Job Aid: Replacing the Field Replaceable Units
(FRUs) for the Avaya G450 Media Gateway
!Important:
Important: Always check the Avaya Support Website for Product Support Notices at http://
support.avaya.com and select Communication Manager > Product Support
Notices.
This Job Aid describes the steps required to complete the following replacement procedures for
Avaya G450 Media Gateway replaceable parts:
●Ordering equipment
●Replacing or inserting an MP20 or MP80 VoIP module
●Replacing the fan tray
●Replacing a power supply unit
Ordering equipment
When ordering any of the field replaceable units, quote the following comcode:
Table 1: Avaya G450 Media Gateway comcodes for customer and services ordering
Product Comcode
80 channels DSP daughterboard (MP80 VoIP module) 700432503
20 channels DSP daughterboard (MP20 VoIP module) 700432511
G450 fan tray 700438278
G450 power supply unit 400W AC 700432529

Job Aid: Replacing the Field Replaceable Units (FRUs) for the Avaya G450 Media Gateway
2 Job Aid: Replacing the Field Replaceable Units (FRUs) for the Avaya G450 Media Gateway
Replacing or inserting an MP20 or MP80 VoIP module
The G450 has four slots for media resources modules. Each slot can accommodate either an
MP20 or an MP80 DSP daughterboard, each providing 20 or 80 VoIP channels, respectively.
The basic configuration includes one MP20 or MP80 daughterboard in one of the four slots. You
can replace an MP20 or MP80 daughterboard or insert one into an empty slot.
The slots are located on the G450 main board. You must pull out the main board to remove or
insert a media resources module. The G450 supports hot insertion and removal of the main
board without power drop. However, all services are suspended while the G450 main board is
out, and all calls are disconnected. Any translation and other data that is in the running
configuration but has not been saved to the startup configuration is lost.
This procedure requires the following steps:
1. Removing the main board
2. Removing an MP20 or MP80 module — Skip this step if you are inserting a daughterboard
into an empty slot.
3. Inserting an MP20 or MP80 module
4. Reinserting the main board
Removing the main board
ELECTROSTATIC ALERT:
ELECTROSTATIC ALERT: Hold the module only by the edges to avoid damage from static electricity. Do not
touch the top or bottom of the circuit board. If possible, wear a wrist-strap and use
an anti-static bag.
!CAUTION:
CAUTION: The connector pins can be bent or damaged if the module is handled roughly, or if
misaligned and then forced into position.
To remove the main board:
1. Unscrew the two captive screws, one at each side of the main board front panel (see
Figure 1).
2. Open the latches on both sides of the main board.
3. Grasp the latches and pull out the main board from its slot.
4. Place the main board carefully on a table.

Replacing or inserting an MP20 or MP80 VoIP module
03-602059 Issue 1 January 2008 3
Figure 1: Removing and inserting the main board
Removing an MP20 or MP80 module
ELECTROSTATIC ALERT:
ELECTROSTATIC ALERT: Hold modules only by the edges to avoid damage from static electricity. Do not
touch the top or bottom of the circuit board. If possible, wear a wrist-strap and use
an anti-static bag.
!CAUTION:
CAUTION: The connector pins can be bent or damaged if the module is handled roughly, or if
misaligned and then forced into position.
To remove an MP20 or MP80 module:
1. Locate the MP20 or MP80 module slot (see Figure 2).

Job Aid: Replacing the Field Replaceable Units (FRUs) for the Avaya G450 Media Gateway
4 Job Aid: Replacing the Field Replaceable Units (FRUs) for the Avaya G450 Media Gateway
Figure 2: Locations of MP20 and MP80 module slots
2. Open the latches on both sides of the module slot. The module lifts up.
3. Pull out the module. Touch the module only at the edges.
Inserting an MP20 or MP80 module
ELECTROSTATIC ALERT:
ELECTROSTATIC ALERT: Hold modules only by the edges to avoid damage from static electricity. Do not
touch the top or bottom of the circuit board. If possible, wear a wrist-strap and use
an anti-static bag.
!CAUTION:
CAUTION: The connector pins can be bent or damaged if the module is handled roughly, or if
misaligned and then forced into position.
To insert an MP20 or MP80 module:
1. Position the MP20 or MP80 module at a 45 degree angle to the main board, and start
inserting it into an MP20 or MP80 slot (see Figure 3).
Figure notes:
1. MP20 or MP80 module slot
2. MP20 or MP80 module slot 3. MP20 or MP80 module slot 4. MP20 or MP80 module slot

Replacing or inserting an MP20 or MP80 VoIP module
03-602059 Issue 1 January 2008 5
Figure 3: Inserting an MP20 or MP80 module
2. Push the module in all the way. Do not use too much force.
3. Flatten the module so it is flush with the main board. The latches at both sides click shut.
Reinserting the main board
To insert the main board:
1. Open the latches on both sides of the slot.
2. Insert the main board vertically into the slot.
3. Push the main board in until the latches begin to close.
4. Close the latches.
5. Close and tighten the two captive screws on the front panel.

Job Aid: Replacing the Field Replaceable Units (FRUs) for the Avaya G450 Media Gateway
6 Job Aid: Replacing the Field Replaceable Units (FRUs) for the Avaya G450 Media Gateway
6. Use the show platform mainboard CLI command to make sure everything is OK. For
example, when the main board is successfully installed, the output includes:
When a VoIP module is successfully installed in a given VoIP module slot, the output for the
slot includes:
When no VoIP module is installed in a given VoIP module slot, the output for the slot
includes:
Replacing the fan tray
The fan system is field replaceable. It is mounted on a fan tray that can be replaced as one unit.
The G450 supports hot swap of the fan tray. There is no need to power down or reset the G450
when replacing a faulty fan tray unit.
Prepare the new fan tray for insertion before removing the current the fan tray: take the new fan
tray out of its package and place it nearby.
!Important:
Important: Replace the fan tray within one minute, to avoid overheating the G450. If the
G450 exceeds its allowed heat level, it shuts down.
MAINBOARD BOARD:
-------------------------------------------------
Type : G450 mainboard
Description : G450 field replaceable mainboard
Serial Number : 0725IS123456
HW Vintage : 0
HW Suffix : A
FW Version : 1
Faults : No Fault Messages
MEDIA SOCKET #1:
Type : MP80 VoIP DSP Module
Description : VoIP DSP resource with 80 channels
Serial Number : 0715IS812717
HW Vintage : 0
HW Suffix : A
Faults : No Fault Messages
MEDIA SOCKET #1:
Type : UNKNOWN
Description : UNKNOWN
Serial Number : UNKNOWN
HW Vintage : UNKNOWN
HW Suffix : UNKNOWN
Faults : NOT PRESENT

Replacing the fan tray
03-602059 Issue 1 January 2008 7
Figure 4: Replacing the fan tray
To remove the fan tray:
1. Move away any cables that may obstruct the removal of the tray.
2. Unscrew the two captive screws on the front panel of the fan tray.
3. Grasp the screws and pull the fan tray out of its slot.
To insert the fan tray:
1. Insert the fan tray all the way into the slot.
2. Close and tighten the two captive screws on the front panel.
The fans start operating immediately.
3. Wait one minute and then use the show platform fans CLI command to make sure
everything is OK. For example:
G450-001(super)# show platform fans
FAN TRAY UNIT #1:
-------------------------------------------------
Type : G450 FAN TRAY
Description : G450 FAN TRAY UNIT
Serial Number : 0728IS123123
HW Vintage : 1
HW Suffix : A
Faults : No Fault Messages

Job Aid: Replacing the Field Replaceable Units (FRUs) for the Avaya G450 Media Gateway
8 Job Aid: Replacing the Field Replaceable Units (FRUs) for the Avaya G450 Media Gateway
Replacing a power supply unit
The G450 provides full redundant, load sharing power supply units (1 + 1). A single power
supply unit (PSU) provides sufficient power for any G450 configuration. If you choose to install
two PSUs, they operate in a load sharing mode.
The G450 supports hot swap of the PSU. Even if you have only one PSU installed, there is no
need to power down or reset the G450 when replacing a faulty PSU. You can install the
replacement PSU in the second PWR slot, and it will become the active PSU once you remove
the faulty PSU.
Figure 5: Replacing a power supply unit
To remove a PSU:
1. Disconnect the G450 power cable from the mains socket.
2. Disconnect the G450 power cable from the power connector, located on the front panel of
the PSU, at the rear of the G450.
3. Loosen the two captive screws, one on each side of the PSU.
4. Grasp the two side handles and pull the PSU out of its slot.
To insert a PSU:
1. Position the PSU before the opening and engage both sides of the unit in the interior
guides.
2. Slide the PSU slowly into the chassis, maintaining an even pressure to assure that the unit
does not become twisted or disengaged from the guides.
3. Close and tighten the two captive screws on the front panel.
4. Connect the power cable to the power connector on the PSU.
5. Plug the power cable into a mains socket. When the PSU is powered, the green LED on the
PSU panel lights.

Replacing a power supply unit
03-602059 Issue 1 January 2008 9
6. After powering up, use the show platform power CLI command to make sure
everything is OK. The upper PSU is referred to as PSU #1, and the lower PSU is PSU #2.
For example:
G450-001(super)# show platform power
POWER SUPPLY UNIT #1:
-------------------------------------------------
Type : G450 PSU
Description : G450 FR Power Supply 400W
Serial Number : 0735IS123321
HW Vintage : 0
HW Suffix : A
Faults : No Fault Messages
POWER SUPPLY UNIT #2:
-------------------------------------------------
Type : G450 PSU
Description : G450 FR Power Supply 400W
Serial Number : 0735IS654321
HW Vintage : 0
HW Suffix : A
Faults : No Fault Messages
