©Copyright 2016Axiomtek Co., Ltd.
VersionA1 Nov 2016
Printed in Taiwan
9416K565000E
4
Installation of Express Mini Card
Step 1 Turn off the system, and unplug the power adaptor.
Step 2 Turn the system upside down to locate screws at the bottom,
and then loosen all screws.
Step 3 Loosen the screws to remove SSD/HDD bracket and then
located the Mini PCIe slot.
Step 4 Please follow your requirement to connect PCI Express Mini
Card module, EX: WIFI, mSATA and GPS.
Step 5 Slide Mini Card into Mini Card slot with caution, and fasten
screw of Express Mini Card.
Step 6 Assembly the bottom cover back and fasten all screws.
Note: Please refer to the user’s manual to get more detail information.

eBOX565-500-FL Quick Installation Guide
©Copyright 2016Axiomtek Co., Ltd.
VersionA1 Nov 2016
Printed in Taiwan
9416K565000E
1
Packing List
System Unit x 1 DVD/CD x 1 (for Driver & Manual)
Quick Installation Guide x 1 2-pin Terminal block x 1
Pre-installed Foot pad x 4 Screw pack x 1
Do not try to apply power to the system if any damaged components.
Dimensions
eBOX565-500-FL Series Embedded System
©Copyright 2016Axiomtek Co., Ltd.
VersionA1 Nov 2016
Printed in Taiwan
9416K565000E
2
I/O Outlets
The following figures show I/O outlets on the eBOX565-500-FL.
Front View
Rear View
©Copyright 2016Axiomtek Co., Ltd.
VersionA1 Nov 2016
Printed in Taiwan
9416K670000E
3
Installation of Hard Disk Drive
Step 1 Turn off the system, and unplug the power adaptor.
Step 2 Turn the system upside down to locate screws at the bottom,
and then loosen all screws.
Step 3 Open the bottom cover.
Step 4 Locate SSD/HDD within the red line marked.
Step 5 Please prepare the following items to assemble SSD/HDD.
Step 6 Connected the SATA cable and Power cable and Fasten
screws of HDD bracket to complete the SSD/HDD installation.
Step 7 Recover and fasten all screws of the bottom cover.
