On a budget or looking for a lower cost wood stove? The new Spokane wood stove line from Avalon
is the perfect choice. The Spokane line is available in two entry level models that are ideal for small
to mid-sized homes or for those wishing to heat specific areas of their homes. Avalon engineers have
managed to produce a low cost wood stove with the great performance and style you've come to
expect from Avalon. No frills added.
Just beautiful,radiant heat. All models feature large cooktop surfaces
and are available with a choice of sculptured legs or pedestal. Add the optional 160 CFM fan to enhance
the transfer of radiant heat into your home.
For heating solutions that meet every lifestyle. Avalon. Firestyles for life.
™

Visit our Website at:
www.avalonfirestyles.com
© Copyright T. I. 2006 Printed in U.S.A. We reserve the right to improve or change our products without prior notification. Consult the Owner’s Manual for complete installation requirements. #98800009
Back Wall
Side Wall
16”
6” Min.
6” Min.
A
B
16” Min.
6” Min.
6” Min.
Note: Vent
diameter
may vary
depending
on brand and
model.
Floor
Protection
C
Your Avalon Authorized Dealer is Located At:
D
Clearances To Combustibles
Measure rear and side clearances (A)
(B) & (C) from edge of the stove
flue. Measure corner clearance (D)
from the top corner of stove.
Floor
Protection
™
Measure front, rear and side hearth pad clearances from edges of the stove top. Floor protection must be non-combustible and at least .018” thick
(26 gauge). Minimum hearth pad sizes: Model 1250 - 36” Wide x 37” Depth Model 1750 - 36” Wide x 45 1/2” Depth
For all installation and clearance information please consult the Owner’s Manual or visit www.avalonfirestyles.com.
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
* * BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Model 1250 Model 1750
19 1/4”
27”
17 3/4”
10”
Single Wall
Connector Double Wall
Connector
11 1/4”
26 1/2”
17 1/4”
10”
A =
B =
C =
D =
17 3/4”
24”
24”
15”
Single Wall
Connector Double Wall
Connector
6 1/2”
21 1/2”
15”
6 1/2”
A =
B =
C =
D =
Model
1750
Model
1250
Height - Legs 26 1/2” Height - Pedestal 29 3/4”
Width - 23 5/8” Depth - 14 5/8”
Flue Center From Back - 4 1/8”
Weight
243 Lbs.
EPA
Emissions
4.4 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
66,800
Firebox
Size
1.6 Cu. Ft.
Heating Capacity*
600 to
1,200 Sq. Ft.
Maximum
Burn Time**
Up to 8 Hours
Maximum
Log Length
Up to 18 inches
Height - Legs 26 1/2” Height - Pedestal 30 5/8”
Width - 24” Depth - 23 1/2”
Flue Center From Back - 5 3/4”
Weight
430 Lbs.
EPA
Emissions
1.9 Grams/Hr.
Efficiency
Up To 78.8 %
Maximum
Btu’s/Hour**
72,400
Firebox
Size
2.2 Cu. Ft.
Heating Capacity*
1.200 to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to 10 Hours
Maximum
Log Length
Up to 18 inches
