AVT MAGIC AE1 DAB+ User manual

MAGIC AE1 DAB+ Go
DAB+ Audio Encoder
Hardware Manual

.

M A G I C A E 1 D A B + G o
D A B + A u d i o E n c o d e r
H a r d w a r e M a n u a l
To get automatically informed about the latest soft-
ware, please register on our homepage:
http://www.avt-nbg.de
Please click on Create an account under the Log In
section. Now you need to enter your name/com-
pany, a user name and a valid email address.
Please click on Register to receive your confirmation
email which includes the link to activate your ac-
count.
With your account you can also download manuals
and the latest software in the Download section of our
website.


A publication of:
AVT Audio Video Technologies GmbH
Nordostpark 12
D-90411 Nuernberg
Telephone +49-911-5271-0
Telefax +49-911-5271-100
Printed in Germany, December.2018
AVT Audio Video Technologies GmbH
All rights reserved. Reproduction in
whole or in parts is prohibited without
previous written consent of Audio Video
Technologies GmbH.
Subject to change.
Release date: (12.18)

.

C o n t e n t
C o n t e n t
INTRODUCTION 9
SAFETY 11
Introduction 11
General Safety Requirements 11
Conventions 12
1 CONSTRUCTION 13
2 SYSTEM DESCRIPTION 15
2.1 Functionality 15
3 PUTTING THE SYSTEM INTO OPERATION 17
3.1 Mounting 17
3.2 Connection to the mains voltage 17
3.3 Earthing of the system 18
3.4 Operating elements on the front side 18
3.5 Wiring diagramm 19
3.6 Applications 20
3.6.1 MAGIC AE1 DAB+ Go connected to Ensemble Multiplexer 20
A1 INTERFACES 21
A1.1 LAN interface 22
A1.2 Audio inputs 23
A1.2.1 Analogue Audio input 23
A1.2.2 Digital AES/EBU Audio input 23
A1.3 Control Interface 24
A1.3.1 LAN interface 24
A1.3.2 TTL/RELAY interface 24
A1.4 Power supply interface 25
A2 TECHNICAL DATA MAGIC AE1 DAB+ GO 26
A3 GENERAL 28
A3.1 Order numbers 28
A3.2 Scope of delivery 29
A3.3 Declaration of conformity 29

C o n t e n t
A4 SERVICE INFORMATION 30
A4.1 Software Updates 30
A4.2 Support 30
A4.3 Repairs 30
INDEX 31
DECLARATION OF CONFORMITY 33

PAGE 9
I n t r o d u c t i o n
I N T R O D U C T I O N
The system MAGIC AE1 DAB+ Go is implemented as DAB+ Audio Encoder
and has analogue and digital AES/EBU audio inputs.
The MPEG-4 HE-AAC-V2 DAB+ audio encoder is an implementation of the
FhG (Fraunhofer Gesellschaft) in Erlangen. The configuration of the system
can be carried out via the Windows application included in delivery or via the
front keypad and display of the unit.
MAGIC AE1 DAB+ Go is available as 1/2 x 19“x 1 U system with external 12V
power supply.
English
Deutsch
Menu
Select
System Settings
System Settings
Language
Sprache
Cap
Ok
Save Settings?
Yes
No
Operation Settings
Select
Line Mode
ISDN
ISDN Single Hybrid
POTS
Audio
Audio Settings
Audio Settings
Audio Input
Audio Output
Analogue
Digital
PRETALK Interface
No Device
Phone
Handset
Delete
Opts.
ON AIR
HOLD
PRETALK
Call Out...
Callin
Disconnect
Locked
Line
Ring Tone
Search
Names
New Entry

PAG E 10
I n t r o d u c t i o n
Edit
View
Delete Entry
Save as Quick dial
Presets
Load
New
Save
Delete Preset
Ring Tone
Signal Processing
Keypad 9600, none
Status Information
Login
Shift

PAG E 11
S a f e t y
S A F E T Y
Introduction
The unit described has been designed to the latest technical parameters and
complies with all current national and international safety requirements. It
operates on a high level of reliability because of long-term experience in de-
velopment and constant and strict quality control in our company.
In case of normal operation the unit is safe.
However, some potential sources of danger for person, material and optimal
operation remain - especially if daily routine and technical errors coincide.
This manual therefore contains basic safety instructions that must be ob-
served during configuration and operation. It is essential that the user reads
this manual before the system is used and that a current version of the manual
is always kept close to the equipment.
General Safety Requirements
To keep the technically unavoidable residual risk as low as possible, it is ab-
solutely necessary to observe the following rules:
– Transport, storage and operation of the unit must be under the permissible
conditions only.
– Installation, configuration and disassembly must be carried out only by
trained personnel on the basis of the respective documentation.
– The unit must be operated by competent and authorised users only.
– The unit must be operated in good working order only.
– Any conversions or alterations to the unit or to parts of the unit (including
software) must be carried out by trained personnel authorised by the man-
ufacturer.
Any conversions or alterations carried out by other persons lead to a com-
plete exemption of liability.
– Only qualified personnel is authorised to remove or override safety meas-
ures and to carry out the maintenance of the system.
– External software is used at one’s one risk. Use of external software can af-
fect the operation of the system.
– Use only tested and virus-free data carriers.

PAG E 12
S a f e t y
Conventions
In this manual, the following conventions are used as text markers:
Emphasis: Product names or important terms
LCD Text: Labelling on the front display of the system
PC Text: Labelling in the PC software
TIP The symbol TIP labels information which facilitates the operation of the sys-
tem in its daily use.
NOTE The symbol NOTE labels general notes to observe.
ATTENTION The symbol ATTENTION labels very important advice that is absolutely to
observe. In case of non-observance disfunctions and even system errors are
possible.
!

PAG E 13
C o n s t r u c t i o n
1 C O N S T R U C T I O N
The functions of the MAGIC AE1 DAB+ Go are implemented in a single unit.
The system is designed for mounting in a 19" rack (1 U).
FIG. 1 MAGIC AE1 DAB+ GO TELEPHONE HYBRID

PAG E 14
C o n s t r u c t i o n

PAG E 15
S y s t e m D e s c r i p t i o n
2 S Y S T E M D E S C R I P T I O N
The functional elements of the system are pictured in Fig. 2.
FIG. 2 FUNCTIONAL ELEMENTS OF MAGIC AE1 DAB+ GO
2.1 Functionality
The MAGIC AE1 DAB+ Go system incorporates a LAN interface. via which it
can be connected to a DAB/DAB+ system.
The complete signal processing is taken over by a digital signal processor. In
this way the following functions are carried out:
–MPEG-4 HE-AAC V2 (FhG Licence) coding
– PAD over LAN
– control of the complete system ( Display, Relay, TTL, LAN)
Via the main audio channel the high quality Stereo or Mono audio signal is
inserted analogue or digitally. If the digital AES/EBU audio input is used, a
Sample Rate Converter is available for automatic clock synchronisation be-
tween network and audio source.
The configuration and operation can be primarily carried out via the front
keypad and the illuminated display.

PAG E 16
S y s t e m D e s c r i p t i o n
Configuration and control is especially comfortable with the MAGIC AE1
DAB+ Windows PC Software which is included in delivery and which com-
municates with the system via the LAN interface.
Four programmable TTL contacts can be used for external signalling. Two re-
lays are available for status indication.

PAG E 17
P u t t i n g t h e s y s t e m i n t o o p e r a t i o n
3 P U T T I N G T H E S Y S T E M I N T O O P E R A T I O N
3.1 Mounting
With its dimensions (W x H x D) of 220 mm x 44,5 mm (1 U) x 220 mm the
MAGIC AE1 DAB+ Go system can be either used as desktop device or
mounted in a 19 inch rack. Corresponding 19“ mounting brackets are in-
cluded in delivery.
When mounting the unit please keep in mind that the bending radius of the
cables is always greater than the minimum allowed value.
When the MAGIC AE1 DAB+ Go Telephone Hybrid is installed, please make
sure that there is sufficient air ventilation: It is recommended to keep a spac-
ing of ca. 3 cm from the openings. In general, the ambient temperature of the
system should be within the range of +5 °C and +45 °C. These limits are espe-
cially to observe if the system is inserted in a rack. The systems works without
ventilation.
During operation air humidity must range between 5% and 85%.
3.2 Connection to the mains voltage
The system can be operated with mains voltage in the range of 90 V and 253 V
via the external power supply adapter included in delivery. The mains fre-
quency can range from 45 Hz to 65 Hz. The maximum power consumption is
15W. The rack must be earthed according to the VDE Regulations. This can be
carried out via the earthing screw on the back side of the unit.
After plugging in the external power supply adapter the unit boots in a few
seconds. In standby mode the level meter/status display is shown on the dis-
play.
TIP The system temperature can be indicated on the display (
)
ATTENTION Incorrect ambient temperature and humidity can cause functional defi-
ciencies.
Operation outside the threshold values indicated above leads to a loss of war-
ranty claim.
!

PAG E 18
P u t t i n g t h e s y s t e m i n t o o p e r a t i o n
3.3 Earthing of the system
For EMC reasons an earthing via the earthing screw of the system must be car-
ried out in either case.
3.4 Operating elements on the front side
The system has an illuminated graphical display with a resolution of 160 x 32
Pixels and 21 operating buttons.
On the right next to the display there are two softkeys whose current func-
tions are indicated on the display. In the middle there are two buttons for nav-
igation (selection upwards/downwards), two buttons for establishing/dis-
connecting connections as well as an OK button. The numerical pad supports
in addition to the numericals 0...9 also the ’*’and ’#’button. For entering text
the numerical pad can also be used as a normal keypad.
FIG. 3 OPERATING ELEMENTS ON THE MAGIC AE1 DAB+ GO FRONT SIDE
ATTENTION Earthing
A lacking earthing can cause functional deficiencies within the unit.
!
Softkeys Cursor keys
Establish connection
Drop connection/
Main menu
Text entry
Confirm entry/
Graphical
display
Status window

PAG E 19
P u t t i n g t h e s y s t e m i n t o o p e r a t i o n
3.5 Wiring diagramm
The following figures show the system in the different operating modes and
their respective cablings.
The minimal wiring for the operation is pictured in Fig. 4.
FIG. 4 MINIMUM WIRING
The maximum wiring with all options is shown in Fig. 5. The LAN interface
allows the connection with a PC with a Windows PC Software.
FIG. 5 MAXIMUM WIRING
ATTENTION Earthing
The system must be earthed via earthing screw for EMC reasons. If the earth-
ing is not carried out, the Audio signal can be faulty (humming).
!
Analogue Audio Left Input
Analogue Audio Right Input
Earthing!
Power supply
interface
A PC with a
Windows PC Software
AES Input
Analogue Audio Left Input
Analogue Audio Right Input
Earthing!
Power supply
interface
A PC with a
Windows PC Software
AES Input
REL2
TTL1
TTL2
TTL3
Programmable
TTL Inputs/Outputs
REL1
Programmable
Relays
TTL4

PAG E 20
P u t t i n g t h e s y s t e m i n t o o p e r a t i o n
3.6 Applications
Below you will find some example applications with MAGIC AE1 DAB+ Go.
3.6.1 MAGIC AE1 DAB+ Go connected to Ensemble Multiplexer
In the following drawing you can see MAGIC AE1 DAB+ Go connected to an
Ensemble MUX.
FIG. 6 APPLICATION: CONNECTED TO A ENSEMBLE MULTIPLEXER
Other manuals for MAGIC AE1 DAB+
2
Table of contents
Other AVT Media Converter manuals

AVT
AVT MAGIC AE4 User manual

AVT
AVT MAGIC ACX Dante WAN User manual

AVT
AVT MAGIC AE4 User manual

AVT
AVT MAGIC AE1 DAB Mounting instructions

AVT
AVT MAGIC DAB Operating and installation instructions

AVT
AVT MAGIC EEC User manual

AVT
AVT MAGIC AE1 DAB+ Mounting instructions

AVT
AVT MAGIC AE4 User manual

AVT
AVT MAGIC EEC Mounting instructions

AVT
AVT CVT-SDI-MAV User manual
