AV Access HDW100 User manual

1080P Wireless HDMI Extender
User Manual
HDW100

Introduction
Introduction
Overview
The 1080P wireless HDMI extender set extends HDMI signals
from a source device to a display device wirelessly up to 200
meters or through a Cat 5e/6 cable up to 120 meters. It is ideal
for applications for homes and offices.
Features
Transmits 1080P HDMI signals up to 200m wirelessly.
Transmits 1080P HDMI signals up to 120m through a Cat
5e/6 cable.
HDMI loop-out on the transmitter to connect to a local
display, allows easy monitoring of the source signal.
IR extension allows you to control the source device from a
remote location.
Package Contents
Before you start the installation of the product, please check the
package contents:
Transmitter x 1; Receiver x 1; Others: Antennas x 2; Power
Adapters (DC 5V 1A) x 2; IR Emitter x 1; Broadband IR Receiver
(30-50KHz) x 1; Mounting Ears (with Screws) x 4; User Manual x 1

Introduction
Panel
Transmitter
Receiver

Installation and Application
Installation and Application
Bracket Installation
Note: Before installation, please ensure the device is
disconnected from the power source.
1. Position and install the mounting
brackets using the mounting screws
provided. Repeat above step for the
other side of the device.
2. Attach the brackets to the surface you
want to hold the device against using the screws (not
included).

Application
(1) 1-1 Wireless Transmission
DVD Player
IR Emitter IR Receiver
DVD Player Remote
TV
Transmitter Receiver
TV
Fig 1
(2) 1-1 Wired Transmission
DVD Player
IR Emitter IR Receiver
DVD Player Remote
TV
Transmitter Receiver
TV
Fig 2
Note:
"Work Mode" Switch Settings
Fig 1
Fig 2
Transmitter
Wireless
Wire
Receiver
Wireless
Wire

Specifications
Specifications
Technical
Input A/V Port
Transmitter: 1 x HDMI
Receiver: 1 x LAN, 1 x WLAN
Input Resolutions
Up to 1080P@60Hz
Output A/V Port
Transmitter: 1 x HDMI, 1 x LAN, 1 x WLAN
Receiver: 1 x HDMI
Output Resolutions
Up to 1080P@60Hz
Compliance
HDMI 1.3, HDCP 1.4
Transmission
Distance
Wireless: 200m/656ft (line of sight)
Wired: 120m/394ft
General
Operating
Temperature
+32°F ~ +113°F (0°C ~ +45°C)
10% ~ 90%, non-condensing
Storage Temperature
-4°F ~ 140°F (-20°C ~ +70°C)
10% ~ 90%, non-condensing
Power Supply
DC 5V 1A
Power Consumption
TX: 3.5W (Max) RX: 1.6W (Max)
ESD Protection
Human body model:
±8kV (air-gap discharge)/±4kV (contact discharge)
Product Size
(W x H x D)
140mm x 21mm x 80mm/5.5'' x 0.83'' x 3.15" each
for TX and RX (Antennas not included)
Net Weight
TX: 0.31kg; RX: 0.30kg
Gross Weight
1.10kg

Warranty
Warranty
Products are backed by a limited 1-year parts and labor warranty. For
the following cases AV Access Technology Limited shall charge for the
service(s) claimed for the product if the product is still remediable and
the warranty card becomes unenforceable or inapplicable.
1. The original serial number (specified by AV Access Technology
Limited) labeled on the product has been removed, erased,
replaced, defaced or is illegible.
2. The warranty has expired.
3. The defects are caused by the fact that the product is repaired,
dismantled or altered by anyone that is not from an AV Access
Technology Limited authorized service partner. The defects are
caused by the fact that the product is used or handled improperly,
roughly or not as instructed in the applicable User Guide.
4. The defects are caused by any force majeure including but not
limited to accidents, fire, earthquake, lightning, tsunami and war.
5. The service, configuration and gifts promised by salesman only but
not covered by normal contract.
6. AV Access Technology Limited preserves the right for
interpretation of these cases above and to make changes to them
at any time without notice.
Thank you for choosing products from AV Access.
If you have any question, please contact us via the following emails:
General Enquiry: [e-mail]
Customer/Technical Support: [e-mail]
