AVer FV2028-T User manual

AVer Vandal Dome Type Camera
Installation Guide

Table of Contents
IMPORTANT SAFEGUARD.................................................................................................1
PACKAGE CONTENTS.......................................................................................................2
OPTIONAL ACCESSORIES................................................................................................2
IP CAMERA PARTS.............................................................................................................3
IP CAMERA INSTALLATION...............................................................................................4
DEPLOYING NETWORK ........................................................................................................4
Network Connection via Ethernet Switch....................................................................4
Connect the power adapter to power jack of camera..................................................4
Power over Ethernet Connection................................................................................5
CONNECTING EXTERNAL DEVICES TO I/OTERMINAL BLOCK....................................................6
INTERNAL CONNECTION DIAGRAM OF DI/DO.........................................................................6
MOUNTING THE IP CAMERA .................................................................................................7
FOCUSING THE IPCAMERA WITH BNC MONITOR ...................................................................8
INSERTING MICROSD CARD TO SYSTEM................................................................................9
RESETTING HARDWARE.................................................................................................10
TECHNICAL SPECIFICATIONS........................................................................................11
FV2028-T (E)/FV2028-TM (E) .....................................................................11
FV3028-RT (E)/FV3028-RTM (E) ................................................................15
FV2028 (E)....................................................................................................19
FCC NOTICE (CLASS B) ..................................................................................................23
NOTICE..............................................................................................................................23
WARNING..........................................................................................................................23
GOVERNING LAW AND YOUR RIGHTS ..........................................................................25

1
ENGLISH
Important Safeguard
Do not use power supply with different voltage
other than DC 12V / PoE.
Do not submerge the unit in the water.
Unplug the power of this unit as soon as smoke
or unusual odor is detected.
Unplug the power supply before cleaning. Use
only a lens cleaning cloth and never use
benzene, thinner, or other solvent for cleaning.
Do not attempt to service this unit by yourself.
Always refer all servicing to qualified service
personnel.
Do not place the unit in unsteady surface and
also do not drop the unit.
Keep the IP camera housing close and prevent
the dust from getting in the housing.

2
Package Contents
The following items are included in the package.
AVer Vandal Dome type
Camera
Software & Manual CD
L-type Wrench
Alignment Sticker
4 Screws
4 Washers
4 Plastic Anchors
Optional Accessories
Power Adapter (12V, 2A)
* The power adapter will vary depending on the
standard power outlet of the country where it is
sold. Depending on your package the power
adapter maybe included.

3
ENGLISH
IP Camera Parts
No.
Function
(1)
Camera Lens
(2)
Light Sensor
(3)
Power Jack
(4)
BNC Jack (Video Out)
(5)
RJ45 Ethernet Jack
(6)
I/O Terminal Block
(7)
Phone Jack (Audio In)
(8)
Phone Jack (Audio Out)

4
IP Camera Installation
This section provides useful tips on how to adjust the IP camera to meet your needs.
Deploying Network
Network Connection via Ethernet Switch
Connect the RJ45 cable from the Ethernet switch to RJ45 Ethernet jack of camera
Connect the power adapter to power jack of camera

5
ENGLISH
Power over Ethernet Connection
AVer vandal dome type camera fully complies with PoE standard. It allows you to use PoE enabled
switch or PoE injector to transmit data and power thru single Ethernet cable.
PoE Enabled Switch Connection Diagram
PoE Injector Connection Diagram

6
Connecting External Devices to I/O Terminal Block
No.
Function
(1)
Power 12V
(2)
Digital Output
(3)
Digital Input
(4)
Ground
[Note] Maximum power output is 12V/100mA
Internal Connection Diagram of DI/DO

7
ENGLISH
Mounting the IP Camera
1. Place the sticker on the wall surface. Then
spot the mark and drill the 5 holes indicated
on the sticker. If you are going to run the wire
through the lateral side, it’s not necessary to
drill through the big hole.
2. Insert the 4 plastic anchors in the wall.
3. Hook the IP Camera and place the washer on
the 4 screws. Use the hex socket cap bolt to
secure the IP camera.
4. After adjusting the focus and zoom control,
use the L-type wrench to secure the case of
IP camera from being tampered.

8
Focusing the IP Camera with BNC Monitor
The IP camera is supported with BNC analog video out jack which allows you to connect an analog
display devices such as an LCD BNC monitor for you to adjust the camera focus and zoom.
1. Connect the LCD BNC monitor to the BNC jack.
2. Open up the IP camera case.
3. Slightly loosen the focus and zoom control knobs and adjust the focus and zoom range. Slightly
tighten the focus and zoom knobs once you are done the adjustment.

9
ENGLISH
Inserting microSD Card to System
1. Open up the IP camera case.
2. Insert microSD card
[Note] We recommend to use industrial grade microSD card (support operating temp from -40°C to
85°C) for extreme temperature condition.

10
Resetting Hardware
1. Open the IP camera case.
2. Short PJ1 pins around 10 seconds.
Warning!!
This will cause all the configuration settings back to factory default.

11
ENGLISH
Technical Specifications
FV2028-T (E)/FV2028-TM (E)
Model
FV2028-T (E)
FV2028-TM (E)
Lens spec.
CBC AG3Z0312LMRP-N
CBC AGP3Z0312LMRP-E111T51
Lens type
vari-focal Lens (Board mount, M19)
F/no
F/1.2
Iris type
DC Iris
Focal length
f3~9mm
View Angle
H 115.2°(W)~10.1°(T)
V 74.9°(W)~23.1°(T)
MFZ support
N//A
Yes
Camera image
Min. illumination
0.4 Lux in day mode (IR off)
0.05 Lux in night mode (IR off)
0 Lux in night mode (IR on)
Built-in LED
Yes
IR distance
30M
Built-in mechanical ICR
Yes
Auto IRIS
Yes
Video
Compression
H.264/MPEG-4/MJPEG
Max. resolution
1920 x 1080
Frame rate
1920 x 1080 @ 30fps
H.264/MPEG-4
bit rate mode
VBR, 5 levels
CBR, 64/128/512/768Kbps & 1/2/3/4/6/8/10/12Mbps
MJPEG quality
5 levels
Regional of Interest
Yes
Smart Stream
Yes, 5 windows
Image orientation
mirror, flip
Motion Detection zones
3

12
Model
FV2028-T (E)
FV2028-TM (E)
Video
Privacy mask areas
3
BLC
Yes
D-WDR
Yes
De-noise
2D/3D
Day & night function
Auto/Manual/Schedule
ePTZ
Yes
Corridor Mode
Yes
Cross Detection
Yes
Audio
Encoder
G.711 (μ-law)/G.726 (bit rate 16K~64bps) /AAC
audio compression
Streaming
2-ways audio
Microphone
external microphone input
Network
protocols
TCP/IP (IPv4/IPv6), HTTP, HTTPS, UPnP, SMTP, FTP, DHCP, NTP,
DDNS, PPPoE, Samba, QoS, SNMP(V1/V2c/V3), 802.1X
Ethernet
10/100 Base-T, RJ45 connector
ONVIF
V2.X (Profile S), conformance test V12.06
Security
Password protection/IP Filter
Users
up to 10 users simultaneously
Event
Profiles
32 sets
Triggers
Alarm Interval, Motion Detection Region, Digital Input, SD Card,
Network
Actions
Trigger: Digital Output, Alarm Audio
Send out video clip: FTP, NAS, SD card
Send out snapshot / log: FTP, NAS, SD card, mail

13
ENGLISH
Model
FV2028-T (E)
FV2028-TM (E)
Interface
Digital input/output
1/1
BNC Video output
Yes
Built-in storage option
Micro SDHC & SDXC card (64GB max.)
Built-in microphone
N/A
External microphone input
Yes
External Audio output
Yes
General
Power supply
DC 12V(2A)/PoE
Power consumption
PoE (TYP.):
7W (LED/Heater off)
14W (LED on, Heater off)
15W (LED off, Heater on)
22W (LED/Heater on)
DC-IN (TYP.):
5W (LED/Heater off)
12W (LED on, Heater off)
13W (LED off, Heter on)
20W (LED/Hearer on)
PoE
PoE Class 4 (IEEE802.3at)
Dimensions
ψ144.3 x H114.4 (mm)
3-axis bracket adjustment
angle
pan: 280°, tilt: 30°~90°, rotation: 100°
Net weight
1200g
Temperature and humidity
-15°C~50°C, 20%~90% Cold Start
-50°C~50°C, 20%~90% Operating
IP Rating
IP68
IK Rating
IK10

14
Model
FV2028-T (E)
FV2028-TM (E)
Software Requirement
OS
Windows® XP/7/8
Browser
IE 8/9/10/11 (Full Function), Chorme
Firefox and Safari (Basic Function)
Firmware remote upgrade
Yes (via HTTP)
Bundled Software
ExpreeGO
free up to 32CH
IPCAM Utility
Yes
SecureCenter
Yes
Warranty
Main body
3 years
Accessories
1 year

15
ENGLISH
FV3028-RT (E)/FV3028-RTM (E)
Model
FV3028-RT (E)
FV3028-RTM (E)
Lens spec.
CBC AG3Z0312LMRP-N
CBC AGP3Z0312LMRP-E111T51
Lens type
vari-focal Lens (Board mount, M19)
F/no
F/1.2
Iris type
DC Iris
Focal length
f3~9mm
View Angle
H 92°(W)~30.2°(T)
V 65.2°(W)~23.2°(T)
MFZ support
N//A
Yes
Camera image
Min. illumination
0.8 Lux in day mode (IR off)
0.1 Lux in night mode (IR off)
0 Lux in night mode (IR on)
Built-in LED
Yes
IR distance
30M
Built-in mechanical ICR
Yes
Auto IRIS
Yes
Video
Compression
H.264/MPEG-4/MJPEG
Max. resolution
2048 x 1536
Frame rate
2048 x 1536 @ 20fps (Wide Angle)
1920 x 1080 @ 30fps (Normal mode)
H.264/MPEG-4
bit rate mode
VBR, 5 levels
CBR, 64/128/512/768Kbps & 1/2/3/4/6/8/10/12Mbps
MJPEG quality
5 levels
Regional of Interest
Yes
Smart Stream
Yes, 5 windows
Image orientation
mirror, flip
Motion Detection zones
3

16
Model
FV3028-RT (E)
FV3028-RTM (E)
Video
Privacy mask areas
3
BLC
Yes
Sensor-WDR
Yes
De-noise
2D/3D
Day & night function
Auto/Manual/Schedule
ePTZ
Yes
Corridor Mode
Yes
Cross Detection
Yes
Audio
Encoder
G.711 (μ-law)/G.726 (bit rate 16K~64bps) /AAC
audio compression
Streaming
2-ways audio
Microphone
External microphone input
Network
Protocols
TCP/IP (IPv4/IPv6), HTTP, HTTPS, UPnP, SMTP, FTP, DHCP, NTP,
DDNS, PPPoE, Samba, QoS, SNMP(V1/V2c/V3), 802.1X
Ethernet
10/100 Base-T, RJ45 connector
ONVIF
V2.X (Profile S), conformance test V12.06
Security
Password protection/IP Filter
Users
up to 10 users simultaneously
Event
Profiles
32 sets
Triggers
Alarm Interval, Motion Detection Region, Digital Input, SD Card,
Network
Actions
Trigger: Digital Output, Alarm Audio
Send out video clip: FTP, NAS, SD card
Send out snapshot / log: FTP, NAS, SD card, mail

17
ENGLISH
Model
FV3028-RT (E)
FV3028-RTM (E)
Interface
Digital input/output
1/1
BNC Video output
Yes
Built-in storage option
Micro SDHC & SDXC card (64GB max.)
Built-in microphone
N/A
External microphone input
Yes
External Audio output
Yes
General
Power supply
DC 12V(2A)/PoE
Power consumption
PoE (TYP.):
7W (LED/Heater off)
14W (LED on, Heater off)
15W (LED off, Heater on)
22W (LED/Heater on)
DC-IN (TYP.):
5W (LED/Heater off)
12W (LED on, Heater off)
13W (LED off, Heter on)
20W (LED/Hearer on)
PoE
PoE Class 4 (IEEE802.3at)
Dimensions
ψ144.3 x H114.4 (mm)
3-axis bracket adjustment
angle
pan: 280°, tilt: 30°~90°, rotation: 100°
Net weight
1200g
Temperature and humidity
-15°C~50°C, 20%~90% Cold Start
-50°C~50°C, 20%~90% Operating
IP Rating
IP68
IK Rating
IK10

18
Model
FV3028-RT (E)
FV3028-RTM (E)
Software Requirement
OS
Windows® XP/7/8
Browser
IE 8/9/10/11 (Full Function), Chrome
Firefox and Safari (Basic Function)
Firmware remote upgrade
Yes (via HTTP)
Bundled Software
ExpressGO
free up to 32CH
IPCAM Utility
Yes
SecureCenter
Yes
Warranty
Main body
3 years
Accessories
1 year
