AVT MAGIC AE1 DAB Mounting instructions

MAGIC AE1 DAB
DAB Audio Encoder
Hardware/Software Manual

.

MAGIC AE1 DAB
DAB Audio Encoder
Hardware/Software Manual

A publication of:
AVT Audio Video Technologies GmbH
Nordostpark 12
D-90411 Nuernberg
Germany
Phone : [phone]
Fax: [phone]
Support : [email protected]
Printed in Germany, August 2006
© AVT Audio Video Technologies GmbH
All rights reserved. Reproduction in whole or
in parts is prohibited without the written
consent of AVT Audio Video Technologies
GmbH.
Subject to changes.
Release date: (08.06)

.

Content
Content
INTRODUCTION 11
SAFETY 13
Introduction 13
General safety requirements 13
1CONSTRUCTION15
2 SYSTEM DESCRIPTION 17
2.1 Functionality 17
3 PUTTING THE SYSTEM INTO OPERATION 19
3.1 Mounting 19
3.2 Connection to the mains voltage 19
3.3 Earthing of the system 19
3.4 Operational elements on the front side 20
3.5 Wiring diagram 21
4 OPERATION VIA DISPLAY AND KEYPAD 23
4.1 Standard functions 23
4.2 Basic configurations 23
4.2.1 Setting the Audio interface: Analogue or digital 24
4.2.2 Configuring of the ISO/MPEG Encoder 24
4.2.3 Activating and configuring the PAD interface 25
4.3 The Status Display - Operation during a connection 26
4.4 Working with Presets 27
5 WINDOWS PC SOFTWARE 29
5.1 Hardware requirements 29
5.2 Installing the Windows PC Software 29
5.3 MAGIC AE1 DAB main window 30
5.3.1 Operating elements 31
5.4 Menu file 32
5.4.1 Operation Settings Presets 32
5.4.2 Basic Settings 32
5.4.3 Submenu Exit 32
5.5 Menu Configuration 33
5.5.1 Submenu COM Port 33

Content
5.5.2 Submenu MAGIC AE1 DAB 34
5.5.2.1 Operation Settings 34
5.5.2.1.1 MPEG Parameter 34
5.5.2.1.2 PAD Interface 36
5.5.2.2 Basic Settings 37
5.5.2.2.1 General 37
5.5.2.2.2 Audio Interface 39
5.5.2.2.3 Relay / TTL 40
5.5.2.3 Login 44
5.5.2.4 Date and Time 46
5.5.3 Submenu Presets 47
5.5.3.1 Manage Presets 47
5.5.3.2 Activation of a Preset 48
5.6 Menu Administration 49
5.6.1 Submenu Registration 49
5.6.2 Submenu File System 51
5.6.3 Submenu System Panel 52
5.6.4 Submenu Software Download 53
5.6.5 Submenu Set Factory Settings 54
5.7 Menu Extras 55
5.7.1 Submenu System Monitor 55
5.8 Menu Help 57
5.8.1 Submenu About MAGIC AE1 DAB 57
A1 MENU STRUCTURE 59
A1.1 Basic Settings 60
A1.2 Operation Settings 61
A1.3 Presets 62
A1.4 Status Information 63
A1.5 Login 64
A2 INTERFACES 65
A2.1 Control and data interfaces 66
A2.1.1 DATA/CONTROL interface 66
A2.2 ISDN interface 68
A2.3 LAN interface 68
A2.4 X.21 interface 69
A2.5 TTL/RELAY interface 70
A2.6 Audio interfaces 71
A2.6.1 Analogue Audio interface 71
A2.6.2 Digital AES/EBU Audio interface 71
A2.6.3 HEADSET/MIC interface 72
A3 TECHNICAL DATA 73

Content
A4 GENERAL 75
A4.1 Ordering numbers 75
A4.2 Scope of delivery 75
A4.3 Declaration of Conformity 75
A5 SERVICE INFORMATION 77
A5.1 Software Updates 77
A5.2 Support 77
A5.3 Repairs 77
INDEX 79
DECLARATION OF CONFORMITY 83

Content

PAGE 11
Introduction
INTRODUCTION
The system MAGIC AE1 DAB is implemented as DAB Audio Encoder and has ana-
logue and digital AES/EBU audio interfaces. For monitoring each system contains
an own decoder which allows a control of the system and to asses the audio qual-
ity.
The ISO/MPEG2 Layer II audio encoder is an implementation of the IRT (Institut
für Rundfunktechnik) in Munich.
The configuration of the system can be carried out via the Windows application
included in delivery or via the front keypad and display of the unit.
English
Deutsch
Menu
Select
Back
Basic Settings
Basic Settings
Language
Language
Cap
Ok
Save settings?
Yes
No
Operation Settings
Select
Mode
ISDN
Analogue POTS
Audio
Audio Settings
Audio Settings
Audio input
Audio output
Analogue
Digital
PRETALK Interface
No system
Telephone
Handset
Delete
Opt.
ON AIR
HOLD
PRETALK
Dialling...
Callin
Beendet
Line
Ringing Tone
Search
Names
New Entry
Edit

PAGE 12
Introduction
Display
Delete entry
Save as Quick Dial
Presets
Load
New
Save
Delete Preset
Ringing Tone
Signal Processing
Keypad 9600, none
Status information
Login
Shift
Mon.
Cod
Org
MPEG Parameter
Max Mono Rate
Max LSF Rate
Mono Mode
Mono L+R/2
Mono Left
Mono Right
Stereo Mode
Stereo
Joint Stereo
Dual Channel
PAD Interface
Activate PAD
Active
Baudrate
38400
57600
115200

PAGE 13
Safety
SAFETY
Introduction
The unit described has been designed to the latest technical parameters and
complies with all current national and international safety requirements. It oper-
ates on a high level of reliability because of long-term experience in development
and constant and strict quality control in our company.
In normal operation the unit is safe.
However, some potential sources of danger for person, material and optimal op-
eration remain - especially if daily routine and technical errors coincide.
This manual therefore contains basic safety instructions that must be observed
during configuration and operation. It is essential that the user reads this manual
before the system is used and that a current version of the manual is always kept
close to the equipment.
General safety requirements
To keep the technically unavoidable residual risk to a minimum, it is absolutely
necessary to observe the following rules:
– Transport, storage and operation of the unit must be under the permissible
conditions only.
– Installation,configurationanddisassemblymustbecarriedoutonlybytrained
personnel on the basis of the respective manual.
– The unit must be operated by competent and authorised users only.
– The unit must be operated in good working order only.
– Any conversions or alterations to the unit or to parts of the unit (including soft-
ware) must be carried out by trained personnel authorised by the manufac-
turer. Any conversions or alterations carried out by other persons lead to a
complete exemption of liability.
– Only specially qualified personnel is authorised to remove or override safety
measures, and to carry out the maintenance of the system.
– Externalsoftwareisusedat one’s one risk.Useofexternal software can affect
the operation of the system.
– Use only tested and virus-free data carriers.

PAGE 14
Sicherheit
Text Conventions
In this manual the following conventions are used as text markers:
Accentuation: Product names or important terms
LCD Text : Labelling on the front display of the system
PC Text: Labelling in the PC Software
TIP
The symbol TIP marks information which facilitates the operation of the system in
its daily use.
NOTICE
The symbol NOTICE marks general notes to observe.
ATTENTION ThesymbolATTENTIONmarks very important advice that is absolutelytoobserve.
In case of non-observance disfunctions and even system errors are possible.
!

PAGE 15
Construction
1CONSTRUCTION
Thefunctions oftheMAGICAE1DABare implementedinasingle unit. Thesystem
is additionally equipped with a module for MPEG Coding. The system is designed
for mounting in a 19" rack (1 U). 19“ brackets are part of the delivery.
FIG. 1 FRONT VIEW: MAGIC AE1 DAB DAB AUDIO ENCODER

PAGE 16
Construction

PAGE 17
System Description
2SYSTEMDESCRIPTION
The functional elements of the system are pictured in Fig. 2.
FIG. 2 FUNCTIONAL ELEMENTS OF MAGIC AE1 DAB DAB AUDIO ENCODER
2.1 Functionality
The MAGIC AE1 DAB System incorporates a X.21 interface
1
for a direct connec-
tion to the e.g. DM-001 Ensemble Multiplexer from Rohde & Schwarz. The X.21
clock is derived from the Ensemble Multiplexer clock.
The complete signal processing is taken over by two digital signal processors. In
this way the following functions are realised:
DSP1:
– ISO/MPEG2 Layer II Decoder
– digital audio router
– Signalling management
– Control of the complete system (Keypad, display, relays, TTL, RS232)
– PAD multiplexer
1
The LAN interface for control & management will be supported in a later release.

PAGE 18
System Description
DSP2:
– ISO/MPEG2 Layer II Encoder
Via the main audio channel the high quality Stereo or Mono audio signal is in-
serted analogue or digitally. If the digital AES/EBU audio interface is used, two
separate Sample Rate Converters are available for automatic clock synchronisa-
tion between network and audio source. For external clocking a clock input and a
clock output are available.
The audio outputs can be used for monitoring purposes. The encoded signal is
looped at every time to the MPEG decoder. The decoded audio signal is available
as analogue or digital audio output. As second audio monitoring interface a head-
phone interface is available.
The configuration and operation can be primarily carried out via the front keypad
and the illuminated display.
Configuration and control is especially comfortable with the MAGIC AE1 DAB Win-
dows PC Software which is included in delivery and which communicates with the
system via the RS232 interface
1
.
SixprogrammableTTL contactscanbeused for external signalling. Two relaysare
available for status indication.
1
LAN control is planned.

PAGE 19
Putting the system into operation
3 PUTTING THE SYSTEM INTO OPERATION
3.1 Mounting
With its dimensions (W ×H ×D) of 431 mm ×44,5 mm (1 U) ×250 mm the
MAGIC AE1 DAB system can be used either as desktop device or mounted in 19
inch racks. Corresponding 19“ mounting brackets are included in delivery.
Whenmountingthe unit pleasekeepinmindthat the bendingradiusofthe cables
is always greater than the minimum allowed value.
When the MAGIC AE1 DAB audio encoder is installed, please make sure that
there is sufficient ventilation: It is recommended to keep a spacing of ca. 3 cm
from the openings. In general, the ambient temperature of the system should be
within the range of +5°C and +45°C. These thresholds are especially to observe
if the system is inserted in a rack. The system works without ventilation.
During operation air humidity must range between 5% and 85%.
3.2 Connection to the mains voltage
The system can be operated with mains voltages in the range from 90 V to 253 V.
The frequency can vary from 45 Hz to 65 Hz. The maximum power consumption
is 15W (typically 12W).
After plugging the mains connector and switching on the system boots within a
few seconds. In standby mode the MAGIC AE1 DAB logo is shown on the display.
3.3 Earthing of the system
For EMC reasons an earthing via the earthing screw of the system is recom-
mended.
TIP
The system temperature can be indicated on the display ( Menu Status informa-
tion
(see CHAPTER A1.4, Page 63))
ATTENTION Incorrect ambient temperature and humidity can cause functional deficiencies
Operation outside the threshold values indicated above leads to a loss of war-
ranty claim.
ATTENTION Earthing
A lacking earthing can cause functional deficiencies within the unit.
!
!

PAGE 20
Putting the system into operation
3.4 Operational elements on the front side
The system has an illuminated graphical display with a resolution of 160 x 32 Pix-
els and 19 operating buttons.
On the right next to the display thereare two softkeys whose current functions are
indicated on the display. In the middle there are two buttons for navigation (
and ), two buttons for establishing ( )/dropping ( ) connections as well
as an
OK button. The numerical pad supports in addition to the numerics 0...9 the
’
* ’ and ’ # ’ key. For text entries the numerical pad can also be used as normal key-
pad.
The operation is similar to standard mobile telephones.
FIG. 3 OPERATIONAL ELEMENTS ON THE FRONT SIDE
Softkeys Navigation
buttons/
Establish connection
Drop connection/
Main menu
Keypad for
text entry Display
shift
Confirm entry
Graphical
display
Status window
Headphone
Level
