AWA PDVD-13609LC User manual

Before connecting, operating or adjusting this product,
please read this user's manual carefully and completely.
USER'S MANUAL
PDVD-13609LC
9" (22cm) portable DVD Player
with USB and Card Slot

Table of Contents
1
Contents
P2
Safety Precautions
P1
Table of Contents
P3-P5
Identification of Controls
P3
Main Unit
P4-P5
R emote control unit
P6-P8
SETUP Menu Setting
P6
General Setup Page
P9
Parameters and specifications
Audio Setup Page
P6-P7
P7-P8
Preference Page
Video Setup Page
P7
Password Setup Page
P8
Battery Parameters P9
P5
T ypes of Playable Discs

NNotes on Copyrights:
It is forbidden by law to copy, broadcast, show,broadcast via
cable, play in public, or rent copyrighted material without
permission.
SERIAL NUMBER:
You can find the serial number on the back of the unit.This number
is unique to this unit and not available to others.You should record
requested information here and retain this guide as a permanent
record of your purchase.
Model No. ______________________________
Serial No. ______________________________
Date of Purchase_________________________
Warning:To reduce the risk of electric shock,do not remove
the cover or back of this product.There are no user-serviceable
parts inside. Refer servicing to qualified service personnel.
2
Safety Precautions
N
Warning: when the unit using by child, parents must make sure
to let the child understand all contents in Instruction book how
battery using to guarantee using battery correctly all the time.
Warning: when find battery overheat, swell or dour, please
stop using battery and contact service centre for getting
replacement.
Warning: do not charging battery on the place of insufficient
ventilation such as: mattress, sofa, cushion , soft mat......
Warning: we will not take any responsibility if user incorrectly
use battery, not following our warning instruction label on the
battery case.
expose this product to dripping or splashing water,rain, or
moisture. Do not place objects filled with water such as vases,
on the Product.
Warning: To reduce the risk of fire or electric shock, do not
Warning: This digital video disc player employs a laser system.
Use of controls,adjustments, or the performance of procedures
other than those specified herein may result in hazardous
radiation Exposure.
Warning: To prevent direct exposure to laser beam,do not open
the enclosure.Visible laser radiation when open.
Warning: Never stare directly into the laser beam.
Caution: Do not install this product in a confined space such
as a book case or similar unit.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
charge
over
heat
40 C
strong
impact
This item incorporates copy protection technology that is
protected by U.S.patents and other intellectual property rights
of Rovi Corporation.Reverse engineering and disassembly
are prohibited.

4
1
Identification of Controls
Main Unit
Insert the battery
Remove battery during storage or when you are not using the DVD
player for a long time.
1.Open the battery door. 2.Insert two AAA size batteries.
1 2
NNOTES:
3
10. PLAY/PAUSE
11. STOP
5.MENU
13.USB
17.Power ON/OFF switch
15.Headphone out jacks
16.AV OUT
18.DC IN 9-12V
12 13 14 15 16
12.SD/MMC/MS
4.MODE
1.TFT screen
18
6.DVD/SD/USB
Select input source,DVD/Card/USB
7.UP/DOWN/LEFT/RIGHT
select an item in the menu.
when playing CD,VCD,DVD,If available
UP:previous track
Down:Next track
Left:Fast reverse
Right:Fast forward
8.VOL+
9.VOL-
14.COAXIAL
17
DC IN 9-12V
COAXIAL
USB
SD/MMC/MS
2
6
7
5
9
8
3
11
2.Speakers
3.SETUP
10

MUTE
DVD
SD/USB
SLOW
MENU
4
Remote control unit
11 9
16
5
18
8
14
21
1
2
6
7
22
23
12
20
19
13
4
3
24
15
17
10
25
26 27
Identification of Controls
1.PLAY/PAUSE
Press PLAY/PAUSE once to pause playback, pressing PLAY/
PAUSE second time will resume the playback.
2.STOP
When this buttom is pressed once, the unit records the stopped
point,from where playback will resume if ENTER is pressed after
wards. But if STOP button is pressd again instead of ENTER
button, there will be no resume function.
3.Reverse Skip
Go to previous chapter/ track to the beginning.
4.Forward Skip
Go to next chapter/ track.
5.ZOOM
: Use ZOOM to enlarge or shrink the video image.
DVD VCD
1.Press ZOOM during playback or still playback to activate the
Zoom function. The square frame appears briefly in the right bottom
of the picture.
2. Each press of the ZOOM button changes the TV screen in the
following sequence:
JPEG
: Use ZOOM to enlarge or shrink the picture.
1.Press 'ZOOM' .
2,Used " " to enlarge,or " " to shorten the picture.
Use the button to move through the zoomed picture.
6.REPEAT
Press REPEAT during playback to select a desired repeat mode.
: you can play a chapter/title/all on a disc.
VCD CD
DVD
: you can play a track/all on a disc.
: you can select shuffle/ random/ single/ Repeat one/
Repeat folder/ folder play mode on a disc.
7.A B
To repeat a segment: press AB once to set the starting point for
repeat segment, press it again to set an end point, and the player
will repeat the segment from the start to the end point.
8.PROGRAM
:The program function enables you to store your
favourite tracks from the disc. Press PROGRAM button ,then
PROGRAM MENU will appear on screen, now you can use the
number key to direct input the titles,chapters or tracks number and
select START option. TO resume normal playback, press PROGRAM
and select STOP option on the program menu.
Mp3 WMA
DVD VCD CD
VOL- VOL+
GOTO
OSD

Identification of Controls
5Turn off the power and keep AC cord pulled out from the outlet when connecting the systerm.
Remote control unit
:You can press PROGRAM repeatly to select the slide show
mode, the are 16 types slide show.
9. MUTE
Disable Audio output.
10.TITLE
Return to DVD title menu.
11.OSD
Switches the OSD language.
12.0-9 NUMBER BUTTON
Selects numbered items in a menu.
13.ENTER
Confirms menu selection.
14. MENU
Accesses menu on a DVD disc.
15.DISPLAY
To display the playtime and status information.
16.AUDIO
Press AUDIO repeatedly during playback to hear a different
audio language or audio track, if avilable.
Press AUDIO repeatedly during playback to hear a different
audio channel (Stereo, Left, or Right).
17.SUBTITLE
Press SUBTITLE repeatedly during playback to hear a different
subtitle languages.
18.ANGLE
Press ANGLE will change the view angle, on DVDs that support this
feature.
19.SETUP
Accesses or removes setup menu.
20.10+ BUTTON
In order to select a track 10 or greater, first press 10+, For example;
select track 12, first press 10+, and then press number 2 button.
21.STEP
Press STEP once to pause playback, Form this station, press STEP
to advance one video frame.
22. BUTTON
Press BUTTON allow skipping back at 5-level speed(X2->X4->
X8->X16->X32), press ENTER button return to normal playback.
23. BUTTON
Press BUTTON allow skipping ahead at 5-level speed(X2->X4->
X8->X16->X32), press ENTER button return to normal playback.
24. PBC
PBC on/off switch. Only for VCD, For other discs, the function
is invaild.
25.SLOW
Press Slow button repeatedly to enter slow playback, and cycle
between different speeds. The speeds are 1/2,1/4,1/8,1/16,and
normal.
26.GOTO
Goto time point , title or chapter you want in DVD Mode.
27.DVD/SD/USB
DVD/CARD/USB.
JPEG
DVD
VCDCD
_________________________________________
_________________________________________
_________________________________________
_________________________________________
_________________________________________
Video CD (VCD)
(8 cm / 12 cm disc)
DVD
(8 cm / 12 cm disc)
Audio CD
(8 cm / 12 cm disc)
In addition, this unit plays , DVD -R, DVD +R,DVD -RW,DVD +RW,
Kodak Picture CDs, SVCD, and CD-R / CD-RW that contains audio
titles,MP3, WMA,JPEG and DivX files.
Types of Playable Discs

SETUP Menu Setting
General Setup Page
6
OSD Language
You can select your own preferred language seetings.
Wide Squeeze: Set screen mode to 4:3.
Angle Mark
Displays current angle setting information on the right hand corner
of the TFT screen if available on the disc.
Closed Captions
Closed captions are data that are hidden in the video signal of some
discs.Before you select this function,please ensure that the disc
contains closed captions information and your TV set also has this
function.
Screen Saver
This function is used to turn the screen saver On or Off.
Audio Setup Page
Audio Setup Page
-- --
DOWNMINX STR
DIGITAL OUTPUT RAW
DOLBY DIGITAL
LT/RT
STEREO
SPDIF/OFF
SPDIF/RAW
SPDIF/PCM
DUAL MONO
DYNAMIC
STR STR
L-MONO
R-MONO
MIX-MONO
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
FULL
OFF
-
Press SETUP button to get the setup menu. Use direction buttons
to select the preferred item. After finishing settings, press
SETUP again to normal display.
The following menu items can be changed:
GENERAL: selects the GENERAL PAGE menu.
AUDIO: selects the AUDIO PAGE menu.
VIDEO: selects the VIDEO PAGE menu.
PREFERENCE : selects the PREFERENCE PAGE menu.
PASSWORD: selects the PASSWORD PAGE menu.
General Setup Page
- - GENERALSETUP PAGE - -
GOTO GENERAL SETUP PAGE
TV DISPLAY WIDE
ANGLE MARK ON
OSD LANGUAGE ENG
CLOSED CAPTIONS ON
SCREEN SAVER ON
4:3 PANSCAN
4:3 LETTERBOX
16:9
WIDE SQUEEZE
ON
OFF
ENGLISH
FRENCH
GERMAN
ITALIAN
SPANISH
PORTUGUESE
ON
OFF
ON
OFF
TV DISPLAY: selects the aspect ratio of the playback picture.
4:3 PANSCAN: if you have a normal TV and want both sides of the
picture to be trimmed or formatted to fit your TV screen.
4:3 LETTERBOX: if you have a normal TV. In this case, a wide picture
with black bands on the upper and lower portions of the TV screen will
be displayed.
16:9:wide screen display.
- - - -AUDIO SETUP PAGE
GO TO AUDIO SETUP PAGE

SETUP Menu Setting
7
Video Setup Page
Video Setup Page
- - VIDEO SETUP PAGE - -
GOTO VIDEO SETUP PAGE
SHARPNESS MID
BRIGHTNESS 00
CONTRAST 00
HUE 00
SATURATION 00
VIDEO INVERSE
HIGH
MEDIUM
LOW
Sharpness,Brightness,Contrast,Hue,Saturation:setting the video
quality.
Preference Page
Preference Page
- - PREFERENCE SETUP PAGE - -
GOTO PREFERENCE PAGE
TV TYPE PAL
AUDIO ENG
SUBTITLE ENG
DISC MENU ENG
PARENTAL
DEFAULT
PAL
AUTO
NTSC
OTHERS
ENGLISH
FRENCH
GERMAN
SPANISH
ITALIAN
PORTUGUESE
OTHERS
ENGLISH
FRENCH
GERMAN
SPANISH
ITALIAN
PORTUGUESE
OTHERS
ENGLISH
FRENCH
GERMAN
SPANISH
ITALIAN
PORTUGUESE
1 KID SAF
2 G
3 PG
4 PG13
5 PGR
6 R
7 NC17
8 ADULT
RESET
TV Type
Selecting the colour system that corresponds to your TV when AV
outputs.This DVD Player is compatible with both NTSC and PAL.
Downmix
This options allows you to set the stereo analog output of your
DVD Player.
Audio Setup Page
LT/RT :Select this option if your DVD Player is connected to a
Dolby Pro Logic decoder.
Stereo :Select this option when output delivers sound from only
the two front speakers.
Digital Output
The function is used to select the SPDIF Output:SPDIF Off,SPDIF
/RAW,SPDIF/PCM.
SPDIF Off: Turns off the SPDIF output.
SPDIF/RAW: If you have connected your DIGITAL AUDIO OUT
to a multi-channel decoder/receiver.
SPDIF/PCM: Only if your receiver is not capable of decoding
multi-channel audio.
Dolby digital
The options included in Dolby Digital Setup are: and
'Dynamic '.
'Dual Mono '
Dual Mono
Stereo:Left mono sound will send output signals to Left speaker
and Right mono sound will send output signals to Right speaker.
L-Mono:Left mono sound will send output signals to Left speaker
and Right speaker.
R-Mono:Right mono sound will send output signals to Left speaker
and Right speaker.
Mix-Mono:Left and Right mixed mono sound will send output
signals to Left and Right speakers.
Dynamic
Dynamic range compression.
OFF
Video Inverse:setting TFT screen display inverse on or off.

SETUP Menu Setting
8
Password: select the menu password change page.
Password Setup Page
OLD PASSWORD
NEW PASSWORD
CONFIRM PWD
OK
OLD PASSWORD: Enter the OLD password, (Factory setting is
1369), and the cursor will jump automatically to
NEW PASSWORD
.
NEW PASSWORD: Enter the NEW password. Enter 4 digits from
the remote control unit numeric buttons, and the
cursor will automatically jump to CONFIRM PASSWORD.
CONFIRM PASSWORD: Confirm the NEW password by entering
it again. If the confirmation is incorrect, the cursor
will stay in this column. After entering, the correct new password
again, the cursor will jump automatically to OK.
OK: When cursor is on this button, press ENTER key to confirm
setting.
PAL - Select this if the connected TV is PAL system.It will change the
video signal of a NTSC disc and output in PAL format.
NTSC-Select this if the connected TV is NTSC system.It will change
the video signal of a PAL disc and output in NTSC format.
Auto:Chang the video signal output automatic according to the
playing disk format.
Preference Page
Audio:Selects a language for audio (if available).
Subtitle:Selects a language for subtitle (if available).
Disc Menu:Selects a language for disc menu (if available).
Parental
Some DVDs may have a parental level assigned to the complete disc
or to certain scenes on the disc.This feature lets you set a playback
limitation level.The rating levels are from 1 to 8 and are country
dependent. You can prohibit the playing of certain discs that are not
suitable for your children or have certain discs played with alternative
scenes.
Default:Back to the factory setting.
Password Setup Page
Password Setup Page
- - PASSWORD SETUP PAGE - -
GOTO PASSWORD SETUP PAGE
PASSWORD MODE ON
PASSWORD
ON
OFF
Password mode: Set password mode on/off. If set to off, change
parental level will not check password.
Note: If the password has been changed, the parentaland disc
lock code will also be changed.
The default password(1369)is always active even the password
has been changed.
N

9
Parameters and specifications
Item Standard requirement
Output
Audio :Speaker:1WX2, output, Coaxial outputHeadphones
Electronical parameters
VIDEO OUT
AUDIO OUT :1.4 Vrms (1 KHz, 0 dB)
Power requirements
Power consumption
Dimensions (Approx.)
Weight (Approx.)
Operating humidity
: 260(L)X182(W)X37.5(H)MM
: <10W
: 0.9KG
: 5 % to 90 %
System
Laser :Semiconductor laser, wavelength 650 nm
Signal system : NTSC / PAL
Frequency
response
Signal-to-noise ratio :More than 80 dB (ANALOG OUT connectors only)
Dynamic range :More than 85 dB (DVD/CD)
Accessories
Note: Design and specifications are subject to change prior notice.
N
:Video/Audio cable,Remote control,
Stereo headphone,Rechargeable battery,
Car cigarette Adapter,car Bag
: 20Hz to 20 kHz(1dB)
Battery Parameters
Battery Specifications：
Output：DC 7.4V
Charge / Discharge Time：
Standard charge time：3h ~ 4h
Storage and work circumstances：
1. Storage circumstances Temperature Humidity
2.Work circumstances Temperature Humidity
6 months -20 C +45 C~
-20 C +65 C~
65+20%
65+20%
Standard charge
Standard discharge
0 C +45 C~
-20 C +65 C~
65+20%
65+20%
1 week
Battery Parameters
: 9-12V 1.5A
