Axial SCX10 Dingo User manual

4
4
4
2

4
4
4
3

2. Install the battery
Put back the Body.
1. Removing the Body
Put the battery in the car.
3. Turn on the transmitter.
4. Turn on the electronic speed controller.
4

Tactic TSX45 Servo
Front Bumper
C-Hub
Receiver Box
Front Body Mount
Steering Rack
Steering Knuckle
Transmission
Lower 4-link Bar
ESC Plug
Shock Absorber
Battery Straps
Rear Body Mount
Battery Tray
Spur/Pinion/Slipper
(Under Cover)
Motor 27T
AE-5 Electronic
Speed Control (ESC)
Rock Rail
2. Install the battery
Put back the Body.
1. Removing the Body
Put the battery in the car.
3. Turn on the transmitter.
4. Turn on the electronic speed controller.
5
Top View Parts

Getting-Started Checklist
The following checklist is a guide for getting you vehicle running for the first time.
Read ‘Cautions’ in Manual. (Page 2) Familiarize yourself with vehicle and
its components.
Even though the vehicle is new check
driveshaft setscrews and other screws to
make sure they are tight from the factory.
Charge battery pack. (Page 4) Install 4X AA batteries into Transmitter.
(Page 7)
Install battery pack in vehicle. (Page 4)
Turn on transmitter FIRST then ESC.
(Page 4)
Check to make sure steering and throttle
operation work correctly. (Page 7)
Range check radio system. (Next Page)
Drive vehicle, challenge yourself and
have fun!
Maintain vehicle. (Next Page)
6

6
KEEP CHASSIS FREE OF DIRT
OR DEBRIS
CHECK FOR LOOSE SCREWS
ON CHASSIS ESPECIALLY
THE KNUCKLE, C-HUB AND
AXLE LOCKOUT SCREWS
CHECK FOR WEAR ON
THE BALL JOINTS IN THE
STEERING AND SUSPENSION
LINKS
(REPLACE IF NECESSARY)
CHECK DRIVESHAFT SET
SCREWS AND RE-THREAD
LOCK IF NECESSARY
CHECK WHEEL NUTS MAKING
SURE THEY’RE SNUG
CHECK TIRES MAKING SURE
THE BEADS ARE STILL FIRMLY
BONDED TO THE ENTIRE
CIRCUMFERENCE OF THE RIM
REPLACE TRANSMITTER
AA’S IF THE GREEN LIGHT IS
BLINKING
INSPECT THE SPUR AND
PINION GEARS FOR DAMAGE
CHECK SLIPPER CLUTCH IF
APPLICABLE, FOR PROPER
OPERATION (SEE PAGE 25 STEP
23 FOR SETUP INSTRUCTIONS)
CHECK DRIVELINE FOR
SMOOTH BIND-FREE
OPERATION
CHECK FOR ANY LOOSE
CONNECTIONS OR FRAYED
WIRING
INSPECT SHOCK
ABSORBERS FOR SMOOTH
DAMPENED OPERATION
CHECK RECEIVER ANTENNA
TO CONFIRM IT’S NOT
DAMAGED
CHECK STEERING
OPERATION FOR ANY BINDS
REPLACE ANY NOTICEABLE
BENT OR BROKEN PARTS
Maintaining Your Vehicle
Just like a full size car or truck your RC vehicle must undergo periodic maintenance in order to ensure peak running performance. Preventative
maintenance will also help avoid needless breakages which could result in costly repairs. Below are some suggestions to properly maintain
your vehicle.
Range-Checking Your Radio System
The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range.
1. Turn on the transmitter first and then the vehicle.
2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts.
3. Walk away until you are at the farthest distance you plan to operate the vehicle.
4. Steer the vehicle back and forth and throttle both forward and reverse making sure there is no erratic behavior.
5. If any erratic behavior is exhibited do not operate the vehicle, call customer service for further assistance.
RANGE-CHECKING FOR DISTANCE
7

AE-5 Forward/Reverse ESC w/ Drag Brake
NOTES
8

ST-TRIM TH-TRIM ST-D/R
BIND
9

Warranty Info
AXIAL LIMITED WARRANTY
Your Axial product is warranted to be free of defects in materials and workmanship when new in the factory sealed box. This warranty does not cover damages
due to normal wear and tear, users' failure to perform routine maintenance, error of assembly or installation, modications or addition of aftermarket parts or
option parts. This warranty lasts as long as the original purchaser owns the product and is not transferable (verified by dated itemized sales receipt
accompanied with product). In the event of a defect under this warranty, Axial will, at our discretion, repair or replace the product, provided our inspection
indicates that an original defect exists. Axial provides a 10-day warranty from the date of purchase on electronics (i.e. servo, esc, radio). Axial reserves the
right to replace any product which is no longer available with a product of comparable value and function. If Axial determines the repair is not covered under
warranty guidelines, there could be a charge applied for the repair and return shipping charges. Note: Purchasing products from unauthorized distributors may
void warranty and prevent support and service.
INTERNATIONAL CUSTOMER WARRANTY
Please return product to the dealer where the purchase was made. If your Axial product purchase was made through an on-line retailer, any warranty issues
must be taken care of by that retailer. Axial assumes no responsibility for Axial products sold internationally by on-line retailers.
REPAIR
For warranty repair, please contact Axial Customer Service at (877) 64-AXIAL (877-642-9425).
HOURS AVAILABLE:
8:00 am - 5:00 pm Monday through Friday, Central Time.
10

NOTES
11

12

13
AX80003 1
2 3
AX80003
Solid Axle Set x2
AX80004
1 1
2
AX80004
Hub Set x1
AX80006
1 2 3 4
5 6 7 8
AX80006
Servo Set x1
AX80012
2 1
AX80012
C Hub Carrier x1
AX80025 12
33
AX80025
SCX10 Shock Hoops Parts Tree x1
AX80020
AX80020
Straight Axle Adapter Parts Tree x1
AX80078
Transmission Gear Cover x1
AX80018
11
11
22
33
AX80018
Hardware Parts Tree x2
AX80009
Transmission Set x1
AX80009
1
23
45
6
1
7
AX80041 x2
1/10th Scale Rock Rails Set
AX80041
1 1
2
AX80017
1 1
2 3 2
AX80017 x1
Steering Linkage Parts Tree
AX80002
Diff Case x2

14
AX80043 x2
Links Parts Tree 1
5
3
2
1
1
1
2
2
3
3
5
5
4
4
6
6

15
AX80125
X 1
Poison Spyder Front Bumper
AX80125
1
2
3
2
3
4
AX80085
X 1
Light Bar 1
AX80085A
4
2
2
1
3
3
5
54
AX80085
X 1
Light Bar 2
AX80085B
12
4 4 6
3
7 78
8
11 11666
9
10
5 56 3
AX80086
X 1
Light Bar Lenses
AX80086
1
AX80115
X 1
Light Bar Lense Grills
AX80115
11
2
2
3
3
AX31114
X 1
WB8-HD Driveshaft

16
AX80129
Roll Cage Top x1
AX80130
Roll Cage Sides x1
AX08138
1.9 Walker Evans Wheels - Black x4
AX80010
Gear Set x1
AX31027
56T 32P Spur gear x1
AX31027
4x11mm bushing x1

17
AX30420
Solid Axle Dogbone 6x74mm x2
AX30421
Solid Axle Dogbone 6x104.5mm x2
AX30392
38T Bevel Gear x2
AX30491
AX10 Scorpion Motor Plate x1
AX30408
Input Shaft 5x29mm x2
AX30146
Shock Shaft 3x50mm x4
AX30162
Pin 1.5x8mm x2
AX30163
Pin 2x10mm x6
AX31028
Pin 2x11mm x4
AX30207
Spring 12.5x40mm x4
AX30200
Spring 12.5x20mm x4
AX30413
Spring 8.5x12 x1
AX30393
13T Bevel Gear x2
AX30502
SCX10 Chassis Rail x2
AX30385
Diff Gasket 16x25x0.5mm x2
AX30427
12mm Aluminum Hub x4
AX30450
Flange Pipe 3x4.5x5.5 x4
AX30499
Transmission Spacer
5x6.9x4.8mm - Grey
x1
x2
AX30435
Outdrive Shaft x1 AX30435
Outdrive Shaft x1
AX30724
Pinion Gear
32P 13T - Steel
x1
AX31148
Universal joint Axle Pin holder
x4
AX31026
Slipper Plate x2
AX31068
Slipper Pad x2
AX31148
WB8-HD Coupler Set x4 AX31148
WB8-HD Coupler Set x4
AX31149
Drive gear Shaft 5x54.5mm x4
AX30166
Pin 1.5x11mm
x4

18
AXA013
M2x6mm x14
AXA089
M3x25mm x7
AXA1070
Washer 3x6x0.5mm x3
AXA083
M3x6mm x2
AXA088
M3x20mm x1
AXA087
M3x16mm x8
AXA1221
Bearing 5x11x4mm x10
AXA1218
Bearing 5x10x4mm x4
AXA1225
Bearing 8x16x5mm x2
AXA1230
Bearing 10x15x4mm x6
AXA1045
M4 Nylon Lock Nut x5
AXA1053
M3 Nylon Locking Hex Nut x15
AXA1059
6mm Body Clip x8
AXA1393
E2.5 e-clip x2
AXA1392
E2 e-clip x8
AXA1358
Shock Damper 3x7x8 x4
AXA1179
O-Ring 2.5x1.5mm x8
AXA1163
O-Ring 7x1mm x4
AXA291
M4x4mm Set Screw (Black) x1
AXA086
M3x12mm x4
AXA015
M2x10mm x8
AXA465
M3x10mm Hex Socket Tapping Flat Head x4
AXA117
M3x15mm Hex Socket Button Head x1
AXA0113
M3x6mm Hex Socket Button Head x5
AXA119
M3x20mm Hex Socket Button Head x4
AXA464
M3x8mm Hex Socket Tapping Flat Head x14
AXA463
M3x6mm Hex Socket Tapping Flat Head x3
AXA0414
M2.6x10mm Hex Socket Tapping Flat Head x3
AXA434
M3x8mm Hex Socket Tapping Button Head x11
AXA435
M3x10mm Hex Socket Tapping Button Head x4
AXA433
M3x6mm Hex Socket Tapping Button Head x8
AXA436
M3x12mm Hex Socket Tapping Button Head x8
AXA440
M3x25mm Hex Socket Tapping Button Head x1
AXA176
M3x2.5x13mm Screw Shaft x6
AXA121
M3x30mm Hex Socket Button Head
x1
AXA0424
M2.6x10mm Hex Socket Tapping Button Head x10
AXA144
M3x8mm Hex Socket Flat Head x4
AXA438
M3x18mm Hex Socket Tapping Button Head x10
AXA0425
M2.6x12mm Hex Socket Tapping Button Head x2
AXA0443
M3x40mm Hex Socket Tapping Button Head x1
AXA0109
M3x10mm x4
AX31073
M3x4x15mm Step Screw x2
AXA0286
M4x12mm Screw Shaft x4
AXA1417
5x6mm Spacer - Grey x4
AXA0114
M3x8mm Hex Socket Button Head x2

19
Body Assembly
AX80115
AXA0424
AXA0424
AX04038
AX04038
Sold Separately
AXA438
AXA0423
AXA0423
AXA0423
AXA0423
AX80086
AX24256
AXA013
AXA024
AXA024
AXA024
AXA436
AXA436
AXA436
AXA436 AXA436
AXA436
AXA436
AXA436
AXA114
AXA114
AXA024
AX80085B 2
AX80085A 4
AX80085B
10
AX80085B 9
AX80085A 4
AX80085A 1
AX80130 4
AX80130 5
AX80130 6
AX80130 5
AX80130 6
AX80130 2
AX80130 3
AX80129 2
AX80130 5
AX80130 6
AXA438
AXA438
AXA438
AX80130 5
AX80130 6
AXA438
AX80130 5
AX80130 6AXA438
AX80130 5
AX80130 6
AX80130 1
*

20
AXA0286
AXA0286
AX31148
AX31148
AX31148
AXA0286
AXA0286
AX31148
AX31148
AX31028
AX31028
AX31148
AX80041
AX80041
AXA176
AXA176
AXA119
AXA119
AX80041
AX80031
AX80031
AXA464
AXA464
AXA464
AXA464
AXA464
AXA464
AXA433
AXA433
AXA433
AXA176
AX80125
AX80125
AX80125
AX31114
AX31114
AX31114
AX80010
AX80010
AX31149
AX30499
AX31144
AX80125
AXA0425
AXA0425
AX80028
AXA464 AXA464
AXA464 AXA464
AXA466
AXA466
AX30435
AX30435
AXA176
AXA0175
AX80041
AXA176
AX80041
AX80041
AXA176
AXA176
AXA176
AX31026
AX31026
AX30491
AXA1053
AX31068
AX31068
AX31027
AX31144
AX30724
AXA291
AXA083
AXA083
20
AX80078 2
AX80009 2
AX80026 2
AXA464
AXA464
AXA464
AXA464
AXA433
AXA433
AXA433
AXA433
AXA433
AXA465
AXA465
AXA466
AXA466
AX80026B
AX80078
AX80078
AXA0414
AXA0414
AXA0414
AXA0286
AXA0286
AX31148
AX31148
AX31148
AXA0286
AXA0286
AX31148
AX31148
AX31148
AX31028
AX31028
AX31114
AX31114
AX31114
AX31114
AXA465
AXA463
AXA463
AX80027
AXA463
