1
Product Overview
1
Feature Overview
TheSwitchViewSCisspecificallydesignedtomakedatatransferbetweenconnected
computers virtually impossible. Users who access secure and unsecure networks
from one set of peripherals can rely on the unique architecture of the SwitchView
SC to keep their private data completely separate and secure at all times. With no
software to install or boards to configure, installation is simple.
TheSwitchViewSCallowsyoutocontroluptoeightPCswithonekeyboard,monitor
and mouse. Each computer can be up to 30 feet away from the SwitchView SC unit.
The unit works with IBM PC/AT and PS/2 systems, and 100% compatible machines
with support for VGA, SVGA, XGA and XGA-II video. PS/2 keyboard and PS/2 mouse
peripheralsaresupportedthroughtherearoftheunit.ASwitchViewSCwillsupport
from one to eight attached PCs, or channels.
The AutoBoot feature boots all attached servers during initial power up or after a
powerfailure.PCsarebootedtransparentlywithoutoperatorintervention,andmay
be powered up one at a time or all at once. When the power stabilizes, a channel
may be selected. The first available channel is automatically selected upon power
up of the SwitchView SC unit.
The SwitchView SC offers full support for the Microsoft IntelliMouse.
Switch computer channels quickly and easily via the SwitchView SC
push-buttons.
The unit's “Keep Alive” feature allows attached servers to power the unit in the
event of a power failure. This prevents attached PCs from locking up and keeps
you from losing time and data.
AutoBoot technology
Support for up to
eight computers
IntelliMouse support
Push-buttons
“Keep Alive” feature

SwitchView SC Installer/User Guide
2
Indicator LEDs give you constant readings on the status of your SwitchView SC.
Channel LEDs take the guesswork out of system operation and diagnostics.
A typical SwitchView SC configuration is shown below.
Status indicator LEDs

Product Overview
3
The SwitchView SC requires a PS/2 mouse and keyboard. The following mice are
known to be compatible:
IBM PS/2-style Logitech Trackman
Kensington Microsoft Serial-PS/2 mouse
Logitech Mouseman (PS/2) Microsoft IntelliMouse
Other manufacturers' mice may operate with the SwitchView SC. If you experience
problems using an untested mouse, contact Avocent Technical Support with the
manufacturer and model number of the mouse.
PS/2 peripherals
Compatibility

SwitchView SC Installer/User Guide
4
