)
Starting Address Preset Data(Data) Error Check(CRC16)
High Low High Low Low High
11 H 06 H 00 H 00 H 00 H 0A H ## H ## H
Response(Slave)
Slave Address Function
(Command)
Starting Address Preset Data(Data) Error Check(CRC16)
High Low High Low Low High
11 H 06 H 00 H 00 H 00 H 0A H ## H ## H
CRC16
CRC16

1 Modbus RTU protocol
16 © Copyright Reserved Autonics Co., Ltd.
1.6 Preset Multiple Registers(Func16–10H)
Writes the binary data of Holding Registers (4X reference) continuously in the Slave device.
(1) Query(Master)
Slave
Address
Function
(Comma
nd)
Starting Address
No. of Register
(Number of
register)
Byte Count
(Number of
data byte)
Data Data Error Check
(CRC16)
High Low High Low High Low High Low Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
(2) Response(Slave)
Slave Address Function
(Command)
Starting Address No. of Register
(Number of register) Error Check(CRC16)
High Low High Low Low High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
The below example is to write all “10(A H)” at Holding Register 40001(0000 H) to 40002(0001 H)
of the Slave(Address 17) from the Master.
Query(Master)
Slave
Address
Function
(Comma
nd)
Starting Address
No. of Register
(Number of
register)
Byte Count
(Number of
data byte)
Data Data Error Check
(CRC16)
High Low High Low High Low High Low Low High
11 H 10 H 00 H 00 H 00 H 02 H 04 H 00 H 0A H 00 H 0A H ## H ## H
Response(Slave)
Slave Address Function
(Command)
Starting Address No. of Register
(Number of register) Error Check(CRC16)
High Low High Low Low High
11 H 10 H 00 H 00 H 00 H 02 H ## H ## H
Except downloading the pre-designated min/max parameter accoriding to input specification or
default value from PC loader program, it is recommended to use signle register write (Single
Register Write) than multi register write (Multi Regiter Write) to connect external device such as
PLC, graphic panel, etc.
CRC16
CRC16

1Modbus RTU protocol
© Copyright Reserved Autonics Co., Ltd. 17
1.7 Exception process (Exception Response-Error Code)
If communication error occurs, it sends response command and transmits the applicable
Exception Code after setting(1) the highest-level bit of received commend (Function).
Slave Address
Function
(Command)
+80 H
Exception Code
Error Check(CRC16)
Low High
1Byte 1Byte 1Byte 1Byte 1Byte
ILLEGAL FUNCTION (Exception Code: 01 H): Command is not supported.
ILLEGAL DATA ADDRESS (Exception Code: 02 H): Starting address of the queried data is
inconsistent with transmittable data address.
ILLRGAL DATA VALUE (Exception Code: 03 H): The number of the queried data is
inconsistent with the number of transmittable data.
SLAVE DEVICE FAILURE (Exception Code: 04 H): Not properly completes the queried
command.
The below example is to read the output status (ON: 1, OFF: 0) of non-existing coil 01001(03E8
H) on the Slave(Address 17) from the Master.
Query (Master)
Slave Address Function
(Command)
Starting Address No. of Points(Number of data) Error Check(CRC16)
High Low High Low Low High
11 H 01 H 03 H E8 H 00 H 01 H ## H ## H
Response (Slave)
Slave Address
Function
(Command)
+80 H
Exception Code
Error Check(CRC16)
Low High
11 H 81 H 02 H ## H ## H
CRC16

1 Modbus RTU protocol
18 © Copyright Reserved Autonics Co., Ltd.

2Modbus TCP protocol
© Copyright Reserved Autonics Co., Ltd. 19
2Modbus TCP protocol
Modbus TCP is the communication using TCP/IP network consisting of MBAP(MODBUS
Application Protocol header) and PDU(Protocol Data Unit).
MBAP Header
(7 Byte)
Function code
(1 Byte)
Data
(n Byte)
MBAP Header is as following table.
Fields Length Description Slave (Client) Master (Server)
Transaction
Identifier 2 Byte Transaction
identifier Allots from Client
Copies and transfers
the received value
from the Master
Protocol
Identifier 2 Byte
Protocol identifier
(0 = MODBUS
protocol)
Allots from Client
Copies and transfers
the received value
from the Master
Length 2 Byte Next data length Next data length
(Unit: Byte)
Next data length
(Unit: Byte)
Unit Identifier 1 Byte Identifier Allots from Client
Copies and transfers
the received value
from the Master
TCP/IP communication port uses "502".
For more information about MODBUS TCP, refer
to http://modbus.org/docs/Modbus_Application_Protocol_V1_1b.pdf file.
PDU
MODBUS TCP

2 Modbus TCP protocol
20 © Copyright Reserved Autonics Co., Ltd.
2.1 Read Coil Status(Func01–01H)
Reads the output (OX reference, Coil) ON/OFF status in the Slave device.
(1) Query(Master)
MBAP Header Function
(Command)
Starting Address No. of Points(Number of data)
High Low High Low
7Byte 1Byte 1Byte 1Byte 1Byte 1Byte
(2) Response(Slave)
MBAP Header Function
(Command)
Byte Count
(Number of data
byte)
Data Data Data
7Byte 1Byte 1Byte 1Byte 1Byte 1Byte
The below example is to read the output status (ON: 1, OFF: 0) of 10EA within coil 000001(0000
H) to 000010(0009 H) on the Slave from Master.
Query(Master)
MBAP Header Function
(Command)
Starting Address No. of Points(Number of data)
High Low High Low
00 0a 00 00 00 06 01H 01 H 00 H 00 H 00 H 0A H
The below example is when coil 000008(0007 H) to 000001(0000 H) value on the Slave is “ON-
ON-OFF-OFF-ON-ON-OFF-ON” and 000010(0009 H) to 000009(0008 H) value is “OFF-ON”.
Response(Slave)
MBAP Header Function
(Command)
Byte Count
(Number of data byte)
Data
(000008 to 000001)
Data
(000010 to 000009)
00 0a 00 00 00 05 01H 01 H 02 H CD H 01 H
