Avaya one-X 9641G Installation and operating instructions

Using Avaya 9621G/9641G/9641GS IP
Deskphones SIP for Call Center Agents
Release 7.0
August 2015

© 2014-2015, Avaya Inc.
All Rights Reserved.
Notice
While reasonable efforts have been made to ensure that the
information in this document is complete and accurate at the time of
printing, Avaya assumes no liability for any errors. Avaya reserves
the right to make changes and corrections to the information in this
document without the obligation to notify any person or organization
of such changes.
Note
Using a cell, mobile, or GSM phone, or a two-way radio in close
proximity to an Avaya IP telephone might cause interference.
Documentation disclaimer
“Documentation” means information published by Avaya in varying
mediums which may include product information, operating
instructions and performance specifications that Avaya may generally
make available to users of its products and Hosted Services.
Documentation does not include marketing materials. Avaya shall not
be responsible for any modifications, additions, or deletions to the
original published version of documentation unless such
modifications, additions, or deletions were performed by Avaya. End
User agrees to indemnify and hold harmless Avaya, Avaya's agents,
servants and employees against all claims, lawsuits, demands and
judgments arising out of, or in connection with, subsequent
modifications, additions or deletions to this documentation, to the
extent made by End User.
Link disclaimer
Avaya is not responsible for the contents or reliability of any linked
websites referenced within this site or documentation provided by
Avaya. Avaya is not responsible for the accuracy of any information,
statement or content provided on these sites and does not
necessarily endorse the products, services, or information described
or offered within them. Avaya does not guarantee that these links will
work all the time and has no control over the availability of the linked
pages.
Warranty
Avaya provides a limited warranty on Avaya hardware and software.
Refer to your sales agreement to establish the terms of the limited
warranty. In addition, Avaya’s standard warranty language, as well as
information regarding support for this product while under warranty is
available to Avaya customers and other parties through the Avaya
Support website: http://support.avaya.com or such successor site as
designated by Avaya. Please note that if You acquired the product(s)
from an authorized Avaya Channel Partner outside of the United
States and Canada, the warranty is provided to You by said Avaya
Channel Partner and not by Avaya.
Licenses
THE SOFTWARE LICENSE TERMS AVAILABLE ON THE AVAYA
WEBSITE, HTTP://SUPPORT.AVAYA.COM/LICENSEINFO OR
SUCH SUCCESSOR SITE AS DESIGNATED BY AVAYA, ARE
APPLICABLE TO ANYONE WHO DOWNLOADS, USES AND/OR
INSTALLS AVAYA SOFTWARE, PURCHASED FROM AVAYA INC.,
ANY AVAYA AFFILIATE, OR AN AVAYA CHANNEL PARTNER (AS
APPLICABLE) UNDER A COMMERCIAL AGREEMENT WITH
AVAYA OR AN AVAYA CHANNEL PARTNER. UNLESS
OTHERWISE AGREED TO BY AVAYA IN WRITING, AVAYA DOES
NOT EXTEND THIS LICENSE IF THE SOFTWARE WAS
OBTAINED FROM ANYONE OTHER THAN AVAYA, AN AVAYA
AFFILIATE OR AN AVAYA CHANNEL PARTNER; AVAYA
RESERVES THE RIGHT TO TAKE LEGAL ACTION AGAINST YOU
AND ANYONE ELSE USING OR SELLING THE SOFTWARE
WITHOUT A LICENSE. BY INSTALLING, DOWNLOADING OR
USING THE SOFTWARE, OR AUTHORIZING OTHERS TO DO SO,
YOU, ON BEHALF OF YOURSELF AND THE ENTITY FOR WHOM
YOU ARE INSTALLING, DOWNLOADING OR USING THE
SOFTWARE (HEREINAFTER REFERRED TO
INTERCHANGEABLY AS “YOU” AND “END USER”), AGREE TO
THESE TERMS AND CONDITIONS AND CREATE A BINDING
CONTRACT BETWEEN YOU AND AVAYA INC. OR THE
APPLICABLE AVAYA AFFILIATE (“AVAYA”).
Avaya grants You a license within the scope of the license types
described below, with the exception of Heritage Nortel Software, for
which the scope of the license is detailed below. Where the order
documentation does not expressly identify a license type, the
applicable license will be a Designated System License. The
applicable number of licenses and units of capacity for which the
license is granted will be one (1), unless a different number of
licenses or units of capacity is specified in the documentation or other
materials available to You. “Software” means computer programs in
object code, provided by Avaya or an Avaya Channel Partner,
whether as stand-alone products, pre-installed on hardware products,
and any upgrades, updates, patches, bug fixes, or modified versions
thereto. “Designated Processor” means a single stand-alone
computing device. “Server” means a Designated Processor that
hosts a software application to be accessed by multiple users.
“Instance” means a single copy of the Software executing at a
particular time: (i) on one physical machine; or (ii) on one deployed
software virtual machine (“VM”) or similar deployment.
License types
Designated System(s) License (DS). End User may install and use
each copy or an Instance of the Software only on a number of
Designated Processors up to the number indicated in the order.
Avaya may require the Designated Processor(s) to be identified in
the order by type, serial number, feature key, Instance, location or
other specific designation, or to be provided by End User to Avaya
through electronic means established by Avaya specifically for this
purpose.
Shrinkwrap License (SR). You may install and use the Software in
accordance with the terms and conditions of the applicable license
agreements, such as “shrinkwrap” or “clickthrough” license
accompanying or applicable to the Software (“Shrinkwrap License”).
Copyright
Except where expressly stated otherwise, no use should be made of
materials on this site, the Documentation, Software, Hosted Service,
or hardware provided by Avaya. All content on this site, the
documentation, Hosted Service, and the product provided by Avaya
including the selection, arrangement and design of the content is
owned either by Avaya or its licensors and is protected by copyright
and other intellectual property laws including the sui generis rights
relating to the protection of databases. You may not modify, copy,
reproduce, republish, upload, post, transmit or distribute in any way
any content, in whole or in part, including any code and software
unless expressly authorized by Avaya. Unauthorized reproduction,
transmission, dissemination, storage, and or use without the express
written consent of Avaya can be a criminal, as well as a civil offense
under the applicable law.
Third Party Components
“Third Party Components” mean certain software programs or
portions thereof included in the Software or Hosted Service may
contain software (including open source software) distributed under
third party agreements (“Third Party Components”), which contain
terms regarding the rights to use certain portions of the Software
(“Third Party Terms”). As required, information regarding distributed
Linux OS source code (for those products that have distributed Linux
OS source code) and identifying the copyright holders of the Third
Party Components and the Third Party Terms that apply is available
in the products, Documentation or on Avaya’s website at: http://
support.avaya.com/Copyright or such successor site as designated
by Avaya. You agree to the Third Party Terms for any such Third
Party Components.
Preventing Toll Fraud
“Toll Fraud” is the unauthorized use of your telecommunications
system by an unauthorized party (for example, a person who is not a
corporate employee, agent, subcontractor, or is not working on your
company's behalf). Be aware that there can be a risk of Toll Fraud
associated with your system and that, if Toll Fraud occurs, it can
result in substantial additional charges for your telecommunications
services.
Avaya Toll Fraud intervention
If You suspect that You are being victimized by Toll Fraud and You
need technical assistance or support, call Technical Service Center
Toll Fraud Intervention Hotline at [phone] for the United
States and Canada. For additional support telephone numbers, see

the Avaya Support website: http://support.avaya.com or such
successor site as designated by Avaya. Suspected security
vulnerabilities with Avaya products should be reported to Avaya by
sending mail to: [email protected].
Trademarks
All non-Avaya trademarks are the property of their respective owners.
Linux® is the registered trademark of Linus Torvalds in the U.S. and
other countries.
Downloading Documentation
For the most current versions of Documentation, see the Avaya
Support website: http://support.avaya.com, or such successor site as
designated by Avaya.
Contact Avaya Support
See the Avaya Support website: http://support.avaya.com for product
or Hosted Service notices and articles, or to report a problem with
your Avaya product or Hosted Service. For a list of support telephone
numbers and contact addresses, go to the Avaya Support website:
http://support.avaya.com (or such successor site as designated by
Avaya), scroll to the bottom of the page, and select Contact Avaya
Support.
Federal Communications Commission (FCC) Interference
Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user's
authority to operate this equipment.
FCC/Industry Canada Radiation Exposure Statement
This device complies with the FCC's and Industry Canada's RF
radiation exposure limits set forth for the general population
(uncontrolled environment) and must not be co-located or operated in
conjunction with any other antenna or transmitter.
Warning
The handset receiver contains magnetic devices that can attract
small metallic objects. Care should be taken to avoid personal injury.
Power over Ethernet (PoE) warning
This equipment must be connected to PoE networks without routing
to the outside plant.

Contents
Chapter 1: Introduction to the Avaya Call Center agent deskphones................................. 5
Differences between the H.323 and SIP deskphones................................................................. 5
About Call Center Agent Phone screen..................................................................................... 6
Quick Touch Panel options....................................................................................................... 8
Setting the Quick Touch panel............................................................................................ 9
About Agent work modes and states......................................................................................... 9
About call center-related icons................................................................................................ 10
About Lamp States for Call Center features............................................................................. 12
Agent Status line display combinations for agents.................................................................... 13
About incoming calls.............................................................................................................. 16
About Message Waiting Indicator............................................................................................ 17
Chapter 2: Call Center Agent operations.............................................................................. 18
About Call Center Agent features............................................................................................ 18
About Reason Codes............................................................................................................. 18
Logging in as an agent........................................................................................................... 19
Logging out as an agent......................................................................................................... 20
Activating After Call Work....................................................................................................... 20
Activating Auxiliary Work........................................................................................................ 21
Activating Auto In.................................................................................................................. 21
Activating Manual In.............................................................................................................. 22
Activating Logout Override..................................................................................................... 22
Chapter 3: Call Center Deskphone operations.................................................................... 24
Answering and ending a call................................................................................................... 24
Switching to another deskphone during an active call............................................................... 25
Enabling wireless headset bidirectional signaling..................................................................... 25
Enabling SAC when DND is active.......................................................................................... 25
Entering Stroke Counts.......................................................................................................... 26
Entering Call Work Codes...................................................................................................... 27
Viewing Queue Stats............................................................................................................. 27
Viewing Vu Stats................................................................................................................... 28
Activating Supervisor Assist................................................................................................... 29
Viewing ASAI UUI................................................................................................................. 29
Call observation.................................................................................................................... 30
Activating or deactivating call observation............................................................................... 30
Assisting an agent on an observed call................................................................................... 31
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 4
Comments on this document? [email protected]

Chapter 1: Introduction to the Avaya Call
Center agent deskphones
The 9608, 9608G, 9611G, 9621G, 9641G, and 9641GS are multiline deskphones that you can use
in a standard office environment or with Avaya Call Center 3.0 or later releases. The 9621G, 9641G,
and 9641GS deskphones are touch-based phones with a color display. The 9611G, 9608, and
9608G are button-based phones. The 9611G has a color display, while the 9608 has a monochrome
display.
You can connect a dual headset adapter to the 9641G, 9641GS, 9608, and 9611G models so that
two persons can listen in on calls. You can attach up to three button modules to these models to
extend call appearances or features or both.
Additionally, the 9641G and 9641GS deskphones have an optional faceplate designed specifically
for using this model in a call center. With these deskphones you can obtain convenient features and
capabilities at your fingertips, including a Phone Screen to view and manage your calls, and icons
indicating agent status, call states, feature status, queued calls, and missed calls. Using the
designated feature buttons, you can change your agent work mode or state with one touch.
Not all functions and features described in this user guide may be available on your deskphone or
applicable to the way your call center operates. If you find that a function or feature is not available,
contact your supervisor or administrator.
Important:
This guide describes only the features and operation of the 9621G, 9641G, and 9641GS
deskphones in a call center environment. Specific user guides address standard office
deskphone operation and features such as placing calls, reviewing call history, conference
calling, and modifying deskphone options and settings for your personal preferences.
Depending on which deskphone model you are using, see Avaya one-X® Deskphone SIP for
9608 and 9611G IP Telephone User Guide or the Avaya one-X® Deskphone SIP 9621G and
9641G User Guide for 9600 Series IP Telephones, available on the Avaya Support Site:http://
avaya.support.com.
Differences between the H.323 and SIP deskphones
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 5
Comments on this document? [email protected]

There are differences between the H.323 deskphones and the SIP deskphones, which include:
• The Agent Greetings feature is supported by H.323 deskphones, but is currently not available
for the 96x1 SIP deskphones. The feature is supported only with phones that use the Avaya
one-X® Deskphone H.323 application.
• Call Center features, such as login and logout, function differently with SIP using the advanced
capabilities of the SIP architecture.
• If collected digits are available for a call, they appear on the Agent Status line automatically on
the SIP deskphones. No action is required on your part.
About Call Center Agent Phone screen
Your Phone screen displays information about your phone and agent settings as well as information
about calls.
What is displayed on your Phone screen is dependent on the phone model and what has been
configured for your system by your system administrator.
No. Name Description
1 Top Line Display Displays date and time and set information.
2 Agent Status Line Displays agent information, such as work mode and state, and when provided,
collected digits.
If collected digits are available with the call, they are displayed without any
action on your part.
If User-to-User Information (UUI) is associated with the call, it is displayed
here when you press the UUI Info button.
Table continues…
Introduction to the Avaya Call Center agent deskphones
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 6
Comments on this document? [email protected]

No. Name Description
3 Agent Information
Line
Displays Vu Stats information when you press the Vu Stats button.
When you press the Queue Stats button, the Queue Stats information
overrides the Vu Stats information. If Interruptible Aux is activated, the
Interruptible Aux message is displayed.
4 Softkeys Tap a softkey to perform that task. The softkeys that are displayed depend on
which features are active and whether you are on a call.
5 Quick Touch panel Tap to access the configured Call Center features. What is displayed here is
dependent on a number of factors, including which features are configured,
your Agent Status, and how the Quick Touch Panel is configured (not
displaying, one line displaying, or two lines displaying).
No. Name Description
1 Icon area Displays icons such as Forced Logout, Forced Logout Override, pending state
changes, and phone settings.
2 Agent ID Displays your Agent ID when you have logged in. The phone extension
number is displayed when you are not logged in.
3 Agent Work Mode Displays your agent work mode: Auto or Manual. No icon is displayed when
you are not logged in.
4 Agent State Displays your agent state as a icon: Available, Auxiliary Work (with or without
Reason Code), After Call Work, or On call (ACD or non-ACD). See About call
center-related icons on page 10.
5 Features Screen Tap the button to access the configured Call Center Features.
The Top line display, Agent Status line, and Agent Information line are also visible when viewing the
Features screen.
Use Call Center Agent features by tapping Features, or by tapping the feature from the Quick
Touch panel, if configured.
About Call Center Agent Phone screen
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 7
Comments on this document? [email protected]

Quick Touch Panel options
You can configure the Quick Touch panel to display one line, two lines, or not to display.
Not displayed
One line display
Two line display
Introduction to the Avaya Call Center agent deskphones
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 8
Comments on this document? [email protected]

Setting the Quick Touch panel
About this task
When you use the Quick Touch panel, the Phone screen provides access to your features or call
appearance buttons at a glance. You can set the Quick Touch Panel to display one or two lines, or
not display any lines. Displaying the Quick Touch panel can limit your call appearances display to
three lines at a time.
Procedure
1. Press Home.
2. Tap Settings.
3. Tap Options & Settings.
4. Tap Screen and Sound Options.
5. On the Screen and Sounds menu, tap Show Quick Touch Panel to change the setting
from 1 Line to 2 Lines, from 2 Lines to No, or from 0 to 1 Line.
6. Tap Save to save the setting or Cancel to return to the menu without saving.
About Agent work modes and states
When you are logged in as an agent, the Agent Status line shows your current work mode and
state.
When logged in, the agent work mode is Aux Work but changed to Auto In and Manual In if ACD
call is received.
The agent states are:
State Description
Available This state is automatically assigned when you are available to receive ACD
calls. With Auto In, you are returned to Available after each call is released.
With Manual In, you must tap Manual In to return to the available state.
Aux Work You are placed in the Auxiliary Work state after agent login without a
specified work mode. You must change to Auto In or Manual In work mode
to become available to receive incoming call center calls and to select your
mode of operation. You can change back to Auxiliary Work to indicate you
are not available to receive call center calls; for example, when you want to
take a break. Depending on how your system is administered, you might be
prompted to enter a Reason Code when changing to Aux Work
Table continues…
About Agent work modes and states
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 9
Comments on this document? [email protected]

State Description
After Call Work Switch to ACW to perform after-call work, such as completing a call-related
form. The call distribution system automatically changes your agent state to
ACW if you are in Manual-In mode.
You may also enter this state automatically when you are in Auto-In mode,
if your system administrator has configured automatic ACW for a preset
time period after call completion.
On Call This state is automatically assigned when you are active on a call. If you
are active on an ACD call, the “On-ACD Call” icon is displayed; otherwise,
the “On non-ACD Call” icon is displayed.
Forced Logout This state is assigned at a specified time determined by your system
administrator. The Forced Logout icon is displayed on the top line only if the
administrator has assigned a logout time for you. If you are not on a call,
you are logged out of the ACD regardless of which agent state you are in.
Logout Override You can invoke this state if you want to continue working after your
scheduled logout time. The Logout Override icon is displayed on the top
line only if you have invoked to override the administered Forced Logout
before the scheduled time.
Pending states are assigned whenever you request a state change while active on a call. For
example, you request to change to an Aux Work state while active on a call. When the call is
released, the pending state change become effective immediately.
About call center-related icons
What you see on the Deskphone display depends on the features that are provisioned for your
Deskphone.
Icon Icon name Where it
appears
Description
After Call
Work
Agent Status
line
The Deskphone displays this icon when you activate
ACW.
Use this state when you are performing any after
call-related work, such as filling in paperwork after an
ACD call.
Pending ACW Top Line
display
The Deskphone displays this icon when you activate
ACW when you are active on a call.
Aux Work Agent Status
line
The Deskphone displays this icon when you activate
Aux Work.
Enter this state when you are performing non-ACD
activities such as taking a break, or placing an
Table continues…
Introduction to the Avaya Call Center agent deskphones
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 10
Comments on this document? [email protected]

Icon Icon name Where it
appears
Description
outgoing call. You may need to enter a Reason Code
for entering the Aux Work state if this requirement is
configured by your system administrator.
Pending Aux Top Line
display
The Deskphone displays this icon when you activate
Aux Work while you are active on a call.
Available Agent Status
line
You are available for any incoming call.
The Deskphone displays this icon when you are not
active on a call, in ACW, or in Aux Work.
Pending
Available
Top Line
display
The Deskphone displays this icon when you are
changing your state to Available from Aux Work or
ACW and you are active on a call.
Forced Logout Top Line
display
The Deskphone displays this icon when Forced
Logout is active for your Agent ID.
Forced Logout
Override
Top Line
display
The Deskphone displays this icon if you activate
Forced Logout Override.
Pending
Logout
Top Line
display
The Deskphone displays this icon if you press the
Log Out button while you are active on a call or when
the Forced Logout time arrives and you are active on
an ACD call.
Alerting icon Agent Status
line
The Deskphone displays this icon when you receive
an incoming call. When you receive an ACD or DAC
call, the icon displays the respective text, ACD or
DAC, horizontally beside the bell.
On call Agent Status
line
The Deskphone displays this icon when you are
active on a call. When you receive an ACD or DAC
call, the icon displays the respective text, ACD or
DAC, horizontally.
If you are active on an ACD call, the On ACD call
icon is displayed, otherwise, the On non-ACD call
icon is displayed.
Held call Agent Status
line
The Deskphone displays this icon when you have
placed a call on hold. When you place an ACD or
DAC call on hold, the icon displays the respective
text, ACD or DAC, vertically.
Queue Stats Agent
Information
line
The Deskphone displays this icon when you activate
Queue Stats.
The clock icon appears before the oldest call time
and the calls icon appears before the number of calls
in the queue.
Table continues…
About call center-related icons
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 11
Comments on this document? [email protected]

Icon Icon name Where it
appears
Description
Time in
Queue
Threshold
warning
Queue Stats
feature button
The Deskphone displays this icon to indicate when
the time threshold for the oldest call in the queue has
been reached.
Call threshold
warning
Queue Stats
feature button
The Deskphone displays this icon when the number
of calls in the queue has reached the maximum
configured by your system administrator.
UUI icon Agent Status
line
If an incoming call has UUI information, the UUI
feature button lamp is solid.
When you tap the feature, or press the button
associated with this feature, the Deskphone displays
this icon before the UUI information.
Collected
Digits
Information
Agent Status
line
If the incoming call has collected digits information,
the Deskphone displays this icon before the digits.
Collected digits are digits that the caller entered
before reaching you.
About Lamp States for Call Center features
Call center features that are associated with an administered feature button display different lamp
states, indicating the status of the feature.
Lamp State Feature Status
Dark Off
Steady On: Observing, listening, or coaching.
Wink Pending state change: Listening, listen-talk and coaching.
Flash • Prompt to enter Reason Code or
• Indicates a threshold has been reached.
• Occurs between calls.
Flutter Displayed during a number of feature states, including:
• On call, or in Aux, or ACW with DAC call waiting.
Table continues…
Introduction to the Avaya Call Center agent deskphones
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 12
Comments on this document? [email protected]

Lamp State Feature Status
• Pending Logout
• Stroke count was entered while you are in an invalid state
• Call Work Code entered while you are in an invalid state
• Error has occurred.
Agent Status line display combinations for agents
What you see on the Agent Status line of the screen depends on what you are doing at the time
(your agent work mode) and whether you are idle or have an active, held, or incoming call.
In the following example, the Agent Status line indicates you are in Auto In mode and there is an
incoming DAC call.
Use this chart as a guide to possible agent status line display combinations.
• ACD=Automatic Call Distribution
• ACW=After Call Work
• Auto=Auto In
• Aux=Auxiliary Work state
• DAC=Direct Agent Call
• Man=Manual In
• RC=Reason Code #
Agent Work
Mode shows
Agent Status
shows
Icon area shows What this means:
Auto or Man You are ready to receive DAC or ACD calls.
Auto or Man Incoming You have an incoming non-ACD or non-DAC
call.
Auto or Man Incoming-ACD You have an incoming ACD call.
Table continues…
Agent Status line display combinations for agents
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 13
Comments on this document? [email protected]

Agent Work
Mode shows
Agent Status
shows
Icon area shows What this means:
Auto or Man Incoming-DAC You have an incoming DAC call.
Auto or Man On-ACD You are on an ACD call.
Auto or Man On-ACD A DAC call is waiting in the queue while you
are on an ACD call.
Auto or Man On-DAC You are on a DAC call.
Auto or Man On-DAC A DAC call is waiting in the queue while you
are on a DAC call.
Auto or Man Hold You have a non-ACD, non-DAC call on hold.
Auto or Man Hold A DAC call is waiting in the queue while you
have a non-ACD, non-DAC on hold.
Auto or Man On-ACD-Hold You have an ACD call on hold.
Auto or Man On-ACD-Hold A DAC call is waiting in the queue while you
have an ACD call on hold.
Auto or Man On-DAC-Hold You have a DAC on hold.
Auto or Man On-DAC-Hold A DAC call is waiting in the queue while you
have a DAC on hold.
Auto or Man Aux or Aux RC You are performing auxiliary work and not
available to receive DAC or ACD calls.
Table continues…
Introduction to the Avaya Call Center agent deskphones
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 14
Comments on this document? [email protected]

Agent Work
Mode shows
Agent Status
shows
Icon area shows What this means:
(RC if applicable) Note:
If you have just logged in as an agent, the
work mode is blank.
Auto or Man Aux or Aux RC
(RC if applicable)
A DAC call is waiting in the queue while you
are performing auxiliary work and not available
to receive DAC or ACD calls.
Note:
If you have just logged in as an agent, the
work mode is blank.
Auto or Man ACW You are performing after call work and not
available to receive DAC or ACD calls.
Auto or Man ACW A DAC call is waiting in the queue while you
are performing after call work and not available
to receive DAC or ACD calls.
Auto or Man On-ACD
or
On-DAC
Aux Pend or Aux RC
Pend
You are active on a call, are switching into Aux
state, and have no incoming or pending calls.
Auto or Man On-ACD
or
On-DAC
Aux Pend or Aux RC
Pend
You are active on a call, a DAC call is waiting
in the queue while you are switching into Aux
state.
Note:
If you put a call on hold, then the Agent
Status line displays the On-hold icon.
Auto or Man On-ACD
or
On-DAC
ACW Pend You are active on a call, you are switching into
ACW state, and have no incoming or pending
calls.
Auto or Man On-ACD ACW Pend You are active on a call and a DAC call is
waiting in the queue while you are switching
into ACW state.
Table continues…
Agent Status line display combinations for agents
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 15
Comments on this document? [email protected]

Agent Work
Mode shows
Agent Status
shows
Icon area shows What this means:
or
On-DAC
Note:
If you put a call on hold, then the Agent
Status line displays the On-hold icon.
About incoming calls
What information is displayed for an incoming call is dependent on the call type and what has been
configured for your system.
VDN information
Depending on how vector programming is configured for your system, incoming calls may traverse
multiple VDNs (Vector Directory Number) or they may stay within the original VDN that received
them.
Note:
A Vector Directory Number (VDN) is a contact number in CM that is, in general, used as a point
of entry of a call into a Call Center. In many cases, it is the mapping of an 1–800 telephone
number that a caller dials to access the services provided by a Call Center.
If the calls traverse multiple VDNs, one of these VDNs is configured as the active VDN for the call.
The active VDN controls what information is displayed on the Deskphone that receives the call.
Your Deskphone displays the following information: “caller_ID info→ VDN_name”, where “caller_ID
info” is the calling party identification, if available, and “VDN_Name” is the administered name of the
active VDN before delivery to you. The active VDN for an unanswered redirected call, along with a
Call Redirected (CR) indicator, is displayed for an incoming call, as is the case for calls that are
received from Routing On No Answer (RONA) redirection..
ASAI UUI
When you receive a call with User-to-User Information (UUI), the UUI Info feature button is lit on the
Deskphone screen. When you press the UUI Info key, the UUI icon is displayed, followed by the UUI
information. The UUI icon is used to distinguish UUI information from other call information, such as
collected digits.
Collected digits
Introduction to the Avaya Call Center agent deskphones
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 16
Comments on this document? [email protected]

If collected digits are associated with the incoming call, the digits are displayed on the Agent Status
line, without requiring any action on your part. The Info icon is displayed, followed by the collected
digits information.
When this information is cleared from the Agent Status line is dependent on your system
configuration.
Incoming call ring alert type
• All internal ACD or DAC calls rings with an internal alert type.
• All external ACD or DAC calls rings with an external alert type.
• All internal ACD or DAC priority calls rings with a priority alert type.
• All phones while receiving a supervisor assist call rings with priority alert.
About Message Waiting Indicator
An illuminated red LED in the upper-right corner of your deskphone and the Message Button on the
deskphone faceplate indicate you have unopened voice mail messages. If Visual Alerting is
enabled, the corner LED also flashes when you receive an incoming call. Depending on your system
configuration, the message waiting indicators indicate messages either for the deskphone
extension, or for the Agent LoginID after agent login. When configured for Agent LoginID, the
message waiting indications are for the agent when the agent is logged in. Immediately after agent
login, the screen displays MWI is indicated for the Agent ID or MWI is indicated
for the extension.
Your deskphone can also be configured to indicate when other extensions have unopened voice
mail messages, using the lamp indication of specific Message Waiting Indicator (MWI) feature
buttons defined for each extension to be monitored. If your administrator has enabled this feature,
the button lamp is green and the touchscreen displays an open envelope icon when there are
unopened messages for the configured extensions on your deskphone.
When all messages are cleared, the touchscreen displays a close envelope icon.
About Message Waiting Indicator
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 17
Comments on this document? [email protected]

Chapter 2: Call Center Agent operations
About Call Center Agent features
Most Call Center features are provisional and configured by your system administrator. You may not
see all the features described in the next two chapters.
The feature name that is displayed on your deskphone is dependent on your deskphone display
settings.
Note:
The half-width mode is not supported for Avaya Aura® Contact Center Elite features.
You can gain access to the Call Center Agent features from:
• Quick Touch panel
• Features list
For the purposes of this user guide, the instructions are based on Features list. To access the
features from the Quick Touch panel, simply tap the feature.
About Reason Codes
Some Call Center features, such as Agent Logout and Auxiliary Work state, may require you to
enter a Reason Code.
Reason Codes are configured as “Forced” or “Requested”, or “None”. Forced means a Reason
Code must be entered and Requested means you can bypass entering a Reason Code.
If your system administrator did not configure Reason Codes, you may not be prompted to enter a
Reason Code.
Speak to your system administrator or supervisor for more information about the Reason Codes
your system uses.
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 18
Comments on this document? [email protected]

Logging in as an agent
Before you begin
To log in as an agent, your extension must be registered to the Avaya Aura network and you must
have your agent ID and, if required by your system administrator, your password.
Procedure
1. Tap Features to access the Features list.
2. From the Features list, tap Agent Login using the up or down navigation arrows.
3. Enter your Agent ID.
4. Tap Enter.
5. If an agent password has been configured, enter your password. If not, proceed to the
following step.
6. Tap Enter.
Result
The deskphone displays the following information:
• Whether Message Wait Indicator is configured for your Agent ID, or for the extension
• Which agent skills you are assigned and logged into
• Which agent skills you are assigned, but not logged into, perhaps because that assigned skill
has reached a predetermined system limit
Note:
You can view Skills information at any time by tapping the Skills softkey from the Features
screen.
Upon log in, your agent state is Aux Work and you do not have a work mode assigned. You must
select a work mode to become available.
Logging in as an agent
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 19
Comments on this document? [email protected]

Upon successful login, the Agent Login feature toggles to the Agent Logout feature.
Note:
If you enter an incorrect password, you hear an error beep and the following error message
shows on the display:
Incorrect Password
Logging out as an agent
Before you begin
Your system administrator can configure Reason Codes as “Forced” which means a Reason Code
must be entered upon Agent Log Out. Speak to your system administrator or supervisor for more
information about the Reason Codes your system uses.
Procedure
1. Tap Features to access the Features list.
2. From the Features list, tap Agent Logout using the up or down navigation arrows.
3. If configured by your system administrator, enter the Reason Code for logout.
4. Tap Enter.
Result
Upon successful logout, the Agent Logout feature toggles to the Agent Login feature.
Activating After Call Work
About this task
You can activate After Call Work at any time while you are logged in as an agent. If After Call Work
is activated while on a call, the phone indicates it is pending After Call Work until after your active
call is released.
Procedure
1. Tap Features to access the Features list.
2. From the Features list, tap After Call Work using the up or down navigation arrows.
3. Tap Select.
Result
The After Call Work icon ( ) appears on the Agent Status Line.
Call Center Agent operations
August 2015 Using Avaya 9621G/9641G/9641GS IP Deskphones SIP for Call Center Agents 20
Comments on this document? [email protected]
