Axial YETI JR. ROCK RACER User manual

2

3
4
4
4
4

4
r.
3. Turn on the transmitte
Note:
Power to the vehicle is controlled by
connecting / disconnecting the battery.
4. Connect the battery to the ESC.
5. Install the body and body clips.
2. Install the battery.
1. Remove the body clips and body.
DTXP4175 USB NiMH Charger and DTXC2031 Battery Instructions
Before using your factory assembled RTR, review the entire instruction manual to become familiar with the vehicle.
This is a quick start guide for care and usage of the charger and battery that comes with the vehicle.
DTXP4175 - Duratrax Onyx USB Charger
NiMH 6C Mini Connector
DTXC2031 - Duratrax NiMH Onyx 7.2V
1300mAh Flat Mini Connector
CAUTION: The DTXP4175 charger is for use
with 6-Cell 7.2v NiMH batteries ONLY and
should not be used with any other batteries.
CAUTION: Never leave the battery unattended
while charging. Always disconnect the battery
and unplug the charger when finished charging.
CAUTION HOT!!!
NiMH batteries may become hot while charging.
Allow to cool before handling the battery.
When using the DTXP4175 charger, the DTCX2031 battery should fully charge in 2-3 hours.
• Remove the battery from the vehicle
before charging.
• Place the battery on a fire resistant surface.
• Avoid any contact with water or other fluids.
1. Connect USB connector to USB power on
PC or USB AC wall adapter.
2. Connect battery to mini connector.
3. Charger will automatically begin charge
process.
Red LED: Charging
Green LED: Finish Charging

5
Receiver Box and
Electronic Speed
Control (ESC)
Steering Servo
C-Hub
Steering Knuckle
Motor 40T
Driveshaft
Battery Tray
Rear Differential
Front Bumper
Front Shock
Absorber
Front Control Arm
Front Body Mount
Steering Rack
Rear Shock
Absorber
Spur/Pinion
(Under Cover)
Rear Swing Arm
Battery Door
Top View Parts

6
Getting-Started Checllist
The following checklist is a guide for getting you vehicle running for the first time.
Read ‘Cautions’ in Manual. (Page 2) Familiarize yourself with vehicle and
its components.
Before vehicle operation
check all nuts and screws on moving parts
are securely tightened.
Charge battery pack. (Page 4) Install 4X AA batteries into Transmitter.
(Page 7)
Install battery pack in vehicle. (Page 4)
Check to make sure steering and throttle
operation work correctly. (Page 7)
Range check radio system. (Next Page)
Drive vehicle, challenge yourself and
have fun!
Maintain vehicle. (Next Page)
Turn on transmitter first,
then plug in battery
(power ESC) (Page 4)

7
CHECK FOR WEAR ON
THE BALL JOINTS IN THE
STEERING AND SUSPENSION
LINKS
(REPLACE IF NECESSARY)
INSPECT SHOCK
ABSORBERS FOR SMOOTH
DAMPENED OPERATION
REPLACE ANY NOTICEABLE
BENT OR BROKEN PARTS
Maintaining Your Vehicle
Just like a full size car or truck your RC vehicle must undergo periodic maintenance in order to ensure peak running performance. Preventative
maintenance will also help avoid needless breakages which could result in costly repairs. Below are some suggestions to properly maintain
your vehicle.
Range-Checking Your Radio System
The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range.
1. Turn on the transmitter first and then the vehicle.
2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts.
3. Walk away until you are at the farthest distance you plan to operate the vehicle.
4. Steer the vehicle back and forth and throttle both forward and reverse making sure there is no erratic behavior.
5. If any erratic behavior is exhibited do not operate the vehicle, call customer service for further assistance.
RANGE-CHECKING FOR DISTANCE
CHECK DRIVELINE FOR
SMOOTH BIND-FREE
OPERATION
CHECK STEERING
OPERATION FOR ANY BINDS
INSPECT THE SPUR AND
PINION GEARS FOR DAMAGE
REPLACE TRANSMITTER
AA’S IF THE GREEN LIGHT IS
BLINKING
CHECK FOR ANY LOOSE
CONNECTIONS OR FRAYED
WIRING
CHECK WHEEL NUTS MAKING
SURE THEY’RE SNUG
CHECK TIRES MAKING SURE
THE BEADS ARE STILL FIRMLY
BONDED TO THE ENTIRE
CIRCUMFERENCE OF THE RIM
KEEP CHASSIS FREE OF DIRT
OR DEBRIS
CHECK FOR LOOSE SCREWS
ON CHASSIS ESPECIALLY
THE KNUCKLE, C-HUB AND
AXLE LOCKOUT SCREWS

8
AXIAL LIMITED WARRANTY
Your Axial product is warranted to be free of defects in materials and workmanship when new in the factory sealed box. This warranty does not cover damages due to normal wear and tear,
users' failure to perform routine maintenance, error of assembly or installation, modications or addition of aftermarket parts or option parts. This warranty lasts as long as the original
purchaser owns the product and is not transferable (verified by dated itemized sales receipt accompanied with product). In the event of a defect under this warranty, Axial will, at
our discretion, repair or replace the product, provided our inspection indicates that an original defect exists. Axial provides a 10-day warranty from the date of purchase on electronics
(i.e. servo, esc, radio). Axial reserves the right to replace any product which is no longer available with a product of comparable value and function. If Axial determines the repair is not
covered under warranty guidelines, there could be a charge applied for the repair and return shipping charges. Note: Purchasing products from unauthorized distributors may void warranty
and prevent support and service.
INTERNATIONAL CUSTOMER WARRANTY
Please return product to the dealer where the purchase was made. If your Axial product purchase was made through an on-line retailer, any warranty issues must be taken care of by that
retailer. Axial assumes no responsibility for Axial products sold internationally by on-line retailers.
REPAIR
For warranty repair, please contact Axial Customer Service at (877) 64-AXIAL (877-642-9425).
HOURS AVAILABLE:
8:00 am - 5:00 pm Monday through Friday, Central Time.
Warranty Info

10

11

12

13

14

15

16

17
AX31516
Yeti Jr.™ Steering Knuckle Set x1
AX31508
Yeti Jr.™ Rear Cage Battery Tray x1
AX31515
Yeti Jr.™ Front Carrier Set x1
AX31512
Yeti Jr.™ Chassis Components x1
AX31514
Yeti Jr.™ Front Lower Control Arm Set x1
AX80029
Shock Cap Parts Tree x4
AX31518
Yeti Jr.™ Rear Axle Link Set x1 AX31506 Yeti Jr.™ Molded Chasis Tub x1 AX80032 Shock Parts x2

18
AX31520
Yeti Jr.™ Battery Door x1
AX31511
Dogbone and Center Driveline Set x1
AX31519
Yeti Jr.™ Body Cage x1
AX31505
46-63mm Shock Body Set x1 AX31009 Mini servo saver mold x1
AX80030
61-90mm Shock Body Set x1
AX31509
Dierential Outputs Set x1
AX31509
Center Shaft Drive Cup x1 AX31509 Output Support Sleeve x4 AX31509 10T Spider Gear x8 AX31509 20T Di Output Short Side x2 AX31509 20T Di Output Long Side x2
AX31517
Yeti Jr.™ Front Shock Tower and Bumper Set x1
AX31507
Jr. Helmet Set (White) x1
AX31513
Spur Gear 48P 60T x1 AX31522
1.55 Method Beadlock Style Wheels
(Black)
x4
AX31510
AR18 Axle Housing x1

19
AX31496
Pinion Gear 48P 10T
(2.3mm Motor Shaft) x1 AX31494
15T Pinion Gear x2 AX31494
35T Ring Gear x2
AX31441
Spring 12.5x60mm 1.13 lbs/in - (White) x2
AX31501
Spring 12.5x35mm 1.79 lbs/in x2
AX31009
Servo Saver Spring x1
AX30162
1.5x8mm pin x2 AX30168 2x8mm pin x1
AX30146
Shock Shaft 3x50mm Polished x2
AX31497
2.0x20mm Pin x4
AX31504
2.5mm shaft x2
AX31502
Shaft 6x54mm x2
AX31502
Axle x2 AX31502 Cross Pin x2
AXA1218
Bearing 5x10x4mm x2
AX31495
8x12x3.5mm Bearing x14
AX31492
M2.6 Caphead - Hex Socket Screw Shaft 40mm x2
AX31499
Ball Stud 4mm x10
AXA1392
E2 e-clip x10
AXA180
M3x3mm Set Screw x1
AXA1041
M2.5 Nylon Locking Hex Nut x1
AXA1060
3mm Body clip (Black) x4
AXA013
M2x6mm Cap Head x2
AX31493
M2.6x25mm Cap Head x1
AX31399
M2.6x18mm Cap Head x3
AX31398
M2.6x12mm Cap Head x4
AXA0023
M2.6x8mm Cap Head x8
AX31489
M2.5x10mm Step Screw - Hex Socket x2
AX31490
M2.5x12mm Step Screw - Hex Socket x2
AX31280
M2.6x6mm Hex Socket Button Head x4
AXA0065
M2.6x10mm Hex Socket Button Head x10
AX31195
M2.6x12mm Hex Socket Button Head x10
AXA0422
M2.6x6mm Hex Socket x4
Tapping Button Head
AXA0423
M2.6x8mm Hex Socket x6
Tapping Button Head
AX31491
M2.6x18mm Hex Socket Button Head x11
AXA117
M3x15mm Hex Socket Button Head x8
AXA146
M3x12mm Hex Socket Flat Head x2
AXA147
M3x16mm Hex Socket Flat Head x2
AX31542
M2x12mm Hex Socket Button Head x1
AXA1358
Shock Damper 3x7x8 x2
AXA0414
M2.6x10mm Hex Socket x1
Tapping Flat Head
AXA0425
M2.6x12mm Hex Socket x2
Tapping Button Head
AXA0413
M2.6x8mm Hex Socket x4
Tapping Flat Head
AXA1179
O-Ring 2.5x1.5mm x8
AXA1163
O-Ring 7x1mm x4
AX31543
Washer 2x7x0.5mm x1
AX31289
M8x10x0.3mm Shim x4
AX31488
Shock Shaft 3x35mm Polished x2

20
Chassis and Transmission
AX31518
AX31542
AX31543
AX31009
AX31009 AX31009
AX31009
AX31506
AXA0413
AXA0413
AX31508
AX31511
AX31512
AX31497
AX31497
AX31512
AX31512
AX31499
AX31499
AXA1041
AX31499
AX31489
AX31489
AX31499
AX31512
AX31513
AXA1218
AXA1218
AX31512
AX31512
AX31496
AXA180
AX31512
AX31509
AX31520
AX31520
AX31520
AX31520
AX31520
AX31195
AX31195
AX31195
AX31195
AX31195
AXA0065
AX31195
AX31195
AX31195
AX30168
AX31280
AX31280
AXA0065
AXA0065
AXA0065
AX31399
AX31491
AX31491
AX31491
AX31491
AX31491
AXA0414
