Auvon TU2124-A User manual

Please read the product introduction carefully
before using the product
USER MANUAL
Model TU2124-A
TENS and Powered Muscle
Stimulator
Device Name: TENS and Powered Muscle Stimulator

1. INTRODUCTION ......….........….......……….......……..……….. 1
- Foreword …......…...…......………......…...….......………..……... 1
- How does tens work ................……..…...….......…....…….... 1
- Standard package .....…......…...….......……............……....... 2
- Features ..….......……............….......……............…....……....… 2
- Warnings ..….......……............….......……..................……........ 3
- Danger ..….......……............….......……..................……............ 5
- Notice ..….......……............….......……............….....……....…… 6
- Contraindication ..….......……............….......………..…......... 10
2. ILLUSTRATIONS OF THE
DEVICE AND ACCESSORIE ….......……….........……….. 12
- Mode descriptions ..…................….......……........................ 14
- Operating procedure ..…...............….......…….................... 18
3. PLACEMENT OF ELECTRODES ..………........................ 21
4. TROUBLESHOOTING ..….......……......….......……............... 23
5. CLEAN AND MAINTENANCE ..……................................... 27
6. DISPOSAL METHOD ..….......……................……................. 28
7. SYMBOLS ..….......……............….......…........….......….....…..... 29
8. CUSTOMER SERVIC ..….......…….....….......……................. 29
TABLE OF CONTENTS

1
1. INTRODUCTION
FOREWORD
TU2124 is a TENS and EMS machine which
is highly effective in relieving pain, different
programs suit different parts of the body
and pain. Before using, please read all the
instructions in this user manual carefully and
keep it safe for future reference.
HOW DOES IT WORK?
TENS - Transcutaneous Electrical Nerve
Stimulations Transcutaneous
Transcutaneous Electrical Nerve Stimulations
(TENS) are safe, non-invasive, drug-free
methods of pain management. TENS is
currently one of the most commonly used forms
of electro-analgesia. The TENS device relieves
pain by sending small electrical impulses
through electrodes placed on the skin to
underlying nerve fibers.
EMS- Electrical Muscle Stimulation, also known
as powered muscle stimulator (PMS).
EMS is an electrically powered device that
repeatedly contracts muscles by passing
electrical currents through electrodes contacting
the affected body area.

2
The intended uses include:
TENS:
- Temporary relief of pain associated with
soreness.
- Aching muscles in shoulder, waist, back, neck
and upper extremities (arm).
- Lower extremities (leg) pain caused by
exercise strain.
- Lower extremities (leg) pain caused by normal
household work activities.
EMS:
- Improve or facilitate muscle performance.
STANDARD PACKAGE
● TENSandPoweredMuscleStimulator*1pcs
● Pads*1set
● SetofLeadWires*1set
● USBCable*1pcs
● UserManual*1pcs
● Clip*1pcs
FEATURES
● 20intensitylevels
● 20-minutedefaulttimer,adjustablefrom10-90
minutes or continuously
● Rechargeablelithiumbattery
● 2outputswith24modes

3
WARNINGS:
DO NOT USE THIS UNIT UNDER THESE
CONDITIONS:
Consult with your physician before using
this unit. This unit may cause lethal rhythm
disturbances in certain susceptible individuals.
If you have had a surgery recently, the
stimulation may disrupt the healing process.
Before using your unit, inspect these things.
1. Cord is not broken.
2. Pad gel is not damaged.
3. Electrode cord connection is not broken.
4. Unit is intact and working.
5. There is no battery leakage.
DO NOT USE UNDER THE FOLLOWING
CONDITIONS
● Pregnantwomen.
● Donotuseitonchildrenorinfantsbecause
the device has not been evaluated for pediatric
use.
● Keepoutofthereachofyoungchildren
because the electrode cord could cause
strangulation.
● Personsincapableofexpressingtheir
thoughts or intentions.

4
● Persons incapable of operating the unit by
themselves.
● Usewithcautionifyouhaveatendencyto
bleedinternally,suchasfollowinganinjuryor
fracture.
● Ifyou’resuspectedordiagnosedwith
heart disease, you should follow precautions
recommended by your physician.
● Ifyou’resuspectedordiagnosedwith
epilepsy, you should follow precautions
recommended by your physician.
● Usewithcautionifstimulationisappliedover
the menstruating uterus.
● Useofaccessoriesandcablesotherthan
those specified or provided by the manufacturer
of this equipment could result in increased
electromagnetic emissions or decreased
electromagnetic immunity of this equipment and
result in improper operation.
● PortableRFcommunicationsequipment
(including peripherals such as antenna cables
and external antennas) should be used no
closer than 30cm (12 inches) to any part of the
ME EQUIPMENT, including cables specified
by the manufacturer. Otherwise, it may result
in degradation of the performance of this

5
equipment.
● Useofthisequipmentadjacenttoorstacked
with other equipment should be avoided
because it could result in improper operation. If
such use is necessary, this equipment and the
other equipment should be observed to verify
that they are operating normally.
DANGER:
NEVER APPLY THE PADS TO THESE BODY
AREAS:
● Thehead,themouth,oranyareaofthe
face.
● Theneckoranyareaofthethroatbecause
this could cause severe muscle spasms
resulting in closure of the airway, difficulty in
breathing, or adverse effects on heart rhythm or
blood pressure.
● Donotuseitneartheheart,orongenital
area.
● Bothsidesofthethoraxsimultaneously
(lateral or front and back), or across your chest
because the introduction of electrical current
may cause rhythm disturbances which could be
lethal.
● Onthecalvesofbothlegsoracrosstheleft

6
and right limbs at the same time, because this
may cause cardiac disturbance.
● Openwoundsorrashesoroverswollen,
red, infected or inflamed areas or skin
eruptions (such as varicose veins, phlebitis,
thrombophlebitis and thrombosis), or on top of
or close to cancerous lesions, or over areas of
skin that lack normal sensation.
● Don'tusethedeviceifyouuseahigh
frequency surgical ME EQUIPMENT
simultaneously. Such use may result in burns
and possible damage to the device.
● Operationincloseproximity(e.g.1m)toa
shortwave or microwave the ME EQUIPMENT
may produce instability in the device output.
● Theapplicationofelectrodesnearthethorax
may increase the risk of cardiac fibrillation.
NOTICE:
Caution should be used in the presence of the
following:
●When there is a tendency to hemorrhage
following acute trauma or fracture.
●Following recent surgical procedures when
muscle contraction may disrupt the healing
process.

7
●Over area of the skin which lack normal
sensation.
●Some patients may experience skin
irritation or hypersensitivity due to the electrical
stimulation or electrical conductive medium.
The irritation can usually be reduced by using
an alternate conductive medium or alternate
electrode placement.
●Electrode placement and stimulation settings
should be conducted under the guidance of the
prescribing practitioner.
●Do not attempt to move the electrode pads
while the device is ON or operating.
●Any electrodes that have current densities
exceeding 2mA/cm2 may require special
attention of the operator.
●Do not use the device around the heart,
on the head, mouth, genitals or blemished
skin areas, on the front of the neck, or from
electrodes placed on the chest and the upper
back or crossing over the heart.
● Usecautioniftheuserhasatendencyto
bleedinternally,suchasfollowinganinjuryor
fracture.

8
DO NOT USE THIS UNIT DURING THESE
ACTIVITIES
● Wheninbathorshower;
● Whilesleeping;
● Whiledriving,operatingmachinery,orduring
any activity in which electrical stimulation puts
youatriskofinjury.
PAIN MANAGEMENT WARNINGS
● Thelong-termeffectsofchronicelectrical
stimulation are unknown.
● Ifyouhavehadmedicalorphysical
treatment for your pain, consult with your
physician before using this unit.
● Ifyourpaindoesnotimprove,andbecomes
serious, chronic or severe, stop using the unit
and consult with your physician.
● Themereexistenceofpainfunctionsasa
very important warning telling us that something
is wrong. Therefore, if you suffer from any
serious illness, consult your physician in order
to confirm that it is advisable for you to use this
Power Relief unit.
● Thedeviceisnotasubstituteforpain
medications and other pain management
therapies.
● Thedeviceisnoteffectiveforpainofcentral

9
origin (i.e. appendicitis, Hepatitis), including
headache.
● Thedeviceisanasymptomatictreatment
and, as such, suppresses the sensation of
pain that would otherwise serve as a protective
mechanism.
PRECAUTIONS REGARDING THE PADS
● Donotmovethepadstoanotherlocation
while the unit is on.
● Therapywon'tworkwithjustonepad.You
MUST USE TWO PADS at the same time.
● Makesurethecomponentsareconnected
well and the pads are fixed on the part of the
body you wish to treat or the therapy may not
be effective.
● Padshouldnottouchanymetalobject,such
as a belt buckle, necklace, or other metal worn
under clothing.
● Donotoverlappadsorputpadsontopof
each other. It may weaken or stop therapy, or
the unit may stop working. Gel pads may also
stick together and cause gel to be removed
when separating.
● Donotsharepadswithanotherperson.This
may cause skin irritation or infection. Pads are

10
intended for one person to use only.
● Donotleavepadsattachedtotheskinafter
treatment.
● Donotbendorfoldbecausethegelmayget
damagedanditwon'tstickorfunctionproperly.
● Toavoiddamagingtheadhesivesurfaceof
the pads, put the pads only on the skin or on
the plastic pad film provided.
● Alwaysplacecleanpadsinaccordancewith
illustrations provided.
● Donotapplyointmentoranysolventto
the pads or to your skin because it will disrupt
the pads from functioning properly. The self-
adhesive pads will adhere to your skin.
● Donotuseitwhenthecolloidattachedto
pads becomes less or dry.
CONTRAINDICATION:
● Heartdisease;
● Malignanttumor;
● Infectiousdisease;
● Highfever;
●Abnormal blood pressure, coagulopathy or
bleedingtendency;
● Spasticparalysis;
● Severeheart,liverandkidneyfailure;

11
●There is a spasm period after a
cerebrovascularaccident;
●Cognitive impairment, consciousness or
unclearperception;
● Pregnantwomen;
●Patients wearing metal built-in devices such
ascardiacpacemakers;
● Acutesuppurativeinflammationsite;
● Skindamageorabnormalparts;
● Aroundtheheart,aroundthehead;Near
carotidartery;Neartheeye;
● Limbboneandjointcontracturedeformity;
● Abnormalnervestress;
●Any condition requiring the active
supervision of a physician.

12
2. ILLUSTRATIONS OF THE
DEVICE AND ACCESSORIES
1
3
2
4
12
13
5
6
7
9
10
11
14
8

13
①Time indicator
②TENS modes (P1-P16)
③EMS modes (P17-P24)
④Intensity indicator
⑤Master mode selection button/lock button
⑥Intensity decrease button
⑦Time selection button
⑧Two output ports
⑨Mode number indicator
⑩Lock indicator
⑪Battery indicator
⑫Intensity increase button
⑬On / Off switch button & Sub-mode
selection button
⑭USB port

14
Program Master
Mode
Sub-
Mode You could feel
TENS
P1 Continuous comfortable
tingling.
P2 Comfortable tingling and
pulsing sensation.
P3 Comfortable rhythmic
tingling.
P4 Continuous comfortable
tingling.
P5
Comfortable and slow
tingling firstly, then the
frequency is significantly
increased, and it
becomes a noticeable
tingling sensation.
P6
Low frequency beating
with a slight tingling
sensation.
P7
Low frequency slight
beating firstly and then
continuous comfortable
tingling.
P8
Low frequency slight
beating firstly and then
comfortable pulsing
sensation.
MODE DESCRIPTION

15
TENS
P9
Comfortable tingling
from shallow to deep
with 3-4 seconds pause.
P10
Comfortable pulsing
sensation from shallow
to deep with 3-4
seconds pause.
P11
Variable comfortable
tingling, slight beating
and scrapeing
sensation.
P12
Comfortable slight
tingling from shallow to
deep with 3-4 seconds
pause.
P13
Comfortable tingling and
pulsing sensation from
shallow to more deep
with 3-4 seconds pause.
P14 Rhythmic continuous
beating.
P15 Rhythmic scrapeing
sensation.
P16
Quick slight beating
first, then comfortable
tingling.

16
EMS
P17 Low frequency slight
beating.
P18 Low frequency beating.
P19
Beating from low
frequency to a little high
frequency.
P20
Muscle twitches at a
very low frequency.
It feels like a tapping
massage.

17
EMS
P21
This program activates
the muscle in a short
tingling cycle. It is
smoother than P1/P2.
P22
This program gently
warms up the muscles
priortoexercise;it
feels like a rhythmic
massage. Increase
intensity until you get a
strong but comfortable
muscle movement.
P23
This program uses
a pulse frequency
appropriate to fast
twitching muscle
fibers. It improves their
anaerobic capacity and
is used for improving
maximum muscle
strength.
P24
This program gently
warms up the muscles
priortoexercise;itfeels
like a rhythmic beating
and comfortable tingling.
Increase intensity until
you get a strong but
comfortable muscle
movement.

18
OPERATING INSTRUCTIONS
BEFORE USE:
1. Do not use this device during charging (fully
charged in 3-4 hours). It is normal that it cannot be
turned on while charging.
2. When the device is in no-output status, it will
automatically shut down if there is no further action
within 5 minutes.
HOW TO USE
1. Clean your skin before use. Use the pads on
clean and flat areas, no sweat and no oil.
2. Attach one pair or two pairs of the electrode
pads to the massager area, such as the shoulder
and leg.
Note: If the stickiness is not good enough after
a period of use, please try to add a few drops of
water on the pads and dry the pads naturally. It can
increase their longevity. Make sure both pads on
the skin do not overlap.
3. Connect a pair of electrode pads to one lead
wire, and the other end of the wire should be
connected to one of the two output ports of the
device. Similarly, the other pair of electrode pads
should be connected to the other output port of the
device through the remaining wire.
