Awenta COSY CM100 User manual

EN
Operation and assembly
manual should be carefully
read and kept at hand to be
referred to at any time.
NOTICE: Safety guidelines:
•
Do not use the device against
its intended use.
•
The device may be used only with closed sources of heat which do not
generate harmful substances, exhaust etc. (closed fireplace or furnace)
•
The assembly of the ventilator should be performed only by a specialist
electrician bearing in mind regulations concerning the installation.
•
Electrical installation must be equipped with a switch in which the distance
between contacts is at least 3 mm.
•
Before commencing the assembly and doing maintenance switch off the
power of the device and secure from undesirable switching on.
•
Ventilators of this series of types are meant only for household use and
similar; do not use for business activity and/or industrial purposes.
•
During preparation of the electrical installation and assembly of the devices
observe domestic regulations concerning the installation.
•
Ventilators are meant to work at air temperature from 0 to 40 °C.
•
Assembly height of the ventilator should be at least 2,3 m above the floor.
•
It is forbidden to use the ventilator in a situation where there is a danger of
foreign bodies entering the ventilator air stream. They may damage the rotating
parts or even lead to the ventilator jamming.
•
Ventilator should be assembled in ventilation ducts free from exhaust and
other gases, as well as aggressive factors.
•
Adequate measures should be taken to prevent reverse flow of gases to a
room from an open ventilation duct or other devices with open fire!
•
These devices are not meant to be operated by persons (including children)
with limited manual, sensual or intellectual abilities or persons who do not have
experience and/or have sufficient knowledge, unless they remain under
supervision of a person responsible for their safety or are trained by that person
to operate these devices.
COSY CM100
Operation and
assembly manual.

•
It is forbidden to mount ventilators in vertical positions „in the ceiling, roof”
with direct air exhaust to the outside.
The set is composed of:
- exhaust fan (Awenta Classic WC100 series)
- thermostat
- section of ventilation duct (Ø100, 200 mm long)
- air grate
COSY is used for hot air distribution. The product should be installed close to a
heat source such as a replace (closed) or wood burning furnace (picture 1).
A programmed thermostat will activate the exhaust fan which shall distribute the
hot air an adjacent room. The ventilator will switch o once the temperature drops
in the room with the heat source.
SET DIMENSIONS
thermostat
ventilator
min. 50 cm
min. 1,5 m
min. 2,3 m
Pic. 1
155 13 15
103
200 170
170
155

COMPOSITION OF THE SET
1 – ventilator front
2 – screw
3 – central body part cover
4 – ventilator body
5 – central part of the
body
6 – connection block
7 – opening for power lead
8 – part of ventilation duct
9 – ventilation grate body
10 – ventilation grate front
11 – thermostat cover
12 – thermostat
13 – thermostat handwheel
TECHNICAL DATA FOR THE VENTILATOR
- feed: 230V
- nominal frequency: 50Hz
- power: 7W
- capacity: 60m³/h
- protection rating: IPX4
345
8
910
1
2
67
Spot for a wire
Mounting holes

Wall thickness
min. 100 mm
Wall thickness
max. 240 mm
ventilation
grate
ventilation
grate
adjacent
room
adjacent
room
room with
heat source
room with
heat source
hot air
exhaust direction
hot air
exhaust direction
ventilator ventilator
INSTALLATION AND ASSEMBLY
The set has to assembled following the rules below:
- the ventilator needs to be in a room where the replace or wood-burning furnace
is
- the ventilator and thermostat should be placed in the distances as in picture 1
- the adjacent room may be living room, dining room, bedroom, study room or a
corridor
- it is not recommended to use the product if the adjacent room to which heat
would be transferred is kitchen, pantry, bedroom, bathroom, toilet
- ensure power source
- ventilation duct must be inside the wall separating the room with the replace
from the adjacent room (i.e. the room which is to receive the hot air)
- the wall through which the duct runs should measure at least 100 mm and no
more than 240 mm. If the wall is thicker than 240 mm the customer needs to
purchase ventilation duct of suitable length.
- mount the ventilation grate in the adjacent room to end ventilation duct
- make a hole in the wall and place the duct in horizontal position
- seal the duct
- after the seal dries, mount the ventilator and ventilation grate
- t thermostat mounting
- remove thermostat cover (11) using a screwdriver and mark points on the wall for
mounting
- prepare electrical connection according to the directions found in ‘Electrical
connection’section
- put the cover in place (11)

ELECTRICAL CONNECTION
NOTICE !!!
Connection to power grid should be done by a qualified electrician with
appropriate license.
Electrical installation must include a switch in which the distance between
contacts of all poles is no less than 3 mm. The installation must be made with
the power turned off!!!
Connecting the ventilator:
- remove the front (1) and cover of the central part of the body (3)
- move the power lead using the hole in the body of the ventilator (7)
- place the lead in the connection block (6) keeping in mind the picture below
Connecting the thermostat:
- lead the conductor to the back part of the thermostat base (12) as in the picture
below
MODE OF USE
The ventilator starts operating once the thermostat is turned (13).
Programme the desired temperature according to the scale 0C.
MAINTENANCE
•
Before beginning maintenance, switch o the power.
Maintenance must be performed at least one a year by a qualied electrician.
L
143 N
VENTILATOR
THERMOSTAT
PHASE
NEUTRAL
