Avaya S8400 Instruction Manual

Installing and Configuring the
Avaya S8400 Media Server
Release 3.1
03-300678
Release 3.1
February 2006
Issue 1

© 2006 Avaya Inc.
All Rights Reserved.
Notice
While reasonable efforts were made to ensure that the information in this
document was complete and accurate at the time of printing, Avaya Inc. can
assume no liability for any errors. Changes and corrections to the information
in this document may be incorporated in future releases.
For full legal page information, please see the complete document,
Avaya Legal Page for Hardware Documentation, document number
03-600759.
To locate this document on our Web site, simply go to
http://www.avaya.com/support and search for the document number in
the search box.
Documentation disclaimer
Avaya Inc. is not responsible for any modifications, additions, or deletions to
the original published version of this documentation unless such modifications,
additions, or deletions were performed by Avaya. Customer and/or End User
agree to indemnify and hold harmless Avaya, Avaya's agents, servants and
employees against all claims, lawsuits, demands and judgments arising out of,
or in connection with, subsequent modifications, additions or deletions to this
documentation to the extent made by the Customer or End User.
Link disclaimer
Avaya Inc. is not responsible for the contents or reliability of any linked Web
sites referenced elsewhere within this documentation, and Avaya does not
necessarily endorse the products, services, or information described or offered
within them. We cannot guarantee that these links will work all of the time and
we have no control over the availability of the linked pages.
Warranty
Avaya Inc. provides a limited warranty on this product. Refer to your sales
agreement to establish the terms of the limited warranty. In addition, Avaya’s
standard warranty language, as well as information regarding support for this
product, while under warranty, is available through the following Web site:
http://www.avaya.com/support.
Copyright
Except where expressly stated otherwise, the Product is protected by copyright
and other laws respecting proprietary rights. Unauthorized reproduction,
transfer, and or use can be a criminal, as well as a civil, offense under the
applicable law.
Avaya support
Avaya provides a telephone number for you to use to report problems or to ask
questions about your product. The support telephone number
is 1-800-242-2121 in the United States. For additional support telephone
numbers, see the Avaya Web site: http://www.avaya.com/support.

Installing and Configuring the Avaya S8400 Media Server February 2006 3
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
How to use this documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Pre-installation: before going on site . . . . . . . . . . . . . . . . . . . . . . . . 9
Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Verifying site readiness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Laptop preparation, software, and system information. . . . . . . . . . . . . 10
Copying files to the laptop . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
About ASG and the unique on-site password . . . . . . . . . . . . . . . . . . 11
Obtaining license and Avaya authentication files . . . . . . . . . . . . . . . . 11
Pre-installation: at the site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Equipment specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
About media server port connections . . . . . . . . . . . . . . . . . . . . . . . . 14
Ethernet ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Media server cable adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Ethernet connectivity with the TN8412AP circuit pack . . . . . . . . . . . . . 16
Services access port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
About Modem connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
About Media Gateways . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
About Processor Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
About SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
High level overview of installation process . . . . . . . . . . . . . . . . . . . . . 23
Installing and cabling the media gateways . . . . . . . . . . . . . . . . . . . 23
Installing Avaya Communication Manager. . . . . . . . . . . . . . . . . . . . 23
Configuring the MPC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Configuring the media server. . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Translating the SIPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Completing the installation administration . . . . . . . . . . . . . . . . . . . 24
Testing the finished installation . . . . . . . . . . . . . . . . . . . . . . . . . 24
Chapter 2: SNMP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Configuration of the SNMP modules in the UPS . . . . . . . . . . . . . . . . . . 25
Default UPS IP addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Preparing to configure the SNMP module . . . . . . . . . . . . . . . . . . . . 26
Administering the SNMP module . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setting selected traps (alarming) . . . . . . . . . . . . . . . . . . . . . . . . 28
Contents

Contents
4Installing and Configuring the Avaya S8400 Media Server February 2006
Chapter 3: Communication Manager Installation . . . . . . . . . . . . . . . . . . . . 29
Clearing the ARP cache on the laptop . . . . . . . . . . . . . . . . . . . . . . . . 29
Connecting the CD/DVD drive to the media server . . . . . . . . . . . . . . . . . 30
Powering up the media server . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Accessing the media server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Configuring Telnet for Windows 2000/XP . . . . . . . . . . . . . . . . . . . . . . 31
Installing Avaya Communication Manager . . . . . . . . . . . . . . . . . . . . . 32
Installing IA 770 INTUITY AUDIX Messaging . . . . . . . . . . . . . . . . . . . . 33
Chapter 4: Media server configuration. . . . . . . . . . . . . . . . . . . . . . . . . . 35
Opening the Maintenance Web Interface. . . . . . . . . . . . . . . . . . . . . . . 35
Copying files to the media server . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Enabling Network Time Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Using the Installation Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Verifying MPC IP information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Installing MPC firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Verifying media server connection to the customer’s LAN (if provided) . . . . . 40
Enabling firewall settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Configuring the modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Chapter 5: IP interface translations . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Starting SAT terminal emulation . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Inputting initial system translations . . . . . . . . . . . . . . . . . . . . . . . . . 44
Adding media gateways . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Enabling SIPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Adding the SIPI to the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Setting alarm activation level . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Saving translations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Chapter 6: IP interface configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . 49
SIPI address configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Programming the SIPI for static addressing . . . . . . . . . . . . . . . . . 50
Setting the VLAN and diffserv parameters. . . . . . . . . . . . . . . . . . . . . . 52
Resetting the SIPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Verifying connectivity to media server . . . . . . . . . . . . . . . . . . . . . . . 54
Verifying that SIPI is translated . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Contents
Installing and Configuring the Avaya S8400 Media Server February 2006 5
Upgrading the SIPI firmware version (if necessary) . . . . . . . . . . . . . . . . 54
Enabling control of SIPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Verifying license status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Chapter 7: Post-installation administration . . . . . . . . . . . . . . . . . . . . . . . 57
Verifying translations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Setting daylight savings time rules . . . . . . . . . . . . . . . . . . . . . . . . . 58
Setting locations (if necessary) . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Verifying date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Clearing and resolving alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Backing up files to the compact flash media . . . . . . . . . . . . . . . . . . . . 61
Enabling alarms to INADS via modem . . . . . . . . . . . . . . . . . . . . . . . . 61
Enabling alarms to INADS via SNMP . . . . . . . . . . . . . . . . . . . . . . . . 62
Before leaving the site. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Chapter 8: Installation verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Testing the SIPI circuit pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Testing the license file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
TN8400AP Media Server LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Faceplate interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
LED descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
UPS LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
TN8412AP SIPI LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Appendix A: Media server access . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Accessing the server’s command line interface with SSH . . . . . . . . . . . . . 73
Connecting to the media server directly . . . . . . . . . . . . . . . . . . . . . . 75
Connecting to the media server remotely over the network . . . . . . . . . . . . 76
Connecting to the media server remotely over a modem . . . . . . . . . . . . . 77
Accessing the Maintenance Web Interface . . . . . . . . . . . . . . . . . . . . . 78
Using the SAT command line prompt . . . . . . . . . . . . . . . . . . . . . . . . 78
Logins for Avaya technicians and Business Partners . . . . . . . . . . . . . . . 79
Configuring the network for Windows 2000/XP . . . . . . . . . . . . . . . . . . . 80
Setting browser options for Internet Explorer 6.0. . . . . . . . . . . . . . . . . . 81

Contents
6Installing and Configuring the Avaya S8400 Media Server February 2006
Appendix B: Installation troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 83
Troubleshooting media server hardware installation . . . . . . . . . . . . . . . . 83
Troubleshooting configuring the media server hardware . . . . . . . . . . . . . 84
Troubleshooting the installation of license files and Avaya authentication files . 86
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Installing and Configuring the Avaya S8400 Media Server February 2006 7
Chapter 1: Introduction
To configure the media server, use the Avaya Installation Wizard. To configure gateways and
other hardware components, use two administration interfaces:
●Maintenance Web Interface
●Command line interface, directly through, secure shell (SSH), telnet, or a terminal
emulation program such as Avaya Native Configuration Manager.
You are not required to install the media server before the port networks (media gateways);
however, the license file allows only 30 minutes to "see" the administered and connected IP
Interface (SIPI) circuit packs.
The following information is included in this installation procedure:
●Pre-installation: before going on site on page 9
●Configuration of the SNMP modules in the UPS on page 25
●Media server configuration on page 35
●IP interface translations on page 43
●IP interface configuration on page 49
●Post-installation administration on page 57
●Installation verification on page 63
●Media server access on page 73
●Installation troubleshooting on page 83
Audience
This documentation is for the following people tasked with installing and configuring the media
server components:
●Trained field installation and maintenance personnel
●Technical support personnel
●Authorized Business Partners

Chapter 1: Introduction
8Installing and Configuring the Avaya S8400 Media Server February 2006
How to use this documentation
Use this documentation as a guide to install and configure Avaya media servers. For
information about a particular task, use the index or table of contents to locate the page number
where the information is described.
For an overview of the installation process, see High level overview of installation process on
page 23.
Read Pre-installation: before going on site on page 9 first. This section lists the tasks that must
be completed before going to the installation site. Next, read Pre-installation: at the site on
page 13. This section lists the tasks that must be completed on site before beginning the
installation procedures.
Technical specifications for the hardware are described in Equipment specifications on page 13.
For the physical installation and cabling of the hardware, see the Quick Start for Hardware
Installation: Avaya S8400 Media Server in an Avaya G650 Media Gateway (03-300705). Use
the remaining sections of this document in the sequence they are presented. If certain
components are not to be installed, skip the procedures for those components. You install and
configure the media server components using information in the following sections:
●Configuration of the SNMP modules in the UPS on page 25
●Media server configuration on page 35
●IP interface translations on page 43
Next, install the port networks and media gateways, using sections in the following documents:
●Installing the Avaya G650 Media Gateway (03-300144)
●Installation and Configuration for the Avaya G150 Media Gateway (03-300395)
●Quick Start for Hardware Installation: Avaya G350 Media Gateway (03-300148)
●Installation of the Avaya G350 Media Gateway (555-245-104)
●Quick Start for Hardware Installation: Avaya S8300 Media Server and Avaya G700 Media
Gateway (555-233-150)
●Installation and Upgrades for the Avaya G700 Media Gateway and Avaya S8300 Media
Server (555-234-100)
Program the IP interface using Chapter 6: IP interface configuration.
Complete the installation using information in the following sections:
●Post-installation administration on page 57
●Installation verification on page 63
●Media server access on page 73
If problems occur during the installation, use Installation troubleshooting on page 83 to try to
resolve them.

Pre-installation: before going on site
Installing and Configuring the Avaya S8400 Media Server February 2006 9
Pre-installation: before going on site
This section describes the steps you need to take to before going to the installation site.
Documentation
Avaya recommends that you have the following documents on hand for the installation. These
are included on the Documentation for Avaya Communication Manager, Media Gateways and
Servers CD (03-300151).
●Quick Start for Hardware Installation: Avaya S8400 Media Server in an Avaya G650 Media
Gateway (03-300705) — a quick reference guide providing physical installation and
connection information.
●Completed Electronic Preinstallation Worksheet — An Excel spreadsheet providing the
customer’s network information needed to use the Avaya Installation Wizard to configure
the control network components. Get from the Avaya project manager, Avaya software
technician, or customer network administrator. See the Avaya Installation Wizard Web site
(http://support.avaya.com/avayaiw) for the blank form.
●Job Aid: Approved Grounds (555-245-772) — provides a description of all approved
grounds.
Verifying site readiness
Before going on site, make sure the customer has:
●adequate power
●19-in. (48-cm) 4-post data racks securely installed to EIA-310D (or equivalent) standards
and grounded
●a local area network set up and running
●a network administrator available the day of the installation
If you are staging the installation at a location other than the customer’s site, verify that you
have all the equipment by comparing the list of items ordered against the items in the boxes.
Your project manager can supply you with an inventory list. Do not rely solely on the packing
slips inside the boxes.

Chapter 1: Introduction
10 Installing and Configuring the Avaya S8400 Media Server February 2006
Laptop preparation, software, and system information
Verify that:
●The services laptop has the right hardware and software. See Connecting to the media
server directly on page 75 for the list of computer hardware and software specifications.
●Current Avaya Communications Manager translations are available for download.
●You have a completed Electronic Preinstallation Worksheet (EPW) on the services laptop.
See the Avaya Installation Wizard Web site (http://support.avaya.com/avayaiw) for the
blank form.
The EPW provides customer system information, including:
- IP addresses
- Product IDs for the media server, remote maintenance board, and IA 770 if used
- Avaya services telephone number for remote access over modem
- Avaya services IP address for alarms through the network
●You have the current Communications Manager software update, if required, on your
services laptop
●You have current firmware, including for the media server BIOS. Check the Avaya Support
Web site (http://support.avaya.com), Download Software and Firmware, for the latest
software and firmware. Firmware for the SIPIs, C-LAN, MedPro, and VAL circuit packs are
on the software CD.
●You have License and Avaya authentication files on your services laptop.
●You have all login IDs and passwords needed to access the media server, maintenance
adapter, and server complex components. This includes the unique service password for
your customer’s equipment.
- To obtain the unique password for a specific media server, call ASG Conversant
(1.800.248.1234 or 1.720.444.5557). You must have the IL, FL, or product ID to get
the password.
- To log in through the services port as craft after you install the Avaya authentication
file, use this password, which does not require an ASG challenge or response.
Copying files to the laptop
In addition to the license and Avaya authentication files, you must copy other required files to
the services laptop. This includes the filled-out Electronic Preinstallation Worksheet (EPW); any
service packs; current firmware, including firmware for the BIOS, remote maintenance board,
and programmable circuit packs.

Pre-installation: before going on site
Installing and Configuring the Avaya S8400 Media Server February 2006 11
To get a filled-out EPW, go to the project manager or customer. To get a blank EPW, go to the
Avaya Installation Wizard Web site (http://support.avaya.com/avayaiw). Have the customer fill it
out.
To get the service pack, go to the Avaya Support Web site (http://avaya.com/support) and select
Software & Firmware Downloads to identify and copy the required service pack.
To get the latest firmware for the BIOS, remote maintenance board, and programmable circuit
packs, go to the Avaya Support Web site at http://avaya.com/support and select Software &
Firmware Downloads to identify and copy the latest firmware.
To get instructions on installing firmware, go to:
ftp://ftp.avaya.com/incoming/Up1cku9/tsoweb/firmware/TNpackFirmwareDownloadInstructions.pdf
About ASG and the unique on-site password
After installing the Avaya authentication files, Access Security Gateway (ASG) protects Avaya
services logins to the media server. The ASG challenge/response protocol confirms the validity
of each user, reducing the opportunity for unauthorized access.
If you use the craft password that is unique to the server of the customer and access the media
server on site, you can use this password the next time you log in as craft. You do not need an
ASG challenge/response to log in this way. Every other means of craft access still requires an
ASG challenge/response.
Obtaining license and Avaya authentication files
Use Remote Feature Activation (RFA) to obtain the Communication Manager license and Avaya
authentication files. RFA is a Web-based application, available to Avaya employees and
authorized BusinessPartners. WIth RFA, you can create and deploy license files for all
Communication Manager product platforms. For more information about RFA and how to
generate license and Avaya authentication files, see the RFA Information page at http://
rfa.avaya.com.
Note:
Note: To access the RFA application, you must complete the RFA online training and
have received access authorization.
To generate a license file, you need the following information:
●Your personal Single Sign-On (SSO) for the RFA Web site authentication login
●SAP order number
●Required customer information

Chapter 1: Introduction
12 Installing and Configuring the Avaya S8400 Media Server February 2006
●For a new license, the serial number of one TN2312BP Internet Protocol Server Interface
(IPSI) or TN8412AP System Internet Protocol Interface (SIPI) circuit pack designated the
reference IP interface.
●For an updated license, the RFA system ID (SID) for the existing media server, which is
necessary to locate the existing license
●Internet access to the RFA Web page with Internet Explorer 5.0 or higher
Before arriving on site, download the license and Avaya authentication files to the services
laptop. The license and Avaya authentication files are installed during the installation process.
Once the Avaya authentication files are installed, a challenge/response system called Access
Security Gateway (ASG) protects Avaya services logins to the media server. The ASG
challenge/response protocol confirms the validity of each user, reducing the opportunity for
unauthorized access.
When finished installing the Avaya authentication file, Avaya Communication Manager has a
password for the craft login. This password is unique to the server of the customer. You can use
the password the next time you log in as craft, provided you access the media server through
the services port. You do not need an ASG challenge/response to log in this way, even though
every other means of craft access still requires an ASG challenge/response. RFA records the
revised password. ASG Conversant provides this password at 1-800-248-1234 or
1-720-444-5557.

Pre-installation: at the site
Installing and Configuring the Avaya S8400 Media Server February 2006 13
Pre-installation: at the site
Before beginning the installation, verify that you have all the equipment on site by comparing
the list of items ordered against the items in the boxes. Your project manager can supply you
with an inventory list. Do not rely solely on the packing slips inside the boxes.
The pre-installation team should have done the following tasks. If they were not all done, do not
continue with the installation.
●Verify that the open, customer-supplied, EIA-310D (or equivalent) standard 19-in. (48-cm)
4-post equipment rack(s) is(are) properly installed and solidly secured. Make sure that the
screws that come with the racks are there. If using a rack cabinet, make sure it has
adequate ventilation.
●Verify that the rail kit to support the media server is available for installation.
●Verify that the rail kit, required to support the very heavy UPS, is installed on the rack or
available for installation. For information on installing the rails, see the documentation that
comes with the rail kit.
●Verify that the equipment rack(s) is(are) grounded per local code. See Job Aid: Approved
Grounds (555-245-772).
●Verify that the customer provides AC power to the rack from a nonswitched outlet.
●Verify that cabling between the TN8400AP and the TN8412AP (SIPI) circuit packs is in
place.
Equipment specifications
The S8400 Media Server control network components consist of a G650 Media Gateway with a
TN8400AP circuit pack installed in slot 2, a TN8412AP (SIPI) installed in slot1, and one UPS.
See Table 1: Control network components specifications.
Table 1: Control network components specifications
Component Dimensions
English (in.) Metric (cm) U (height) Weight (lb/kg)
Media Gateway:
G650 14h x 17.5w x 22d 30h x 56w x 48d 8 39/18
UPS:
700 VA
1500 VA 3.5h x 17w x 19d
3.5h x 17w x 24d 9h x 43w x 48d 9h x 43w x 61d 2 234/15 50/23

Chapter 1: Introduction
14 Installing and Configuring the Avaya S8400 Media Server February 2006
The internal room temperature must not exceed 104° F (40° C).
TN8400AP features and specifications on page 14 outlines the features and specifications of
the TN8400AP circuit pack.
Note:
Note: Some values are shown at maximum configuration. Avaya values may be lower
than the maximum.
About media server port connections
The following section provides information on connecting the Ethernet ports on the back of the
media server.
Ethernet ports
All S8400 Media Server backplane Ethernet ports on the backplane I/O adapter can connect to
the customer LAN.
Table 2: TN8400AP features and specifications1
1. Values of some parameters may change with future versions of the TN8400S.
Feature Specifications
Microprocessor One Intel Celeron M (600 MHz)
Memory 512 MB RAM
Storage Single IDE SSD, 2 Gbyte
Single IDE hard drive.
Environment: Air
Temperature Media server on:
41.0° to 104.0° F (5° to 40° C)
altitude: -1,257 to 10,617 feet (-383 below sea level to 3,286 meters above sea level)
Environment:
Humidity 10% to 90%
Voltage and
Current
Requirements
+5 VAC, 10 A

About media server port connections
Installing and Configuring the Avaya S8400 Media Server February 2006 15
For control and adjunct connectivity, the S8400 Media Server supports the internal processor
ethernet or separate C-LAN. Messaging and administration use the customer link. If LAN
connectivity is required only for administration, processor ethernet is not required.
Media server cable adapter
The media server cable adapter is mounted on the rear of the TN8400AP Media Server circuit
pack. The media server cable adapter provides the connection between the backplane pins and
RJ-45 connectors for:
●four backplane Ethernet ports
●one backplane USB port
See Figure 1: Media server cable adapter on page 15.
Figure 1: Media server cable adapter
Figure notes:
1. USB modem connector
2. Connection to TN8412AP circuit pack
3. Connection to LAN
4. Not used
5. Not used
addp84bk LAO 112905
USB
ETH-A
ETH-B
ETH-C
ETH-D
1
2
3
4
5

Chapter 1: Introduction
16 Installing and Configuring the Avaya S8400 Media Server February 2006
Table 3: Media server cable adapter port labeling on page 16 describes the connections for the
media server cable adapter.
Ethernet connectivity with the TN8412AP circuit pack
The S8400 Media Server supports connectivity with the TN8412AP (SIPI) circuit pack through a
10/100 BaseT Ethernet twisted pair on the IPSI-2 cable adapter. This interface is for control only
- no bearer traffic is carried over this connection. This Ethernet is connected to the
Communication Manager Processor complex. The IPSI-2 cable adapter is mounted on the rear
of the TN8412AP SIPI circuit pack.
The physical connection between the TN8412AP and the TN8400 circuit packs is made by
either:
1. Using a 10/100 Base T Ethernet crossover cable that directly interconnects the
appropriate backplane pins of the two circuit packs. This cable plugs into the TN8400AP
cable adapter RJ45 ETH-A port and the TN8412AP IPSI-2 adapter RJ45 control port.
2. Connection to the customer LAN.
Table 3: Media server cable adapter port labeling
Location (counting from
the top of the adapter) Port Name Adapter Label Function
USB Backplane USB
modem port USB Provides power to the USB modem, can hard reset the USB modem,
provides a USB modem interface to
support Services remote alarming
and access.
Top Ethernet Ethernet
connectivity with
the TN8412AP
circuit pack
ETH-A 10/100Base T Mbps Ethernet
Interface for the control links - uses
crossover cable to connect directly
to the SIPI.
Second Ethernet Ethernet
connectivity with
the LAN
ETH-B 10/100Base T Mbps Ethernet
Interface to the customer LAN.
Messaging over IP.
Connections to adjuncts and IP
endpoints.
Remote administration over IP.
Third Ethernet Future ETH-C Not used
Bottom Ethernet Future ETH-D Not used

About media server port connections
Installing and Configuring the Avaya S8400 Media Server February 2006 17
IPSI-2 cable adapter on page 17 shows the IPSI-2 cable adapter for the S8412AP SIPI circuit
pack.
Figure 1: IPSI-2 cable adapter
Figure 2: Cable adapters on TN8412AP and TN8400AP circuit packs in a G650 on page 18
shows the location of the two backplane adapters on a G650.
Figure notes:
1. D9 connector 2. RJ45 for connection to the TN8400 or LAN
addpipsi LAO 112905
10/100bT
ETHERNET
10/100bT
ETHERNET
1
2

Chapter 1: Introduction
18 Installing and Configuring the Avaya S8400 Media Server February 2006
Figure 2: Cable adapters on TN8412AP and TN8400AP circuit packs in a G650
Figure notes:
1. Media server cable adapter on the
TN8400AP Media Server circuit pack 2. IPSI-2 cable adapter on the TN8412AP SIPI circuit pack
h2dp650b LAO 121605
USB
ETH-A
ETH-B
ETH-C
ETH-D
RS232DEBUG
10/100bT
ETHERNET
1
2

About media server port connections
Installing and Configuring the Avaya S8400 Media Server February 2006 19
Services access port
The S8400 Media Server has one Services laptop access port that is off the Maintenance
Processor. Use this port to access the MPC and the media server on the S8400AP circuit pack.
Table 4: Services access on the MPC on page 19 lists the Services access protocols. The MPC
receives Service requests on only two TCP ports: 10022 (Secure Shell access) and 10443
(Secure Web access).
Table 4: Services access on the MPC
Access Method Service
Requested IP Address TCP Port Service Granted
Services laptop SSH 192.11.13.6 10022 Secure Shell access to MPC
Services laptop HTTPS 192.11.13.6 10443 Secure Web access to MPC
Services laptop SSH 192.11.13.6 22 Secure Shell access to media
server
Services laptop HTTPS 192.11.13.6 443 Secure Web access to media
server
Services laptop Telnet 192.11.13.6 23 Access to media server
Services laptop Telnet 192.11.13.6 5023 Access to SAT on media
server
Modem dial-in ppp>SSH Modem IP
address 10022 Secure Shell access to MPC
Modem dial-in ppp>HTTPS Modem IP
address 10443 Web https access to MPC
Modem dial-in ppp>SSH Modem IP
address 22 Secure Shell access to media server
Modem dial-in ppp>HTTPS Modem IP
address 443 Secure Web access to media server
Modem dial-in ppp>Telnet Modem IP
address 23 Access to media server
Modem dial-in ppp>Telnet Modem IP
address 5023 Access to SAT on media server
Modem dial-in ppp>SSH Modem IP
address 5022 Secure access to SAT on media server

Chapter 1: Introduction
20 Installing and Configuring the Avaya S8400 Media Server February 2006
About Modem connections
Note:
Note: USB modems cannot connect to rotary lines. A Touch Tone line is required.
The TN8400AP Media Server circuit pack supports a USB modem. The modem communicates
directly to the maintenance processor or tunnels through to the Communication Manager
processor application. The modem provides Avaya Services with remote alarming and dial-in
and dial-out access.
Connect the USB modem to port labeled USB on the media server cable adapter. The adapter
is mounted on the rear of the TN8400AP Media Server circuit pack.
Modem options are set when you configure the media server. No options are set on the
modems themselves.
About Media Gateways
In a new installation, the S8400 Media Server is installed only in the Avaya G650 Media
Gateway.
In a migration the media server is installed only in the following Avaya Media Gateways:
●G600
●CMC1
In addition, the media servers work with Avaya G150, G250, G350, and G700 Media Gateways.
These gateways register with the S8400 either through the S8400 Processor Ethernet interface
or through a TN799DP C-LAN circuit pack.
