Axent One User manual

USER MANUAL

ENGLISH EN PAGE 
We appreciate your choice of a product from AXENT. To fully benefit from
the options offered by this product please read this User Guide before use
and save it for future reference.
DEUTSCH DE SEITE 
Herzlichen Glückwunsch und vielen Dank für die Wahl eines Produktes von
AXENT. Um alle Möglichkeiten des Produktes kennen zu lernen, empfehlen
wir Ihnen, diese Bedienungsanleitung zu lesen und für den späteren
Gebrauch aufzubewahren.
FRANÇAIS FR PAGE 
Félicitations pour l’acquisition de notre produit AXENT. Afin de bénéficier
pleinement des possibilités offertes par ce produit, il est recommandé
de lire attentivement cette manuel de l’utilisateur avant utilisation et de la
conserver comme référence.
ITALIEN IT PAGINA 
Congratulazioni e grazie per aver scelto un prodotto AXENT. Per imparare
a conoscere tutte le funzioni LED prodotto, si consiglia di leggere il manuale
e di conservarlo per future consultazioni.
NEDERLANDS NL PAGE 
Van harte feliciteert met uw keuze voor een product van AXENT. Om
optimaal gebruik te maken van alle mogelijkheden die dit product biedt,
raden wij u aan deze informatie goed door te lezen, voordat u het product
gaat gebruiken. Bewaar deze gebruikshansleiding als naslagwerk.
www.axentbath.ch

1
EN
SAFETY 
INTRODUCTION 
REMOTE CONTROL 
APP 
OPERATION AND FUNCTION 
COMFORT FUNCTIONS AXENT.ONEPLUS 
SETTINGS 
SETTINGS AXENT.ONEPLUS 
CLEANING AND CARE 
MALFUNCTIONS DURING OPERATION 
ENVIRONMENT 
END USER WARRANTY 
TECHNICAL DATA 
EN
USER MANUAL
AXENT.ONE AND AXENT.ONE PLUS

2EN
APPROPRIATE USE
The AXENT shower toilet is designed for anal and genital
cleansing. Not included are other purposes deemed improper.
AXENT does not accept liability for the consequences of
improper use or installation.
OPERATION
As a functioning toilet, the AXENT shower toilet is suitable for all
age groups. However, children must not carry out cleaning or
maintenance work without supervision.
Each person perceives temperatures individually; therefore
check the water, Air Dryer and Seat temperature before use.
BATTERIES
–Batteries can be life-threatening if swallowed. Therefore keep
batteries out of the reach of small children. If a battery has
been swallowed, call for medical assistance immediately.
–Batteries may not be recharged, reactivated by other means,
dismantled, exposed to fire or short-circuited.
–Always remove discharged batteries from the remote control
immediately, because they may leak and cause damage.
–Remove the batteries if you do not intend to use the remote
control for a longer period.
–Clean the battery and contacts before inserting the battery.
Note the proper polarity.
–Do not expose the batteries to extreme conditions. Batteries
must not be set down on hot surfaces or exposed to direct
sunlight. Otherwise there is a risk of leakage.
–If battery acid has leaked out, avoid contact with skin, eyes
and mucous membranes. In case of contact with the acid,
flush the affected areas with large amounts of clean water and
consult a doctor immediately.
–Do not insert new and old batteries together in the remote
control.
USE
This user manual corresponds to the state of the device
technology at the time of printing. AXENT reserves the right
to make changes in terms of further development. This
documentation is also subject to change. A current version of
this document and additional documents can be downloaded
via www.axentbath.ch
SAFETY INSTRUCTIONS
Do not take a damaged device or main connection cables into
operation. Connect the device only to an earthed electrical
voltage as specified on the type label. For further information
please refer to the technical data sheet.
The original hose-sets supplied with the appliance shall be used.
The old hose-sets should not be re-used.
Check regularly that all functions are working normally. If you
suspect a fault, disconnect the shower toilet from the mains
power supply immediately and contact AXENT customer
service.
Do not open and repair the unit yourself or install it. Never modify
the device or add any additional modules.
The AXENT shower toilet carries live parts and opening it
exposes those present to fatal danger!
Repairs done by not skilled or authorised persons can lead to
malfunction, damage and dangerous accidents. Therefore
repairs may only be carried out by authorised and trained
persons using original spare parts and accessories. Only
standard accessories, original spare parts and the delivery
included main connection cable may be used.
Do not make any modification on the main connection cable.
Should it be damaged, it must be replaced by AXENT customer
service.
In case of malfunction during operating consult the basic
information at the point Troubleshooting. If required contact
customer service.
Operation and maintenance work may only be performed by the
operator or user as described in these operating instructions.
For the use of AXENT shower toilet only drinking water may be
used no rain nor grey water
SAFETY

3
EN
SAFETY
CLEANING
Cleaning and care must be followed according to the cleaning instructions (page 14).
No liability is accepted in the event of non-compliance.
Every 4 months, the night light flashes red to let you know that all parts in contact with water
need to be descaled.
Once you have run the descaling programme (page 15), the night light resets itself to the
previously set mode.
LEGAL DIRECTIONS
This manual contains important information on the intended use, correct operation and proper maintenance of the equipment.
Knowledge and compliance with the instructions of this manual are provided for both the safe use of the equipment and for the safety
of its operation and maintenance. In this manual, not all kinds of applications and improper manipulations are considered. In addition,
attention is drawn to the following: The content of these instructions is neither part of any previous or existing agreement, commitment
or legal relationship, nor does it change from an existing agreement, commitment or legal relationship. Any commitment by AXENT
results from the respective warranty. These include the complete and authoritative warranty obligation AXENT. The statements in
this manual do not constitute an extension or a restriction of the claims under the warranty provisions. This manual is protected by
copyright. Copies and / or translations into other languages may be made only with prior written approval of AXENT.
PLEASE KEEP THIS USER MANUAL SAFE
A current version of this document and additional documents can be downloaded
via www.axentbath.ch
TOILET SEAT AND LID WITH LOWERING FUNCTION
Dampers cushion the toilet seat and lid noiselessly and slow down closing. The seat and lid
open just like any normal toilet seat and lid.
Do not press the toilet seat and lid down with your hand. This will damage the dampers.
The maximum static loading capacity of seat is 150 kg.

4EN
INTRODUCTION
Two versions of the shower toilet are available.
AXENT.ONE
The shower toilet cleanses the anal area (rear wash) and the lady wash also cleanses
thegenital area. The water temperature, flow rate of the shower spray, and spray arm position
are adjustable. Individual user profiles can be programmed.
AXENT.ONEPLUS
The PLUS version offers additional comfort functions such as seat heating, Air Dryer,
Deodorizer, User detection and Massage functions.
AXENT REMOTE CONTROL
The shower toilet is controlled via the remote control or via the smartphone app.
On delivery, the remote control comes with a magnetic bracket and fastening materials
(double-sided adhesive tape) for wall mounting. The small screw also supplied is used for fixing
the remote control to the wall bracket.
Position the remote control bracket in such a way that you can reach it comfortably while sitting
on the shower toilet.
Standby mode
If the remote control is not used for a while, it automatically switches to standby mode and
all LEDs switch off.
To exit Standby mode, press any icon.

5
EN
AXENT.ONE
AXENT.ONEPLUS
REMOTE CONTROL
AXENT.ONEPLUS
AXENT.ONE
Rotating Ring
AXENT logo
LED display
AXENT logo
LED display
Lady Wash
User Profile
Temperature
Water temperature
Lady Wash
Air Dryer
User Profile
Temperature
Water temperature
Seat temperature
Air Dryer temperature
Rear Wash
Spray Arm position
Water volume
Stop
Rear Wash
Massage
Spray Arm position
Water volume
Stop
Rotating Ring

6EN
APP
BLUETOOTH
You can switch off Bluetooth if you do not wish to use this function.
Remote control settings mode is active (see page 10).
1. Press and hold Lady Wash and press Rear Wash
2. Stop - flashes slowly Bluetooth is enabled.
- flashes quickly Bluetooth is disabled.
Factory setting: Bluetooth is enabled.
APP AXENT REMOTE
The AXENT.ONE shower toilet can be controlled via Bluetooth using the app for iOS and
Android.
As with the remote control, you can use it to individually adjust the water temperature, flow rate
and spray arm position.
AXENT Remote – Download the app free of charge from
the App Store or Google Play.
Please register your product via app.

7
EN
31° 39°
OPERATION AND FUNCTION
EVERYDAY USE
To clean intimate areas with water, press Rear Wash or Lady Wash. The spray arm extends
and cleans you with a gentle spray of water. The water has a pleasant temperature. The water
temperature and position and intensity of the shower spray can be individually adjusted.
REAR WASH
You are sitting on the shower toilet.
1. Press Rear Wash and the shower process is started.
2. Press Stop to stop the rear wash.
The rear wash will stop automatically after continuous usage of 3 minutes.
LADY WASH
You are sitting on the shower toilet.
1. Press Lady Wash and the shower process is started.
2. Press Stop to stop the lady wash.
The lady wash will stop automatically after continuous usage of 3 minutes.
WATER TEMPERATURE
You are sitting on the shower toilet and the shower function is active.
Temperature and Water temperature light up.
1. Turn the rotating ring
- clockwise the temperature is increased
- counter-clockwise the temperature is reduced
2. The set temperature can be viewed on the LED display.
3. If the LED lights are off, the water temperature is cold.

8EN
OPERATION AND FUNCTION
WATER VOLUME
You are sitting on the shower toilet and the shower process is active.
1. Press Water volume
2. Turn the rotating ring
- clockwise the Water volume is increased
- counter-clockwise the Water volume is reduced
3. The chosen flow rate can be viewed on the LED display.
SPRAY ARM POSITION
You are sitting on the shower toilet and the shower process is active.
1. Press Spray Arm position
2. Turn the rotating ring
- clockwise the spray arm moves forward
- counter-clockwise the spray arm moves back
3. The chosen Spray Arm position can be viewed on the LED display.
USER PROFILE
The Water temperature, flow rate and spray arm position can be individually saved in 5 user
profiles for the rear wash and the lady wash functions.
Saving a personal profile
You are sitting on the shower toilet.
1. Press User Profile to select where you want to save the profile (LED 1–5).
2. Start the Rear Wash or Lady Wash shower function.
3. While the shower is in operation, adjust the Water temperature, flow rate and Spray Arm
position according to your needs.
4. To save, press Stop .
The shower stops and your selected settings are saved.
Using a personal profile
You are sitting on the shower toilet.
1. Keep pressing User Profile to select your saved profile (LED 1–5).
2. Start the Rear Wash or Lady Wash shower function.
3. To finish, press Stop .

9
EN
29°
30°
37°
50°
COMFORT FUNCTIONSAXENT.ONEPLUS
MASSAGE AXENT.ONEPLUS
You are sitting on the shower toilet and the shower process is active.
The massage function can be activated and set as desired.
1. Pressing Massage multiple times.
- Once oscillating (shower spray moves forwards and backwards)
- Twice pulsating (spray alternates between stronger and weaker spray)
- Three times oscillating and pulsating at the same time
- Four times massage function stops
SEAT TEMPERATURE AXENT.ONEPLUS
You are sitting on the shower toilet.
1. Press Temperature multiple times to select a seat temperature .
2. Turn the rotating ring
- clockwise the temperature is increased
- counter-clockwise the temperature is reduced
3. The set temperature can be viewed on the LED display.
4. If the LED lights are off, the seat heating is switched off.
AIR DRYER AXENT.ONEPLUS
You are sitting on the shower toilet and the shower process is finished.
1. Press Air Dryer to start the Air Dryer function.
2. Press Stop to stop the Air Dryer
The Air Dryer stops automatically after 3 minutes of continuous operation.
AIR DRYER TEMPERATURE AXENT.ONEPLUS
You are sitting on the shower toilet and the drying process is active.
Temperature and Air Dryer temperature light up.
1. Turn the rotating ring
- clockwise the temperature is increased
- counter-clockwise the temperature is reduced
2. The set temperature can be viewed on the LED display.
3. If the LEDs are off, the Air Dryer temperature is cold.

10 EN
REMOTE CONTROL SETTINGS MODE
In settings mode, you can manage additional functions:
–Night light
–Signal tone
–System reset
–Shower toilet standby mode
–System purge
–Emptying the water tank
SETTINGS
ACTIVATING SETTINGS MODE
1. Press and hold Stop and also press Temperature until
the LED display flashes slowly.
2. The AXENT logo lights up without flashing.
3. You are now in settings mode.
EXITING SETTINGS MODE
1. Press Stop to exit settings mode.
The setting mode is automatically terminated after 3 minutes of inactivity.
–Seat heating energy-saving mode (AXENT.ONEPLUS)
–Automatic Deodorizer (AXENT.ONEPLUS)
–Automatic self-cleaning function (AXENT.ONEPLUS)
NIGHT LIGHT
Settings mode is active.
1. Press Temperature multiple times.
2. The icon - lights up without flashing the night light is permanently on.
- flashes quickly the night light is permanently off.
- flashes slowly The night light switches on and off
automatically depending on ambient
brightness.
3. The display switches off after a few seconds, and your setting is saved.
Factory setting: The night light switches on and off automatically depending
on ambient brightness.

11
EN
SETTINGS
SIGNAL TONE
Settings mode is active.
1. Press User Profile multiple times.
2. The icon - flashes slowly the signal tone is active.
- flashes quickly the signal tone is off.
3. The display switches off after a few seconds, and your setting is saved.
Factory setting: The signal tone is active.
SYSTEM RESET
You would like to reset your personal settings to the factory default settings.
Settings mode is active.
1. Press and hold Temperature and press Flow Rate once.
2. Stop flashes three times.
3. The settings of the remote control and the device are reset to the factory settings.
SHOWER TOILET STANDBY MODE
If you are away for prolonged periods (e.g. on holiday), you can set the shower toilet
to standby mode.
Settings mode is active.
1. Simultaneously press User Profile and Spray Arm Position .
2. Hold until Stop flashes three times and then switches off.
3. The Standby mode of the device is now activated.
To deactivate standby mode, gently knock the rear cover on the left side.

12 EN
SYSTEM PURGE
If the shower toilet has not been used for a prolonged period, all water bearing parts can be
purged with fresh water.
Settings mode is active.
1. Press Lady Wash .
2. The process starts.
3. The system purge process stops automatically after 90 seconds.
4. To stop it before this time, press Stop .
EMPTYING THE WATER TANK
In the event of service intervention, or before a holiday or prolonged period of no use, the
water tank may need to be emptied.
Settings mode is active.
1. Press Rear Wash .
2. The process starts.
3. The water tank is emptied.
If the wash function is started again, the tank is refilled with water.
SETTINGS

13
EN
SETTINGSAXENT.ONEPLUS
SEAT HEATING ENERGYSAVING MODE AXENT.ONEPLUS
When energy-saving mode is active, the shower toilet remembers when it has been used
and records this hourly. The seat heating switches on in line with the stored schedule.
A new record is saved every day.
Settings mode is active.
1. Press and hold Air Dryer and press Massage multiple times..
2. The icon - flashes slowly energy-saving mode is active.
- flashes quickly energy-saving mode is off.
3. The display switches off after a few seconds, and your setting is saved.
Factory setting: Seat heating energy-saving mode is off.
AUTOMATIC DEODORIZER AXENT.ONEPLUS
The deodorizer starts automatically as soon as you sit on the shower toilet.
This function can be activated or deactivated.
Settings mode is active.
1. Press Massage multiple times.
2. The icon - flashes slowly the deodorizer is active.
- flashes quickly the deodorizer is off.
3. The display switches off after a few seconds, and your setting is saved.
Factory setting: The automatic deodorizer is active.
AUTOMATIC SELFCLEANING AXENT.ONEPLUS
The spray arm is cleaned with fresh water as soon as you sit on the shower toilet.
This function can be activated or deactivated.
Settings mode is active.
1. Press Air Dryer multiple times.
2. The icon - flashes slowly self-cleaning is active.
- flashes quickly self-cleaning is off.
3. The display switches off after a few seconds, and your setting is saved.
Factory setting: Automatic self-cleaning is active.

14 EN
The shower toilet has been developed and produced with the utmost care and a keen eye for detail. If you heed a few easy-to-follow
cleaning instructions, the quality and aesthetics of your shower toilet will continue to impress you every day.
CLEANING RECOMMENDATION
Cleaning interval Cleaning steps
Regularly –Wipe off drops of water with a soft, dry cloth (cotton, not microfibre).
Weekly/monthly –Remove the toilet seat and lid and clean them separately.
–Clean the hinges and bolts of the toilet seat and lid with a damp cloth, then dry.
–Wipe all surfaces and corners thoroughly with a soft, damp cloth (cotton, not microfibre)
and a gentle liquid detergent.
–Inspect the spray arm for signs of scale.
Quarterly –Run the descaling programme (page 15).
CLEANING AND CARE
CLEANING THE REMOTE CONTROL
Wipe the remote control with a soft cloth (cotton, not microfibre).

15
EN
CLEANING AND CARE
DESCALING PROGRAMME
The entire water system can be descaled as easily as a coffee machine.
Fill a container with 200ml liquid descaler (preferably Durgol, dilute if necessary as per
manufacturer’s instructions).
Settings mode is active.
1. Press Flow Rate .
The process starts and the water system is fully emptied.
The spray arm extends without spraying any water.
2. Immerse the spray arm in the container of liquid descaler.
3. The liquid is absorbed.
4. The spray arm moves back to its starting position. The liquid descaler circulates all around
the water system and dissolves any limescale.
5. The liquid descaler is flushed away automatically.
The entire water system is purged three times with fresh water.
This process takes about 3 minutes.
The night light flashes slowly throughout this process.
Do not interrupt the descaling programme once it has started.
CLEANING THE SPRAY ARM
The stainless steel spray arm should be cleaned at regular intervals.
Settings mode is active.
1. Press Spray Arm Position .
2. The spray arm extends without spraying any water.
3. Clean the spray arm with a soft cloth (cotton, not microfibre) or a soft brush, without
exerting any pressure.
4. To finish, press Spray Arm Position or Stop .
The spray arm moves back to its starting position.

16 EN
CLEANING AND CARE
CLEANING INSTRUCTIONS CERAMIC
Under no circumstances should you use harsh or abrasive cleaning substances such as
abrasive cream cleansers, scouring powder or drain cleaner on your ceramic surfaces. Also
avoid using steam cleaners and hard, abrasive sponges. Please bear in mind that hair colouring
products can reduce the effectiveness of AXENT Easy Clean.
If you follow this guidance then you should remain satisfied with the performance of AXENT
Easy Clean for many years. Recommended cleaners for sanitary ceramic surfaces with
AXENT Easy Clean finish. The use of acidic cleaners with a pH value between 1 and 4 is highly
recommended. Cleaners with a pH value in the neutral range (5 to 8) are not always suitable.
We strongly advise against using either weak or strong alkaline cleaners, i.e. substances with
pH values from 9 to 12.
CLEANING INSTRUCTIONS SEAT, LID AND REAR COVER
To continue enjoying your toilet seat and lid for as long as possible, please follow these care tips.
Clean them regularly and promptly to prevent stubborn mineral stains.
The toilet seat and lid can be removed, cleaned and refitted quickly and easily.
Clean surfaces thoroughly with a soft cloth (cotton, not microfibre).
–Use clear, warm water, and a bit of gentle detergent to remove heavier soiling.
–Do not use spray cleaners or microfibre cloths.
–Leave the toilet seat and lid open while the detergent acts on ceramic surfaces.
–Do not use detergents that foam or contain chlorine.
–Wipe the hinges dry.
The seat of the AXENT.ONEPLUS contains electronics, therefore do not immerse
or rinse in water!
