Fanaway CLASSIC User manual

V2.0 –EN –AU WS Classic ( 07/ 2018)
FANAWAY CLASSIC
CEILING FAN
INSTALLATION
OPERATION
MAINTENANCE
WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.

Fanaway Classic Installation Instructions
2 | P a g e
THANK YOU FOR PURCHASING
Thank you for purchasing this quality Fanaway product. To ensure correct function and safety, please
read and keep all instructions before using the product.
SAFETY PRECAUTIONS
1. In Europe: This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the appliance in a safe way and
understand the hazards involved. Cleaning and maintenance shall not be undertaken by children
without supervision.
2. In Australia: The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless theyhave been
given supervision or instruction concerning the use of the appliance by a person responsible for their
safety.
3. Children should be supervised to ensure that they do not play with the appliance.
4. An all-pole disconnection switch must be incorporated into the fixed wiring, in accordance with local
wiring rules.
IN AUSTRALIA
WARNING:
FOR SAFE USE OF THIS FAN AN ALL-POLE DISCONNECTION
MUST BE INCORPORATED INTO THE FIXED WIRING IN
ACCORDANCE WITH THE WIRING RULES.
As outline in clause 7.12.2 of AS/NZS 60335-1 for meeting the
minimum electrical safety of this standard.
Please note warranty will be void if installation is without a means
for an all-pole disconnection incorporated in the fixed wiring in
accordance with the wiring rules.

Fanaway Classic Installation Instructions
3 | P a g e
Example: If a fan is connected to a circuit that can be isolated via an
all-pole safety switch at the switchboard, then this is considered to
be an all-pole disconnection to the ceiling fan electrical circuit,
meeting the requirements of clause 7.12.2 of AS/NZS 60335.1.
A single-pole switch on the active of the receiver input of remote
control must also be included in the wiring, and located the
same room as the ceiling fan.
5. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection
facilities. Contact your local government for information regarding the collection systems available. If
electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the
ground water and get into the food chain, damaging your health and well-being.
6. The structure to which the fan is to be mounted must be capable of supporting a weight of 50kg.
7. The fan should be mounted so that the blades are at least 2.3m above the floor in Europe or 2.1m
above the floor in Australia.
8. This fan is designed for indoor use only. Mounting the fan in a location where it is subject to water or
moisture is dangerous and will void the warranty.
9. Only a licensed electrician should execute the installation.

Fanaway Classic Installation Instructions
4 | P a g e
BEFORE INSTALLATION
Unpack your ceiling fan and carefully identify the parts. Please refer to Fig 1.

Fanaway Classic Installation Instructions
5 | P a g e
Fig. 1

Fanaway Classic Installation Instructions
6 | P a g e
1
Mounting bracket x 1
10
Retraction mechanism x 1
2
Canopy screws x 4
11
Lamp base x 1
3
Canopy x 1
12
Lamp shade x 1
4
Down rod x 1
13
Light kit x 1
5
Bolt and pin cover x 1
14
Light kit screw x 3
6
Bolt x 1
15
Wooden screw x 2
7
Pin x 1
16
Wall swtich x 1 set
8
Top housing x 1
17
9
Blades x 4
INSTALLING THE MOUNTING BRACKET
The ceiling fan must be installed in a location so that the blades are a minimum 300mm spacing from
the tip of the blade to the nearest objects or walls.
Secure the hanging bracketto the ceiling joist or structure that is capable of carrying a load of at least
50kg, with the two long screws provided. Ensure at least 30mm of the screw is threaded into the
support.
NOTE: The bracket screws provided are for use with wooden structures only. For structures
other than wood, the appropriate screw type MUST be used.
Angled Ceiling Installation
This fan hanging system supports a maximum 15 degree angled
ceiling installation.
Fig. 2
Fig. 3

Fanaway Classic Installation Instructions
7 | P a g e
INSTALLING THE FAN
Installing the down rod
1) Feed the down rod (5) through the canopy (4) and the bolt and pin cover (6).
2) Remove the ball joint (2) by loosening the set screw (3), insert the motor wires through the down
rod then secure the ball joint back to the down rod.
3) Insert the down rod to the coupling (7), line up the coupling holes with the down rod holes and
insert the bolt (8). Then insert the pin (9) to the end of the bolt.
4) Finally secure the down rod and coupling by tightening the two set screws (10) on the coupling.
Fig. 4
HANGING THE FAN
Lift the fan assembly onto the mounting bracket. Ensure the registration slot (A) of the hanger ball is
positioned on the stopper (B) of the mounting bracket (C) to prevent the fan from rotating when in
operation. (Fig.5)
Fig. 5
Fig. 4

Fanaway Classic Installation Instructions
8 | P a g e
FAN INSTALLATION
Light kit installation
1. Loosen the screw (1) from the lamp shade bracket (3). Align the two slot screws (2) with the keyhole
slots of the lamp shade (4). Fig.6
2. Turn the lamp shade counterclockwise until the slot screws are firmly at the end of the slots.
3. Secure screw 1 back to the lamp shade bracket. Tighten all three screws. Do not over-tighten.
4. Connect the plugs (8) together.
5. Loosen the screw (5) from the lamp shade (4). Align the two slot screws (6) with the keyhole slots of
the light kit (7). Fig.7
6. Turn the light kit counterclockwise until the slot screws are firmly at the end of the slots.
7. Secure screw 5 back to the lamp shade. Tighten all three screws. Do not over-tighten.
8. Install the globes (Not included) to the lamp holders.
Fig. 6
Fig. 7

Fanaway Classic Installation Instructions
9 | P a g e
ELECTRICAL WIRING DIAGRAM
WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A
LICENSED ELECTRICIAN.
NOTE: AN ADDITIONAL ALL POLE DISCONNECTION MUST BE INCORPORATED IN THE FIXED
WIRING IN ACCORDANCE WITH THE WIRING RULES.
USE WITH WALL SWITCH WIRING DIAGRAM:
USE WITH REMOTE WIRING DIAGRAM: (REMOTE sold seperately)
1/ Remote without plugs
Fig. 9
Fig. 10

Fanaway Classic Installation Instructions
10 | P a g e
2/ Remote with plugs
FINISHING THE INSTALLATION
After completing the electrical connection at the mounting bracket terminal block, connect the ceiling
fan wiring via the quick connector plug.
Cover the mounting bracket with the canopy. Ensure all electrical wiring is tucked inside the canopy
and that the wires are not damaged during this step. Secure the canopy to the hanger bracket using
the screws provided.
Fig. 12
Fig. 11

Fanaway Classic Installation Instructions
11 | P a g e
USING YOUR CEILING FAN
FAN WALL CONTROL
Turn on the power and check the operation of the fan.
• OFF Position – Fan Off
• 3rd Position – Low fan speed
• 2nd Position – Medium fan speed
• 1st Position – High fan speed
Light Control
• Toggle Switch – ON / OFF
REVERSING SWITCH
Your ceiling fan can operate in either summer or winter mode.
SUMMER Mode: The reverse switch should be in the “LEFT” (SUMMER) position to rotate the fan in an
anticlockwise direction. The airflow will be directed downwards, for cooling in summer.
WINTER Mode: The reverse switch should be in the “RIGHT” (WINTER) position to rotate the fan in a clockwise
direction. The airflow will be directed upwards assisting in the circulation of warm air, for energy conservation in
winter.
Fig. 13
Fig. 14

Fanaway Classic Installation Instructions
12 | P a g e
AFTER INSTALLATION
WOBBLE:
NOTE: ceiling fans tend to move during operation due to the fact that they are mounted on a rubber
grommet. If the fan was mounted rigidly to the ceiling it would cause excessive vibration. Movement of a
few centimetres is quite acceptable and DOES NOT suggest any problem.
TO REDUCE THE FAN WOBBLE:
Please check that all screws which fix the mounting bracket and down rod are secure.
NOTE: This fan has been precision balanced at the factory and will not need to be balanced again.
NOISE:
When it is quiet (especially at night) you may hear occasional small noises. Slight power fluctuations and
frequency signals superimposed in the electricity for off-peak hot water control, may cause a change in
fan motor noise. This is normal. Please allow a 24-hour “breaking-in” period, most noises associated with
a new fan disappear during this time. Please note that this is not a product fault and as such is not covered
under warranty –All electric motors are audible to some extent.
CARE AND CLEANING:
Periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint free
cloth to avoid scratching the paint finish. Please turn power off when you do so.
Do not immerse your ceiling fan in the water. It could damage the motor or the blades and create the
possibility of an electrical shock.
Ensure that the fitting does not come in contact with any organic solvents or cleaners.
To clean the fan blade, wipe with only a damp clean cloth with NO organic solvents or cleaners.
The motor has a permanently lubricated ball bearing so there is no need to oil.
NOTE: Always turn off the power at the mains switch before attempting to clean your fan.
TECHNICAL INFORMATION
FAN models
Rated Voltage
Rated power (motor)
Light power
FANAWAY Classic Fan
220-240VAC
60W
3 X Max. 25W , E27

Fanaway Classic Installation Instructions
13 | P a g e
Warranty
THIS WARRANTY IS VALID IN AUSTRALIA ONLY
Note:
Please complete the following details when you have unpacked the product and retain this card with the purchase
invoice or sales docket.
Warranty
These products are covered by a Warranty in addition to all rights available to you by statute. The Warranty is for a
period of twentyfour (24) months from the date of purchase, subject to the following conditions. Fanaway undertakes,
at its option, to repair or replace, free of charge, each product or part thereof subject to the following conditions. The
conditions abovementioned are:
1. That the purchaser carefully follows all instructions provided and complies with electrical wiring regulations;
2. That the purchaser carefully follows the installation instructions provided in the owner’s handbook relating to
the proper use and care of the product and does not use the product for any purpose other than the domestic
use for which it has been designed;
3. That the product was purchased and is installed in Australia;
4. That this Warranty does not extend to:
A. Optional light diffusers
B. Light globes
C. Damage to plastic light dome caused by inappropriate cleaning
D. Damage to surface coatings caused by cleaning or maintenance using inappropriate cleaning products
E. Defects caused by normal wear and tear, accident, negligence, alteration or misuse;
F. Aproduct dismantled, repaired or serviced by any serviceman other than an authorized employee or agent
of Fanaway
G. Product installed by an unqualified person. Must be a qualified electrician in Australia
H. Damage or defects caused by fans being installed externally.
(FANS ARE DESIGNED FOR INDOOR USE ONLY).
5. The provisions of this warranty do NOT apply to other Ceiling Fans.
6. The provision of service under this Warranty is limited by the boundary of the nearest service agent’s area.
Traveling cost incurred for the service outside this area is not covered by this warranty and will incur commercial
cost to be paid by the customer regulated by the number of kilometers traveled beyond the service area.
7. The cost associated with the hire of extension ladders and scaffolding to service fans installed on ceilings
greater than 3 meters will not be covered by this warranty. Such costs will be borne by the customer.
In the event of a service being required, please call the Lucci Warranty Service Hotline acting as the service agent

Fanaway Classic Installation Instructions
14 | P a g e
for Fanaway on 1800 602 243 between 9AM and 5PM (E.S.T) Monday to Friday. Ensure you have the following
details on hand. If you are unable to establish the date of purchase, or the fault is not covered by this Warranty, or
if the product is found to be in working order, you will be required to bear all service call charges.
PRODUCT TYPE: ......................................................
MODEL NUMBER: .....................................................
SERIAL NUMBER: .....................................................
DATE OF PURCHASE: ..............................................
INVOICES/SALES DOCKET NO: ..............................
PURCHASER’S NAME: .............................................
PURCHASER’S ADDRESS: ......................................
RETAILER’S/DEALER’S NAME: ...............................
RETAILER’S/DEALER’S ADDRESS: ........................
INSTALLED BY: …………………………………………
LICENCE NUMBER OF INSTALLER: …………………
PHONE NUBER OF INSTALLER: ……………………..
DESCRIPTION OF FAULT: …………………………….
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
CONTACTS:
Contact Lucci Warranty Service Hotline acting as the service agent for Fanaway on 1800 602 243 between 9AM
and 5PM (E.S.T) Monday to Friday, or go to Website: www.fanaway.com for more information.
Distributed by:
Beacon Lighting
140 Fulton Drive
Derrimut, Victoria, 3030
Australia
Ph [phone]
Fax [phone]
Email: [e-mail]
