Axial GRAVE DIGGER SMT10 User manual

INSTRUCTION MANUAL
AX90055-I001

4
4
4
2

4
4
4
3

Do not use a Nickel Cadmium or Nickel Metal Hydride battery charger to
charge LiPo batteries. Damage to the batteries and charger will likely
occur resulting in a fire.
Verwenden Sie keine Nickel-Cadmium-oder Nickel-Metall-Hydrid-Akku
Ladegerät LiPo-Akkus aufladen. Schäden an den Batterien und
Ladegerät wird wahrscheinlich auftreten, was zu einem Brand.
Ne pas utiliser un chargeur de batterie au nickel-cadmium ou
nickel-métal-hydrure pour recharger les batteries LiPo. Les dommages
aux batteries et le chargeur se produira probablement de provoquer un
incendie.
2 Turn on the transmitter
1
Install and connect the battery
3
1.Remove clip to open battery access door
2.Slide battery into try to check clamp height
3.Remove x4 M3x8mm AXA434 screws
4.Adjust battery clamp to fit snug against battery.
5. Reinstall x4 M3x8mm screws
6. Close battery access door and insert clip
Battery Tray Adjustment
Note:
Power to the vehicle is controlled
by connecting / disconnecting the
battery.
Always unplug the battery when
not in use, do not leave vehicle
stored plugged in.
4 Reattach the body to vehicle
Remove the body
4

Electronic Speed
Control (ESC)
Steering Servo
C-Hub
Steering
Transmission
Rear Sway Bar
Shock Absorber
Spur/Pinion/Slipper
(Under Cover) Motor 27T
Receiver Box
Steering Knuckle
Driveshaft
Upper 4-link Bar
Lower 4-link Bar
Battery Tray
Differential
(inside axle housing)
Do not use a Nickel Cadmium or Nickel Metal Hydride battery charger to
charge LiPo batteries. Damage to the batteries and charger will likely
occur resulting in a fire.
Verwenden Sie keine Nickel-Cadmium-oder Nickel-Metall-Hydrid-Akku
Ladegerät LiPo-Akkus aufladen. Schäden an den Batterien und
Ladegerät wird wahrscheinlich auftreten, was zu einem Brand.
Ne pas utiliser un chargeur de batterie au nickel-cadmium ou
nickel-métal-hydrure pour recharger les batteries LiPo. Les dommages
aux batteries et le chargeur se produira probablement de provoquer un
incendie.
2 Turn on the transmitter
1
Install and connect the battery
3
1.Remove clip to open battery access door
2.Slide battery into try to check clamp height
3.Remove x4 M3x8mm AXA434 screws
4.Adjust battery clamp to fit snug against battery.
5. Reinstall x4 M3x8mm screws
6. Close battery access door and insert clip
Battery Tray Adjustment
Note:
Power to the vehicle is controlled
by connecting / disconnecting the
battery.
Always unplug the battery when
not in use, do not leave vehicle
stored plugged in.
4 Reattach the body to vehicle
Remove the body
5
Top View Parts

Getting-Started Checklist
The following checklist is a guide for getting you vehicle running for the first time.
Read ‘Cautions’ in Manual. (Page 2) Familiarize yourself with vehicle and
its components.
Even though the vehicle is new check
driveshaft setscrews and other screws to
make sure they are tight from the factory.
Charge battery pack. (Page 4) Install 4X AA batteries into Transmitter.
(Page 7)
Install battery pack in vehicle. (Page 4)
Turn on transmitter FIRST then ESC.
(Page 4)
Check to make sure steering and throttle
operation work correctly. (Page 7)
Range check radio system. (Next Page)
Drive vehicle, challenge yourself and
have fun!
Maintain vehicle. (Next Page)
6

KEEP CHASSIS FREE OF DIRT
OR DEBRIS
CHECK FOR LOOSE SCREWS
ON CHASSIS ESPECIALLY
THE KNUCKLE, C-HUB AND
AXLE LOCKOUT SCREWS
CHECK FOR WEAR ON
THE BALL JOINTS IN THE
STEERING AND SUSPENSION
LINKS
(REPLACE IFNECESSARY)
CHECK DRIVESHAFT SET
SCREWS AND RE-THREAD
LOCK IF NECESSARY
CHECKWHEEL NUTS MAKING
SURE THEY’RE SNUG
CHECK TIRES MAKING SURE
THE BEADS ARE STILL FIRMLY
BONDED TO THE ENTIRE
CIRCUMFERENCE OF THE RIM
REPLACE TRANSMITTER
AA’S IF THE GREEN LIGHT IS
BLINKING
INSPECT THE SPUR AND
PINION GEARS FOR DAMAGE
CHECK SLIPPER CLUTCH IF
APPLICABLE, FOR PROPER
OPERATION
CHECK DRIVELINE FOR
SMOOTH BIND-FREE
OPERATION
CHECK FOR ANY LOOSE
CONNECTIONS OR FRAYED
WIRING
INSPECT SHOCK
ABSORBERS FOR SMOOTH
DAMPENED OPERATION
CHECK RECEIVER ANTENNA
TO CONFIRM IT’S NOT
DAMAGED
CHECK STEERING
OPERATION FOR ANY BINDS
REPLACE ANY NOTICEABLE
BENT OR BROKEN PARTS
Maintaining Your Vehicle
Just likeafull size car or truck your RC vehicle must undergo periodic maintenance in order to ensure peak running performance. Preventative
maintenance will also help avoid needless breakages which could result in costly repairs. Below are some suggestions to properly maintain
your vehicle.
Range-Checking Your Radio System
The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range.
1. Turn on the transmitter first and then the vehicle.
2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts.
3. Walk away until you are at the farthest distance you plan to operate the vehicle.
4. Steer the vehicle back and forth and throttle both forward and reverse making sure there is no erratic behavior.
5. If any erratic behavior is exhibited do not operate the vehicle,call customer service for further assistance.
RANGE-CHECKING FOR DISTANCE
7

AE-5 Forward/Reverse ESC w/ Drag Brake
Mount the ESC in an area that is well ventilated and isolated from vibration and shock.
Connect the ESC motor wires to the motor red-red & black-black.
Plug the receiver with into the throttle channel on the receiver. The black negative wire should be
towards the outside of the receiver.
Before plugging the battery into the ESC, make sure your transmitter is on and the throttle trim is set at
zero.
Connect the battery to the ESC, this will turn on the ESC.
Test forward and reverse control using the transmitter.
To calibrate the ESC, make sure the transmitter is on and the throttle control is at neutral.
Connect the battery to the ESC and wait 3 seconds to let the ESC initiate a self-test and automatic
throttle calibration.
When the ESC is ready to run a long beep sound will be emitted from the motor.
Always disconnect the battery when the vehicle is not in use.
8

Pinion 56 60 64 68
11 34.04 36.47 38.90 41.33
12 31.20 33.43 35.66 37.89
13 28.80 30.86 32.91 34.97
14 26.74 28.65 30.56 32.47
15 24.96 26.74 28.53 30.31
16 23.40 25.07 26.74 28.41
17 22.02 23.60 25.17 26.74
Pinion 56 60 64 68
11 38.69 41.45 44.22 46.98
12 35.47 38.00 40.53 43.07
13 32.74 35.08 37.42 39.75
14 30.40 32.57 34.74 36.91
15 28.37 30.40 32.43 34.45
16 26.60 28.50 30.40 32.30
17 25.04 26.82 28.61 30.40
32 Pitch 38/13T (Stock Gearing AX30392 or AX30395)
*NOTE: NOT ALL GEAR FITMENT OPTIONS ARE AVAILABLE
Spur Gear
32 Pitch 36/14T (Overdrive Gearing AX30401)
Spur Gear
Pinion 56 60 64 68
11 43.78 46.91 50.04 53.16
12 40.13 43.00 45.87 48.73
13 37.05 39.69 42.34 44.98
14 34.40 36.86 39.31 41.77
15 32.11 34.40 36.69 38.99
16 30.10 32.25 34.40 36.55
17 28.33 30.35 32.38 34.40
32 Pitch 43/13T (Underdrive Gearing AX30402)
Spur Gear
22.02:1
53.16:1
Final Drive Gear Ratio = (Spur/Pinion) X 7.2
Gesamtübersetzung = (Spur/Pinion) X 7.2
Warranty Info
AXIAL LIMITED WARRANTY
Your Axial product is warranted to be free of defects in materials and workmanship when new in the factory sealed box. This warranty does not cover damages
due to normal wear and tear, users' failure to perform routine maintenance, error of assembly or installation, modications or addition of aftermarket parts or
option parts. This warranty lasts as long as the original purchaser owns the product and is not transferable (verified by dated itemized sales receipt
accompanied with product). In the event of a defect under this warranty, Axial will, at our discretion, repair or replace the product, provided our inspection
indicates that an original defect exists. Axial provides a 10-day warranty from the date of purchase on electronics (i.e. servo, esc, radio). Axial reserves the
right to replace any product which is no longer available with a product of comparable value and function. If Axial determines the repair is not covered under
warranty guidelines, there could be a charge applied for the repair and return shipping charges. Note: Purchasing products from unauthorized distributors may
void warranty and prevent support and service.
INTERNATIONAL CUSTOMER WARRANTY
Please return product to the dealer where the purchase was made. If your Axial product purchase was made through an on-line retailer, any warranty issues
must be taken care of by that retailer. Axial assumes no responsibility for Axial products sold internationally by on-line retailers.
REPAIR
For warranty repair, please contact Axial Customer Service at (877) 64-AXIAL (877-642-9425).
HOURS AVAILABLE:
8:00 am - 5:00 pm Monday through Friday, Central Time.
9

10

11
AX80072 x1
AX80069 x2
AX80071
Straight Axle Adapter Rear x1
AX31316
AR60 Dual Shear
Steering Knuckle Set x1
AX80018
Hardware
Parts Tree x3
AX31301
10mm Shock Caps
Parts Tree (Blue) x2
AX31114
WB8 Driveshaft x2
AX31300
10mm Shock
Parts Tree 2 (Blue) x2 AX80033
10mm Shock Set 1 x2
AX31317
x2
AX31463
Servo Set
x1
AX31354
AR60 Heavy Duty C-Hub Carrier x1
AX80131
Helmet Set (Black)
x1
AX31355
AX31354
AX31317
AX80078
Transmission Gear Cover x1
AX31109
Yeti™ Rear 4 Link Set x2
AX31355
Monster Truck Motor Details x1

12
AX31464
2.2 Monster Truck Wheels
63mm (Silver)
x4
AX31083
Radio Box Seals x1
AX31058
Yeti Rear Sway Bar 3.0mm
x1
AX80009
Transmission Set x1
AX31179
Tube Frame Electronics Box x1
AX31349
AR60 Heavy Duty Steering Linkage x1
AX31348
Monster Truck Skid Plate and
Battery Capture
x1
AX31351
AX80009
1
23
45
6
1
7
AX31349
AX31348
AX31353
AX31352
AX31351
Monster Truck Cage Roof and Hood (Green)
x1
AX31353
Monster Truck Body Post Set x1
AX31113
Yeti™ Rear Sway Bar Mount Set x1
AX31352
Monster Truck Cage Front and Rear x1

13
AX31346
Monster Truck Cage Side
(Left) (Green)
x1 AX31347
Monster Truck Cage Side
(Right) (Green)
x1
AX31350
Monster Truck Electronics and
Battery Tray (Green)
x1

14
AX80002
x 2
AX30385
x2
A
Pad
X31068
Slipper x2
AX31026
Slipper Plate x2
AX30429
12mm Aluminum Hub x4
AX30408
Input Shaft 5x29mm x2
AX31148
WB8-HD Joint 10X15mm x4
AX31148
WB8-HD Joint Male Universal x4
AX30392
38T Bevel Gear x2
AX30112
Shock Diaphragm 13x4.5mm x4
AX30113
Rubber Bump Stop 3.6x7x4 x4
x1
AX30419
Solid Axle Dogbone 7x125mm
x1
AX30419
Solid Axle Dogbone 7x69mm
AX30776
Straight Axle Shaft 6x160.2mm x1
AX30776
Straight Axle Shaft 6x104.2mm
AX31054
Shock Shaft 3x71 x4
AX30368
Axle 6x39mm x2
x1
AX31027
Spur Gear 32P 56T x1
AX30435
Outdrive Shaft x1
AX30435
Outdrive Shaft x1
AX30491
AX10 Scorpion Motor Plate x1
AX30722
Pinion 32DP 11T x1
AX31149
Top Shaft 5x54.50mm
x1
AX31180
Aluminum Spur Gear Spacer
x1
AX80010
Gear Set x1
AX30390
Dierential Gear Set x4 AX30391 Dierential Gear Set x4
AX31296
Shock Body 12x59mm x4
AX30413
Slipper spring 8.5x12 x1
AX31027
4x11mm Bushing x1
AX31296
Spring 14x90mm 2.78lbs/in Firm (Yellow) x2
AX30213
Spring 14x90mm 1.32lbs/in Super Soft (Red) x2

15
AXA436
M3x12mm x16
AXA087
M3x16mm x8
AX31028
PIN 2.0 x11 x8
AX30162
PIN 1.5 x8 x1
AX30163
Pin 2x10mm x2
x2
AX30170
Pin 3x22mm
AXA1393
E2.5 e-clip x2
AXA1045
M4 Nylon Lock Nut x5
AXA1041
M2.5 Nylon Lock Nut x4
AXA1070
Washer 3x6x0.5 mm x3
AXA1202
O-Ring 3.5x2mm x8
AXA1184
O-Ring 7.5x1.5mm x4
AXA1230
Bearing 10x15x4mm x6
AXA1225
Bearing 8x16x5mm x2
AXA1221
Bearing 5x11x4mm x21
AXA180
M3x3mm x10
AX30450
Flange Pipe 3x4.5x5.5 x4
AXA0109
M3x10mm
Oversize Flat Hex Socket x4
AXA116
M3x12mm x2
AXA117
M3x15mm x15
AXA118
M3x18mm
x2
AXA144
M3x8mm x8
AXA1059
6mm Body Clip x5
AXA015
M2x10mm x16
AXA091
M3x30mm x2
AXA088
M3x20mm x1
AXA0113
M3x6mm x9
AX31280
M2.6x6mm x14
AX30810
Universal joint Axle Pin holder x4
AXA083
M3x6mm x2
AXA089
M3x25amm x3
AX31185
M3x10mm x2
AXA0286
M4x12mm Screw Shaft
x8
AXA0414
M2.6x10mm x10
AXA465
M3x10mm x10
AXA434
M3x8mm x9
AXA0437
M3x15mm x4
AXA438
M3x18mm x2
AXA0439
M3x20mm
x10
AXA466
M3x12mm x2
AXA0467
M3x16mm x6
AXA013
M2x6mm Hex Socket Cap Head x4a
AXA115
M3x10mm x13
AXA1218
Bearing 5x10x4mm x4
x1
AX30190
Shaft 5x18
x1
AXA291
M4x4mm Set Screw
AXA1069
Washer 2.7x6.7x0.5 mm x8
AXA1052
M3 Thin Nylon Locking Hex Nut x10
AXA1053
M3 Thin Nylon Locking Hex Nut x4

16
AXA434
AXA1347
AXA434
AXA434
AXA434
AXA436
AXA436
AXA436
AXA436
AXA436
AXA436
AXA436
AXA436
AXA436
AX31280
AX31280
AX31280
AX31280
AX31280
AX31280
AX31280
AX31280
AX31280
AX31350
AX31350
AX31350
AX31350
AX31348
AX31348
AX31351
AX31351
AX31352
AXA0826
AXA0286
AXA0286
AXA0286
AX31352
AX31352
AX31352
AX31083
AX31083
AX31083
AX31179
AXA0414
AXA0414
AXA0414
AXA0414
AXA0414
AXA0414
AXA0414
AX31179
AX31350
AX31280
AX31280
AX31368
AX31436
AX31436
AXA434
AXA434
AXA434
AXA434
AX31356
AXA436
AXA436
AXA436
AXA436
AXA436
AXA434
AXA438
AXA1059
AXA1059
AX31353
AX31355
AX31355
AX31353
AX31353
AXA1059
AXA1059
AXA1059
AXA436
AXA465
AXA465
AXA465
AXA465
AXA436
AXA0467
AXA0467
AXA0467
AXA0467
AX31280
AXA0467
AXA0467
AXA465
AX31280
AX31368
AX31280
AX31280
AX31280

17
AXA1052
AXA1052
AXA1052
AXA1052
AXA1053
AXA118
AXA118
AXA091
AXA015
AXA015
AXA438
AX80018
AX80018
AX8 0018
AX80018
AX80018
AXA0109
AXA0109
AXA116
AXA114
AXA115
AXA115
AXA0113
AXA0113
AXA144
AXA117
AXA117
AXA0437
AXA0437
AXA0439
AXA117
AXA117
AXA0439
AXA144
AXA144
AXA144
AXA0113
AXA0113
AX31317
AX31317
AX31317
AX31317
AX80002
AX30390
AX30391
AX30385
AX30392
AX30170
AX30163
AX31028
AX31028
AX31114
AX31114
AX31114
AX31114
AX31114
AX31148
AX31148
AX31148
AX31148
AX30810
AX30810
AX80072
AX31317
AXA115
AXA1221
AXA1221
AXA1221
AXA1221
AXA1221
AXA180
AX80069
AXA087
AXA087
AXA180 AXA180
AXA1221
AXA1221
AXA0286
AXA0286
AX30408
AXA1230
AXA1230
AXA1230
AXA1230
AX30368
AX30368
AX30419
AX30419
AX30392
AXA1393
AXA31316
AXA31316
AXA115
AXA115
AXA115
AX31185
AX31185
AX0018
AXA1053
AX31463
AX31349
AX31317
AX30450
AX30450
AX30450
AX30450
AX31354
AX31109
AX31109
AX31109
AX31109
AX31354
AX31349
AX8 0018
AX8 0018
AX8 0018
AX8 0018
AX8 0018
AX8 0018
AX8 0018
AX80018
AXA0439

18
AXA0286
AX31114
AX31114
AX31114
AX31114
AX31114
AX31148
AX31148
AX31028
AX31028
AX30810
AX30810
AX31148
AX31148
AXA144
AXA144
AX31317
AX31317
AX31109
AX31109
AX31109
AX31109
AX80018
AX80018
AX80018
AX80018
AX80018
AX80018
AX80018
AX80018
AX80018
AX80018 AX80018
AX80018
AXA0439
AXA0439
AXA117
AXA117
AXA117
AXA117
AXA0437
AXA0437
AXA1053
AXA1052
AXA1052
AXA091
AX80069
AXA1221
AXA1221
AXA1221
AX80017
AX80017
AX30776
AX30776
AX31068
AX31113
AX31113
AX31113
AX31113
AX31113
AX31113
AX31113
AX31113
AXA0113
AXA0113
AXA0113
AXA0113
AXA1221
AXA0286
AXA180
AXA180
AXA180
AXA087
AXA087
AX30408
AX30163
AX30392
AXA1393
AXA1230
AXA439
AX80002
AX30390
AX30170
AX30391
AX30385
AX30392
AXA015
AXA1230
AX31317
AX31317
AXA115
AXA116
AXA116
AXA116
AXA116 AXA115
AX31317
AXA015
AXA015
AXA144
AXA144
AX80072

19
AXA41045
AX30413
AX31026
AX31026
AX31180
AX80034
AX80033
AX31301
AX31301
AX31301 AXA1202
AXA1069
AXA1069
AXA1202
AX30216 Yellow FRONT AX30213 Red REAR
AX31301
AXA1184
AX31301
AX30113
AX31300
AX31300
AXA117
AXA1052
AX80018
AX30112
AXA1041
AX80033
AX80033
AX31054
AX31296
AX31068
AX31068
AX31027
AX31027
AX80078
AX80078
AX30491
AXA1070
AXA1053
AXA465
AXA465
AXA466
AXA466
AXA013
AXA013
AXA013
AXA089
AXA0439
AXA089
AXA089
AXA088
AXA1218
AXA1225
AXA1225
AX30435
AX30435
AX80010
AX80010
AX30394
AX31149
AX30162 AXA1218
AX30190
AXA1218
AXA1218
AX80009
AX80009
AX80009
AXA1070
AX80078
AXA0414
AXA0414
AXA0414
AXA291
AX24004
AXA083
AXA083
AX30722

20
AX31028
AX31028
AXA180
AXA180
AX30429
AX30429
AXA1045
AXA1045
AX31345
AX31344
AX31344
AX31459
