©Copyright 2018Axiomtek Co., Ltd.
Version A1 Aug 2018
Printed in Taiwan
94160638020E
4
Installation of the PCI Card
Step 1 Turn off the system and unplug the power cord.
Step 2 Unplug the power-cord.
Step 3 Turning counterclockwise to loosen the thumb screw as
marked and then pull the lower left cover out.
Step 4 Identify the location of the PCI slot as below red marked.
Step 5 Inset the PCI card and put the side cover back.
eBOX638-842-FL Quick Installation Guide
©Copyright 2018Axiomtek Co., Ltd.
Version A1 Aug 2018
Printed in Taiwan
94160638020E
1
Packing List
System Unit x 1 DVD/CD x 1 (for Driver & Manual)
Quick Installation Guide x 1 Foot Pad x4
Screws Pack x 1 2-pin terminal block connector x 1
Optional SSD/HDD Optional Wall-mount Bracket
Optional Mini Card Modules Optional DRAM

Do not try to apply power to the system if any damaged components.
Dimensions
eBOX638-842-FL Series Em edded System
©Copyright 2018Axiomtek Co., Ltd.
Version A1 Aug 2018
Printed in Taiwan
94160638020E
2
I/O Outlets
The following figures show you I/O outlets on front and rear panels of the
eBOX638-842-FL Series.
I/O View
1 1 x PS/2 KB/MS 11 LEDs
2 1 x RS-232/422/485
(COM1) 12
1 x RS-232 (COM4)
3 1 x VGA 13
1 x RS-232 (COM3)
4 1 x HDMI 14
2 x USB 2.0
5 1 x LAN1 15
1 x 9~36 VDC power input
6 3 x USB 2.0 16
1 x USB 3.0
7 1 x LAN2 17
2 x PCI slot
8 1 x Audio (Mic-in/Lin-out) 18
Flexible IO window
9 1 x ATX power button 19
1 x RS-232/422/485
(COM2)
10 1 x Reset button
©Copyright 2018Axiomtek Co., Ltd.
Version A1 Aug 2018
Printed in Taiwan
94160638020E
3
Installation of the Hard Disk Drive
Step 1 Turn off the system, and unplug the power cord.
Step 2 Eight screws on the top heatsink are used to fasten the
heatsink to the chassis.
Step 3 Locate SSD/HDD within the red block marked at the back side.
Step 4 Connect SATA cable with the SSD/HDD and then fasten four
screws at the back side of chassis.
Step 5 Assembly the top cover back and fasten all screws.
Note:
Please be informed that you can get more detail information in
eBOX638-842 user’s manual.
