EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
AVerMedia EN715 Carrier board and
NO111B/ TN111B/ NX211B Box PC
Apply to NVIDIA®Jetson Nano(Version B01)/ TX2 NX/ Xavier NX module
AVerMedia Technologies, Inc.
No. 135, Jian 1st Rd., Zhonghe Dist., New Taipei City 23585, Taiwan
Tel: [phone]
Fax: [phone]
Sales and Marketing: Contact
Technical Support: Professional User

1
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
Table of Contents
0.0 Preface..................................................................................................... 3
1.0 Introduction............................................................................................. 7
1.1Product Specifications __________________________________________________8
1.2OPTIONACCESSORY ______________________________________________ 10
2.0 Product Overview ...................................................................................11
2.1Block Diagram_________________________________________________________ 11
2.2Front View and Back View of Carrier board _______________________ 12
2.3Front View and Three-Quarter View of BoxPC ____________________ 14
2.4Connector Summary__________________________________________________ 16
2.5Switch Summary ______________________________________________________ 16
3.0 Feature Description............................................................................... 17
3.24 lane mipi connector __________________________ 錯誤! 尚未定義書籤。
3.3Jetson module Connector_____________________________________________ 20
3.4Fan Power connector__________________________________________________ 20
3.5MIPI CSI-2 DPHY Lanes_____________________________________________ 21
3.6RTC Battery Connector ______________________________________________ 23
3.7USB Micro-Type Connector__________________________________________ 23
3.820-Pin GPIO expansion_______________________________________________ 24
3.9Power Supply Connector _____________________________________________ 27
3.10 Gigabit Ethernet Connector _______________________________________ 28
3.11 USB 3.1 Gen 1 Type-A Connector #1 and #2 _____________________ 29
3.12 HDMI OUTPUT____________________________________________________ 29
3.13 Optional Function Selection _______________________________________ 30
3.14 Micro SD Card Slot_________________________________________________ 30

2
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
3.15 Other Switches and Jumpers ______________________________________ 30
4.0 Installation............................................................................................. 31
4.1 BSP Setup Instructions ......................................................................... 31
5.0 Software................................................................................................. 33
6.0 Force Recovery Mode............................................................................ 33
7.0 Power Consumption.............................................................................. 34
8.0 Accessory Drawings .............................................................................. 35
8.1Fan Module Power Cord _____________________________________________ 35
8.2PowerAdapter:________________________________________________________ 39
8.3Power Cord ____________________________________________________________ 40
9.0 Dimension Drawings and Assembly Drawings .................................... 43
9.1Dimension Drawings of carrier board_______________________________ 43
9.2Dimension Drawing of NO111B/ TN111B/ NX211B Box PC _____ 44

3
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
0.0 Preface
Disclaimer
The information contained in this user manual, including but not limited to any product
specification is subject to change without notice. AVerMedia assumes no liability for any
damages incurred directly or indirectly from any technical or typographical errors or omissions
contained herein or for discrepancies between the product and the user manual.
Technical Support
If you experience the difficulty after reading this manual and/or using the product, please contact
the reseller from which you purchased the product. In most cases, the reseller can help you with
the product installation and the difficulty you encountered.
In case the reseller is not able to resolve your problem, our highly capable global technical
support team can certainly assist you. Our technical support section is available 24/ 7 through our
website, with the click here. For more contact information, you may find it in the section of
AVerMedia Global Offices.
Contact Enquiry
For more information of our products, pricing, and order placement, please fill in our inquiry
form here, we will contact you within 24 hours.
Copyright Notice
The information contained in this document is subject to change without notice. AVerMedia
shall not be liable for errors contained herein or for incidental consequential damages in
connection with the furnishing, performance, or use of this material. This document contains
proprietary information that is protected by copyright. All rights are reserved. No part of this
document may be photocopied, reproduced, or translated to another language without the prior
written consent by AVerMedia.

4
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
Limited Product Warranty
AVerMedia provides the two-year product warranty. Should this product, in AVerMedia's
opinion, fail to be in the good working order during the warranty period, AVerMedia will, at its
option, repair or replace it at no charge, provided that the product has not been subjected to abuse,
misuse, accident, disaster, or non-AVerMedia authorized modification or repair.
You may obtain the warranty service by delivering this product to an authorized AVerMedia
business partner or to AVerMedia along with the proof of purchase. Product returned to
AVerMedia must be pre-authorized by AVerMedia with an RMA (Return Material Authorization)
number marked on the outside of the package and sent prepaid, insured, and packaged for the safe
shipment. AVerMedia will return the product by prepaid shipment service.
It is not recommended to disassemble the box PC, which will impact the warranty. The limited
product warranty is only valid over the serviceable life of the product. This is defined as the
period during which all components are available. Should the product prove to be irreparable,
AVerMedia reserves the right to substitute an equivalent product if available or to retract the
product warranty if no replacement is available.
The above product warranty is the only warranty authorized by AVerMedia. Under no
circumstances will AVerMedia be liable in any way for any damages, including any lost profits,
lost savings, or other incidental or consequential damages arising out of the use of, or inability to
use, such product.
.

5
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
TrademarkAcknowledgement
AVerMedia acknowledges all the trademarks, registered trademarks, and/or copyrights referred to
in this document as the property of their respective owners. Not listing all possible trademarks or
copyright acknowledgments does not constitute the lack of acknowledgment to the rightful
owners of the trademarks and copyrights mentioned in this document.
ESD Warning
Electronic components and circuits are sensitive to Electrostatic Discharge (ESD). When
handling any circuit board assemblies including AVerMedia AVerMedia products, it is highly
recommended that ESD safety precautions can be observed. ESD safe best practices can include,
but are not limited to the following ones.
1. Leave the circuit board in the antistatic package until it is ready to be installed.
2. Use a grounded wrist strap when handling the circuit board. At a minimum, you need to touch
a grounded metal object to dissipate any static charge, which may be present on you.
3. Avoid handling the circuit board in the carpeted areas.
4. Handle the board by the edges and avoid the contact with the components.
5. Only handle the circuit boards in ESD safe areas, which may include ESD floor and/or table
mats, wrist strap stations, and ESD safe lab coats.
Safety Precaution:
1. All cautions and warnings on the device should be noted.
2. For safety consideration, do NOT open the device if not a qualified service stuff.
3. Place the device on a solid surface during installation to prevent falls.
4. Keep the device away from humidity.
5. Do NOT leave this device in an un-controlled environment with temperatures beyond the
device’s permitted storage temperature to avoid damage.
6. All adaptors and cables supplied by AVerMedia are verified. Do NOT use any others not
supplied by AVerMedia to avoid any malfunction or fires.
7. Make sure the power source matches the power rating of the device.
8. Place the power cord where people cannot step on it. Do not put anything on the power cord.
9. Always completely disconnect the power while the device is not usage or idle for a long time.
10. Disconnect the device from any AC supply before cleaning. While cleaning, use a damp cloth
instead of liquid or spray detergents.
11. Make sure the device is installed near a power outlet and easy for accessible.
12. Do not cover the openings on the device to ensure optimal heat dissipation.

6
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
13. Watch out the heatsink or heat spreader of the device when the system is running.
14. Never pour any liquid into the openings. This could cause fire or electric shock.
15. The static electricity should be noted while installing any internal components. Consider to
use a grounding wrist strap and put all electronic parts in static-shielded containers.
If the following situations occur, please contact our service personnel:
(1) The device is dropped or damaged
(2) Damaged power cord or plug
(3) Exposure to moisture
(4) Liquid intrusion into the device
(5) Any obvious signs of damage displayed on the device
(6) Device is not working as expected or in a manner as described in this manual
Revision History
Revision
Date
Updates
Version 1.0
Feb,20, 2021
1st Released
Version 1.1
Apr, 22, 2021
J4/J5 pin define update
Version 1.2
June 30, 2021
J1 pin define update, TN111B data update
Version 1.3
Jan 26, 2022
P12 front view/black view
P21 3.7 OTG/USB Micro Type Connector
P26 3.9 Power Supply Connector
Version 1.4
May 4, 2022
P17 3.2 SerDes (J1)
P30 4.1 BSP setup Instruction
P37-41 8.0 Accessory drawings
Version 1.5
Oct,31 2022
Update Safety Precaution:
Version 1.6
Feb,21 2024
Update 3.2 J1 information

7
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
1.0 Introduction
AVerMedia AVerMedia EN715/NO111B/ TN111B/ NX211B includes fully featured carrier
board which is all developed for NVIDIA®Jetson Nano(Version B01)/ /TX2 NX/ Xavier NX
modules. AVerMedia EN715/NO111B/ TN111B/ NX211B provides not only the access to a
great list of latest interfaces on NVIDIA®Jetson Nano (Version B01)/ TX2 NX/ Xavier NX
modules but also one RJ-45 interface and one RTC battery as the function enrichment.
EN715/NO111B/ TN111B/ NX211B provide one 4Kp60 HDMI video output, two USB 3.0 ports,
one GbE RJ-45 port, 20-pin GPIO expansion, and one Micro-B USB 2.0 port for recovery.
Operating with NVIDIA®Jetson Nano(Version B01)/TX2 NX/ Xavier NX modules and the rich
I/O functions, AVerMedia EN715/ NO111B/ TN111B/ NX211B is the perfect choice in
building a compact, high performance AI edge computing platform for the intelligent video
analytics applications.

8
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
1.1 Product Specifications
Model
EN715
Compatibility
Apply to NVIDIA®Jetson Nano(Version B01)/TX2 NX/ Xavier NX
module
Networking
1x GbE RJ-45
Display Output
3840 x 2160 at 60Hz
Temperature
Operating temperature 0°C~70°C
Storage temperature -40°C ~ 85°C
Relative humidity 40 °C @ 95%, Non-Condensing
MIPI Camera
Inputs
(internal I/O)
-2x 2 Lane MIPI CSI-2, 15 pin FPC 1mm Pitch Connector
-1x 4 Lane MIPI CSI-2, 36 pin FPC 0.5mm Pitch Connector
USB
1x USB 2.0 Micro-B for recovery
2x USB 3.0 Type-A
Storage
1x micro-SD card slot
GPIO Expansion
20 pin: 2x I2C, 1x UART, 9x GPIOs
Input Power
3.5mm Screw Terminal, 12V/5A ; 9V~19V is recommended.
Buttons
Power and Recovery
RTC Battery
Support RTC battery and Battery Life Monitoring by MCU
Dimension/ Weight
W: 87mm x L: 70.6mm x H: 27.3mm (3.43” x 2.78” x 1.07”), Weight: 70g
Accessory
12V/5A adapter and power cord (optional)
Certifications
CE, FCC, KC

9
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
Model
NO111B/ TN111B/ NX211B
Compatibility
NVIDIA®Jetson Nano(Version B01) for NO111B
NVIDIA®Jetson TX2 NX for TN111B
NVIDIA®Jetson Xavier NX for NX211B
Networking
1x GbE RJ-45
Display Output
3840 x 2160 at 60Hz
Temperature
Operating temperature 0°C~60°C for NO111B, 0°C~55°C for TN111B
(TBD), 0°C~55°C for NX211B,
Storage temperature -40°C ~ 85°C
Relative humidity 40 °C @ 95%, Non-Condensing
MIPI Camera
Inputs
(internal I/O)
2x 2 Lane MIPI CSI-2, 15 pin FPC 1mm Pitch Connector
1x 4 Lane MIPI CSI-2, 36 pin FPC 0.5mm Pitch Connector
USB
1x USB 2.0 Micro-B for recovery
2x USB 3.0 Type-A
Storage
1x micro-SD card slot
GPIO Expansion
(internal I/O)
20 pin: 2x I2C, 1x UART, 9x GPIOs
Input Power
12V/5A ; 9V~19V is recommended.
Buttons
Power and Recovery
RTC Battery
Support RTC battery and Battery Life Monitoring by MCU
Dimension/ Weight
W: 91.4mm x L: 76.6mm x H: 70mm (3.60” x 3.02” x 2.76”)
Weight: 495g
Accessory
12V/5A adapter and power cord
Certifications
CE, FCC, KC

10
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
1.2 OPTION ACCESSORY
Item
EN715/NO111B/ TN111B/ NX211B
NVIDIA®
Jetson
NVIDIA®Jetson Nano(Version B01) for NO111B
NVIDIA®Jetson TX2 NX for TN111B
NVIDIA®Jetson Xavier NX for NX211B
Power cord
EU/JP/TW/US/CN/UK./AU
MIPI Camera
(internal I/O
for Box PC)
For 15 pin MIPI connector
1. raspberry pi camera v2
2. Manufacturer: APPRO.PHO
B-04: IMX179(8M)MIPI, 1080P(30fps)
C-04: IMX290(2M)MIPI, 1080P(30fps)
C-05: IMX290(2M)+ISP(YUV), 1080P(30fps)
For 36 pin MIPI connector
1. Manufacturer: APPRO.PHO
B-03: IMX334(4K) MIPI, 4K(30fps)
A-06: IMX334(4K) V-by-One® HS x1,
4K(30fps)

11
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
2.0 Product Overview
2.1 Block Diagram
Jetson Nano/
TX2 NX/
Xavier NX

12
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
2.2 Front View and Back View of Carrier board
Front view
VerC
VerC (as yellow circle)
White cable connect to
“+”
Black cable connect to
“-“(GND)
VerB
VerB (as yellow circle)
White cable connect to
“+”
Black cable connect to
“-“(GND)
+
▁+
+
▔
▔

13
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
Back View

14
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
2.3 Front View and Three-Quarter View of BoxPC

15
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com

16
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
2.4 Connector Summary
PCB Code
Designation
Description
NO111B/TN1
11B/NX211B
J1
4 Lane MIPI CSI-2 camera connector
J2
SO-DIMM socket for NVIDIA®Jetson / NX module
J3
Fan Power connector
J4
2 Lane MIPI CSI-2 camera connector
J5
2 Lane MIPI CSI-2 camera connector
J6
RTC battery connector
J7
USB 2.0 Micro-B
J8
20-pin GPIO expansion
J9
Power connector
J10
Gigabit Ethernet connector
J11
USB 3.1 Gen 1 Type-A connectors
J12
HDMI 2.0 connector
J13
Micro SD card slot
2.5 Switch Summary
Designation
Description
SW3
RECOVERY button
SW4
POWER on button
SW5
Fan PWM controller/Auto Power on

17
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
3.0 Feature Description
3.1 Connector and Switch Locations
J3
J1
J2
J6
J10
J5
J4
J11
J12
J7
SW5
5
J13
SW3
SW4
J8
J9

18
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
3.2 4 lane mipi connector
Function
MIPI camera module connector
Location
J1
Type Description
WAFER_1*36PIN_0.5㎜_180°
Manufacturer and
Part Number
PINREX 979-44-93610A_ZIF FPC
Mating Connector
4 Lane MIPI CSI-2 camera connector (36PIN)
PIN OUT
Pin
Number
Signal
Pin
Number
Signal
1
5V
2
5V
3
1.8V
4
3.3V
5
3.3V
6
3.3V
7
GND
8
CSI4_D0_P
9
CSI4_D0_N
10
GND
11
CSI4_CLK_P
12
CSI4_CLK_N
13
GND
14
CSI4_D1_P
15
CSI4_D1_N
16
GND
17
CSI4_D2_P
18
CSI4_D2_N
19
GND
20
CSI4_D3_P
21
CSI4_D3_N
22
GND
23
N/A
24
N/A
25
N/A
26
MIPI4_PWDN
27
CSI4_I2C_SDA
28
CSI4_I2C_SCL

19
EN715_NO111B_TN111B_NX211B User Manual www.avermedia.com
29
GND
30
N/A
31
N/A
32
N/A
33
N/A
34
GND
35
CAM4_MCLK
36
GND
