4MP WATER-PROOF TURRET NETWORK CAMERA
QUICK START GUIDE

Warning and Caution...............................................................................................................
Package Content..................................................................................................................................
Overview...................................................................................................................................
Overview: Connecting Network Cable ..................................................................................
Network Connection.................................................................................................................
TABLE OF CONTENTS
1
2
3
4
7
Camera Installation .................................................................................................................. 5
Lorem ipsum

1
4MP WATER-PROOF TURRENT NETWORK CAMERA| AVC-ELN41AVT
1
Warning and Caution
If the product does not work properly, please contact your dealer or the nearest
service center. Never attempt to disassemble the camera yourself. (We shall not be responsi-
ble for any problems caused by unauthorized repair or maintenance.)
Do not allow water or liquid intrusion into the camera.
In the use of the product, you must be strict compliance with the electrical safety
regulations of the nation and region. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
Do not use camera beyond specified voltage range.
Do not drop the camera or subject it to physical shock.
Avoid touching the camera lens.
If cleaning is necessary, please use clean cloth to wipe it gently.
Do not aim the camera at the sun or extra bright place.
Do not place the camera in extremely hot, cold (the operating temperature shall be
-30˚C~60˚C), dusty or damp locations, and do not expose it to high electromagnetic radia-
tion.
To avoid heat accumulation, good ventilation is required for operating environment.
Please read this instruction carefully before operating the unit and keep it for
further reference.
All the examples and pictures used here are for reference only.
The contents of this manual are subject to change without notice.

Package Contents
AVC-ELN41AVT
ITEMS
DEFAULT
QUANTITY DESCRIPTION
Avycon Network Camera 1 Pc The purchased model
Quick Start Guide
CD
Drill Template
1 Pc
1 Pc
Printed material
Printed material
Tapping Screws 3 Pc Materials
1 Pc Material
Rubber Plug 1 Pc Material
Screwdriver 1 Pc Material
Plastic Plug 3Pc Material
Caution
* Do not expose the product to rain moisture
* Make sure the device is firmly fixed when mounting it on the wall or ceiling
* Make sure that the power supply voltage is correct before using ther camera
* Do not use a 3rd party Power Adapter
* Never attempt to disassemble or modify the camera
System Requirements
OPERATING SYSTEM: Windows XP / Vista / 7 / 8 / 10 / 11/ Server 2000 / Server 2008
CPU: 1.66 Ghz or Higher
RAM: 1G or Higher
Graphic Memory: 128MB or more
Internet Protocol: TCP / IP (IPv4 / IPv6)
Plastic plug x 3
DrilltemplateRubber plug ScrewdriverQuick Start Guide CD Tapping screws x3
Camera
2
4MP WATER-PROOF TURRENT NETWORK CAMERA | AVC-ELN41AVT
Thank you for purchasing this AVYCON IP Network Camera. This guide provides basic
instructions on installing and accessing this IP Network Camera. For more details, please
refer to the User Manual.

Overview
AVC-ELN41AVT
3
4MP WATER-PROOF TURRENT NETWORK CAMERA| AVC-ELN41AVT
1 Ethernet connector
2 Audio input connector
3 Power connector
4 Mounting base
5 Fixed screw
6 Microphone
7 Micro SD card slot
8 Reset
4
5
1
2
3
6
78

Overview - Connecting Network Cable
AVC-ELN41AVT
2
13
4
4MP WATER-PROOF TURRENT NETWORK CAMERA | AVC-ELN41AVT
Security Cap
DC12V
* 1,It is recommended to install the security cap for outdoor installation.
* 2, If the PoE switch is used to power the camera, DC12V power supply is not required.
Step 1: Loosen the nut from the main element.
Step 2: Run the network cable (without RJ 45 connector) through the both elements. Then
crimp the cable with RJ 45 connector.
Step 3: Connect the cable to the hermetic connector. Then tighten the nut and the main
cover.

Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of
the camera. Please install the camera under dry environment.
Step 1: Loosen the fixed screw to disassemble the camera. Then open the cover of the dome
and then insert a micro SD card. After that, install the cover back. Finally, install the dome and
enclosure to the mounting base with the fixed screw, but do not fully tighten.
Step 2: Drill the screw holes and the cable hole on the wall according to the drill template.
Camera Installation
AVC-ELN41AVT
5
4MP WATER-PROOF TURRENT NETWORK CAMERA | AVC-BLN41AVT
Cover
Insert a micro SD card
Fixed Screw
Mounting Base
Enclosure
Dome
∅130.7
∅119.5
∅4.5
120°
120°
103.5 mm
59.7mm
29.9mm
* Note: *Check whether the waterproof ring on the card slot cover is installed proper-
ly before installing the cover back.
* Please install the cover in the same way you disassemble it, so that the sealing
performance will not be affected.

6
4MP WATER-PROOF TURRENT NETWORK CAMERA | AVC-ELN41AVT
Step 3: Route and connect the cables and then secure the camera to the ceiling or wall with
the screws.
Step 4: Adjust the camera to obtain an optimum angle. Before adjustment, preview the
image of the camera on a monitor.
Step 5: After that, tighten the fixed screw.
Rubber Plug
Fixed ScrewPan: 360°
Tilt: 80°

Access through IP-Tool
Network Connection
AVC-ELN41AVT
7
4MP WATER-PROOF TURRENT NETWORK CAMERA |AVC-ELN41AVT
MENU
IPC
Network Cable Network Cable
Router
Switch
Computer
DeviceNetworkSearch
name
name
ImmediateRefresh
name
IPC
IPC
IPC
unknown
unknown
unknown
192.168.226.201
192.168.1.2
80
80
80
192.168.1.3
9008
9008
9008
255.255.
255.255.
255.255.
Modify Network Parameter
Mac Address
IP Address
Modify
CE :98 :23 :75 :35 :22
192.168. 226. 201
255. 255. 255. 0
192.168. 226. 1
i
Tip: Enter the administrator password, and
Total Device: 3
then modify the network parameters.
Device NameDevice Type IP AddressHttp PortData PortSubnet
About
Product Model
Local IP Address:192.168.1.4Subnet Mask:255.255.255.0Gateway: 192.168.1.1DNS：210.21.196.6
Subnet Mask
Gateway
Restore IPC Default Configuration
Step 1:Make sure that the camera and the PC are well connected to the local network.
Step 2: Install IP-Tool from the CD and run it after installation.
Step 3: Modify the IP address. The default IP address of this camera is 192.168.226.201. Click
the information of the camera listed in the above table to show the network information on
the right hand. Modify the IP address and gateway of the camera and make sure its network
address is in the same local network segment as the computer’s. Please modify the IP
address of your device according to the practical situation.

8
4MP WATER-PROOF TURRENT NETWORK CAMERA | AVC-ELN41AVT
For Example, if the IP address of your computer is 192.168.1.4 then the IP address of the
camera shall be changed to 192.168.1.X.
The default password of the administrator is “123456”.
The default username is admin; the default password is 123456.
Step 4: Double-click the camera listed in the IP-Tool or manually enter the IP address in the
address bar of the web browser to connect IP camera. Then follow directions to download
and install the plugin.
Step 5: Enter the username and password in the login interface.
Mac Address
IP Address
Modify
Modify Network Parameter
CE :98 :23 :75 :35 :22
192.168. 1 . 201
255. 255. 255. 0
192.168. 1 . 1
Subnet Mask
Gateway
Name:
Password:
Stream Type:
Language:
Remember me
Login
admin
1920x1080 25fps
English

1
