Avantree BTHS-AH6 User manual

Stereo Wireless Headset
BTHS-AH6
User Manual
Product Overview
Basic operation
Status of LED indicators
Connect to a Bluetooth mobile device
Connect to two Bluetooth mobile devices simultaneously
Reconnect to Bluetooth device
Connect to PC / Laptop
Qualcomm® aptX™HD
Qualcomm® aptX™ Low Latency
Use as a wired headphone
Charging
Clear pairing history
Troubleshooting
1
2
3
3
4
5
5
6
6
6
7
8
8
············································································································
················································································
·································································································
········································································································
···············································································································
··························································································
··············································································
····································································································
··················································································································
·································································································································
································································································
····················
································································

Product Overview
1

2
Basic Operations
Button Function Operations
Power ON
Pairing
Power OFF
Microphone
Mute ON/OFF
Answer /
End a call
Reject a call
Activate smart
voice assistant
Track forward
Track backward
Play/Pause
Volume
Wheel Volume up
Volume down
Microphone
Mute ON/OFF
Voice Prompt OFF
&
&
Voice Prompt ON
NOTE: Functionality varies by applications
Hold 1s whilst a call coming
Tap once
Tap twice
While on an active call, tap and hold 1s to activate/close
Microphone Mute function. You’ll hear “Microphone Mute
ON/OFF”
MUTE
MUTE
While on an active call with boom mic, tap and hold
1s to activate/close Microphone Mute function. You’ll hear
“Microphone Mute ON/OFF”
Hold & till you hear “Voice Prompt OFF”
Hold & till you hear “Voice Prompt ON”
Tap once
Tap once
Tap once
Rotate the volume wheel forward to volume up
Rotate the volume wheel backward to volume down
Power
Switch
Slide the power switch towards middle you’ll hear
“Welcome to Avantree”
Slide the power switch to left and hold for 3 seconds.
You’ll hear “Pairing” and the LED indicator blinks and
alternately.
RED BLUE
Slide the power switch to right you’ll hear “Good Bye”

3
Status of LED indicators
Blinks RED three times every 10 seconds
Working Status LED indicator
Blinks BLUE & RED alternately
Reconnecting Blinks BLUE once every 1 second
Disconnected Blinks BLUE once every 10 seconds
Microphone Mute ON Remains WHITE
Connected with SBC Codec Blinks BLUE once every 5 seconds
Connected with Fast Stream Codec Remains BLUE
Blinks WHITE once every 5 secondsConnected with AptX Codec
Connected with AptX-LL Codec
Connected with AptX-HD Codec
Low battery
Remains WHITE
Blinks WHITE twice every 5 seconds
Paring Mode
•
•
aptX-LL supported devices: Avantree Oasis, Avantree Audikast etc.
aptX-HD supported device: Avantree Oasis Plus
For full list of suppprted devices please visit www.aptx.com
Connect to a Bluetooth mobile device
Enter Headphones into Pairing Mode:
Slide the power switch to left and hold for 3 seconds. You’ll hear “Pairing” and the LED indicator blinks
and alternately.RED BLUE

4
4:30 4G
Settings Bluetooth
Bluetooth
OPPO R9s
Avantree HS134
Avantree AH6
Not Connected
Bose Bluetooth Audio... Not Connected
Now discoverable as “iPhone(2)”
MY DEVICES
OTHER DEVICES
To pair an Apple Watch with your iPhone, go to the Watch
app.
Connect to two Bluetooth mobile devices simultaneously
Note:This feature only works for two mobile devices, such as cellphones and tablets. It doesn’t work for PCs or
Bluetooth transmitters.
Pair to mobile device
Set the headphones into Pairing Mode as above.
Activate Bluetooth on your phone and set it to search for new devices.
Select “Avantree AH6”,once successfully paired you’ll hear “connected”.
Connect with the FIRST phone as above, then turn o the headphones.
Connect headphones with SECOND phone as above.
Tap and select “Avantree AH6” on the FIRST phone Now, Avantree AH6 connected with TWO phones
simultaneously.
•
•
•
•
•
•
4:30 4G
Settings Bluetooth
Bluetooth
OPPO R9s
Avantree HS134
Avantree AH6 Connected
Bose Bluetooth Audio...
Not Connected
Now discoverable as “iPhone(2)”
MY DEVICES
OTHER DEVICES
To pair an Apple Watch with your iPhone, go to the Watch
app.
Not Connected

5
Connect to PC / Laptop
Reconnect to Bluetooth device
Normally, when the next time you turn on Avantree AH6, it will automatically reconnect the last paired device.
Alternatively, Slide the power switch to left once then release to enter into its Reconnection Mode.
Set the headphones into Pairing Mode as above.
Activate Bluetooth function on your PC/Laptop, search & select “Avantree AH6” to pair and connect.
For music stream, please set “Avantree AH6” as the
page.
Playback Default Device/Output device in Sound Setting
•
•
•
Avantree AH6
Avantree AH6

Use the supplied 3.5mm audio cable to connect to a non-Bluetooth audio device, or if the headphone battery is depleted.
The headphone will power o automatically once you plug in the 3.5mm audio cable
6
For Skype call, please set “Avantree AH6 Hands-free Headset” as microphone and speaker device in Audio Settings .
•
Qualcomm® aptX™ HD
aptX-HD audio ensures your Bluetooth® wireless enabled device can deliver High Denition (HD) audio. To take advantage of this feature
please ensure that the audio source device or transmitter also supports the aptX-HD Latency codec. Please check if your device is aptX-HD
certied: www.aptx.com
We recommend Avantree Oasis Plus to ensure compatibility with the Alto Clair.
Qualcomm® aptX™ Low Latency
aptX-Low Latency delivers high quality 16bit audio while minimizing audio/video syncing issues. To take advantage of this feature please
ensure that the audio source device or transmitter also supports the aptX-Low Latency codec. Please check if your device is aptX-LL
certied: www.aptx.com
We recommend any of the following Avantree Bluetooth transmitters - Oasis Plus, Audikast, Oasis or Priva III to ensure compatibility with the
Alto Clair.
General
General settings Microphone
Volume
Volume
Speakers
Ringing
Audio settings
Sounds
Video settings
Privacy
Notifications
S
S
Audio settings set up sound on your computer
Avantree AH6
Automatically adjust microphone settings
Automatically adjust speaker settings
Use selected speaker
Low High
Low High
Avantree AH6
Note:
.
Use as a wired headphone

7
Charged with the micro USB cable - The LED indicator on the headphones will remain
and turn o when charging is complete.
RED while charging
•
Charging
When the LED ashes RED 3 times per 10 seconds or you hear the voice prompts “Low battery please turn
o and charge”, you should fully recharge the device for about 1 hour. The headset can be charged with the
desktop charging stand (DC5V/0.5-1A) or with the micro USB cable (DC5V/0.5-1A).
Charged with the desktop charging stand – The LED indicator on the charging stand will remain WHITE while
charging and turnto
when charging is complete.
GREEN
•

Clear pairing history
If you have issues with the audio stream skipping or cutting out when using Avantree AH6, please try to clear
pairing history as following:
Firstly, turn on the headset (Non-calling Status), then Tap and Hold BOTH &
5 seconds till the LED blinks PINK for 2 seconds, then the headphones enter into PAIRING MODE automatically.
Troubleshooting
• Set Avantree Alto Clair as the default device or output device on the PC.
• When using Alto Clair to make VOIP calls through apps, please set Alto Clair Hands-Free as Microphone and
Speakers device.
No sound with PC?
• Ensure Bluetooth transmitter and headphones are connected properly.
• Check to ensure audio source is functioning properly
- AUX & RCA output on TV – test with wired headphones
- OPT output on TV – Set audio format to “PCM/LPCM” or turn o¬ Dolby/DTS
• Change your TV audio out setting to External speakers / Headset.
No sound with Bluetooth transmitter to watching TV?
• Ensure Alto Clair is in Pairing mode – LED ashes BLUE and RED alternately.
• For Bluetooth transmitter, ensure the transmitter is in Pairing mode – refer to its user manual.
• For Smart phone, tablet and PC
- Turn the Bluetooth o¬ and then on again.
- Delete “Avantree Alto Clair headphones” from your devices Bluetooth list and then try to pair again.
• Clear the headphones pairing history and pair again.
Headphones do not pair with Bluetooth device?
8
