Avita MAGUS NS12T5 Guide

e-manual
The PC now in your hands has successfully completed the “AVITA CHECK”.
For more information on the products and services, please visit
www.avita.com
NS12T5
MAGUS
(12.2” )

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
1
Safety Precautions
Warning
Do not attempt to disassemble the cabinet. This device does not
contain customer serviceable components. Refer servicing to
qualified personnel.
Cautions
• The apparatus and AC adapter shall not be exposed to dripping
or splashing and no objects filled with liquids, such as vases, shall
be placed on the apparatus.
• Do not use the Notebook PC in the environment at too high or
too low temperature, never expose the Notebook PC under strong
sunshine or too wet environment. The suitable temperature for
the Notebook PC and accessories is 00C~ 400C.
• Always leave sufficient space around the device for ventilation.
Do not use or place the device on soft surface such as a bed or
cushion which could make the device build up heat.
• When charging, please place the Notebook PC in an environment
that has a normal room temperature and good ventilation. It is
recommended to charge the Notebook PC in an environment with
a temperature that ranges from 50C~ 250C. Please ensure to use
only the adapter offered by the manufacturer. Using unauthorized
adapter may cause danger and violate the authorization of
the Notebook PC and the guarantee article. The maximum
operating ambient temperature of the equipment declared by
the manufacturer is 400C.

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
2
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.
Important
• The AC adapter shall be installed near the equipment and shall
be easily accessible.
• Unplug from the wall outlet during a storm.
• No naked flame sources such as lighted candles should be
placed on the device.
• Do not pinch, bend, or put heavy or sharp objects on its electrical
cord.
• Do not use the device while driving a car or doing any other
activities in which loss of concentration could lead to potential
harm to self or others.
• Excessive sound pressure from earphones and headphones can
cause hearing loss.
Battery safety
This device contains a built-in battery, improper use of which may
result in explosion. Do not heat, open, puncture, mutilate, or dispose
of the product in fire. Do not leave the device in direct sunlight for
an extended period of time, which could cause melting or battery
damage.The battery in this device is not user replaceable and should
only be replaced by AVITA or a AVITA authorized Service Provider.

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
3
CAUTION
Excessive use of the device can cause your vision loss.
1. Do rest your eyes for 10 minutes if use the device for 30 minutes.
2. Do not watch the display for children under 2 years of age. Do
not watch the display over 1 hour everyday for children above
2 years of age.
R3B886
ROHS

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
4
Contents
Safety Precautions .....................................................................1
Getting Started ....................................................................... 5
Getting to know your new MAGUS ..................................... 5
Charging your MAGUS ..................................................... 9
Turning your MAGUS on ......................................................11
Turning your MAGUS off ......................................................12
Put your MAGUS to Sleep .........................................................13
Power management ..............................................................14
Gestures for the Touchscreen and Trackpad .......................... 15
Basics .................................................................................. 20
Start menu ..................................................................................... 20
Action center ......................................................................... 21
Tablet mode ................................................................................ 26
Connections and Setup .......................................................... 29
Inserting a microSD card ................................................................... 29
External display ..................................................................................... 30
Connecting to a Wi-Fi network ....................................................... 32
Airplane mode ...................................................................................... 34
Bluetooth ...................................................................................... 35
Brightness ...................................................................................... 36
Volume ..................................................................................................... 37
Troubleshooting ...................................................................... 38
Specifications ........................................................................... 40
Legal and Safety Notices ......................................................... 41

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
5
Getting to know MAGUS
Top view
Getting Started
8
9
10
11
12

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
6
Microphone
For voice input.
MicroSD card slot
Accepts microSD card (up to 256GB).
Charging indicator
Shows the battery's charge status.
- Blue: Charging
- O:Fully charged
- Blue (blinking): Low battery.
Mini HDMI port
Connects to a TV or a display device.
DC IN jack
Connects with 12V DC charger.
Headphones jack
Headphones connection for personal listening.
Power / Standby button
Press to enter standby/wake up mode;
Press and hold to switch the unit on or off.
USB port
Connects to a USB storage device or a mouse, keyboard or a
camera.
Front camera
9
8

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
7
Start button
Clicks to open/close the Windows Start menu.
Trackpad
Moves the cursor and selects options. Functions as a mouse.
Connector
Connects the PC to the keyboard.
10
11
12

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
8
NOTE
The keyboard connects to the PC via the Connector. When the
connection is successful, it will automatically adjust its settings to
use the keyboard.
Docking / Undocking

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
9
Charging your MAGUS
IMPORTANT! Please Read.
We recommend fully charging your PC before using it for
the rst time. For optimum performance, please connect
the provided AC adapter to your PC when it falls below
20% charge.
Full battery.
Low battery and need to charge.
Your PC is running on battery power
and the battery is discharging.
Battery is charging.
Battery is fully charged and AC
adapter is connected.
Battery icon Description
Battery icon
The battery icon displays in the taskbar.

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
10
Use ONLY the included AC Adapter to charge the battery.
The charging time will vary depending on remaining battery
level. The charging from 0% to 70% will take approximately 3
hours. You may not be able to turn on your PC within a few
minutes if the battery was fully drained.
In order to keep the battery working in best condition,
please pay attention to the following:
• The included AC adapter is for use with this unit only. Do not
use it with other equipment.
• Please do not charge the battery in high temperatures.
• Do not wait for the battery to be fully depleted before
charging again. Keep the battery charged as needed.
• If your PC has not been used for a long period of time, the
battery might be in over discharge protection mode and
may take longer to charge.
To Wall Socket
AC Adapter
(included)

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
11
1. Press and hold the Power button on your PC until the
logo appears.
2. Select the language, then tap .
3. Follow the onscreen instructions to congure your PC.
Turning on your PC in standby mode
1. Press the Power button to turn on the PC screen.
2. Swipe up the lock screen from the bottom edge of the
display.
About Windows Activation
Windows will be active automatically once you connect your PC
to a WiFi network.
Turning MAGUS on
Starting for the rst time
When using the PC for the first time, you will be required to
setup the following:

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
12
1. Tap the icon in the lower-left corner of the screen or click
Start key on the keyboard to go to the Start menu.
2. Tap Power icon in the lower-left corner of the screen
, it
will display 3 options (Sleep, Shut down and Restart).
3. Select Shut down to power the PC o.
Turning MAGUS o
NOTE
• Save all data before turning your PC o.
•
If your PC is unresponsive, press and hold the Power
button until the"Slide to shut down your PC" message
appears, then slide it to the bottom edge of the display and
the PC will be powered o.
• Press & hold the Power button for 10 seconds to force SHUT
DOWN the unit.

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
13
Put MAGUS to sleep
You can put your PC to Sleep mode by doing either of the
following:
• Go to the Windows start menu or the Tablet mode and tap
Power in lower-left screen
, select Sleep and tap it.
• Briefly press the Power button to put the PC in sleep mode.
If you don’t operate for some time, the PC will enter sleep
mode automatically.
TIP: You can go to Settings -> System -> Power & sleep to set
the screen and sleep timeout.

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
14
When the apparatus is not connected power adapter and
not providing the main function or when other energy-using
products are not dependent on its function, the default system
settings and its characteristics enable the apparatus to activate
display sleep mode within 5 minutes of user inactivity, and to
activate a distinct sleep mode within 10 minutes of user inactivity.
In the same scenario, when the apparatus is connected to power
adapter, will activate display sleep mode within 15 minutes of
user inactivity, and activate a distinct sleep mode within 25
minutes of user inactivity. When in sleep mode, the system
becomes fully usable within 5 seconds via network connections
or user interface devices. The power management function is
automatically switched on by the default system settings.
Go to Settings -> System -> Power & sleep to manage how
your PC use power.
Power management

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
15
Finger slide
Slide your finger to scroll up
or down; pan the screen left or
right.
Left edge swipe
Swipe from the left edge of the
screen to shuffle your running
apps.
Here are some basic procedures for interacting with the
touchscreen.
Right edge swipe
Swipe from the right edge of
the screen to launch the Action
Center screen.
Using the Touchscreen
Gestures for the Touchscreen and Trackpad

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
16
Zoom
By placing two fingers on the
screen, you can slide them apart
to "Zoom In", or pinch them
together to "Zoom Out".
Tap/Double tap
To select an item on the
touchscreen, lightly tap it.
On the File Explorer desktop,
double tap an application to
launch it.
Touch & Hold
To move an app, touch and hold
the app tile and drag it to a new
position;
Touch and hold an app to
customize it.

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
17
Use the Trackpad to move the cursor or select an item. The left
and right buttons of the Trackpad act the same as the left and
right buttons of a mouse.
Slide your nger on the Trackpad to move the cursor.
Moving
Using the Trackpad
• In the Start menu, click an app to launch it.
• On the File Explorer desktop, double click an application to
launch it.
Tap the Trackpad or press the left Trackpad button.
Left-click
or
Tap Press

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
18
Press and hold the left button. Select an item using your other
nger then drag and drop it to a new position.
Slide two ngers to scroll up or down.
Dragging and dropping
Two-nger scroll (up/down)
Right-click
To right-click an item, press the right Trackpad button.
• In the Start menu, select an app and press the right Trackpad
button to launch the Setting bar.
• On the File Explorer desktop, select one folder or le and press
the right Trackpad button to open the right-click menu.
Press

MAGUS_NS12T5 (WT9TP2)_e-manual - V.00
19
Slide two ngers to scroll left or right.
Two-nger scroll (left/right)
Pinch two ngers while viewing a website, map, or image.
Zoom out
Zoom in
Spread two fingers apart while viewing a website, map, or
image.
NOTE
• Please keep your fingers dry and clean when using the
Trackpad.
