AVOCOR AVE-30-A Series User manual

AVE-30-A Series User Manual
AVE-6530-A / AVE-7530-A / AVE-8630-A

AVE-xx30-A User Manual | 1
Revision Date: 09/25/2021
TABLE OF CONTENTS
Compliance Information........................................................................................................................3
Declaration of Conformity............................................................................................................................................. 3
Caution...........................................................................................................................................................3
Industry Canada (ICES-003).......................................................................................................................................... 3
Product Disposal................................................................................................................................................................ 3
Disposal of Old Electrical and Electronic Equipment............................................................................................ 4
Introduction...........................................................................................................................................5
About This Manual............................................................................................................................................................. 5
Textual Conventions......................................................................................................................................................... 5
Graphic Conventions ........................................................................................................................................................ 6
What's in the Box? ................................................................................................................................. 7
Specifications.........................................................................................................................................8
The display, at a glance ........................................................................................................................ 10
Display Front .....................................................................................................................................................................10
Display Rear 65” ...............................................................................................................................................................11
Display Rear 75” & 86” ...................................................................................................................................................12
Display Keypad .................................................................................................................................................................13
Guest Inputs.......................................................................................................................................................................14
Side Inputs ..........................................................................................................................................................................15
Rear Lower Inputs............................................................................................................................................................16
Installation........................................................................................................................................... 17
Ambient Considerations................................................................................................................................................18
Ambient Light ..............................................................................................................................................18
Ambient Temperature ................................................................................................................................18
Ventilation ...................................................................................................................................................18
Mounting the Display .....................................................................................................................................................19
Stationary Stands ........................................................................................................................................19
Rolling Cart ..................................................................................................................................................20
Wall Mount ..................................................................................................................................................21

AVE-xx30-A User Manual | 2
Revision Date: 09/25/2021
Peripheral Connections .................................................................................................................................................22
Guest inputs.................................................................................................................................................22
Side inputs....................................................................................................................................................22
REAR LOWER INPUTS...................................................................................................................................................24
OPS Module .......................................................................................................................................................................25
OPS Installation Step-by-Step ...................................................................................................................25
Remote Control ................................................................................................................................................................27
Remote Control Batteries ..........................................................................................................................28
Operation............................................................................................................................................. 29
Precaution...........................................................................................................................................................................29
The UiQ Home Screen....................................................................................................................................................30
UIQ Settings.......................................................................................................................................................................31
Display..................................................................................................................................................................................32
Display Settings Tips...................................................................................................................................33
Network...............................................................................................................................................................................35
Network Settings Tips ....................................................................................................................................................36
Language .............................................................................................................................................................................37
Location & Time ................................................................................................................................................................38
Input......................................................................................................................................................................................39
Input Settings Tips ...........................................................................................................................................................40
Security................................................................................................................................................................................41
About – Need new image...............................................................................................................................................42
Update System – Firmware........................................................................................................................43
External Control .................................................................................................................................. 44
RS232 Connection and Port Configuration............................................................................................................44
TCP/IP Control Configuration.....................................................................................................................................44
Command and Response Format................................................................................................................................44
Serial Command List........................................................................................................................................................45
Warranty Information....................................................................................................................................................49

AVE-xx30-A User Manual | 3
Revision Date: 09/25/2021
COMPLIANCE INFORMATION
Declaration of Conformity
Avocor hereby declares that the following Product Model Number:
AVE-6530-A / AVE-7530-A / AVE-8630-A
conforms to the provisions of the following regulations:
•FCC:
oFCC CFR Title 47 Part 15 Subpart B Class A, CISPR22
oANSI C63.4
oICES-003
•CE:
oEN55032
oEN55035
oEN61000-3-2
oEN61000-3-3
•cULus:
oUL 62368-1
oCAN/CSA-C22.2 No. 62368-1
•CB:
oIEC 62368-1
•ERP
•Energy Star V8
CAUTION
Any changes or modifications not expressly approved by the grantee of this device could void the
user's authority to operate the equipment.
Industry Canada (ICES-003)
CAN ICES-3 (B)/NMB-3(B)
Product Disposal
The Product contains small amounts of tin, lead, and/or mercury. Disposal of these materials may be
regulated due to environmental considerations.

AVE-xx30-A User Manual | 4
Revision Date: 09/25/2021
Disposal of Old Electrical and Electronic Equipment
Applicable throughout the European Union and other European countries with separate collection
programs
This symbol, found on your product or on its packaging, indicates that this product
should not be treated as household waste when you wish to dispose of it. Instead, it
should be handed over to an applicable collection point for the recycling of electrical
and electronic equipment. By ensuring that this product is disposed of correctly, you
will help prevent potential negative consequences to the environment and human
health, which could otherwise be caused by inappropriate disposal of this product.
The recycling of materials will help to conserve natural resources. This symbol is only valid in the
European Union. If you wish to discard this product, please contact your local authorities or dealer, and
ask for the correct method of disposal.

AVE-xx30-A User Manual | 5
Revision Date: 09/25/2021
INTRODUCTION
Your new Avocor AVE-xx30-A series display is an ultra-high-definition interactive touch display
supporting full range 4K@60hz resolution, up to 20 simultaneous touch points, multiple source inputs
for your computers and peripheral devices, and our new intuitive UiQ.
Our display follows our agnostic approach to interactive displays: they are compatible with a wide
range of hardware and software, making it a great addition to any interactive meeting-room solution.
Whether you need a virtual meeting space for your conference room, or a powerfully adaptive
whiteboard or presentation hub for your classroom, the Avocor AVE-xx30-A series will exceed your
expectations.
About This Manual
This user manual was written to help you get the most out of your display.
In addition to detailed descriptions of the display and its features, this manual will guide you through
the installation and setup processes and provide tips, tricks, and best practices on how best to utilize
the display.
We make every effort to ensure that this manual is accurate as of the date it was printed. However, it
may require periodic updating due to ongoing product improvements and customer feedback. Find the
latest version of our manuals at Avocor.com.
Textual Conventions
The following textual conventions are used in this manual to denote certain actions or information for
clarification purposes. Here are the details:
•Remote control and display keypad controls are set in CAPS. For example, "Press OK on the
remote control to accept your changes."
•Menus in the OSD and computer interface are in bold. The ">" symbol is used to help denote
submenu navigation. For example, "Open Display > Picture > Advanced Settings to adjust
various picture settings."
•Keyboard keys with functional names are capitalized and set in <Angle Brackets>. For example,
"press <Enter> to make your selection."
•In addition to the above, underlining, italics, or a combination of the two are used periodically to
help emphasize key points in the text of this manual.

AVE-xx30-A User Manual | 6
Revision Date: 09/25/2021
Graphic Conventions
The following symbols appear throughout this manual to emphasize key points. Keep these in mind not
only to benefit from their advice, but also to avoid problems with the display or personal injury.
TIP Highlights helpful guidelines and best practices for using certain features.
NOTE Provides supplemental information and emphasize text of special significance.
CAUTION Alerts that given actions may degrade the performance of the display or cause
a malfunction.
WARNING Alert that a given action may result in damage to equipment or personal
injury.
DANGER Alert that a given action may cause serious personal injury or death.

AVE-xx30-A User Manual | 7
Revision Date: 09/25/2021
WHAT'S IN THE BOX?
•Avocor AVE-XX30-A, Interactive Display
•Quick Start Guide with QR code
•Remote Control & Batteries
•(2) Touch Stylus 3mm
•Power Cables
oUS Cable 2m
oUK Cable 2m
oEuropean Cable 2m
•(1) HDMI cable 3m
•(1) USB-A 3.0 cable 3m
•(2) USB-A-B Adapter
•(1) VESA 100 x 100 adapter plate

AVE-xx30-A User Manual | 8
Revision Date: 09/25/2021
SPECIFICATIONS
AVE-6530-A AVE-7530-A AVE-8630-A
Diagonal Size (Inches) 65” 75” 86”
Backlight Backlit LED
Aspect Ratio 16:9
Resolution 3840 x 2160 @ 60Hz
Response Time 8 ms
Brightness 370 (cd/m2)
Contrast Ratio 4000:1
Viewing Angle 178°/178
Supported Colors 30 Bit Deep Color
Display Orientation Landscape
Touch System
Touch Up to 20 Point Avocor Intelligent Touch – Supports 1 fine tip stylus
Glass 2mm Bonded, Anti-Glare, Anti-Fingerprint Glass
Supported OS Windows 8 & 10; Mac OSX; Linux
Connectivity
Guest Inputs 1x HDMI 2.0, 1x USB-B 2.0 Dedicated Touch, 1x USB-A 2.0 Hub
Side Inputs 2x HDMI 2.0, 1x DisplayPort 1.2, 3x USB-A 2.0 Dedicated Touch, 1x USB-A 2.0,
1x USB-A 3.0, 1x USB Service Port, 1x HDMI Out (4K@60Hz)
Audio 1x 3.5mm Audio Out, 1x Optical (SPDIF)
Control 1x RS232, 1x LAN Ethernet (RJ-45) in, 1x LAN Ethernet (RJ-45) Out
OPS Slot Yes, 3840 x 2160 @ 60Hz
Audio
Built-in Speakers 2x 15W – Forward Facing
Display Functions
Auto-source detection, Source Preview, Blank, Freeze
Physical Specifications
Product Dimensions
1547 x 944 x 92 mm |
60.90 x 37.16 x 3.62 in
1771 x 1071 x 112 mm |
69.72 x 42.16 x 4.41 in
2018 x 1211 x 112 mm |
79.45 x 47.68 x 4.41 in
Shipping Dimensions 1675 x 1115 x 270 mm |
65.94 x 43.90 x 10.63 in
1920 x 1240 x 270 |
75.59 x 48.82 x 10.63 in
2170 x 1380 x 270 mm |
85.43 x 48.82 x 10.63 in
Weight Net: 37 kg / 81.6 lbs /
Gross: 49.5 kg / 109.1 lbs
Net: 48.5 kg / 106.9 lbs /
Gross: 62 kg / 136.7 lbs
Net: 61.5 kg / 135.6 lbs /
Gross: 78 kg / 172 lbs
Wall Mount (VESA) 600 x 400 mm | 23.62 x
15.75 in
800 x 400 mm | 31.50 x
15.75 in
800 x 400 mm | 31.50 x
15.75 in
Handles 2 4 4

AVE-xx30-A User Manual | 9
Revision Date: 09/25/2021
Power
Power Supply AC100 – 240V (Worldwide), 50/60Hz
Max Power
Consumption
<220W <300W <320W
Standby ≤0.5W ≤0.5W ≤0.5W
Environmental
Operating
Temperature
0°C ~ 40°C / 32° F ~ 104° F
Storage
Temperature
-20° C ~ 60° C / -4° F ~ 140° F
Humidity 20% ~ 80%
Warranty
Global 3 Year RTB with optional upgrades available (contact your reseller for more info)

AVE-xx30-A User Manual | 10
Revision Date: 09/25/2021
THE DISPLAY, AT A GLANCE
The following diagrams depict the front, side, and bottom panels of the display. The physical interface
and connections are labeled, and then described in the tables that follow.
Display Front
Front Panel Interface/Guest Inputs HDMI 2.0, Touch USB-B 2.0, USB-A 2.0 (Accessory Port)
Front Panel Speakers 2 X 15W Forward-Facing Speakers.
Display Buttons On-panel keypad control. See Page 13 for more details.
Pen Tray Magnetized pen storage
1
2
3
2
4

AVE-xx30-A User Manual | 11
Revision Date: 09/25/2021
Display Rear 65”
Main Power Switch A/C Rocker Switch; toggles all power to the display.
Power Socket Three-pin A/C Jack.
OPS Slot TX25A-80P standard OPS input; compatible with non-standard OPS-C
structure.
Rear Source Inputs
Side — 2x HDMI 2.0, 1x DisplayPort 1.2, 3x USB-A 2.0 Dedicated Touch, 1x
USB-A 2.0, 1x USB-A 3.0, 1x USB Service Port, 1x HDMI Out (4K@60Hz)
Bottom—RS232 Female Input, Ethernet In, Ethernet Out.
7
8
6
5

AVE-xx30-A User Manual | 12
Revision Date: 09/25/2021
Display Rear 75” & 86”
Main Power Switch A/C Rocker Switch; toggles all power to the display.
Power Cord Socket Three-pin A/C Jack.
OPS Slot TX25A-80P standard OPS input; compatible with non-standard OPS-C
structure.
Rear Source Inputs
Side — 2x HDMI 2.0, 1x DisplayPort 1.2, 3x USB-A 2.0 Dedicated Touch,
1x USB-A 2.0, 1x USB-A 3.0, 1x USB Service Port, 1x HDMI Out (4K@60Hz)
Bottom—RS232 Female Input, Ethernet In, Ethernet Out.
7
8
6
5

AVE-xx30-A User Manual | 13
Revision Date: 09/25/2021
Display Keypad
Power LED Indicates the power status of the display.
Light sensor Ambient light detector.
Power Turn the display on/off.
Source Switch sources.
Menu settings Open UiQ Settings.
Home Access the Home screen.
Volume - Short press to reduce one level of volume; Long press, continue to
reduce the volume.
Volume + Short press to increase the volume; Long press, continue to increase
the volume.
Freeze "Freeze" the active image on the display; press again to resume normal
operation.
Blank Disables the backlight.

AVE-xx30-A User Manual | 14
Revision Date: 09/25/2021
Guest Inputs
``
HDMI HDMI Guest Input.
USB Touch USB Touch Guest Input.
USB 2.0 USB Accessory Input.
2
1
3
2
3
1

AVE-xx30-A User Manual | 15
Revision Date: 09/25/2021
Side Inputs
DP DP1.2 & HDCP2.2.
HDMI1
HDMI2.0B & HDCP2.2.
HDMI2 HDMI2.0B & HDCP2.2.
USB Touch USB 3.0 Type A for touch control.
USB 3.0 USB 3.0 accessory port.
USB 2.0 USB 2.0 accessory port
USB 2.0 USB 2.0 service port
Line out 3.5mm audio output (no mic).
HDMI Out HDCP compliant HDMI out @ 4K@60Hz; duplicate screen only.
SPDIF Out Sony/Phillips Digital Interface. Connect external and digital powered
speakers, or an audio receiver or amplifier.
1
2
4
4
3
5
6
7
8
9
10
1
3
2
4
5
6
7
8
9
10
4

AVE-xx30-A User Manual | 16
Revision Date: 09/25/2021
Rear Lower Inputs
RS232 DB9 Female Input For interfacing with a PC or
automation/control system.
Ethernet In RJ45 Input Lan In, 10/100Mbps.
Ethernet Out
RJ45 Output Lan Out, 10/100Mbps.
1
1
2
2
3
3

AVE-xx30-A User Manual | 17
Revision Date: 09/25/2021
INSTALLATION
Please read the following precautions carefully before installing your new Avocor AVE-xx30-A
display. Failure to comply may result in damage to the display and equipment and may result in
personal injury or death.
•DO NOT install the display in a high temperature environment or near any apparatus that
produce heat.
oThis may cause damage to the panel and equipment. It may also cause personal injury
due to electrical shock resulting from overheating.
•DO NOT install the display in a high humidity environment or an environment where it can
come into contact with water.
oThis may cause damage to the panel and equipment. It may also cause personal injury
due to electrical shock resulting from overheating.
•DO NOT overload outlets or cables beyond their electrical capacity.
•DO NOT insert the power plug into an outlet rated outside the range of 100~240V A/C.
•DO NOT insert the power plug into a damaged outlet.
•DO NOT use a worn or damaged A/C power cable.
•DO NOT use an improper or mismatched A/C power cable.
•DO NOT place the display on an unstable shelf or surface.
•DO NOT place objects on the display as instructed below:
oDo not cover the vents on the display.
oDo not allow liquid or small particles to enter the vents or other parts of the display.
oDo not put heavy objects on the display.
•Please allow room between the wall and the display panel to maintain proper ventilation and
avoid overheating.
•Make sure you use the handles on the back of the display while lifting or moving the display, to
avoid touching the front panel during the move.
•When unpacking, and carrying the display please follow these guidelines:
o2 people are needed to move displays of 65”
o3 people are needed to move displays of 75” - 86”
Before installing, please make sure the wall is strong enough to hold the necessary weight of the
display and the mount.

AVE-xx30-A User Manual | 18
Revision Date: 09/25/2021
Ambient Considerations
Environmental and ambient factors play a considerable role in determining your viewing experience
and the functional operation of the display. Make sure to follow these guidelines carefully to get the
most out of your display.
AMBIENT LIGHT
For the best viewing experience, make sure to minimize or remove light sources directed at the screen,
especially sunlight.
Any direct light may make images on the screen appear washed out and less vibrant, and direct sunlight
may even affect touch control operation.
AMBIENT TEMPERATURE
Maintain the ambient temperature of the room at a consistent level. This will ensure that the display
continues to operate smoothly.
Do not place the display near heat sources or air conditioning vents, and do not operate or store the
display in temperatures above 40 degrees Celsius (104 degrees Fahrenheit).
VENTILATION
The display should maintain a proper operating temperature provided that the ambient temperature is
not too high, and that the vents on the display have enough room to disperse any heat emanating from
the display.
Do not block the vents on the display! Leave a space of about 4 inches between all sides of the
display and surrounding walls or objects, as shown in the figure, below.

AVE-xx30-A User Manual | 19
Revision Date: 09/25/2021
Mounting the Display
The three primary types of mounting solutions are Stationary Stands, Rolling Carts, and Wall Mounts.
This chapter will examine each type and how they might fit into your installation.
NOTE
Leave mounting to the installation specialists.
Always make sure that your stand, or mount/wall is rated to hold the weight of
your display.
Make sure that the surface you place the mount or stand upon can support the
weight of your display.
Make sure the tilt degree of the display does not exceed 2°.
Always get help when moving or mounting the display.
o2 people are needed to move displays of 65”
o3 people are needed to move displays of 75” - 86”
STATIONARY STANDS
Stationary stands can come in the form of tabletop stands or floor stands. These stands are worthwhile
for either permanent or temporary installations; they are less mobile than rolling carts but are a bit
more flexible than wall mounts.
WARNING
If you decide to implement a tabletop stand, make sure that the table or surface
you plan to place the display on can support the weight of both the display and the
stand.
