Avocent AMX Switch Series User manual

AMX: Smarter, Simpler Multi-User
KVM Switching
AMX5000 • AMIQ • AMX5100 • AMWorks

Foryears Avocent has built KVMswitching solutions
that help many of the world's most successful
companies reduce the complexities of growing IT
infrastructures. Avocent’s field proven KVM
switching and connectivity solutions provide
smarter access and simpler manageability for
“real world” IT environments. Our advanced KVM
switching technologies continue to provide the
solutions and the reliability you’ve come to expect
from the industry leader.
KVM Brief
KVM stands forKeyboard,Video and Mouse.
A KVM solution allows multiple sets of keyboards,
monitors andmice to be replaced with a single setof
control peripherals. KVM technology provides easy
access and control to any connected device.
O U R H I S TO R YO F
innovations

MECHANICAL Height Width Depth Weight
AMX5000 Matrix Switch: 1.7”(4.3cm) 17.2”(43.2cm) 11.1”(28.1cm) 9.3 lbs (3.7kg)
AMIQ-PS2 Cable Interface: 0.8”(2.0cm) 2.4”(6.1cm) 14.1”(36.0cm) 0.8 lbs (0.3kg)
AMX5100 UserStation: 1.74”(4.4cm) 10.9”(27.9cm) 11.5”(29.2cm) 5 lbs (2.0kg)
ENVIRONMENTAL/ POWER / HARDWARE
Operating Temperature 32º (0ºC)to 122º (50ºC)
Storage Temperature -4º (-20ºC)to 122º (50ºC)
PowerRequirements 100 - 240 VAC, 50 - 60 Hz
Supported Hardware - Computer AMIQ-PS2 Cable Interface: IBM PC/AT, PS/2and 100% compatibles
Supported Hardware - Video Modes VGA, SVGA, XGA, SXGA, up to 1600 x 1200 @ 75 Hzresolution
Supported Hardware - Peripherals AMX5100 UserStation: PS/2 keyboard, PS/2mouse,
IntelliMouse (PS/2only), Sun Type 5 and Type 6
Supported Cable Types Unshielded twisted pair, including CAT 5, CAT 5e, CAT 6
Warranty Two Years
ORDERING INFORMATION
AMX5000-EU 8 output ports, 32input ports, rack mount switch
AMIQ-PS2 Single server, CAT 5 connection, cable interface
AMX5100-EU Single user, CAT5 connection, desktop userstation
AMWorks System administration software included
The AMXadvances Avocent’s field proven technology and market
leadership in analogue matrix design by providing smarterKVM switch-
ing solutions.The AMX delivers powerful analogue matrix switching,
simple installation and advanced administrative tools to help net-
work administrators efficiently manage their IT environment.
Designed to support growing server installations, this analogue
matrixsolution brings switching intelligence and flexibility to your net-
work. With this smart solution, ITmanagers easily reduce installation
time and expense while increasing network manageability.
The AMX supports multi-user, multi-platform, multi-rack server
environments and provides end-to-end CAT 5 connectivity for
access from the desk to the server.The AMXincludes the AMX5000
analogue matrix switch, the AMIQ CAT5 cable interface, the
AMX5100 user station and the AMWorks advanced system adminis-
trative software tool.
S W I T C H I N G S O L U T I O N S
smarter AMX
AMX5000 • AMIQ •AMX5100 •AMWorks
SPECIFICATIONS

S W I T C H I N G S O L U T I O N S
flexible
AMX5000, AMIQ &AMWorks
Built on Avocent’s superior analogue switching technology, the AMX5000 matrix
switch is particularly effective in evolving server installations.The AMX5000 highly
scalable architecture easily accommodates additional servers and users.
This matrix switch allows access from a single point or simultaneous access for up
to eight users throughout the data centre.
The AMIQ enhanced CAT5 cable interface is the new choice for flexibility and
performance in robust ITenvironments.The CAT 5 design and video technology
eliminates bulky cabling connections and delivers real-time, high bandwidth video for
KVM switching up to 1,000 feet away from the server.The AMIQ’s built-in memory
eases configuration by assigning and retaining unique server identification codes for
each attached server.This cable interface intelligence enhances security and
prevents unauthorized access to a server through cable manipulation.
AMX features the OSCAR on-screen management tool, which lets you conveniently
switch between connected devices.If you require centralised administration of the
AMX, AMWorks management software is included with each switch.The AMWorks
Java-based system administration tool supports customised userprofiles and multi-
level security. The AMWorks allows system administrators to build a user database
with assigned access and password protection for each server.Administrators can
view all activities that take place on the KVM system, including user login, switches
made to servers and changes made to the system connections or setup. The data-
base is centrally stored and can be downloaded to the switch via the network
connection port available on all AMX5000 units.

R E L I A B L E T E C H N O L O G Y , A D V A N C E D D E S I G N
Avocent’s advanced switching solution
provides the best combination of
flexibility and performance in today’s
IT environment.
FEATURES & BENEFITS
• Access – Full non-blocked, each switch supports eight users and 32servers
•Expandability/Scalability – Architecture makes it easy to add and support
more servers
•Connectivity – End-to-end UTPcable, including CAT 5, CAT5e, CAT 6
•AMIQ Cable Interface – Assigns and stores unique server identification code
for easier configuration and enhanced security
• Multi-platform – PS/2 and Sun server support
• Keep Alive – Allows attached servers to continue operating in the event of
power failure to the switch
•Flash Upgrade – Simultaneous flash updates for all connected devices
•AMWorks – AdvancedJava-based system administration tool
• Event Log – AMWorks tool used to maintain a record of user logins and
switching activity
UNIVERSAL AC POWER
AMWorks
NETWORKCONNECTION
AMIQ CABLE CONNECTION
USING ENHANCED CAT 5 TECHNOLOGY
USER CONNECTION USING
CAT 5 TECHNOLOGY

S W I T C H I N G S O L U T I O N S
simpler
AMX5100
The AMX5100 user station simplifies access at the desk by increasing user
control and delivering optimal real-time video to the user’s desk. The AMX5100
connects to the user’s multi-platform KVM peripherals and sends the KVM
signals over an industry standard CAT 5 cable to Avocent’s AMX5000
analogue matrix switch. This CAT 5 connectivity and analogue switching
technology provide multi-user access and control to any server in yournetwork.
The AMX5100’s design automatically compensates for varying cable types and
lengths and adjusts for signal losses each time a switch is made to the server.
The AMX5100 works with the patented On-Screen Configuration and Activity
Reporting (OSCAR) interface.OSCAR uses multi-lingual, intuitive menus for
point and click system configuration and server selection.This full system
management tool supports switching in share, private and scan modes.

Avocent’s solutions address the
challenges facing “real world” IT
environments. Our solutions provide
simpler network manageability.
M A X I M U M P E R F O R M A N C E F O R “ R E A L W O R L D ” I T E N V I R O N M E N T S
FEATURES & BENEFITS
• Video Display – Optimal video resolutions up to 1900x1600
•Connectivity – End-to-end UTPcable, including CAT 5, CAT 5e, CAT 6
• Compact Design – AMX5100 doubles as a monitorstand with zero footprint on the desk
• Multi-platform – Supports PS/2 and Sun peripherals
•On-screen Management – Point and click intuitive menus with multi-lingual support
•Flash Upgrade – Simultaneous flash updates for all connected devices
• High Quality Video - Automatically compensates for varying cable types and
lengths and adjusts for signal losses each time a switch is made to a server
UNIVERSAL AC POWER
VIDEO PORT
ANALOGUE CONNECTION
FOR KVM ACCESS
CONNECTION TO AMX5000
USING CAT 5 TECHNOLOGYSERIAL PORT
FOR DIAGNOSTICS
OSCAR

IN S TA L L AT I O N
easy
From the server to the desktop, the AMX
provides the easiest analogue matrix installation
for today’s contemporary data centres.
1. Connect the AMIQ CAT 5 cable interface to the appropriate ports on the target server.
2. Connect the AMIQ CAT5 cable interface to one of the 32 server ports on the rear of AMX5000 matrix switch
using CAT 5 cabling.
3. Connect the AMX5000 matrix switch to the user connection on the rear of AMX5100 user station using CAT 5 cabling.
4. Connect the user’s KVM peripherals to the KVM ports on the rear of the AMX5100 user station.

E X P A N D A B I L I T Y
simple
• END-TO-END CAT5 CONNECTIONS
•MULTI-USER,MULTI-RACK, MULTI-PLATFORM ACCESS
•REDUCED CABLEBULK
• REAL-TIME, HIGH BANDWIDTH VIDEO
• PATENTED ON-SCREEN MANAGEMENT
• CONVENIENT SYSTEM ADMINISTRATION
• EASY INSTALLATION
• HIGHLY SCALABLE
Avocent’s reliable, proven
technologies offer smarter, simpler
server management solutions.

Avocent, the Avocent logo, The Power of Being There and AMX are
trademarks of Avocent Corporation. OSCAR is a registered trademark
of Apex Inc. All other marks are the property of their respective owners.
Copyright (c) 2002 Avocent Corporation. All rights reserved.
0502-AMX-VER1
