USER MANUAL
Elo Touch Solutions
2799L 27-inch Open Frame Touchscreen

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 1 of 31
Copyright © 2021 Elo Touch Solutions, Inc. All RightsReserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or
by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of Elo Touch Solutions, Inc.
Disclaimer
The information in this document is subject to change without notice. Elo TouchSolutions, Inc. and its Affiliates (collectively “Elo”) makes no representations or warranties
with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. Elo reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of Elo to notify any person of such revisions or changes.
TrademarkAcknowledgments
Elo, Elo (logo), Elo Touch,Elo Touch Solutions, are trademarks of Elo and its Affiliates. Windows is a trademark of MicrosoftCorporation.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 2 of 31
Table of Contents
Section 1: Introduction ............................................................................................................................................................................................................................. 4
Section 2: Installation............................................................................................................................................................................................................................... 4
Section 3: Mounting ................................................................................................................................................................................................................................. 7
Section 4: Operation ................................................................................................................................................................................................................................ 9
Section 5: Technical Support.................................................................................................................................................................................................................. 14
Section 6: Safety & Maintenance........................................................................................................................................................................................................... 16
Section 7: Regulatory Information.......................................................................................................................................................................................................... 17
Section 8: Warranty Information............................................................................................................................................................................................................. 21

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 3 of 31
Section 1: Introduction
Product Description
This 27-inch ET2799L touchscreen display combines Elo’s latest developments in touch technology and display design with the reliability for use in full environments. It
is designed to meet EN62368-1 Part 22 when properly mounted.
This 27-inch ET2799 touchscreen display incorporates a Full HD 1920x1080 resolution, 24-bit color, 1500nit brightness, active matrix thin-film-transistor LCD panel
to provide high quality display performance. The LED backlight significantly reduces power consumption and eliminates mercury (compared to CCFL-backlit panels).
The ambient light sensor on the front of the screen offers added functionality to adapt the brightness setting to the environmental lighting conditions, helping to
ensure the best user experience in any exterior setting.
With a vandal-resistant (IK10) anti-glare screen, the display is designed for optimal operation in harsh field conditions. The USB 10-point touch operates even if
water or other elements are on the screen, and this product also supports various other touch capabilities: RS232 Touch with 2 touches (via a separate optional
cable kit: E810917), and 2 touches with up to 6mm of cover glass on top of the touchscreen.
The addition of built-in thermal and humidity sensors and 6 internal fans help to prevent the display from overheating. The touchscreen display is also equipped with
a Real Time Clock which gives you the ability to plan a power schedule.
Other features that enhance this LCD monitor’s display performance are Plug & Play compatibility with Windows, Android, or Linux operating systems, tethered
remote on-screen display (OSD) controls for easy access when integrated, simplified flush mounting design for easy IP66 and NEMA4X sealing, flexible flush, VESA,
and touch thru mounting options, and a GPIO connector for additional component control requirements inside the enclosure. The display also supports 12V –24V
DC power input making it very easy to integrate with your current power solution.
Precautions
Follow all warnings, precautions and maintenance as recommended in this user manual to maximize the life of your unit and prevent risks to user safety. See the
Safety & Maintenance Section for more information.
This manual contains information that is important for the proper setup and maintenance of the unit. Before setting up and powering on your new touchscreen, read
through this manual, especially the Installation, Mounting, and Operation Sections.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 4 of 31
Section 2: Installation
Unpacking the Touchscreen Display
Open the carton and verify that the following items arepresent:
• 27-inch Open Frame Touchscreen
• Quick Install Guide
• HDMI cable (screw-lock type)
• EEI label
• VGA cable (screw-lock type)
• USB cable (screw-lock type)
• Flush Mount Brackets w/Screws
• OSD remote

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 5 of 31
Connector Panel & Interfaces
Touchscreen Display Connections
1. Connect the HDMI, DP, or VGA video cables between the monitor’s HDMI, DP, or VGA input connector and your HDMI/DP/VGA video source. Tighten the video
cable’s screws to prevent accidental disconnection when using the HDMI or VGA connector.
2. Connect the USB touch cable between the monitor’s USB connector and your PC’s USB port, or connect the VGA Y-cable (optional cable kit E810917) between
the monitor’s VGA connector and your PC’s COM (Serial) port. Tighten the USB cable’s screws to prevent accidental disconnection.
3. Connect a 12-24VDC power supply to the monitor’s input power jack. Elo offers a 12VDC power adapter with locking connector and regional power cable kits
separately.
4. The touchscreen display ships in an ON state, video should be displayed on your monitor once the cables are connected.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 6 of 31
Installing the Touch Technology Software Drivers
When using USB touch, no additional drivers are required for your projected-capacitive touchscreen display with Windows 7 and 10 or later operating systems,
because it uses Windows HID drivers. If you want to use RS232 touch, follow the below steps to install the Elo touch driver.
Todownload the latest touch drivers:
1. Visitwww.elotouch.com/Support/Downloads/Driver/DriverDownload/Default.aspx
2. Select the “Touch Drivers” from the “Product Category” dropdown menu.
3. Select the “Operating System”from the “Operating System” dropdown menu.
4. Click on the driver version required for your touchscreen display.
Non-Microsoft Windows operating system versions suggested below:
Linux Ubuntu: 18.04 LTS
Mac:OS BIG SUR 11.2
Chrome: 78.0.3904.106
Android: 7.10/8.10

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 7 of 31
Section 3: Mounting
Flush Mount
Flush-mount Bracket Installation Notes:
See dimensional drawing for the exactdetails of the recommended enclosure panel
opening dimensions.
1. Place the 27-inch 2799 touchscreen display into your enclosure panel opening.
2. Attach flush mounting brackets (all four sides) with M4-5mm bracket screws (included)
to secure the touchscreen onto the enclosure panel. Adjust the touchscreen as close
as possible to flush with the front of the enclosure panel before tightening M4 bracket
screws. A socket wrench is recommended if clearance is limited.
3. Tighten the M4-6mm clamping screws on the mounting brackets to bring the
touchscreen glass completely flush with the customer panel, compressing the sealing
gasket, and ensuring a watertight seal to IP66 and NEMA4x standards.
Please ensure 2” clearance behind the touch screen display.
1
2
3

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 8 of 31
Rear VESA Mount
A six-hole mounting pattern for M4(10mm) screws is provided on the rear of the monitor for 200x100 in multiple VESA mounting positions. The VESA FDMI-
compliant counting is coded: VESAMIS-E. Please ensure 2” clearance behind the touch screen display.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 9 of 31
Section 4: Operation
Power
The touchscreen display ships in the ON state.
Toturn the touchscreen display on or off, attach the OSD remote via the RJ45 connector and press the touchscreen display power button on the OSD remote once.
The power status LED on the OSD remote functions according to the following table.
Touchscreen Display/Computer Module Status LED Status
OFF OFF
SLEEP PULSING
ON ON
The system consumes low power when in SLEEP and OFF modes. For detailed power consumption specifications, refer to technical specifications on the Elo
website http://www.elotouch.com
Touching the screen will bring the attached host PC out of SLEEP mode (similar to moving the mouse or pressing a keyboard key).
To improve reliability and reduce power consumption, disconnect the AC power cable from the monitor when long periods of disuse are planned.
Touch
Your touchscreen display is factory-calibrated and should not need manual calibration (unless the input video is not fully scaled to the native resolution, or the touch
experience needs to be calibrated to a specific user).

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 10 of 31
Projected Capacitive Touch Technology
When connected to Windows 7, and 10 or later computers, the touchscreen display can report 10 simultaneous touches. When connected to Windows XP computers,
the touchscreen display reports single touch.
No additional drivers are required for this technology to work with Windows 7, and 10 or later, it uses Windows HID drivers.
Please refer to Chapter 2, Section “Installing the Touch Technology Software Drivers” to find instructions to download touch drivers for RS232 touch with 2 touches.
Gesture Support
The Projected Capacitive Touch enables several gestures that support single and multiple touches. Refer to theMicrosoft Website https://docs.microsoft.com/en-
us/windows/win32/wintouch/windows-touch-gestures-overview on the various gestures that are supported in Windows 7, and 10.
Video
A display’s native resolution is its width and height measured in number of pixels. Generally, for best performance, animage displayed on this monitor will look best
when your computer’s output resolution matches this monitor’s native resolution.
For computer output resolutions at non-native resolutions, the monitor will scale the video to its panel’s native resolution. This involves stretching or compressing the
input image as needed in the X- and Y-dimensions to fit the display’s native resolution.An unavoidable byproduct of the scaling algorithms is a loss of fidelity when the
computer’s output video image is scaled by the monitor to fit the display. This loss of fidelity is most apparent when viewing feature-rich images at close distances (for
example images containing small-font text).
Your touchscreen display will likely not require video adjustments. However, for analog VGA video, variations in video graphic card outputs may require user
adjustments through the OSD to optimize the quality of the monitor’s displayed image. These adjustments are “remembered” by the touchscreen display. Also, to
reduce the need for adjustments for different video mode timings, the monitor correctly scales and displays some of the video industry’s most common video timing
modes. Refer to the technical specifications for this monitor at http://www.elotouch.com for a list of these Preset Video Modes.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 11 of 31
On-Screen Display (OSD)
Four OSD buttons are located on a wired control box. These can be usedto
adjust various display parameters. The buttons and their functionality are:
Button
Function when OSD is not displayed
Function when OSD is displayed
Menu
DisplayOSD Mainmenu
ReturntopreviousOSDmenu
DisplayOSD Miscellaneous submenu
Decreasevalueofselectedparameter/selectpreviousmenuitem
DisplayOSDLuminancesubmenu
Increasevalueofselectedparameter/ selectnextmenuitem
Select
DisplayVideo Prioritysubmenu
Selectparameterforadjustment/selectsubmenutoenter

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 12 of 31
Using the OSD buttons controls an on-screen graphical user interface which displays on top of your input video, allowing intuitive adjustment of the following
displayparameters:
Parameter Available Adjustment
Brightness/Lightsensor
Contrast
LightSensor
Increase/decreasemonitor brightness.
Default:Lightsensoron,ifthelight sensorisdisable,defaultbrightnessissetto100%
Increase/decreasemonitor contrast.
Default: bestgray-shadeperformance
Automatically adjust brightness setting based on ambient light.
Clock Allowfineadjustmentsofthepanel’s pixeldotclock.
OnlyapplicableforVGAinputvideo.
Phase Allowfineadjustmentsofthepanel’s pixeldotclockphase.
OnlyapplicableforVGAinputvideo.
AutoAdjust Automaticallyadjuststhesystemclockto theinputanalogVGAvideosignal,affectingtheH-position,V-position,Clock,and Phasemenuitems.
OnlyapplicableforVGAinputvideo.
H-position Movetheimagehorizontallyon thedisplayinsingle-pixelincrements. Default:centered
OnlyapplicableforVGAinputvideo.
V-position Movetheimageverticallyonthedisplayin single-pixelincrements. Default:centered
OnlyapplicableforVGAinputvideo.
AspectRatio
SwitchthescalingmethodbetweenFillScreen,FillAspectRatio,and Direct Output
Default:FillScreen
FillScreen–scaletheX-and Y-dimensionsoftheinputvideo(upordownasneeded)tothedisplay’s nativeresolution.
FillAspectRatio –Assuminga landscapeorientation,and an inputvideowith aspectratiosmaller than 16:9, scalethe Y-dimension of the inputvideo(upordown
asneeded)tothedisplay’s Y-resolution,and scaletheX-dimensiontomaintaintheinputvideo’s aspectratio(andfillstherestofthedisplaywithequalblackbarson
theleftandright).
DirectOutput–Assumingalandscapeorientation,and an input video is under the native resolution (1920x1080), will keep display center and fills the rest
of the display with equal black bars on four sides.
Sharpness Adjustsharpnessofthedisplayedimages. Default:no sharpnessadjustment.
Onlyapplicableatnon-nativeinputvideoresolutions.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 13 of 31
Color
Selectthe display’s color temperature.The availablecolor temperaturesare 9300K, 7500K,6500K,5500K, Color Enhance, and UserPreset. If the
UserPresetoptionisselected,theusercanchangethecolortemperaturebychangingindividualR,G,andBgainsonascalefrom0to100.Default:
UserPresetwithR,G,andBallsetto100.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 14 of 31
Parameter Available Adjustment
OSDH-Position AdjustthehorizontallocationoftheOSDmenuson thedisplay.
Default: centered.
OSDV-Position AdjusttheverticallocationoftheOSDmenuson thedisplay.
Default: centered.
OSDTimeout AdjusthowlongaperiodofOSDbuttoninactivitythetouchscreen display willwaitbeforeclosingtheOSD. Theadjustablerangeisbetween5and60seconds.
Default:15seconds.
OSDLanguage
OSDRotation
SelectwhichlanguagetheOSDinformationis displayedin. TheavailablelanguagesareEnglish,French,Italian,German,Spanish,SimplifiedChinese,
TraditionalChinese,andJapanese.
Default:English.
Select“Landscape” or “Portrait” to switch OSD between 0°and 90° clockwise.
RecallDefaults Select“Recall Defaults” restoresallfactorydefaultsettingsforOSD-adjustableparameters(exceptOSD
Language)andforPresetVideoModetimings.
VideoPriority
Themonitorcontinuallyscansforactivevideoonthe HDMI,VGA,andDisplay port connectors.
Thisadjustmentselectswhichofthoseinputportsshouldbe givenprioritytobedisplayed. The
optionsareHDMIPriority,DPPriority,VGAPriority
Default:HDMIPriority
TouchonSleep Touchfunctionenabled/disabledwhenthemonitorgoes intothesleepmode.
Default:On
TouchThrough
TouchInterface
Switch to support two touches when adding a 6mm thickness glass in front of the original touch screen with no air gap.
Default: Off
Switch to support two touches via RS232 (requires optional cable and installation of the latest Elo driver)
The options are USB, RS232.
Default: USB.
GPIOControl Allowusertoconnecttwodevices:one isinputdeviceandtheotherreactsviaahigh/lowsignalthrough2799. Thepindefinitionsare
VCC,input,output,GND(fromlefttoright).optionsareSymmetric,Asymmetric.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 15 of 31
D efault:Symmetric
RealTimeClock Manage power schedule and system clock/daylight saving.
Default: GMT time
.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 16 of 31
All touchscreen display adjustments made through the OSD are automatically memorized as soon as they are entered.
This feature saves you from having to reset your choices every time the touchscreen display is unplugged or powered off and on. If there is a power failure, the
touchscreen display settings will not default to the factory specifications.
OSD and Power Lockouts
Press and hold the “Menu” and “Down” buttons for two seconds to enable/disable the OSD Locking feature. When the OSD Locking is enabled, pressing any of the
Menu, Up, Down, or Select keys will have no effect on the system.
Press and hold the “Menu” and “Up” buttons for two seconds to enable/disable the Power Locking feature. When the Power Locking is enabled, pressing the power
switch will have no effect on the system.
Temperature Control
The monitor contains a thermal sensor that provides the user with real-time temperature readings. This reading can be found by opening the OSD menu:
Information ►System Temperature. If the monitor is operated above the operating temperature limit, the monitor will go into “Thermal Protection Mode” which
will turn on the internal fans to dissipate heat until the internal temperature is back within operating range. If the temperature continues to rise and reaches 90°C,
brightness will be limited. If the internal temperature decreases below the Thermal Protection Mode temperature for at least five minutes, normal operation is
resumed.
If the temperature exceeds 70 °C, the user will be prompted to shut off the monitor within sixty seconds. The following icon will appear in the Main
Menu. This will indicate that the Thermal Protection Mode is active.
If the system is not manually turned off within sixty seconds or the display internal temperature is not reduced below 70 °C, the display will
automatically turn off to prevent permanent damage.
Temperature Trigger point
Chassis fans x4
Shielding fans x2
Recover point
1
45 –50 °C
50%
100%
Less than 45 °C
2
55 –60 °C
80%
100%
45 –50 °C
3
65 –70 °C
100%
100%
55 –60 °C

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 17 of 31
Mounting Guidelines
When choosing a mounting location and orientation, consider the following guidelines.
1. The ambient light sensor may not function properly if the portrait orientation is upside-down, a focused light source is close to the sensor window, or the sensor
window is blocked. Reference the dimensional drawing for details on light sensor location.
2. Try to avoid mounting the product in direct sunlight if possible. Use overhangs or orient away from the sun to reduce environmental stress on the product and
prolong its life.

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 18 of 31
Section 5: Technical Support
If you are experiencing trouble with your touchscreen display, refer to the following suggestions.
If the problem persists, please contact your local dealer, or contact Elo Customer Service. Worldwide technical support phone numbers are available on the last page
of this use manual.
Solutions to Common Problems
Problem Suggested Troubleshooting
Thetouchscreen displaydoesnotrespond
when turningonthesystem CheckthattheDCpoweradaptoris properlyconnectedVerifytheDCpoweradaptorisfunctioning
Monitordisplayisdim UsetheOSDtoincreasethebrightness.UsetheOSDtoincreasethecontrast.
CheckifLightsensorison andadjustingforthe ambientlightingconditions.
CheckifthedisplayisoverheatingandrunninginThermalProtectionMode..
Monitordisplayisblank
IfthePowerStatusLEDisblinking,themonitormaybeinSLEEPmodePressany key / movethe mouse / touch the
touchscreento seeif theimage reappearsCheckthatthesignalsourcedeviceis turnedon
Checkthattherearenoloosecableconnections
Monitordisplaysan“Out ofRange” message Adjustyourcomputer’s resolution/timingmodeto bewithintheallowabletimingranges
specifiedforyourtouchscreendisplay(seewebsiteforspecifications)
Monitordisplayimagelooksstrange Adjustyourcomputer’s resolution/timingmodetobewithintheallowabletimingranges specifiedforyourtouchscreendisplay(seewebsiteforspecifications)
UsetheAutoAdjustfunctionintheOSD
Check if color setting is “User Preset”
Touchfunctionalitydoesn’twork VerifyyourPChasthelatestElodriversinstalled
PerformthecalibrationroutineprovidedwiththelatestElodrivers
Check if Touch Interface is set up correctly
TheOSDbuttonsorpowerbutton
doesnotrespondwhenpressed
ChecktoseeiftheOSDlockorpowerlockfunctionsison

User Manual: ET2799L Touchscreen
UM600526 Rev B, page 19 of 31
Can’t wakeon touch ChecktoseeiftheOSDtouchonsleepfunctionis disabled
Checkthattherearenoloosecableconnections
Onlyhavetwotouches ChecktoseeiftheOSDtouchthroughfunctionison
ConfirmthatyouareusingRS232touchorUSBtouch
Fansdonot work Checkthere are no loosecable connections between fans and the unit.
