eBOX100-312-FL Series
Embedded System
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, or any liability arising from such uses.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update any information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted in
any forms or by any means, electronic, mechanical, photocopying, recording, among others,
without prior written permissions of Axiomtek Co., Ltd.
Copyright 2019 Axiomtek Co., Ltd.
All Rights Reserved
Dec 2019, Version A4
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. The eBOX100-312-FL does not come with an operating system which must be loaded
first before installation of any software into the computer.
2. Be sure to ground yourself to prevent static charge when installing any internal
components. Use a wrist grounding strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
3. Disconnect the power cord from the eBOX100-312-FL prior to making any installation.
Be sure both the system and all external devices are turned OFF. Sudden surge of
power could ruin sensitive components. Make sure the eBOX100-312-FL is properly
grounded.
4. Make sure the voltage of the power source is correct before connecting it to any power
outlet.
5. Turn Off system power before cleaning. Clean the system using a cloth only. Do not
spray any liquid cleaner directly onto the screen.
6. Do not leave equipment in an uncontrolled environment where the storage temperature
is below -40℃or above 80℃as it may damage the equipment.
7. Do not open the system’s back cover. If opening the cover for maintenance is a must,
only a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help discharge any static electricity on
human body.
When handling boards and components, wear a wrist grounding strap available from
most electronic component stores.

iv
Classifications
1. Degree of production against electric shock: not classified
2. Degree of protection against ingress of water: IP40
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture with air,
oxygen or nitrous oxide.
4. Mode of operation: Continuous

v
General Cleaning Tips
Please keep the following precautions in mind while understanding the details fully before and
during any cleaning of the computer and any components within.
A piece of dry cloth is ideal to clean the device.
1. Be cautious of any tiny removable components when using a vacuum cleaner to absorb
dirt on the floor.
2. Turn the system off before clean up the computer or any components within.
3. Avoid dropping any components inside the computer or getting circuit board damp or wet.
4. For cleaning, be cautious of all kinds of cleaning solvents or chemicals which may cause
allergy to certain individuals.
5. Keep foods, drinks or cigarettes away from the computer.
Cleaning Tools:
Although many companies have created products to help improve the process of cleaning
computer and peripherals, users can also use house hold items accordingly for cleaning.
Listed below are items available for cleaning computer or computer peripherals.
Pay special attention to components requiring designated products for cleaning as
mentioned below.
Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although
paper towels or tissues can be used on most hardware as well, it is recommended to use
a piece of cloth.
Water or rubbing alcohol: A piece of cloth may be somewhat moistened with water or
rubbing alcohol before being rubbed on the computer. Unknown solvents may be harmful
to plastic parts.
Absorb dust, dirt, hair, cigarette and other particles outside of a computer can be one of
the best methods of cleaning a computer. Over time these items may restrict the airflow
in a computer and cause circuitry to corrode.
Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are applicable to
reach areas in keyboard, mouse and other areas.
Foam swabs: If possible, it is better to use lint free swabs such as foam swabs.
.
【Note】: It is strongly recommended that customer should shut down the system before
start to clean any single components.
Please follow the steps below:
1. Close all application programs;
2. Close operating software;
3. Turn off power switch;
4. Remove all devices;
5. Pull out power cable.

vi
Scrap Computer Recycling
Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in
case computers require maintenance or repair; or for recycling in case computers are out of
order.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®and Pentium®are registered trademarks of Intel Corporation.
MS-DOS, Microsoft C and QuickBasic, Windows 10, Windows 8.1, Windows 8, Windows 7,
Windows XPE, Windows XP, Windows CE embedded, Linux are trademarks of Microsoft
Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

vii
Table of Contents
Disclaimers.............................................................................................................ii
Safety Precautions................................................................................................iii
Classifications.......................................................................................................iv
General Cleaning Tips ........................................................................................... v
Scrap Computer Recycling................................................................................... vi
SECTION 1 INTRODUCTION..................................................................................1
1.1 General Descriptions.........................................................................1
1.2 System Specifications.......................................................................2
1.2.1 CPU ...................................................................................................................2
1.2.2 I/O System ........................................................................................................3
1.2.3 System Specifications.....................................................................................4
1.2.4 Driver CD Contents..........................................................................................4
1.3 Dimensions ........................................................................................5
1.3.1 System Dimensions.........................................................................................5
1.3.2 Wall-mount Bracket Dimensions (A)..............................................................6
1.4 I/O Outlets ........................................................................................10
1.5Packing List...................................................................................... 11
1.6Model List......................................................................................... 12
SECTION 2 HARDWARE INSTALLATION.........................................................13
2.1Installation of 2.5" SATA Device.................................................... 13
2.2 Installation of SO-DIMM................................................................... 15
2.3Installation of Mini PCIe Module (full-size) .................................... 16
SECTION 3 JUMPER & CONNECTOR SETTINGS..........................................17
3.1 Locations of Jumpers & Connectors.............................................17
3.2 Summary of Jumper Settings ........................................................ 19
3.2.1Restore BIOS Optimal Defaults (JP2) ..........................................................20
3.2.2 Auto Power On (SW3)....................................................................................20
3.3 Connectors ..................................................................................... 21
3.3.1 DC Power Jack Connector (screw type)......................................................22
3.3.2 Serial Port Connector (COM 1).....................................................................22
3.3.3HDMI Connector.............................................................................................23
3.3.4 Ethernet Ports (LAN1 and LAN2)..................................................................24
3.3.5ATX Power On/Off button .............................................................................24
3.3.6 Reset button...................................................................................................25
3.3.7Remote Power Switch Connector................................................................25
3.3.8USB 2.0 Port (CN1/11)....................................................................................25
3.3.9USB 3.0 Port (USB 1).....................................................................................26
3.3.10 SATA/SATA Power connector (SATA 1) ......................................................27
3.3.11 Full-size PCI-Express Mini Card Connector (CN4/CN6).............................28
3.3.12SIM Card slot (CN5).......................................................................................29
SECTION 4 BIOS SETUP UTILITY......................................................................31
4.1 Starting............................................................................................. 31
4.2 Navigation Keys............................................................................... 31

viii
4.3 Main Menu........................................................................................ 32
4.4 Advanced Menu ............................................................................... 33
4.5 Chipset Menu................................................................................... 42
4.6 Security Menu.................................................................................. 46
4.7 Save & Exit Menu.............................................................................48
APPENDIX A WATCHDOG TIMER......................................................................51
About Watchdog Timer ..................................................................................51
Sample Program.............................................................................................. 52

eBOX100-312-FL Series user’s Manual
Introduction
1
SECTION 1
INTRODUCTION
This section contains general information and detailed specifications of the
eBOX100-312-FL.Section 1 consist of the following sub-sections:
General Descriptions
System Specifications
Dimensions
I/O Outlets
Packing List
Model List
1.1 General Descriptions
A fan-less embedded system with Intel® Celeron® processor N3350 dual core (formally
codename: Apollo Lake) or Intel® Pentium® processor N4200 quad cord with low power
consumption design. To fulfill smart retails, smart cities and light industries application needs,
the entry-level embedded system supports Windows®10 IoT and it can be wall-mounted, Din-
rail mounted and VESA mounted by optional requests.
The eBOX100-312-FL comes with ultra-slim size, low power consumption and fundamental
features. Equipped with Intel®N3350 or N4200 Processor. Also, the eBOX100-312-FL is
offering 12 voltage DC power input and four antenna connectors for WIFI/3G and LTE.
Besides, the platform is compatible with Microsoft Azure certified and supports full feature I/O
to connect other devices such as RFID/Sensor or display, the total solution can help users
rapidly implement IoT applications and maximize performance.

eBOX100-312-FL Series user’s Manual
Introduction
2
Features
Intel®Celeron®processor N3350 dual core, up to 2.4 GHz with turbo boost
Intel®Pentium®processor N4200 quad core, up to 2.5 GHz
1 COM port, 6 USB ports and 2 GbE LANs
2 HDMI output for 4K UHD content
2 full-size PCIe Mini Card for WLAN and WWAN
1 x 2.5" swappable SATA HDD/SSD drive bay for easy maintain
Supports Jumbo Frame (9k), WoL, PXE Remote Boot
Fan-less operation design with low power consumption
Suitable for smart retails and light industries
Reliable and Stable Design
The embedded system equipped with Intel® Celeron® N3350 or Intel®Pentium®
N4200, ultra-slim size and basic functions. It is the best solution for smart retails and
light industries.
Flexible Connectivity
It comes with basic interfaces including one RS-232 port, two USB 3.0 ports, four
USB 2.0 ports, two HDMI, two GbE LAN ports.
Embedded O.S. Supported
The eBOX100-312-FL supports Windows®10 IoT and Linux.
Easy maintain storage Supported
In terms of storage, the eBOX100-312-FL supports one swappable 2.5" SATA storage drive
bay for easy maintain.
1.2 System Specifications
1.2.1 CPU
CPU
Intel® Celeron®processor N3350 Dual Core, up to 2.4 GHz with turbo boost.
Intel® Pentium®processor N4200 Quad Core, up to 2.5 GHz.
Chipset
SoC integrated
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
System Memory
One 204-pin DDR3L-1600 SO-DIMM socket, up to 8 GB at the maximum.

eBOX100-312-FL Series user’s Manual
Introduction
3
1.2.2 I/O System
Display
2 x HDMI (HDMI 1.4b up to 3840 x 2160@30Hz)
Ethernet
2 x 10/100/1000 Ethernet ports (i211AT)
USB Ports
4 x USB 2.0
2 x USB 3.0
Serial Ports
1 x RS-232 (9-pin D-Sub male connector)
Mini PCIe Interface
2 x full-size PCI Express Mini Card Slots (USB + PCI Express signal)
Storage
1 x 2.5" swappable SATA HDD/SSD drive bay
1 x SIM slot
Indicator
1 x Green LED as indicator for PWR status
1 x Yellow LED as indicator for HDD active
Switch
1 x ATX PWR switch
1 x Remote PWR switch
1 x ATX/AT Quick switch
1 x Reset switch
Antenna
4 x SMA type connector openings for antenna

eBOX100-312-FL Series user’s Manual
Introduction
4
1.2.3 System Specifications
Watchdog Timer
1~255 seconds or minutes; up to 255 levels.
Power Supply
12VDC /36W AC to DC adapter
Operation Temperature
-5℃~+60℃(23 ºF ~ 140ºF), with W.T. SSD & Memory
-5℃~+50℃(23 ºF ~ 122ºF), with W.T. HDD & Memory
Humidity
10% ~ 95% (non-condensation)
Vibration Endurance
3Grm with SSD(5-500Hz, X, Y, Z directions)
Weight
1.15 kg (2.53 lb) without package
1.50 kg (3.3 lb) with package
Dimension
216 mm (8.5") x 137.65 mm (5.41") x 44 mm (1.73")
1.2.4 Driver CD Contents
Ethernet
Chipset
Graphic
Serial Port
USB 3.0
Intel® ME
User Manual
Quick Manual
【Note】: All specifications and images are subject to change without notice.

eBOX100-312-FL Series user’s Manual
Introduction
5
1.3 Dimensions
The following diagrams show dimensions and outlines of the eBOX100-312-FL.
1.3.1 System Dimensions

eBOX100-312-FL Series user’s Manual
Introduction
6
1.3.2 Wall-mount Bracket Dimensions (A)
Instruction
Step 1: Before install the wall mount kit, please remove the four foot pads, and screw the two
pieces of wall-mount kits to the bottom plate of the device.
Total four screws (metric 3 x6) are required.
Step 2: Use the device, with wall mount plate attached, as a guide to mark the correct
locations of the four screws.
Step 3: Insert a tapping-screw (thread diameter less than 4mm) head through middle of the
keyhole-shaped aperture on the plate, and then slide the device downwards.
Tighten the screw head for added stability.

eBOX100-312-FL Series user’s Manual
Introduction
7
1.3.3 Wall-mount Bracket Dimensions (B)
Instruction
Step 1: Before install the wall mount kit, please remove the four foot pads, and screw the two
pieces of wall-mount kits to the bottom plate of the device.
Total four screws (metric 3 x6) are required.
Step 2: Use the device, with wall mount plate attached, as a guide to mark the correct
locations of the four screws.
Step 3: Insert a tapping-screw (thread diameter less than 4mm) head through middle of the
keyhole-shaped aperture on the plate, and then slide the device downwards.
Tighten the screw head for added stability.

eBOX100-312-FL Series user’s Manual
Introduction
8
1.3.4 Din-Rail kit Dimensions
Instruction
Step 1: Screw the Din rail mount Bracket to the bottom plate of the device. Total of four
screws (Flat Head M3 x4) are required.
Step 2: Users can install the eBOX100 in din-rail bracket through din-rail bracket kit.

eBOX100-312-FL Series user’s Manual
Introduction
9
1.3.5 VESA Mount Dimensions
Instruction
Step 1: Please refer to above photo to screw the VESA mount bracket kit with the bottom
plate of the device. Total four screws (metric 4 x6) are required.
Step 2: Insert four screws into the VESA hole of monitor and reserved a gap about
1.2~1.5mm.
Step 3: Users can hang the eBOX100 through VESA bracket on the monitor.

eBOX100-312-FL Series user’s Manual
Introduction
10
1.4I/O Outlets
The following figures show I/O outlets on the eBOX100-312-FL.
Front View
Rear View
1
2 x USB 2.0
7
ATX/AT quick switch
2
1 x swappable HDD drive bay
8
12VDC power input
3
1 x Power button
9
2 x HDMI
4
1 x Remote PWR switch
10
1 x Serial port
5
2 x LEDs for HDD and Power
11
2 x USB 2.0
2 x USB 3.0
6
1 x Reset switch
12
2 x LAN Port

eBOX100-312-FL Series user’s Manual
Introduction
11
1.5 Packing List
The eBOX100-312-FL comes with the following bundle package:
eBOX100-312-FL System Unit x 1
Quick Installation Guide x 1
DVD x 1 (For Driver and Manual)
HDD Screw x 1
HDD Rubber x 1
Remote switch cable x 1
Foot Pad x 4 (Pre-install)
Optional Screw Type AC 36W (12V/3A) Adaptor
Optional power cord
Optional DDR3L SO-DIMM Memory
Optional Wall-mount kit
Optional VESA / DIN-Rail kit
Optional Antenna
Optional Mini Card module
Optional 2.5" SATA Storage

eBOX100-312-FL Series user’s Manual
Introduction
12
1.6 Model List
eBOX100-312-FL-DC-N3350
Fan-less embedded system with Intel®Celeron® N3350 2.4
GHz,2 HDMI, 2 GbE LANs and 6 USB (w/o adapter and
power cord)
eBOX100-312-FL-DC-N4200
Fan-less embedded system with Intel®Pentium® N4200 2.5
GHz,2 HDMI, 2 GbE LANs and 6 USB (w/o adapter and
power cord)
Please contact Axiomtek’s distributors immediately in case any abovementioned items are
missing.
