AVF JNL655 User manual

JNL655 Leaflet No. 463998 rev01
132lbs
60kg
STOP
Read through instructions before commencing installation.
If you have any questions about this product or issues with installation
contact the customer services helpline before returning this product to
the store. See jl.avfgroup.com/p/jnl655 for more information.
ALL
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
80"
203cm
CUSTOMER SERVICES HELP LINE NUMBER:
01952 670009

Fit the TV Mounting Plate
Assembly Overview
Fit the Wall Bracket
Connect the TV
!
Do Not remove
until step 6
Do Not remove
until step 6
!
2 Person Installation Recommended

Measure the TV fixing holes Width and Height
1
Fitting the Wall Bracket
5
Connecting the TV
7
Index
Fitting the TV Mounting Plate
2
3
Fitting the Wall Bracket Covers
4
Preparing the Front Adaptor Plate
6
Retain all packaging in case the bracket needs to be returned.
Contents may vary from photography/ Illustrations.
You will not need all these parts, so expect there to be some left over depending upon the
specification of your TV.
This product is intended for indoor use only. Use of this product outdoors could lead to
failure and personal injury.
It is the responsibility of the installer to ensure that the mounting wall is of a suitable
standard and void of any services (eg gas, electricity, water etc).
AVF accept no responsibility for any damage or loss caused by installing this product in a
sub standard wall.
Preparing the TV Mounting Plate
Cable Management
8

F
Boxed Parts
Stud Finder Ø3mm
Wood
Ø12mm
Masonry
Tools Recommended
B
E
D
C
D
C
A
Gx4

Ox1
4mm
Ix8 Mx6 Nx6
J1x12 J2x4
TV Screws, Reducers and Spacers
L1x4 L3x8
L7x4 L5x4
M4
16mm
M5
M6 M8
16mm
16mm 16mm
L8x4
M8
25mm
L6x4
M6
25mm
L2x4 L4x4
M4
25mm
M5
25mm
K1x4 K2x4
Hx8
M6
16mm

Measure the TV fixing holes Width and Height
1
TV Fixing Holes
75, 100, 200,
300, 400, 600mm
75, 100, 200,
300, 400mm
X
Y
If width X is not equal to 75, 100, 200, 300, 400 or 600mm or
height Y is
STOP installation now and contact the customer help line
not equal to 75, 100, 200, 300, 400mm
!
You are provided with 4 diameters of TV fixing screws, M4, M5, M6 and
M8. Determine the screw diameter that fits and remember for step 4.
After completing step 4 you will have fittings left over, please keep
for future reference
!
L5-L6
L3-L4
L1-L2
M8 =
M6 =
M4 =
M5 =
L7-L8

Preparing the Front Adaptor Plate
2
L3x4
M5
16mm
B
L3
Top

75mm
100mm
200mm
75
mm
Preparing the TV Mounting Plate
3
X
Y
OPTION 1
100
mm 200 mm
OPTION 2
X
Y200
mm
400mm
= fixing position
B
I
J1
H
B
C/D/E
x8
D C
D
E
X = 75, 100, 200mm X = 400mm X = 300 or 400mm X = 600mm
OPTION 1 OPTION 2 OPTION 3 OPTION 4
Y = 75, 100, 200mm Y = 200mm Y = 300 or 400mm Y = 400mm
B
Use the option that fits your TV.
Do not fully tighten.

300
mm
X
400mm
= fixing position
B
300mm
Y
400
mm
C
D
D
C
OPTION 3
OPTION 4
I
J1
H
B
C/D
x8
I
J1
H
B
C/D
x8
X
600mm
= fixing position
B
D C
DC
Y
400
mm

Fitting the TV Mounting Plate
4
No Spacers Spacer
For TVs with
flat/unobstructed back
For TVs with irregular/obstructed back
K1-K2
TV TV
TV
TV
WARNING
After completing step 4 you will have fittings left over, please keep
for future reference
!
Before you fully tighten the TV mounting plate please check that the
mounting plate holes line up with the fixing holes on the back of your TV.
Holes do not line up and
small adjustment is required
before you fully tighten
Holes line up and no
adjustment is required
before you fully tighten

Top
Fixings shown are valid
for options 1,2,3 & 4
B
L1-L8
J2
J1
K2
K1
If required
Screw
diameter
dependant
Attach the bracket to the back of your TV using suitable screw, reducer and spacer
combinations.
L1/L2x4
J2x4
J1x4
M5
J1x4
M6
J1x4
M8
L3/L4x4 L5/L6x4
L7/L8x4
M4
If required
and / or
K2x4
K1x4
and / or
K2x4
K1x4
and / or
K2x4
K1x4
and / or
K2x4
K1x4

Ø3mm
70mm (23/4")
Ensure bracket is in the centre of the wood stud
!
Remove dust
from hole
70mm
(23/4")
Ø12mm
(do not use ½" drill bit)
8mm (5/16") MAX
Fitting the Wall Bracket
5
!
Take care
!
Take care
A
Wood Stud
A
Solid Wall

Mx6 Nx6
DO NOT over tighten screws
Tighten screws by hand only
!
Lubricate screw thread with soap
Mx4
DO NOT over tighten screws Tighten screws by hand only
!
AM
Lubricate screw thread with soap
M
A
N
8mm (5/16")
MAX

Fitting the Wall Bracket Covers
6
G
Connecting the TV
7
Attaching and Locking

Cable Management
8
Check all fittings are tight
!
F
iii iii
F
Ensure cables
don’t restrict
arm movement

TV Levelling
O
Lock Tilt
Optional
i
ii
iii
Lateral Shift
WOOD STUD ONLY
!
x4
Replace
Remove
