KLAY-INSTRUMENTS 2000-SAN Series User manual

H/EN/2000-HART/02-2016/23 KLAY INSTRUMENTS B.V.
INSTRUCTION MANUAL ("HART")
"INTELLIGENT"
PRESSURE- AND LEVEL TRANSMITTERS
SERIES 2000-SAN
SERIES 2000
SERIES CER-2000
SERIES 2000-HYDROBAR
WARNING
Read this manual before working with the product. For personal and system safety and for optimum product
performance, make sure you thoroughly understand the contents before installing, using, or maintaining the
Series 2000, Series 2000-SAN, Series CER-2000 and the Series 2000-Hydrobar.
Read the precautions and warnings on page 25.
SERIES 2000
SERIES 2000-SAN
SERIES CER-2000
Manufactured by:
www.klay-instruments.com
Nijverheidsweg 5
P.O. Box 13
Tel: [phone]
Fax: [phone]
7991 CZ DWINGELOO
7990 AA DWINGELOO
The Netherlands
E-mail: [e-mail]

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 2
CONTENTS
SECTION
PAGE
1
Introduction
4
1.1
Description Series 2000–SAN
4
1.2
Description Series 2000
4
1.3
Description Peramic ‘S” (Series CER-2000)
4
1.4
Description Series 2000-Hydrobar
4
1.5
Barometric reference
4
2
Dimensional drawings
5
2.1
Dimensional drawing 2000-SAN
5
2.2
Dimensional drawing 2000
5
2.3
Dimensional drawing CER-2000
5
2.4
Dimensional drawing 2000-Hydrobar
6
3
Installing transmitter
7
3.1
Installing weld-on nipple
7
3.2
Installing transmitter Series 2000-SAN
7
3.3
Installing transmitter Series 2000
7
3.4
Installing transmitter Series CER-2000
8
3.5
Mounting position
8
3.6
Mounting position effect
8
3.7
Installing transmitter Series 2000-Hydrobar
8
3.8
Calibration
8
3.9
Wiring
8
4
Remaining
9
4.1
Digital local indicator
9
4.2
CE / EMC - Rules
9
4.3
External load
9
4.4
Intrinsically Safe / Non Sparking (Ex version)
10
4.5
Functional safety - SIL
11
4.6
Traceability year of manufacturing
11
4.7
Software Revisions
11
5
Functions of push buttons
12
6
Programming points (P101-P114)
13
7
Reading on the display
13
8
Explanation programming points P101 to P114
14
P101
Zero adjustment (4 mA)
14
P102
Span adjustment (20 mA) without test
pressure
14
P103
Cancel mounting position effect
15
P104
Adjustment pressure unit on display
16
P105
Reverse output (20-4 mA)
17
P106
Adjustment damping (0 till 25 sec)
17
P107
Indication of process temperature
17
P108
Temperature in °C of °F
17
P109
Read out on display
17

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 3
P110
Simulation of current
18
P111
Linearization
19/20
P112
Specific density
21
P113
Write protection
21
P114
Response time from push buttons
21
P115
Service-menu
21
P116 Service -menu
21
9
Programming of the series 2000
22
9.1
Programming with the hand held terminal
22
9.2
Programming with DTM
22
9.3
Programming with PDA
22
10
Specifications
23
11
Precautions and warnings
24
Attachment: EU-Declaration of conformity

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 4
1 INTRODUCTION
The SERIES 2000 and SERIES 2000-SAN are solid-state pressure- and level transmitters
based upon a bridge resistive silicon sensor, with a very high burst pressure. The sensor
element is mounted in a stainless steel foot. A very strong stainless steel "flush" diaphragm
protects the sensor from the process medium. Special oil fills the chamber surrounding the
sensor and transfers pressure from the flush mounted diaphragm to the sensor.
Pressure on the sensor element creates a very small deflection of the silicon substrate and
bridge network. The resulting strain in the silicon resistors causes a change in the bridge
resistance that is proportional to the pressure applied. The transmitter electronics detects this
change in bridge resistance and converts it into 4-20 mA. The amplifier system is based on a
single Integrated Circuit, which ensures a perfect linearity in the 4-20 mA output.
Together with the Klay flush diaphragm technology the long term stability is perfect.
The Series CER-2000 are "All Stainless" pressure transmitters based on a ceramic pressure
cell, with very high burst pressure. These transmitters do not have oil filling.
The Series 2000, 2000-SAN, CER 2000 and Hydrobar I are available as SIL2, proven in use
(Option G200).
1.1 DESCRIPTION SERIES 2000-SAN
The SERIES 2000-SAN are specially designed with a flush mounted diaphragm so they fully
meet the needs of the food, pharma and chemical industries.
The Series 2000-SAN is available as 3-A version (Sanitary Standard - Option G153) and
EHEDG (Sanitary standard –Option G150). Standard the wetted parts are made of SS 316,
other materials are available, like Hastelloy C. Various process connections can be delivered,
such as Tri-Clamp (1,5”, 2” and 3”), SMS (1,5” and 2”), dairy milk couplings (DN 25, 40 and 50),
flanges (DIN and ANSI) and sanitary weld-on nipples (ø 48, 62 and 85 mm.)
1.2 DESCRIPTION SERIES 2000
The SERIES 2000 are specially designed for the pulp- and paper or similar industries, where
clogging is a problem. The very compact construction of the SERIES 2000 permits flush
installation with the tank- or pipe wall. Standard the wetted parts are made of SS 316, a lot of
other materials are available.
All transmitters are fully temperature compensated, which means that various process
temperatures have nearly no effect on the accuracy of the output signal. When a failure occurs,
the transmitter is repairable. However, for optimum accuracy the transmitter has to be send
back to the factory.
1.3 DESCRIPTION PERAMIC "S" (SERIES CER-2000)
The Series CER-2000 are pressure transmitters based on a ceramic pressure cell, which can
be used for all gauge- and absolute pressure measurement on steam, liquids and gases.
These transmitters do not have oil filling.
1.4 DESCRIPTION (SERIES 2000-HYDROBAR)
The SERIES 2000-Hydrobar is a complete range of submersible level transmitter for top
mounting. The 2000-Hydrobar can be used in fluids like waste water, mud, pulp and chemicals.
As standard the cable material is polyethylene. The connections for the wetted parts from the
2000-Hydrobar to the cable are from Viton® FKM.
1.5 BAROMETRIC REFERENCE
The SERIES 2000-SAN is in basic a so-called "relative transmitter" which means that
barometric changes will not affect the zero (4 mA). The venting (4) is placed in the cover of the
housing and is the barometric reference to atmospheric. The venting must be kept clean.

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 5
2 DIMENSIONAL DRAWINGS
2.1 DIMENSIONAL DRAWING 2000-SAN
PARTS DESCRIPTION
MATERIAL
1.
Cover
SS 304
2.
Pushbutton + Display
3.
Cover with venting
SS 304
4.
Venting
PA
5.
PG9 Cable Gland
6.
O-ring (2 pcs)
EPDM
7.
Electronics housing
SS 304
8.
Foot
SS 316
9.
Lock ring
SS 304
10.
Weld-on nipple
SS 316 L
11.
Packing
PTFE
12.
Diaphragm
SS 316 L
2.2 DIMENSIONAL DRAWING 2000
PARTS DESCRIPTION
MATERIAL
1.
Cover
SS 304
2.
Pushbutton + Display
3.
Cover with venting
SS 304
4.
Venting
PA
5.
PG9 Cable Gland
6.
O-ring (2 pcs)
EPDM
7.
Electronics housing
SS 304
8.
Foot with cooling fins
SS 304
9.
O-ring
Viton
10.
O-ring
Viton
11.
M8 bolt
SS 316
12.
Diaphragm and ring
SS 316
13.
Weld-on nipple
33 mm
SS 316 L
2.3 DIMENSIONAL DRAWING CER 2000
PARTS DESCRIPTION
MATERIAL
1.
Cover
SS 304
2.
Pushbuttons + Display
3.
Cover with venting
SS 304
4.
Venting
PA
5.
PG9 Cable Gland
6.
O-ring (2 pcs)
EPDM
7.
Electronics housing
SS 304
8.
Foot with cooling fins
SS 316
9.
Ceramic sensor
Al2O3 (96%)
10.
Process connection
½ " BSP (M) DIN
16288
SS 316
Note:
The ceramic sensor is sealed with an
O-ring (VITON).
Other O-ring materials can be applied
(on request).
108
108
108

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 6
2.4 DIMENSIONAL
DRAWING 2000-HYDROBAR
PARTS DESCRIPTION
MATERIAL
1.
Cover
SS 304
2.
Push buttons + Display
3.
Cover with venting
SS 304
4.
Venting
PA
5.
PG9 Cable Gland
6.
2x O-ring
EPDM
7.
Electronics housing
SS 304
8.
2x Connection to cable
SS 316
9
Cable with venting tube
PE
10
Foot
SS 316
11.
Diaphragm protection
cap
PE
12.
Diaphragm
SS 316L
13.
Mounting bracket (2
holes ø 6,5 mm
SS 304
Note:
The wetted parts of the 2000-hydrobar
are sealed with an O-ring (VITON).
Other O-ring materials can be applied
(on request).
2.5 DIMENSIONAL
DRAWING 2000-HYDROBAR
Junction Box –G59
PARTS DESCRIPTION
MATERIAL
8.
Connection to cable
SS 316
9.
Cable with venting tube
PE
10.
Foot
SS 316
11.
Diaphragm protection
cap
PE
12.
Diaphragm
SS 316L
13.
Junction Box
SS 316L
14.
Mounting bracket (2
holes ø 6,5 mm)
SS 304
Note:
The wetted parts of the 2000-hydrobar are
sealed with an O-ring (VITON).
Other O-ring materials can be applied (on
request).
108

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 7
3 INSTALLING TRANSMITTER
The diaphragm of the transmitter is protected with a special protection cap. Protect the
diaphragm until installation takes place. * DO NOT DAMAGE THE DIAPHRAGM. *
3.1 INSTALLING WELD-ON NIPPLE
A certified welder should perform installation of the weld-on nipple.
Weld with Argon, MIG or TIG. The smallest welding pin should be used.
1. Cut a hole in the process vessel/pipe to accept the weld-on nipple. The hole should
produce a tight fit when coupled with the weld-on nipple.
2. Prepare the hole by beveling the edge to accept filler material.
3. Remove the weld-on nipple from the transmitter.
4. Remove the PTFE packing of the SERIES 2000-SAN.
5. Remove the gasket and O-ring out of the weld-on nipple!
WARNING
Improper installation may result in distortion of the weld-on
nipple. Excessive heat will distort the weld-on nipple. Weld in
sections as shown in the figure left. Allow adequate cooling
between passes. To reduce the chances of distortion to the
weld-on nipple, use a mandrel.
(SERIES 2000-SAN Part.no. 1019)
(SERIES 2000 Part.no. 1016)
Determine (before welding) the position of the electronic
housing, so that the cable entry and the venting are in the right
position. After welding these positions are fixed.
6. Position the weld-on nipple in the vessel hole and tack six places.
The weld sequence is shown in the figure above.
7. Weld the weld-on nipple in place using 0,03 to 0,045 in. (0,762 to 1,143 mm) stainless
rod as filler material in the beveled area. Adjust amperage for penetration.
8. Remove the mandrel after the welding operation.
3.2 INSTALLING TRANSMITTER SERIES 2000-SAN
1. Make sure to correctly locate the packing within the weld-on nipple.
2. Improper installation of the packing can cause a process leak.
3. Position the transmitter into the weld-on nipple and begin engaging threads.
The transmitter can be rotated prior to seating enabling the user to optimize access to
calibration adjustments, cable entry, and local indicator.
4. Once the Lock ring (9) has been hand tightened, it must be tightened with an additional
turn with adjustable pliers (± 1/8").
3.3 INSTALLING TRANSMITTER SERIES 2000
1. After welding, clean up edges, and take care of the inside nipple wall.
2. Make sure the O-rings (10) and (11) are properly located.
Improper installation at the O-ring can cause a process leak.
3. Apply silicone grease to the O-ring(10), diaphragm ring and the hole inside wall of the
weld-on nipple, this prevents galvanic cell corrosion between transmitter and nipple
inside.
4. Install the transmitter and fix it with the SS M8 bolt

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 8
3.4 INSTALLING TRANSMITTER SERIES CER-2000
The position of the electronic housing is depending on the welding position of the weld-on
nipple. Before welding, locate the weld-on nipple so that the cable entry and the venting are in
the right direction. DO NOT DAMAGE THE THREAD.
3.5 MOUNTING POSITION
When the transmitter is mounted horizontally, the cable gland must be pointed downwards.
3.6 MOUNTING POSITION EFFECT (Series 2000 and Series 2000-SAN)
All transmitters are calibrated in vertical position.
If the transmitter is mounted in another position, there can be a little zero shift.
If the transmitter is mounted up, there is a zero shift (e.g. 4,02 mA instead of 4 mA). If the
transmitter is mounted down, there is a zero shift (e.g. 3.98 mA instead of 4 mA). After
installation of the transmitter the zero must be set to 4.00 mA with "P103" in the programming
mode. This will not affect the span.
3.7 INSTALLING TRANSMITTER SERIES 2000-Hydrobar
The diaphragms are protected by a special protection cap (PE). Do not remove this cap. When
clogging is a problem, please contact Klay Instruments B.V. for other solutions. DO NOT
DAMAGE THE DIAPHRAGM.
3.8 CALIBRATION
All transmitters are fully calibrated at the factory, to customer specified range. If calibration is
not specified, the transmitter will be calibrated at the maximum span.
3.9 WIRING
Under the cover (3) you will find the terminal board.
The push buttons "Zero", "Span" and "Prog" are under
the other cover (1). External loads must be placed in the
negative side of the 2-wire loop.
The figure left shows the wiring co nnection of the
transmitter. The 2-wires must be connected to 3 (-) and
4 (+) of the terminal board.
The transmitter must always be connected to earth.
The transmitter must be connected with standard two-
wire shielded cable. Do NOT run signal wiring in open
trays with power wiring, or near “heavy” electrical
equipment (E.g.: Frequency controller or heavy pumps).
Shielding must always be connected at the side of the
power supply. In case the process connection is already
connected to ground (e.g. via the tank or pipe line) Do
not connect the instrument to ground. Please ensure
that the instrument is not connected to ground
twice to prevent an 'earth loop'. In applications with
synthetic process connections, the enclosure (internal or
external) must be connected to ground.
Note: The Cer-2000 type with a synthetic process connection must be connected to earth.
Reversing the polarity will not damage the transmitter, but the transmitter will not function until the + and –are
properly connected.

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 9
4. REMAINING
4.1 DIGITAL LOCAL INDICATOR
All transmitters from the Series 2000 are standard equipped with a digital display.
In the standard circumstances the covers are "closed". The three push buttons and the display
are behind the cover (1).
As an option an "transparent" cover can be delivered to achieve the display can be used as a
local display in the process. The full-scale point may be set to any value between 0000 and
9999 (4 digit). (Option: "I" extra price).
4.2 CE / EMC - RULES
All Klay transmitters are manufactured in accordance with the RFI / EMC directives and comply
with the CE standard. All transmitters are fitted with RFI filters, which provide optimum, trouble-
free operation. Our products are in conformity with EMC-Directive 2014/30/EU based on test
results using harmonized standards.
4.3EXTERNAL LOAD The minimum power supply is based on the total
circuit resistance. The maximum permissible load (Ri
max.) in case of 24 Vdc is 600 Ω (Ohm).
By increasing the power supply, the external load
can be increased to 1200 Ohm / 36 Vdc.
(see figure left).
RI max. = Power Supply - 12 Vdc
20 mA
With a loop resistance of 250 Ωa power supply of at least 17 Vdc must be used.

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 10
4.4 INTRINSICALLY SAFE and NON SPARKING (Ex version)
The Series 2000, Series 2000-SAN, Series CER-2000 and Series 2000-Hydrobar-cable are
also available for intrinsically safe (Zone 0). The Series 2000, Series 2000-SAN, Series 2000-
Cable and Series 2000-SAN-Cable are also available for Non-Sparking (Zone 2).
ATEX –KEMA 03ATEX1092 X
IECEx –DEK 14.0079X
II 1G Ex ia IIC T4 Ga
Ex ia IIC T4 Ga
II 1D Ex ia IIIC T100°C Da (option G100, extra price)
Ex ia IIIC T100°C Da (option G100, extra price)
II 3G Ex nA IIC T4 Gc (option G180, extra price)
Ex nA IIC T4 Gc (option G180, extra price)
For detailed explanation see “EU-Declaration of conformity”on the last page of this manual.
For use in a non-sparking area, the transmitter can be installed without the use of a (intrinsic
safe) barrier. The transmitter can be connected with the following nominal value’s :
UN= 12…26.5 Vdc; IN= 4…20 mA; PN= 0,28 W.
For use in an intrinsically safe area, use a certified power supply from 12 - 26,5 Vdc.
Installation of this device has to be carried out by a certified mechanic / installer.
Transmitter type and options
Equipment category
Ambient temperature range
Pressure / Level Transmitter
Series 2000, Series 2000-SAN, Series 2000-Cable,
Series 2000-SAN-Cable, Series CER-2000,
Series 2000-Hydrobar-Cable and
Series 2000-Hydrobar-EXTD
With transparent indicator cover (Option I)
II 1G
-20 °C to +70 °C
Pressure / Level Transmitter
Series 2000, Series 2000-SAN, Series 2000-Cable
and Series 2000-SAN-Cable.
With closed covers, Option G180
ll 3G
-20 °C to +70 °C
Process temperature range:
-20 °C to +100 °C
Pressure / Level Transmitter
Series 2000, Series 2000-SAN, Series 2000-Cable,
Series 2000-SAN-Cable, Series CER-2000,
Series 2000-Hydrobar-Cable, Series 2000-Hydrobar-
EXTD and Temperature Transmitter Type TT-2000
With closed covers, Option G100
II 1G
and
II 1D
-20 °C to +70 °C
The maximum surface temperature of lP6x enclosure T100 °C is based on a maximum ambient
temperature of 70 °C and maximum process temperature of 100 °C. This temperature is
determined with a dust layer of maximum 5 mm.
Electrical Data
Pressure / Level Transmitter Series 2000, Series 2000-SAN, Series 2000-Cable,
Series 2000-SAN-Cable, Series CER-2000, Series 2000-Hydrobar-Cable,
Series 2000-Hydrobar-EXTD and Temperature Transmitter Type TT-2000:
Supply/output circuit (terminals 3 ‘-’ and 4 ‘+’): in type of protection intrinsic safety Ex ia IIC, or
Ex ia lllC only for connection to a certified intrinsically safe circuit, with the following maximum
values: Ui= 26,5 Vdc; Ii= 110 mA; Pi= 0,9 W (linear source); Li= 1,4 mH; Ci= 63 nF
(without cable between terminals 3 ‘-’ and 4 ‘+’).

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 11
Cable length
The maximum length of the cable for the Series 2000-Cable, 2000-SAN-Cable and 2000-
Hydrobar-Cable is 100 m. Electrostatic charging of the cable and the protection cap by the flow
of non-conductive media (e.g. in stirring vessels or pipes) shall be avoided.
Special conditions for Safe use in Zone 0
As category 1G equipment may be applied directly in the process, electrostatic discharge from
the cable and the protection cap of Pressure / Level Transmitter Series 2000-Hydrobar-Cable
by the flow of non-conductive media (e.g. in stirring vessels or pipes) should be avoided.
Special Instructions for Safe use in Zone 2
For use in non-sparking areas (Zone 2), the following should be taken into consideration:
As standard the transmitter is supplied without a certified cable gland. The cable entry
is fitted with a PE blanking plug for protection during transport. Remove the blanking
plug after installing the transmitter. When using a gland make sure it is certified and
complying with applicable protection level of the transmitter.
Always use the covers supplied by Klay Instruments B.V.
All transmitters from Klay Instrument are designed to last for at least 10 years under
normal process and environmental conditions. The gaskets and seals for the series
2000 are successfully tested according to IEC 60079-0 for temperature endurance (heat
and cold), resistance to impact and ingress protection by DEKRA Certification. In harsh
process and environmental conditions the lifetime of gaskets and seals may be reduced.
Klay Instruments strongly advises to inspect these yearly and replace them when
necessary.
For use in a potentially explosive atmosphere caused by air/dust mixtures the following should
be taken into consideration:
The dust layer may not exceed a thickness of 5 mm.
as standard a transmitter is supplied with a certified cable gland (PG). When using a
different gland make sure it is certified and complying with applicable protection level of
the transmitter.
Always use the covers supplied by Klay Instruments B.V.
All certifications are in compliance with IECEx scheme rules, and the International Standards:
IEC 60079-0:2011, IEC 60079-11:2011, IEC 60079-26:2007, IEC 60079-15:2010 and IEC
17050-1. The transmitters are certified for use in hazardous areas by DEKRA Certification.
DO NOT REMOVE THE SCREW COVER(S) WHEN AN EXPLOSIVE
ATMOSPHERE MAY BE PRESENT.
4.5 FUNCTIONAL SAFETY - SIL
The device is certified as “Proven in use” for a functional safety environment of SIL2 according
to IEC-61511 and SIL1 according to IEC-61508.
Note : Option SIL (Proven in use) is valid on transmitters with a serial number > 4309036, and only
applicable with software version V9.17.
When ordered as a SIL (Proven in use) transmitter, the safety manual will be supplied. (Option
G200). Detailed information can be found in the Safety manual of the instrument. The most
recent version of the Safety manual is available on: www.klay-instruments.com under section
“Downloads”.

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 12
4.6 TRACEBILITY YEAR OF MANUFACTURING
The year of manufacturing of the transmitter can be traced as follows: take the first two
numbers from the serial number that is engraved in the transmitter and add 1970 to it.
For example: if the serial number is 4309036. The year of manufacturing is 1970 + 43 = 2013.
4.7 SOFTWARE REVISIONS
Due to the improvements on the Series 2000, there are several software versions (revisions).
For this reason it is possible the transmitter you are working with does not support some
options, which are discussed in this manual. This instruction is applicable from software revision
V9.17. After powering up, the transmitter will show the revision number on the display.

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 13
5 FUNCTIONS OF PUSH BUTTONS
The Series 2000 can be programmed easily by use of the
3 front panel pushbuttons (See picture right).
The display can show engineering units of:
mH2O, inH2O, bar and PSI.
The functions of the three pushbuttons will be explained
below.
This button has 2 functions:
1. It can be directly used for adjusting the zero (zero / 4mA), with or without a
test pressure. When the zero (4 mA) must be adjusted at 0 (atmospheric
pressure), the button must be held until the word "ZERO" appears on the
display. The transmitter is now set to 4 mA.
2. Also, this button must be used for stepping down in the programming menu
or to decrease a value (-).
Note: For canceling the mounting position effect you have to use P103.
This button has 2 functions:
1. It can be directly used for adjusting the span (20 mA), when using a test
pressure (air). When a test pressure (e.g. 2 bar) is supplied to the transmitter,
the button must be held until the word "SPAN" appears on the display. The
transmitter is adjusted at 20 mA now. The span can also be adjusted without
test pressure (see P102).
2. Also, this button must be used for stepping up in the programming or to
increase a value (+).
This button has 2 functions:
1. It is used to adjust the 14 Programming Points (P101 to P114). Push it once
and P100 is displayed, use the [] (SPAN) to step to P101 etc.
2. This button must also be used for confirming the adjustments (enter).
For example if you want to change the adjustment in bars (P104), the following
steps must be taken:
1. Push on [PROG] till "100" appears on the display.
2. Push on [SPAN] 4 times to go to point "P104" (adjustment pressure unit).
3. Push [PROG] to confirm this.
4. Push several times on [] (SPAN) to reach 3 (= bar). See also the
conversion table (page 11).
1 = mWC, 3 = bar, 5 = PSI, 11 = inch WC
5. Confirm this by pushing once at [PROG].
The transmitter is now adjusted to read in "bar".

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 14
6. PROGRAMMING POINTS (P101 –P114)
The following points can be adjusted by
means of the three push buttons.
For an explanation of these points see page
11 to 18 of this manual.
To change one of these points you have to
push on [PROG] until "100" appears on the
display.
To go to from a lower program (P101) to a
higher one (P102), push on button []
(SPAN).
To confirm the adjustments you always have
to press on [PROG].
*) Standard adjustments ex works.
Programming points:
P101
Zero adjustment (4 mA)
P102
Span adjustment (20 mA)
P103
Cancel mounting position effect
P104
Adjustment pressure unit
(See Conversion table)
P105
4-20 mA *)
20-4 mA (Reverse output)
P106
Adjustment damping (0 to 25 sec)
P107
Indication of process temp. (Read out on
display)
P108
0 = °C (*)
1 = °F
P109
Read out on display:
Curr (0) = current (4 - 20 mA) (*)
Unit (1) = pressure unit (conversion table)
PerC (2) = percentages
TenP (3) = temperature
Hect (4) = hectoliters
CB n (5) = Cubic meters
Ltr (6) = Liters
P110
Simulation of current
P111
Linearization
0 = no Linearization (*)
1 = cylindrical tank
2 = vertical tank with cone
3 = vertical tank with spherical cone
P112
Specific density
P113
Write Protection
P114
Response time from push buttons
7. READING ON THE DISPLAY
On the standard built-in display several values can
be shown.
During the programming of the transmitter the
display shows all the information that is needed.
When the transmitter is in the process the display
gives all the information of the process pressure or
temperature.
On the display the following units can be showed:
mH2O, inH2O, bar and PSI (see also P104 and
P109).
N.B.: The standard transmitter is supplied with two "closed" covers shielding the buttons and the display. As an
option an "open" cover (IP 66) can be fitted. The display can then be used as a local process display.
(Option: "I" extra price). The full scale can be set between -9999 and 9999 (4 digit).

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 15
8. EXPLANATION PROGRAMMING POINTS P101 to P114
P101
ZERO ADJUSTMENT (4 mA)
The transmitter as standard is adjusted to 4.00 mA at atmospheric pressure.
It is also possible to adjust a zero-suppression or elevation.
For example: zero elevation of 1 mWK.
1. Push at [PROG] until "100" is shown on the display.
2. Push once at [] / SPAN till "101".
3. Confirm this by pushing [PROG].
4. Now the display will show 0.00 mH2O. Push at [] till 1.00 mH2O is on the
display.
5. Confirm with [PROG].
6. The output of the transmitter will be lower than 4 mA. The output at
atmospheric pressure will be for example 3.68 mA.
When a pressure of 1 mWC is applied on the diaphragm the output will be
4.00 mA.
The elevation can be canceled by pushing at [ZERO] till zero disappears out of the
display. The transmitter is now adjusted at 4 mA at atmospheric pressure.
P102
SPAN ADJUSTMENT (20 mA) WITHOUT TEST PRESSURE
Before adjusting the span take care the right pressure unit is selected.
(See also P104 and P109).
Example: Adjustment of the span at 0 - 2 bar.
First off all, the pressure unit must be adjusted at "bar". (See P104).
1. Push [PROG] till "100" is shown on the display.
2. Push twice at [] / SPAN until "102" is on the display.
3. Confirm this by pushing [PROG].
4. Push [SPAN] (+) or [ZERO] (-) to select the measuring range that is required.
5. Confirm by pushing [PROG].
The transmitter is adjusted now.
N.B.: P102 is the adjustment of the total span.
When a "compound" range must be adjusted (for example -1 till +3 bar), a
span of 4 bar must be programmed. At P101 (ZERO,4 mA), -1 bar must be
adjusted. Now the transmitter is adjusted at: - 1 bar = 4 mA and +3 bar = 20
mA.
If the process temperature at -1 bar is above 20 °C another filling oil must
be applied inside the transmitter (Option G26).
If the process temperature at -0,5 bar is above 60 °C another filling oil
must be applied inside the transmitter (Option G26).
N.B.: It is not possible to show values larger than '9999' or smaller than '–9999' on
the display. In this case the display will show: - - - - For values larger than '9999' and
smaller than '–9999'. As long as the display shows "- - - - ", the value will not be
saved by pressing "PROG"

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 16
P103
CANCEL MOUNTING POSITION EFFECT
All transmitters are calibrated vertically. When a transmitter of the Series 2000 or
2000-SAN is installed horizontally, there will be a small "mounting effect" on the
zero
(4 mA). For example the transmitter shows 4.03 mA instead of 4.00 mA.
This can be easily canceled with P103. In P103 there are three options:
1. ESC:
Nothing can be changed.
Leave without doing anything. (confirm with PROG).
2. RESET:
Use this option when you are not sure if P103/SET has been done in a
proper way. (confirm with PROG).
when using this option the original factory setting will be valid.
3. SET:
Canceling mounting position effect. (confirm with PROG).
When "SET" is selected the transmitter is automatically adjusted at 4.00 mA.
The span will not be affected.
CAUTION: Do not apply pressure while executing "cancel mounting position effect"
N.B.: From revision 2 the description above is valid. Transmitters working with
software revision 1 will direct process cancel mounting position.

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 17
P104
ADJUSTMENT PRESSURE UNIT ON DISPLAY (See Conversion table)
Several engineering units can be shown on the display by using a conversion factor.
(See conversion table below). As standard the pressure unit of the transmitter is set
to bar. Four engineering units can be used for displaying the applied pressure on the
display (mH2O, inH2O, bar and PSI).
This will be explained with an example (e.g. bar):
1. Push at [PROG] till "100" is shown on the display.
2. Push 4 times at [], go to [P104].
3. Push at [PROG] to confirm this.
4. Push at [] and adjust at 3 (= bar).
1 = mH2O (=mWC), 3 = bar, 5 = PSI, 11 = inch WC.
5. Confirm with [PROG].
The transmitter will now read out in bars.
CONVERSION TABLE:
104
CONVERSION FACTOR
DISPLAY
1
1.000
mH2O (mWC)
*
2
1000
mmH2O (mm WC)
3
0.09806
bar
*
4
98.0665
mbar
5
1.4223
PSI
*
6
0.0967
Atm
7
9.80665
KPa
8
0.009807
MPa
9
0.1
Kgf/cm2
10
73.556
mm HG
11
39.37
inH20 ("WC)
*
12
2.895906
"HG
N.B.: To show one of the engineering units, P109 must be adjusted at 1
(= pressure unit).
*) Pressure units that can be shown on the display. When the value of the
highest range is larger than 9999, "NA" will appear in the display (Not
Applicable). Another unit must be chosen.

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 18
P105
REVERSE OUTPUT (20 - 4 mA)
The transmitter as standard is adjusted to 4-20 mA.
Push on [PROG] and go to P105.
Push once at [] to change the output to 20-4 mA (Reverse output).
Push at [PROG] to confirm this.
Now the transmitter will give 20 mA at atmospheric pressure.
P106
ADJUSTMENT DAMPING (0 till 25 sec)
In P106 an electronic damping can be adjusted between 0 and 25 seconds.
This can be done with the push buttons [] (up) and [] (down).
Always confirm by pushing once at [PROG].
P107
INDICATION OF SENSOR TEMPERATURE (READ OUT ON DISPLAY)
1. Push [PROG] until "100" is shown on the display.
2. Push 7 times at [], go to [P107].
3. Push [PROG] to confirm this. Now the process temperature appears on the
display (Accuracy depending on sensor position).
This will remain on the display. To get the actual pressure back on the display you
have to push again on P107 until the actual pressure appears on the display again.
P108
TEMPERATURE IN °C OR °F
The temperature of the transmitter is standard adjusted at C ("CELC"). When
pushing at [] in P108, this will change into F ("FAHR").
Always confirm by pushing once at [PROG].
P109
READ OUT ON DISPLAY
Curr (0) = current (4 - 20 mA)
Unit (1) = pressure unit (See conversion table)
PErC (2) = percentages (0 - 100%)
TEnP (3) = temperature (C of F)
HECt (4) = hectoliter (only in combination with P111)
Cb n (5) = Cubic meter (only in combination with P111)
Ltr (6) = Liters (only in combination with P111)
FREE (7) = Free adjustable scale (only in combination with P111)
As standard the transmitter is delivered with read out in mA (0).To change this,
follow the next steps:
1. Push [PROG] until "100" is shown on the display.
2. Push 9 times at [] / SPAN till "109" appears on the display.
3. Confirm with [PROG].
4. Push once at [].
5. Push [PROG] to confirm this.
The transmitter will now read mH2O (mWC).
The pressure unit can be changed with the conversion table in "P104".
1 = mH2O (=mWK), 3 = bar, 5 = PSI, 11 = inch WK.
Also the read out can be 0 - 100%. In this case select "P109", option 2.
Indication of process temperature, accuracy depending on sensor position.

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 19
P110
SIMULATION OF CURRENT (4-20 mA)
The transmitter can be used as a simulator of a current between 4 - 20 mA.
This can be done in P110 with the push buttons [] and [].
The user can perform a current simulation (Curr) or a pressure simulation (Unit).
Current-simulation (Curr)
To perform a current-simulation follow the next steps:
1. Push [PROG] until "100" is shown on the display.
2. Push 10 times at [] / SPAN till "110" appears on the display.
3. Confirm with [PROG].
4. The display will readout 'Curr'
5. Confirm with [PROG].
6. The display shows '4.00'. Push [PROG] and the output changes to 4.00
mA.
7. By pushing [] / SPAN or [] / ZERO, you can change the value on te
display. The output value will change as soon as the [] / SPAN OR [] /
ZERO button is released.
8. Pressing the [PROG]-button again will exit the simulation.
Pressure-simulation (Unit)
To perform a pressure-simulation follow the next steps:
1. Push [PROG] until "100" is shown on the display.
2. Push 10 times at [] / SPAN till "110" appears on the display.
3. Confirm with [PROG].
4. The display will readout 'Curr'
5. Press [] / SPAN once
6. The display will readout 'Unit'.
7. Confirm with [PROG].
8. The display shows a pressure value. Push [PROG] and the output
changes to a mA-output corresponding with the range entered in menu
P101 and P102.
9. By pushing [] / SPAN or [] / ZERO, you can change the value on the
display. The output value will change as soon as the [] / SPAN OR [] /
ZERO button is released.
10. Pressing the [PROG]-button again will exit the simulation.
Note: The values that can be entered using the pressure-simulation are
related to the adjustments in menu P101 and P102. These values
are also the minimum and maximum values.
For HART-transmitters: this menu will not work when the device is
operating in multi-drop mode.
P111
LINEARIZATION
0 = no Linearization
1 = cylindrical tank (horizontal)
2 = tank with bottom cone
3 = tank with spherical bottom
4 = Free adjustable scale (Linear) (Option G79)

Instruction Manual Series 2000 HART Klay Instruments B.V.
H/EN/2000-HART/08-2016/24
Page 20
As standard the transmitter is delivered without Linearization (= 0). However, for a
horizontal tank or a tank with a bottom cone, a Linearization can be applied to
achieve the current signal (mA) is equal to the level in the tank. All values must be
programmed in meters.
Linearization horizontal tank (Cylindrical)
Cylindrical horizontal tank Cylindrical tank with cone-shaped ends
1. Push [PROG] until "100" is shown on the display.
2. Push 11 x at [] / SPAN till "111" appears. (Confirm with [PROG])
3. Push [] once. (Confirm with [PROG])
4. Enter the height (H1) of the tank in meters. (Confirm with [PROG])
5. Enter the same height (H2) of the tank in meters. (Confirm with [PROG])
6. Enter the length (L) of the tank. For a "ball" or cone shaped tank, take the
cylindrical length plus the length of 1 "ball" cone. (Confirm with [PROG])
7. Enter H3 in meters if the transmitter is installed like in the left picture. Enter
0m when the transmitter is installed like in the right picture.
8. Enter the percentage of the actual "full" level (for example 80%).
(Confirm with [PROG]).
Linearization horizontal tank (Elliptic)
Cylindrical horizontal tank Cylindrical tank with cone-shaped ends
1. Push [PROG] until "100" is shown on the display.
2. Push 11 x at [] / SPAN till "111" appears. (Confirm with [PROG])
3. Push [] once. (Confirm with [PROG])
4. Enter the height (H1) of the tank in meters. (Confirm with [PROG])
5. Enter the height (H2) of the tank in meters. (Confirm with [PROG])
6. Enter the length (L) of the tank. For a "ball" or cone shaped tank, take the
cylindrical length plus the length of 1 "ball" cone. (Confirm with [PROG])
7. Enter H3 in meters if the transmitter is installed like in the left picture. Enter
0m when the transmitter is installed like in the right picture.
8. Enter the percentage of the actual "full" level (for example 80%).
(Confirm with [PROG]).
Note: If the height (H) of the tank is 1 meter and the maximum level in the tank is 0,8 meter
the percentage (point 8) must be set at 80%.The calibration at P102 must be adjusted at: 1
meter (if s.g. equals 1).
