peerless-AV ACC 050 Guide

ISSUED: 07-19-02 SHEET #: 128-9138-1
Visit the Peerless Web Site at www.peerlessindustries.com For customer service call 1-800-729-0307 or 708-865-8870.
1 of 2
IMPORTANT! Readentire
instruction sheet before
beginninginstallation and
assembly.
Installation and Assembly - Extension Column Stabilizer Model: ACC 050
PARTSLIST
PART # QTY. DESCRIPTION
A128-1029 2 extension column stabilizer bracket
B510-9163 4 #10 x 1 1/2 wood screw
C540-9440 4 1/4 SAE flat washer
D560-0008 1 hose clamp A
Note: Actual parts may appear slightly different than illustrated.
IMPORTANT: If using different bolts, the bolts must be A325 grade.
C
B
D
WARNING! Installer must verify that
the ceiling will safely support the
combined weight of all attached
equipment and hardware.
Before starting make sure that ceiling mount and extension column are
firmly in place.
For Wood Stud Only: Align the stabilizer bracket (A) with the side of the
extension column and wood stud as shown below. Using the stabilizer
bracket (A) as a template drill two 3/16" (5mm) dia. holes to a maximum
depth of 2" (51mm) into the wood stud. Repeat on other side.
IMPORTANT: Make sure stabilizer bracket (A) is flat on wood stud.
Note: Installer is responsible for supplying hardware for installations to
surfaces other than wood stud.

ISSUED: 07-19-02 SHEET #: 128-9138-1
Visit the Peerless Web Site at www.peerlessindustries.com For customer service call 1-800-729-0307 or 708-865-8870.
2 of 2
©2002PeerlessIndustries,Inc. Allrightsreserved.
PeerlessisaregisteredtrademarkofPeerlessIndustries,Inc.
Fasten extension stabilizer (A) to wood studs using two 1/4 flat washers (C)
and #10 wood screws (B).
A
C
B
Fasten extension stabilizer (A) to extension column use hose clamp (D).
Tighten hose clamp (D) until extension stabilizers (A) are completely
secured and column is stabilized.
D
A
