axiim LINK User manual

axiim|LINK
Wireless Home Theater USB Transmitter
V0.0 10.01.2019
User Manual
1

axiim|LINK
Table of Contents
2
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com
Overview 3
Specifications 3
Speaker Configuration for LG OLED and NanoCell TVs 4-6
Speaker Configuration for Xbox One, Windows 10 or Mac 7-9
Mobile App 10-13
Audio Settings 14-15
Device Mode 16
Firmware Update 17
Support 18
Device Features 19
Volume Control for Xbox One 20
Logitech Harmony IR Support 20
Troubleshooting 21
WiSA Certified 22
Additional Information 23
LINK Warranty Information 24

Overview
Wireless Home Theater USB Transmitter
The Axiim LINK HD Wireless System is a multi-channel wireless home theater solution
designed to work with WiSA Ready TVs, Xbox One, Windows 10 PCs and Mac. The Axiim LINK
transmitter connects to the source device using a USB 2.0 cable. The design of the LINK
system eliminates speaker wires with the WiSA compliant wireless audio connection. LINK
supports up to 7.1 (5.1 for LG WiSA Ready TVs) uncompressed 24bit/96kHz audio.
Specifications
•Works with WiSA-Ready sources, Xbox One, Windows 10 PCs and Mac
•WiSA compliant transmitter with 24bit/96Hz wireless audio connection
•Time synchronization +/-1uS between channels at 5.1mS latency
•Up to 7.1 multi-channel wireless audio surround sound
•Audio processing for 10-Band EQ, bass management, and more
•USB 2.0 high speed with USB audio support
•Bluetooth 4.2 wireless connection to mobile devices for system control
•Remote control apps for iOS and Android smartphones & tablets
•LINK and speaker firmware updatable through mobile app
•Dimensions: 108mm x 28mm (D x H)
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com 3

2. Connect LINK to an LG
TV with the provided USB
cable.
ATTENTION: Please
make sure your 2019 LG
OLED/NanoCell is on
firmware 03.60.02 or
later.
3. The TV will pop-up a
message asking if you
want to connect your
WiSA speakers.
Select: YES
Speaker Configuration for LG OLED and NanoCell TVs
The steps below describe the LG First Run speaker setup for your new
Axiim LINK.
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com 4
1. Plug in all of your WiSA
speakers to the nearest
wall power outlet.

4. Search for Speakers.
5. Select the “PLAY”
button to hear a tone play
from the speaker you
would like to assign.
6. Once you have located
the speaker select the
“STOP” button to stop the
speaker tone.
7. Press the “LEFT” arrow
to highlight the speaker
location. Press the “OK”
button and with the
“DOWN” arrow find the
correct speaker location.
Hit the “OK” button to
assign the speaker to the
desired location.
Speaker Configuration for LG OLED and NanoCell TVs
(Continued)
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com 5

8. Repeat steps 5-7 for all
speakers.
9. After all speakers are
assigned to their desired
locations press the
“Settings” button to exit.
Enjoy up to 5.1 immersive
audio!
Speaker Configuration for LG OLED and NanoCell TVs
(Continued)
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com 6

2. Connect LINK to an
Xbox/PC/Mac with the
provided USB cable.
3. Download the Axiim
LINK mobile app for
Android or iOS.
Speaker Configuration for Xbox One, Windows 10 or Mac
The steps below describe the Xbox One, Windows 10 PC and Mac First Run
speaker setup for your new Axiim LINK.
1. Plug in all of your WiSA
speakers to the nearest
wall power outlet.
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

Speaker Configuration for Xbox One, Windows 10 or Mac
(Continued)
4. Launch the Axiim LINK mobile app.
Select the intended source:
a. “Xbox Audio” for Xbox One
b. “USB Audio” for Windows 10 and Mac devices
c. “WiSA READY” for supported LG OLED and
NanoCell TVs
5. Select “Speakers” from the home screen, then
“Search for Speakers” and wait for the Axiim LINK to
discover your WiSA compliant speakers.
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

Speaker Configuration for Xbox One, Windows 10 or Mac
(Continued)
6. Select one unassigned
speaker from the list to
hear an audible tone from
the selected speaker.
Select the the correct
location to assign the
speaker.
7. Repeat step 6 until all speakers are assigned to the correct location.
8. Select “SAVE” and begin
enjoying your Axiim LINK!
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

LINK Mobile App
The following section describes the LINK mobile app for iOS and Android.
App Features
●Volume control
●Speaker volume trimming
●10-band audio EQ and modes
●System speaker setup
●LINK device firmware update
●Speaker firmware update
●Customer support
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

axiim|LINK
About the LINK Mobile App
LINK Home Page
1. Speakers: Provides
details about your
connected speakers,
speaker update, and
speaker setup.
2. Audio: Adjust EQ
settings, volume, etc
under the “Audio” page.
3. Settings: Find more
information about LINK:
connection status,
update, diagnostics,
troubleshooting etc.
4. Mute: Allows you to
instantly mute or unmute
the volume.
5. Volume Display: The
number indicates the
current volume. Volume is
between 0 and 100.
6. Volume Bar: The
volume bar allows you to
adjust the volume output
by sliding. Or, tap the
“Speaker Icons” on either
side of the bar to reduce
or increase volume by a
single step.
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

axiim|LINK
LINK Settings Page
1. Status: Indicates if LINK is
connected to your mobile device
and powered on.
2. Serial Number: Unique
product serial number.
3. Select Mode: Change mode
for selecting the source device:
●Xbox Audio
●WiSA Ready
●USB Audio
4. Connected: LINK is connected
to a USB host.
5. Security (Xbox Only): Device
has been authenticated by the
Xbox One.
6. Audio: LINK is receiving audio
from the host device.
7. Bass Management: Enable or
Disable bass management.
8. Version: LINK firmware version
number. If there is an update
available an update button will
appear below the “Version”.
9. Region: Indicates wireless
region.
10. Help: Diagnostic page for
customer support.
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

Adjust Volume
The volume level is
displayed in the middle of
the screen.
Slide the volume scrub
bar at the bottom of the
screen to change volume
up or down.
OR
Tap the “Speaker Icons”
on either side of the
volume scrub bar to step
volume up or down.
Tap “Mute” to mute the
volume or resume
volume.
Reduce volume Increase volume
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

Audio Settings
The Axiim LINK supports a 10 band custom global and per speaker equalizer and per
speaker volume adjustments.
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com
2. Select the desired
preset Equalizer mode, or
choose “Custom” to
adjust the global EQ or
choose “Custom Per
Speaker”.
The desired frequencies
can be adjusted by
+/-10dB by tapping the “+”
or “-” on the screen.
Adjust the EQ:
1. Select the “Audio”
menu from the main
screen of the Axiim LINK
mobile app.
Select “Equalizer” to
enter the EQ and audio
modes selection page.

Audio Settings
The Axiim LINK supports a 10 band custom global and per speaker equalizer and per
speaker volume adjustments.
How to adjust the per speaker volume levels:
1. Select the “Audio” menu from the main screen of the Axiim LINK mobile app.
2. Select “Speaker Volume”.
3. Set the desired volume level for each speaker channel by tapping the “+” or “-” on the
screen.
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

LINK Device Mode
How to change the audio device mode depending on the source LINK is connected to. By
default the LINK is in WiSA Ready mode. If you are connecting to an Xbox One or USB
audio (Windows 10 PC or Mac) you will need to change the device Mode.
1. Go to the “Settings”
page on the Axiim LINK
mobile app.
2. Tap the “Select Mode”
button to change modes.
3. Select the device LINK
will be connected to from
the three options.
4. The “Audio Mode” will
change and indicate
connection, Security (Xbox
One only), and audio.
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

LINK Firmware Update
How to update the LINK device firmware.
1. Go to the “Settings”
page on the Axiim LINK
mobile app.
2. Scroll down to view the
version. If the firmware is
not up to date, an
“Update” button will be
displayed.
3. Tap the “Update”
button, and wait for the
update process to finish.
This may take several
minutes.
Speaker Firmware Update
How to update the speaker firmware.
1. Go to the “Speakers”
page on the Axiim LINK
mobile app.
2. Select “View
Speakers”.
3. Tap the “Update”
button, and wait for the
update process to finish.
This may take several
minutes.
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

LINK Support
In the event that you need support for your Axiim LINK, it may
be necessary to submit a diagnostic from your system. To
submit a diagnostic:
1. Select “Settings” on
the Axiim LINK mobile
app.
2. Scroll to the bottom
and tap the “Help”
button.
For any additional help, please email [email protected].
3. Enter your contact
information and a
detailed description of the
problem.
4. Tap the “Submit
Diagnostic” button at the
bottom of the screen.
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

LINK Device Features
Below is a detailed list of the LINK physical device features.
axiim|LINK
All specifications are subject to change without notice. All Rights Reserved TM and ©2019 Axiim, Inc. For more information visit https://axiim.com

Volume Control with the Xbox One Media Remote Control
The volume level of your Axiim LINK can be controlled by Xbox One. To configure this
control:
1. Open the Xbox One Settings menu.
2. Select: TV & OneGuide -> Device Control
3. Under Devices select Audio Receiver
4. Choose Audio Receiver Setup.
5. Select “Axiim” as the brand.
6. When prompted to be guided through the setup or enter the model yourself, select
“Enter It”.
7. Type “Link”.
8. If prompted to confirm, select Link from the drop down menu.
9. Make sure the Axiim LINK is within line of sight of the Xbox One IR blaster.
You can now adjust the volume of your Axiim LINK system using your Xbox One media
remote control.
Logitech Harmony IR Support
You can program your Logitech Harmony remote control to control the volume of your
Axiim LINK system. Simply configure your remote using the manufacturer “Axiim” and the
device model “Link”.
axiim|LINK
