INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
Model Number/ No. de Modelo: WC292D
WINE/BEVERAGE COOLER
(REFRIGERADOR PARA BOTELLAS DEVINO/CERVEZA Y SODAS)
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
La sección en español empieza en la página17.
Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604-Miami, Florida 33152
www.avantiproducts.com

2
REFRIGERATOR SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual for your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words”DANGER”, “WARNING”or“CAUTION”.
Danger means that failure to heed this
safety statement may result in severe
personal injury or death.
Warning means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury, or
death.
Caution means that failure to heed this
safety statement may result in minor or
moderate personalinjury, property or
equipment damage.
Allsafetymessageswill alert you to know what potential hazard is, tell you how to reduce the chance
of injury, and let you know what can happen if the instructions are not followed.

3
IMPORTANT SAFEGUIDES
Before the refrigerator is used, it must beproperly positioned and installed as
described in this manual,so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the refrigerator, follow basic precaution,
including the following:
?Plug into a grounded 3 -prong outlet, do not remove groundingprong, do not use an adapter, and
do not use an extension cord.
?It is recommended that a separate circuit, serving only your refrigerator be provided. Use
receptacles that cannotbe turned off by a switch or pull chain.
?Never clean refrigerator parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
?Before proceeding with cleaning and maintenance operations, make sure the power line of the
unit is disconnected.
?Do not connect or disconnect the electric plug when your hands are wet.
?Unplug the refrigerator or disconnect power before cleaning or servicing. Failure to do so can
result in electrical shock or death.
?Do not attempt to repair or replace any part of your refrigerator unless it is specifically
recommended inthismanual. All other servicing should be referred to a qualified technician.
FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
?Use two or more people to move and install refrigerator. Failure to do so can result in back or
other injury.
?To ensure proper ventilation for your refrigerator, the front of the unit must be completely
unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below
90°F(32°C). This unit must be installed in an area protected from the element, such as wind, rain,
water spray or drips.
?The refrigerator should not be located next to ovens, grills or other sources of high heat.
?The refrigerator must be installed with all electrical, water and drain connections in accordance
with state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly
grounded in accordance with the National Electrical Code and local codes and ordinances is
required.
?Do not kink or pinch the power supply cord of refrigerator.
?The fuse (or circuit breaker) size should be 15 amperes.
?It is important for the refrigerator to be leveled in order to work properly. You may need to make
several adjustments to level it.
?All installation must be in accordance with local plumbing code requirements.
?Make certain that the pipes are not pinched or kinked or damaged during installations.
?Check for leaks after connection.
?Never allow children to operate, play with or crawl inside the refrigerator.
?If you use thedrainage container, you MUST set the Drain Select switch to OFF or the water can
overflow from the drainage container
?Although the unit has been tested at the factory, due to long-term transit and storage, the first
batch of cubes must be discarded.
?Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may
damage or discolor the interior.
?Do not use this apparatus for other than its intended purpose.

4
REGISTRATION INFORMATION
Thank you for purchasing this fine Avanti product. Please fill out this form and return it within 100
days of purchase and receive these important benefits to the following address:
Avanti Products, A Division of The Mackle Co., Inc.
P.O.Box 520604–Miami, Florida 33152
?Protect your product:
We will keep the model number and date of purchase of your new Avanti Products product on
file to help you refer to this information in the event of an insurance claim such as fire or theft.
?Promote better products:
We value your input. Your responses will help us develop products designed to best meet
your future needs.
----------------------------------------------------------(detachhere)----------------------------------------------------------
Avanti Registration Form
__________________________________ _____________________________________
Name Model # Serial #
__________________________________ _____________________________________
Address Date Purchased Store/Dealer Name
__________________________________ ______________________________________
City State Zip Occupation
__________________________________ As Your Primary Residence, Do You:
Area Code Phone Number ?Own ?Rent
Did You Purchase An Additional Warranty: Your Age:
?Extended ?Food Loss ?None ?under 18 ?18-25 ?26-30
Reason For Choosing This Avanti Product: ?31-35 ?36-50 ?over 50
Please indicate the most important factors Marital Status:
that influenced your decision to purchase ?Married ?Single
this product. Is This Product Used In The:
?Price ?Home ?Business
?Product Features How Did You Learn About This Product:
?Avanti Products Reputation ?Advertising
?Product Quality ?In Store Demo ?Personal Demo
?Salesperson Recommendation ?Other______________________________
?Friend/Relative Recommendation Comments____________________________
?Warranty _____________________________________
?Other_______________________ _____________________________________

5

6
HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and maintain
your newWine/Beverage Cooler properly.
Keep it handy to answer your questions.
If you don't understand something or you
need more assistance, please call:
Avanti Customer Service
800-220-5570
Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.
Write down the model and serial numbers.
You'll find them on a plate located on the rear
wall of the Wine/Beverage Cooler
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
SerialNumber
Use these numbers in any correspondence or
service calls concerning your Wine/Beverage
Cooler
If you received a damaged Wine/Beverage
Cooler, immediately contact the dealer (or
builder) that sold you the Wine/Beverage
Cooler
Save time and money. Before you call for
service, check the Troubleshooting Guide. It
lists causes of minor operating problems that
youcan correct yourself.
IF YOU NEED SERVICE
We're proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are some
steps to follow for further assistance.
FIRST, contact the people who serviced your
Wine/Beverage Cooler. Explain why you are
not pleased. In most cases, this will solve the
problem.
NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send it to:
Customer Service
Avanti Products
10880 NW 30 Street
Miami, FL 33172 US
CAUTION
:
THIS WINE/BEVERAGE COOLER
IS NOT DESIGNED FOR THE
STORAGE OF MEDICINE OR
OTHER MEDICAL PRODUCTS.

7
PARTS & FEATURES
1
2 2 2
3
4
5
6
1. Countertop
2. Digital Readout
3. Lock Assembly
4. Chrome Shelves
5. Bottle/Can Basket
6. Adjustable Leg

8
TABLE OF CONTENTS
REFRIGERATOR SAFETY _________________________________________________________2
IMPORTANT SAFEGUIDES________________________________________________________ 3
REGISTRATION INFORMATION____________________________________________________ 4
HELP US HELP YOU…____________________________________________________________6
PARTS AND FEATURES __________________________________________________________7
IMPORTANT SAFETY INSTRUCTIONS_______________________________________________9
INSTALLATION INSTRUCTIONS____________________________________________________9
BEFORE USING YOUR WINE/BEVERAGE COOLER ___________________________________ 9
INSTALLATION OF YOUR WINE/BEVERAGE COOLER ________________________________9
ELECTRICAL CONNECTION ______________________________________________________10
EXTENSION CORD _____________________________________________________________ 10
REVERSING THE DOOR SWING OF YOURWINE/BEVERAGOR COOLER ________________ 10
OPERATING YOUR WINE/BEVERAGE COOLER______________________________________10
SETTING THE TEMPERATURE CONTROL __________________________________________ 10
HOW TO CHOOSE THE CELSIUS OR FAHRENHEIT DEGREE__________________________ 11
INTERIOR LIGHT _______________________________________________________________ 11
DOOR LOCK ___________________________________________________________________11
CARE AND MAINTENANCE ______________________________________________________11
CLEANING YOUR WINE/BEVERAGOR COOLER______________________________________11
POWER FAILURE _______________________________________________________________11
VACATION TIME ________________________________________________________________11
MOVING YOUR WINE/BEVERAGOR COOLER________________________________________12
ENERGY SAVING TIPS __________________________________________________________ 12
TROUBLESHOOTING GUIDE _____________________________________________________ 13
SERVICE FOR YOUR WINE/BEVERAGOR COOLER___________________________________14
YOUR AVANTI PRODUCTS WARRANTY ____________________________________________15
WIRING DIAGRAM ______________________________________________________________16
INSTRUCCIONES EN ESPAÑOL _______________________________________________ 17~19

9
IMPORTANT SAFETY INSTRUCTIONS
?WARNING? To reduce the risk of fire, electrical shock, or
injury when using your Wine/Beverage Cooler,
follow these basic precautions:
?Read all instructions before using the Wine/Beverage Cooler.
?DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous . . . even if they will “just sit in the garage a few days”.
?Before you throw away your old Wine/Beverage Cooler: take off the door. Leave the
shelves in place so that children may not easily climb inside.
?Never allow children to operate, play with, or crawl inside the Wine/Beverage Cooler.
?Never clean Wine/Beverage Cooler parts with flammable fluids. The fumes can create a
fire hazard or explosion.
?Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
-Save these instructions-
INSTALLATION INSTRUCTIONS
?Before Using YourWine/Beverage Cooler
?Remove the exterior and interior packing.
?Check to be sure you have all of the following parts:
?4Shelves
?2 Keys
?1 Bottle/Can Basket
?Instruction Manual
?Before connecting the Wine/Beverage Cooler to the power source, let it stand upright for
approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system
from handling during transportation.
?Clean the interior surface with lukewarm water using a soft cloth.
?Installation of YourWine/Beverage Cooler
?This appliance is designed to be free standing only, and should not be recessed or built-in
(fully recessed).
?Place your Wine/Beverage Cooleron a floor that is strong enough to support it when it is fully
loaded. To level your Wine/Beverage Cooler, adjust the adjustable leg at the bottom of the
unit.
?Allow 5 inches of space between the back and sides of the unit, which allows the proper air
circulation to cool the compressor.
?Locate the Wine/Beverage Cooler away from direct sunlight and sources of heat (stove,
heater, radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may
increase electrical consumption. Extreme cold ambient temperatures may also cause the unit
not to perform properly.
?Avoid locating the unit in moist areas.
?Plug the Wine/Beverage Cooler into an exclusive, properly installed-grounded wall outlet. Do
not under any circumstances cut or remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be directed toward a certified electrician
or an authorized Avanti Products service center.
?After plugging the appliance into a wall outlet, allow the unit to cool down for 2-3 hours before
placing items in the compartment.

10
?Electrical Connection
This unit should be properly grounded for your safety. The power cord of this unit is equipped with a
three-prong plug which mates with standard three prong wall outlets to minimize the possibility of
electricalshock.
Do not under any circumstances cut or remove the third ground prong from the power cord supplied.
For personal safety, this appliance must be properly grounded.
This unit requires a standard 115/120 Volt AC ~/60Hz electrical outlet with three-prong ground.Have
the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly
grounded. When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation
to have it replaced with a properly grounded 3-prong wall outlet.
The cord should be secured behind the unit and not left exposed or dangling to prevent accidental
injury.
The unit should always be plugged into its own individual electrical outlet which has a voltage rating
that matches the rating label on the appliance. This provides the best performance and also prevent
overloading house wiring circuits that could cause a fire hazard fromoverheated. Never unplug the
unit by pulling the power cord. Always grip the plug firmly and pull straight out from the receptacle.
Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do
not use a cord that shows cracks or abrasion damage along its length or at either end. When moving
the unit, be careful not to damage the power cord.
?Extension Cord
Because of potential safety hazards under certain conditions, it is strongly recommended that you do
not use an extension cord with this unit. However, if you must use an extension cord it is absolutely
necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord having a
grounding type plug and outlet and that the electrical ratingof the cord be 115 volts and at least 10
amperes.
?Reversing the Door Swing of YourWine/Beverage Cooler
This refrigerator-freezer has the capability of the door opening from either the left or right side. The
unit is delivered to you with the door opening from the left side. Should you desire to reverse the
opening direction, please call service for reversal instructions.
OPERATING YOURWINE/BEVERAGE COOLER
?Setting the Temperature Control
?You can set the temperature as you desire by pushing the button UP ( ) or DOWN ( )
when you push the two buttons for the first time, the LED readout will show the original
temperature set at previous time (the temperature preset at the factory is 50ºF).
?The temperature that you desire to set will increase 1ºF or 1ºC if you push the UP ( ) once,
the contrary the temperature will decrease 1ºF or 1ºC if you push the DOWN ( ) once.
?
Warning
?
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Avanti Products service center.

11
BEER: FOR BEER OR SODA CANS
SPARKL: SPARKLING WINES/ROSE WINES
WHITE: WHITE/DRYWINES
RED: RED WINES
NOTE: WHEN USING FOR BOTH WINE AND BEER SIMULTANEOUSLY WE RECOMMEND THAT
YOU PLACE RED WINE BOTTLES ON TOP SHELF AND BEER ON BOTTOM SHELF.
?How to Choose the Celsius or Fahrenheit Degree?
You can select temperature display setting from Fahrenheit to Celsius degrees by pushing the button
marked °C and then Celsius degrees indicator will be ON or select temperature display setting from
Celsius to Fahrenheit degrees by pushing the button marked °F and Fahrenheit degrees indicator will
be ON.
?Interior Light
You can turn the interior light on or off by pushing the button marked “ ” symbol.
The light will be turned off automatically if it remains ON for 15 minutes. You have to push the button
marked with the “bulb” symbol again and the light will turn back on.
?Door Lock
Your unit is provided with a lock and key combination.
The keys are located inside the plastic bag that contains the User’s Guide. Insert the key into the lock
and turn it counterclockwise to unlock the door. To lock the door do the reverse operation making
sure metal pin is engaged completely. Remove the key and place it in a secure place for safekeeping.
CARE AND MAINTENANCE
?Cleaning Your Wine/Beverage Cooler
?Unplug the Wine/Beverage Cooler, and remove all items including shelves and rack.
?Wash the inside surfaces with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
?Wash the shelves and rack with a mild detergent solution.
?The outside of the Wine/Beverage Cooler should be cleaned with mild detergent and warm water.
?Wring excess water out of the sponge or cloth when cleaning area of the controls, or any
electrical parts.
?Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with
a clean soft cloth.
?Power Failure
?Most power failures are corrected within a few hours and should not affect the temperature of
your Wine/Beverage Cooler if you minimize the number of times the door is opened. If the power
is going to be off for a longer period of time, you need to take the proper steps to protect your
contents.
?Vacation Time
?Short vacations: Leave the Wine/Beverage Cooler operating during vacations of less than three
weeks.
?Long vacations: If the appliance will not be used for several months, remove all items and

12
unplug the power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth,
leave the door open slightly: blocking it open if necessary.
?Moving Your Wine/Beverage Cooler
?Remove all items.
?Securely tape down all loose items (shelves and basket) inside your Wine/Beverage Cooler.
?Turn the adjustable foot up to the base to avoid damage.
?Tape the door shut.
?Be sure the Wine/Beverage Cooler stays secure in the upright position during transportation.
Also protect outside of Wine/Beverage Cooler with a blanket, or similar item.
?Energy Saving Tips
?The Wine/Beverage Cooler should be located in the coolest area of the room, away from heat
producing appliances, and out of the direct sunlight.

13
PROBLEMS WITH YOUR WINE/BEVERAGE COOLER?
You can solve many common Wine/Beverage Cooler problems easily, saving you the cost of a
possible service call. Try the suggestions below to see if you can solve the problem before calling the
servicer.
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE
Wine/Beverage Cooler does not operate. Not plugged in.
The circuit breaker tripped or a blown fuse.
Wine/Beverage Cooler is not cold enough. Check the temperature control setting.
External environment may require a higher
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
The Wine/Beverage Cooler does not have the
correct clearances.
Turns on and off frequently. The room temperature is hotter than normal.
The door is openedtoo often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The Wine/Beverage Cooler does not have the
correct clearances.
Vibrations. Check to assure that the Wine/Beverage Cooler
is level.
The Wine/Beverage Cooler seems to make too
much noise. The rattling noise may come from the flow of the refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in your
Wine/Beverage Cooler.
Contraction and expansion of the inside walls
may cause popping and crackling noises.
The Wine/Beverage Cooler is not level.
The door will not close properly. The Wine/Beverage Cooler is not level.
The door was reversed and not properly installed.
The gasket is dirty.
The shelves are out of position.

14
SERVICE FOR YOUR WINE/BEVERAGE COOLER
We are proud of our customer service organization and the network of professional service
technicians that provide service on your Avanti Products appliances. With the purchase of your Avanti
Products appliance, you can be confident that if you ever need additional information or assistance,
the Avanti Products Customer Service team will be here for you. Just call us toll-free.
AVANTI PRODUCTS CUSTOMER SERVICES
Product Information
800-323-5029 Whatever your questions are about our products, help is available.
Part Orders
800-220-5570 You may order parts and accessories that will be delivered directly to your home by personal
check, money order, Master Card, or Visa.
In-Home Repair Service
800-220-5570 An Avanti Products authorized service center will provide expert repair service, scheduled at a time
that is convenient for you. Our trained servicers
know your Wine/Beverage Cooler inside and out.

15
YOUR Avanti Products WARRANTY Staple your sales receipt here. Proof of
original purchase date is needed to obtain
service under warranty.
WHAT IS COVERED
LIMITED ONE-YEAR
WARRANTY
For one year from the date of
purchase by the original owner, Avanti
Products will, at its option, repair or
replace any part of the unit, which
proves to be defective in material or
workmanship under normal use.
During this period Avanti Products will
provide all parts and labor necessary
to correct such defects free of charge,
so long as the unit has been installed
and operated in accordance with the
written instructions in this manual. In
rental or commercial use, the warranty
period is 90 days. All Avanti
Appliances of 3.5 cubic feet capacity
or less must be brought/sent to the
appliance service shop for repair.
?Content losses of food due to spoilage.
?Incidental or consequential damages.
?Parts and labor costs for the following will
not be considered as warranty:
?Door springs, and/or frames.
?Inner door panels, door rails and/or door
supports.
?Light bulbs and/or plastic housing.
?Plastic cabinet liners.
?Punctured evaporator that voids the
warranty on the complete sealed system.
LIMITED SECOND THROUGH
FIFTH YEAR WARRANTY
For the second through the fifth year from date
of original purchase, Avanti Products will
provide a replacement compressor free of
charge due to a failure. You are responsible
for the service labor and freight charges. In
rental or commercial use, the limited
compressor warranty is one year and nine
months. Cost to move the unit to the servicers’
shop and back to the user's home, as may be
required, are the user's responsibility.
?Repairs performed by unauthorized
servicers.
?Service calls that do not involve defects in
material or workmanship such as
customer education, door reversal, or
proper installation.
?Service calls that are related to external
problems, such as abuse, misuse,
inadequate electrical power, accidents,
fire, floods, or acts of God.
?Replacement of house fuses or resetting
circuit breakers.
?Failure of the product if it is used for other
than its intended purpose.
?This warranty does not apply outside the
Continental USA.
WHAT IS NOT COVERED

16
WIRING DIAGRAM

17
INSTRUCCIONES EN ESPAÑOL
PRECAUCIÓN
Para reducir el riesgo de incendio, descarga eléctrica, o daño cuando use su
electrodoméstico, siga las siguientes
precauciones.
?Lea todas las instrucciones antes de usar su electrodoméstico.
?Peligro o Precaución: Existe el riesgo que los niños queden atrapados.
?Niños atrapados o sofocamiento no son un problema del pasado. Los electrodomésticos
son peligrosos aún si solo los deja en el garaje por un par de días.
?Antes de desechar su electrodoméstico o refrigerador usado: quítele las puertas. Deje
las repisas en su lugar para evitar que los niños se queden atrapados.
?No permita que los niños manejen, jueguen o entren dentro del electrodoméstico.
?No limpie su electrodoméstico con líquidos inflamables. Los gases pueden ocasionar
fuego o una explosión.
?No guarde ni use gasolina u otros líquidos inflamables cerca de este o de cualquier otro
electrodoméstico. Los vapores pueden ocasionar fuego o explosión.
-Guarde estas instrucciones-
?INSTALACION
Retire los accesorios del empaque (plásticos protectores, cartón y tiras engomadas). Limpie el
exterior con un trapo suave y seco, y el interior con un trapo húmedo y tibio.
?UBICACION
1. Seleccione un lugar con un piso firme y nivelado.
2. Su refrigerador requiere ventilación. Deje un espacio mínimo de 5” hacia arriba y espacio
suficiente en el respaldo para permitir la circulación de aire.
3. Evite luz directa del sol o calor. La luz directa del sol puede afectar la capa de pintura. Las
fuentes de calor en su proximidad causarán un consumo mayor de electricidad.
4. Para un mejor desempeño, nivele el refrigerador utilizando las patas ajustables o tornillos
niveladores. Para verificar el nivel, abra la puerta hasta la mitad, debe regresar sola.
?INSTRUCCIONES PARA LA CONEXION A TIERRA
Este aparato electrodoméstico debe estar conectado a tierra. En caso de un cortocircuito eléctrico, la
conexión a tierra reduce el riesgo de choque eléctrico proporcionando un cable de escape para la
corriente eléctrica. Este aparato viene equipado con un cordón que posee un cable a tierra con un
enchufe de conección a tierra. Este enchufe debe estar conectado en un tomacorriente instalado
correctamente y conectado a tierra.
?ADVERTENCIA
El uso inadecuado del enchufe de conexión a tierra puede resultar en un riesgo de choque eléctrico.
Consulte con un electricista si no comprende bien las instrucciones de conexión a tierra o si existe
alguna duda sobre si el aparato está conectado a tierra correctamente.
?NO USE UN CORDON DE EXTENSION
Use un tomacorriente de pared exclusivo. No conecte su refrigerador a cordones de prolongación
eléctrica o junto a cualquier otro electrodoméstico en el mismo tomacorriente de pared.
?CERRADURA DE LA PUERTA
Su unidad viene equipada con una combinación de cerradura y llave.
Las llaves (2) están dentro de la bolsa plástica junto al manual de instrucciones.
Introduzca la llave en la cerradura y gírela hacia la izquierda para abrir la puerta.
Para cerrarla, gire la llave hacia la derecha.
Quite la llave y colóquela en un lugar seguro para evitar que se pierda.

18
?ADVERTENCIA IMPORTANTE:
Un refrigerador vacío es una atracción muy peligrosa para los niños. Quite los sellos magnéticos,
puertas o cerraduras de todo electrodoméstico que esté en uso.
?OPERACION
Enchufeel cable a la toma de corriente, que debe ser 115-120v, A.C.~ 10 AMP ó más. Para evitar
vibraciones, la caja debe estar bien nivelada. Al conectar su vinera por primeravez, puede haber una
variante de varios grados entre la temperatura seleccionada y la indicada en la activación y
desactivación.También hay una variante de 6º a 8º C entre los estantes superiores e inferiores de la
vinera, de forma que si usted quiere combinar una mezcla de vinos rojos (tintos) y blancos, deberá
colocar las botellas de vino blanco en el estante inferior y las de vino tinto en el estante superior . Si
usted ha programado el enfriador de vino a 15ºC por ejemplo, podría aumentarlo oprimiendo el botón
marcado sucesivamente o podría bajarlo oprimiendo el botòn marcado .También puede
cambiar de grados centígrados a Fahrenheit, oprimiendo el botón marcardo C/F. Fº aparecerá en la
pantalla de color rojo, Cº aparecerá en la pantalla de color amarillo.
POSICIONES RECOMENDADAS PARA ENFRIAR EL VINO Y LA CERVEZA:
BEER: Cerveza o sodas
SPARKL: Vino Espumante
WHITE: Vino Blanco/Seco
RED: Vino Tinto
AVISO: CUANDO LLENE EL INTERIOR DE CERVEZAS O VINOS SE RECOMIENDA QUE UD
COLOQUE LAS BOTELLAS DE VINO TINTO EN EL ESTANTE SUPERIOR Y LAS CERVEZAS EN
EL ESTANTE DE ABAJO.
?CUIDADOS EN LOS PERIODOS DE AUSENCIA
?Para cortos períodos de ausencia (menos de 21 días) la unidad podrá quedar funcionando.
?En períodos de ausencia más largos, se aconseja dejar la unidad limpia y desconectada.
?Saque todo lo que tenga adentro de la unidad y haga yla limpieza general.
?Dejelapuerta entreabierta para que penetre el aire y así evitar la formación de olores.
?ECONOMIA DE ENERGIA
?Evite dejar por mucho tiempo la puerta abierta.
?Evite aperturas frecuentes de la puerta.
?Coloque el botón de control de temperaturas en la posición adecuada.
?SI USTED SE VA DE VACACIONES
?Saque todos los artículos de la unidad si Ud. se va de vacaciones por un mes o más.
?Desconecte la unidad del tomacorriente y limpie bien.
?Deje la puerta abierta para evitar la formación de olores, condensación o moho.
?SI USTED SE MUDA
?Desconecte la unidad del tomacorriente y limpie la unidad bien.
?Saque todas las partes movibles y empaquételas para que no se muevan durante la
transportación.
?Cierre la puerta de la unidad y séllela con cinta adhesiva.
?Asegúrese que la unidad va parada durante el viaje y cúbralo con una frazada.
COMO CAMBIAR LA DIRECCION DE APERTURA DE LA PUERTA
En caso de que necesite cambiar el lado de apertura de la puerta, por favor consulte al servicio pos-
venta de su localidad o al empleado que le vendió la unidad.

19
IRREGULARIDADES CON EL FUNCIONAMIENTO DEL REFRIGERADOR
PROBLEMA CAUSAS PROBABLES SOLUCION
El electrodoméstico no
funciona. Falta de energía. Enchufe desconectado. Verifique el fusible. Substitúyalo o arréglelo.
Coloque el botón en laposición
correcta.
Conéctelo.
La refrigeración es insuficiente. Botón de control de
temperatura en la posición
incorrecta.
Elevada frecuencia de apertura
de la puerta.
Observe las instrucciones.
Evite abrir la puerta demasiado.
Ruidos anormales. Expansión del gas en el
evaporador.
Tubos en contacto con
gabinetesoparedes.
Normal.
Aléjelos.
PRINTED IN CHINA
