Avocent LongView IP User manual

Convenient, remote access to your computers via the LAN
The LongView IP digital extension solution provides remote access to your computer over a
local area network (LAN). With LongView IP digital extension, you have remote access to
all of your computer’s peripherals from anywhere on the corporate TCP/IP LAN or point-
to-point over a single UTP cable. LongView IP digital extension lets you easily move your
desktop devices, including your keyboard, video and mouse, speakers and microphone
away from your computer. Convenient IP connectivity gives you access to high quality
DVI video and audio from anywhere in your building. The LongView IP digital extender
technology also improves data security, and environmental and limited workspace problems.
Deploying a LongView solution could not be easier. Simply connect the LongView
transmitter to the computer, and the receiver at the user location (desk) and connect both
units to a LAN.
Key Features and Benefits
Full Hardware Solution.All
connections to the user desktop
peripherals are provided without the
need for software, OS, disk or fan
DVI Video.Connects to single
or dual DVI monitors on the user
desktop
CD Audio.Connects to the analog
speakers on the user desktop
Quad USB Ports.Provides
connection for up to four USB
devices including keyboard, mouse,
and mass storage devices
Dual PS/2.Provides connection for
legacy PS/2 keyboard and mouse
Ethernet Port.Allows the computer
and user to be located anywhere
on the 100 or 1000Mbps network
with full routing of data across
routers, switches and subnets
Encryption of Network Data.128bit
AES encryption of all data passing
between the computer and the
network
Upgradeable.Based on an
embedded Linux OS, the device is
fully upgradeable to allow for future
feature enhancements
Flexible Mounting.Small form factor
can be used on a desk, mounted
directly to the back of a monitor or
inside the display device.
Gigabit
Ethernet Switch
LongView IP
Receiver
LongView IP
Transmitter
LongView IP
Transmitter
Lo
Tr
LongView IP
Transmitter
LongView IP
Receiver
LongView IP
Receiver
Workstation
Workstation
Workstation
LongView IP
Receiver
Workstation
Speakers
UTP
LongView IP
Transmitter
LongView IP
Receiver
Speakers Workstation
UTP
LongView IP
Transmitter
Desktop extension over UTP
Dual monitor extension over UTP
Workstation extension over a LAN
LongView®IP Desktop Extension over IP Solutions

Transmitter Receiver
Connections
PS/2 No 2 (Keyboard & Mouse)
USB 2 x USB 4 x USB
VGA 1280x1024 @ 60Hz 1280x1024 @ 60Hz
DVI 1280x1024 @ 60Hz 1280x1024 @ 60Hz
3.5mm Stereo Speaker
Jack
Yes, Stereo speakers 24 bit 44kHz Yes, Stereo speakers 24 bit 44kHz
Mono microphone jack Yes Yes
Network Port 1 - RJ45 1 - RJ45
Network Speed 100Mbps or 1Gbps 100Mbps or 1Gbps
Encryption SSL/AES 128 bit SSL/AES 128 bit
USB Support USB keyboard & mouse, and mass storage devices USB keyboard & mouse, and mass storage devices
Mechanical
Format self-enclosed module Desktop mounting metal case with external power supply
Height 0.83 in. (21 mm) 1.04 in. (26.5 mm)
Depth 6.02 in. (153 mm) 5.12 in. (130 mm)
Width 2.68 in. (68 mm) 8.27 in. (210 mm)
Weight .66 lbs. (0.3 Kg) 1.54 lbs. (0.7 Kg)
Environmental / Power
Operating Temperature 32° F to 95° F (0° C to 35° C) 32° F to 95° F (0° C to 35° C)
Storage Temperature -4° F to 140° F (-20° C to 60° C) -4° F to 140° F (-20° C to 60° C)
Humidity 10% to 90% (non-condensing) 10% to 90% (non-condensing)
Power In 5VDC / 1.1A 100-250VAC / 50-60 Hz, 1A
Power Consumption 6W 20W
Standards
Approved Agency cUL, UL, CE, FCC15 Class A
LongView IP Specifications

Transmitter Receiver
Connections
PS/2 No 2 (Keyboard & Mouse)
USB 1 x USB 4 x USB
VGA No 2 x 1600x1200 @ 60Hz (with Adaptor)
DVI 2 x DVI-D (supports digital video only) 2 x DVI-I (supports digital and/or analog video)
1900 x 1200 @ 60Hz
3.5mm Stereo Speaker
Jack
Yes, Stereo speakers 24 bit 44kHz Yes, Stereo speakers 24 bit 44kHz
Mono microphone jack No No
Network Port 1 - RJ45 1 - RJ45
Network Speed 100Mbps or 1Gbps 100Mbps or 1Gbps
Encryption SSL/AES 128 bit SSL/AES 128 bit
USB Support USB keyboard & mouse, and mass storage devices USB keyboard & mouse, and mass storage devices
Mechanical
Format External metal case module Desktop mounting metal case with external power supply
Height 1.10 in (28 mm) 1.10 in (28 mm)
Depth 7.87 in (200 mm) 6.06 in (154 cm)
Width 5 in (127 mm) 8.19 in (208 mm)
Weight 1.65 lbs (.75 Kg) 2.09 lbs (.95Kg)
Environmental / Power
Operating Temperature 32° F to 95° F (0° C to 35° C) 32° F to 95° F (0° C to 35° C)
Storage Temperature -4° F to 140° F (-20° C to 60° C) -4° F to 140° F (-20° C to 60° C)
Humidity 10% to 90% (non-condensing) 10% to 90% (non-condensing)
Power In 5VDC 100 – 250VA[email protected]
Power Consumption 6W 1W
Standards
Approved Agency cUL, UL, CE, FCC15 Class A
LongView IP DH Specifications

Avocent, the Avocent logo, and LongView are registered trademarks of Avocent
Corporation or its affiliates in the U.S. and other countries. All other marks are the
property of their respective owners. Copyright © 2008. Avocent Corporation.
0508-LVIP-DS-EN
www.avocent.com/contacts
Transmitter Receiver
Connections
PS/2 2 (Keyboard & Mouse)
USB 2 x USB 2 x USB
VGA 1280x1024 @ 60Hz 1280x1024 @ 60Hz
DVI No No
3.5mm Stereo Speaker
Jack
Yes, Stereo speakers 24 bit 44kHz Yes, Stereo speakers 24 bit 44kHz
Mono microphone jack Yes Yes
Network Port 1 - RJ45 1 - RJ45
Network Speed 100Mbps or 1Gbps 100Mbps or 1Gbps
Encryption SSL/AES 128 bit SSL/AES 128 bit
USB Support USB keyboard & mouse PS/2 / USB keyboard & mouse
Mechanical
Format Self-enclosed module Desktop mounting metal case with external power supply
Height 0.83 in. (21 mm) 1.04 in. (26.5 mm)
Depth 6.02 in. (153 mm) 5.12 in. (130 mm)
Width 2.68 in. (68 mm) 8.27 in. (210 mm)
Weight .66 lbs. (0.3 Kg) 1.54 lbs. (0.7 Kg)
Environmental / Power
Operating Temperature 32° F to 95° F (0° C to 35° C) 32° F to 95° F (0° C to 35° C)
Storage Temperature -4° F to 140° F (-20° C to 60° C) -4° F to 140° F (-20° C to 60° C)
Humidity 10% to 90% (non-condensing) 10% to 90% (non-condensing)
Power In 5VDC / 1.1A 100-250VAC / 50-60 Hz
Power Consumption 6W 20W
Standards
Approved Agency cUL, UL, CE, FCC15 Class A cUL, UL, CE, FCC15 Class A
LongView IP VG Specifications
