AXIOMTEK MANO560 Series User manual

MANO560 Series
Intel®Socket 1700 CoreTM i9/ i7/ i5/ i3
Processors Mini ITX Motherboard
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness, or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without
the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery and dispose of used ones.
©Copyright 2022 Axiomtek Co., Ltd.
All Rights Reserved
May 2022, Version A1
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets from
electrostatic discharge damage, please take care of the following jobs with precautions:
◼Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
◼Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
◼Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their respective
owners.

iv
Table of Contents
Disclaimers ......................................................................................................ii
ESD Precautions............................................................................................. iii
Section 1 Introduction............................................. 1
1.1 Features ................................................................................................2
1.2 Specifications ........................................................................................2
1.3 Utilities Supported .................................................................................3
1.4 Block Diagram.......................................................................................4
Section 2 Board and Pin Assignments.................... 5
2.1 Board Layout.........................................................................................5
2.2 Rear I/O.................................................................................................7
2.3 Jumper Settings ....................................................................................8
2.3.1 COM1 Data/Power Select (JP1) ................................................................. 9
2.3.2 Clear CMOS (JP3) ...................................................................................... 9
2.3.3 LVDS VDD Select (JP4) ............................................................................ 10
2.3.4 AT/ATX Power Mode Select (JP5) ............................................................ 10
2.4 Connectors..........................................................................................11
2.4.1 COM1 and COM2 D-Sub Connector (CN1) .............................................. 12
2.4.2 COM3~COM4 Headers (CN3~CN4)......................................................... 12
2.4.3 SATA 3.0 Connectors (CN7)...................................................................... 13
2.4.4 USB 3.2 GEN1 Stack Port (CN10)............................................................ 13
2.4.5 LAN and USB 2.0 Connectors (CN11 and CN19)..................................... 14
2.4.6 PCI-Express Mini Card Connector (CN21) ............................................... 15
2.4.7 M.2 Key E Socket (CN22) ......................................................................... 16
2.4.8 Digital I/O Connector (CN26) .................................................................... 17
2.4.9 LVDS Signal Connector (CN29) ................................................................ 17
2.4.10 ATX Power Input Connectors (CN30 and CN70) ...................................... 18
2.4.11 DisplayPort1.3 Connector (CN32)............................................................. 19
2.4.12 HDMI1.4 Connector (CN33)...................................................................... 19
2.4.13 VGA Connector (CN34)............................................................................. 20
2.4.14 eDP Connector (CN50) ............................................................................. 20
2.4.15 Audio Header (CN52)................................................................................ 21
2.4.16 LVDS Backlight Control Header (CN55) ................................................... 21
2.4.17 Fan Headers (CN60 and CN61)................................................................ 22
2.4.18 USB 2.0 Header (CN62)............................................................................ 22
2.4.19 Front Panel Header (CN80) ...................................................................... 23
2.4.20 SPI Header (CN81) ................................................................................... 24
2.4.21 Audio Jack (CN82) .................................................................................... 24
2.4.22 M.2 Key B Socket (SCN1)......................................................................... 25

v
2.4.23 SIM Card Slot (SCN2) ............................................................................... 26
Section 3 AMI BIOS Setup Utility.......................... 27
3.1 Starting................................................................................................27
3.2 Navigation Keys ..................................................................................27
3.3 Main Menu ..........................................................................................29
3.4 Advanced Menu ..................................................................................30
3.5 Chipset Menu ......................................................................................43
3.6 Boot Menu...........................................................................................47
3.7 Security Menu .....................................................................................48
3.8 Save & Exit Menu................................................................................50
Appendix A Watchdog Timer................................... 51
A.1 About Watchdog Timer........................................................................51
A.2 Sample Program .................................................................................51
Appendix B Digital I/O ............................................. 53
B.1 About Digital I/O ..................................................................................53
B.2 Sample Program .................................................................................53
Appendix C BIOS Update ........................................ 57
C.1 How to update system BIOS using <F12> key....................................57

vi
This page is intentionally left blank.

MANO560 Mini ITX Motherboard
Introduction 1
Section 1
Introduction
The MANO560 Mini-ITX motherboard supports the new 14nm 12th Generation Intel® Core™ i9
/ i7/ i5 / i3 and Pentium® processors in LGA1700 package. Featuring the new Intel® H610
Express chipset with two DDR4 3200MHz memory support, this motherboard is built to perform
best stability and reliability for industrial applications.
It comes with one SATA 3.0, two USB 3.2 GEN1, five USB 2.0 and four serial ports (one RS-
232/422/485, three RS-232) providing robust storage and I/O options. Users also can increase
board functionality with PCI-Express x16 and full type PCI-Express Mini Card slot. The high
quality MANO560 allows five display interfaces via VGA, HDMI, DisplayPort, LVDS and eDP in
quadruplicate views, making it an ideal solution for gaming, workstation, digital signage,
medical and other IoT&M2M applications.

MANO560 Mini ITX Motherboard
2 Introduction
1.1 Features
⚫LGA1700 Socket for 12th Generation Intel® Core™ i9/ i7/ i5/ i3 and Pentium® processors
(Alder Lake)
⚫2 DDR4 3200MHz memory with maximum capacity up to 64 GB
⚫1 PCI-Express x16
⚫1 M.2 Key E with size 22x30
⚫1 full type PCI-Express Mini Card
⚫1 M.2 key B type 2242/3042/3052
⚫1 SATA-600
⚫2 USB 3.2 GEN1 and 5 USB 2.0
1.2 Specifications
⚫CPU
◼Intel®Alder Lake for LGA1700 Socket CPU (Max TDP at 65W).
⚫Chipset
◼Intel®H610.
⚫BIOS
◼AMI BIOS via SPI interface.
⚫System Memory
◼Two 260-pin SO-DIMM sockets.
◼Maximum up to 64GB DDR4 memory.
◼Support 3200MHz.
⚫Onboard Multi I/O
◼Four serial ports:
- COM1~COM2 in 9-pin D-Sub (on the rear I/O). Only COM1 supports RS-
232/422/485.
- COM3~COM4 in 2x5-pin header (internal).
⚫USB Interface
◼Two USB 3.2 GEN1 ports (on the rear I/O).
◼Four USB 2.0 ports (on the rear I/O).
◼One 4-pin USB 2.0 wafer for Touch (internal).
⚫Ethernet
◼LAN1: 2500/1000/100/10Mbps Gigabit/Fast Ethernet supports Wake-on-LAN, PXE
with Intel®i225V.
◼LAN2: 1000/100/10Mbps Gigabit/Fast Ethernet supports Wake-on-LAN, PXE with
Intel®i219V.
⚫Serial ATA
◼One SATA 3.0 port (6Gb/s).
⚫Audio
◼Realtek Codec ALC897.
◼Support line-out/MIC-in (on the rear I/O).
◼Support Line-in/Line-out/Speaker in box header (internal).
⚫Display
◼Intel®Integrated Graphics:
- One DisplayPort1.3 connector combo with dual USB 3.2 GEN1 connector,
support resolution 5120x2880 @60Hz.

MANO560 Mini ITX Motherboard
Introduction 3
- One HDMI1.4 connector, resolution up to 4096x2160 @24Hz.
- One VGA 15-pin D-Sub connector.
- One 24-bit dual channel LVDS and one 8-pin inverter connector. LVDS
resolution is max. up to 1920x1200.
- One Embedded DisplayPort (eDP) with resolution max. up to 4096x2304
@60Hz; co-layout with LVDS.
⚫Expansion Interface
◼One PCI-Express x16 slot.
◼One PCI-Express Mini Card.
◼One SIM card slot co-lay with miniPCIe and M.2 Key B socket.
◼One M.2 Key B type 2242/3042/3052 includes PCIe x2, PCIe + SATA3.0, PCIe +
USB 3.2 GEN1 interfaces by BOM option. Default is PCIe + SATA3.0.
◼One M.2 Key E type 2230 with PCIe x1 and USB2.0.
⚫Power Input
◼One 24-pin ATX power input connector.
◼One 4-pin ATX v-core power input connector.
⚫Operating Temperature
◼0°C ~ 60°C.
⚫Storage Temperature
◼-10°C ~ 70°C.
⚫Form Factor
◼Mini ITX (6.7”x 6.7”, 17.0cm x 17.0cm).
Note
All specifications and images are subject to change without notice.
1.3 Utilities Supported
⚫Chipset driver
⚫Graphics driver
⚫Intel ME driver
⚫Ethernet driver
⚫Audio driver
⚫Serial IO driver

MANO560 Mini ITX Motherboard
4 Introduction
1.4 Block Diagram

MANO560 Mini ITX Motherboard
Board and Pin Assignments 5
Section 2
Board and Pin Assignments
2.1 Board Layout
Top View

MANO560 Mini ITX Motherboard
6 Board and Pin Assignments
Bottom View

MANO560 Mini ITX Motherboard
Board and Pin Assignments 7
2.2 Rear I/O
Jumpers/Headers/Connectors
1
4-pin ATX Power Input Connector (CN70)
17
Clear CMOS (JP3)
2
PCI-Express x16 Slot (CN20)
18
AT/ATX Power Mode Select Jumper
(JP5)
3
M.2 Key E Socket (CN22)
19
USB 2.0 Header (CN62)
4
PCI-Express Mini Card Connector (CN21)
20
SPI Header (CN81)
5
CPU Fan Header (CN60)
21
COM VDD Select Jumper (JP1)
6
DDR4 SO-DIMM Connectors (DIMM1,
DIMM2)
22
Audio Header (CN52)
7
System Fan Header (CN61)
23
SIM Card Slot (SCN2)
8
LVDS VDD Select Jumper (JP4)
24
M.2 Key B Socket (SCN1)
9
eDP Connector (CN50)
25
USB 3.2 GEN1 Stack Port (CN10)
10
LVDS Backlight Control Header (CN55)
26
VGA Connector (CN34)
11
LVDS Signal Header (CN29)
27
HDMI1.4 Connector (CN33)
12
24-pin ATX Power Input Connector
(CN30)
28
DisplayPort1.3 Connector (CN32)
13
SATA 3.0 Connector (CN7)
29
COM1 and COM2 D-Sub Connector
(CN1)
14
Digital I/O Connector (CN26)
30
LAN1(RJ-45) and USB 2.0 Connector
(CN19)
15
Front Panel Header (CN80)
31
LAN2(RJ-45) and USB 2.0 Connector
(CN11)
16
COM3~COM4 Headers (CN3~CN4)
32
Audio Jack (CN82)

MANO560 Mini ITX Motherboard
8 Board and Pin Assignments
Note
To identify the first pin of a header or jumper, please refer to the following
information:
⚫Usually, there is a thick line or a triangle near the header or jumper pin 1.
⚫Square pad, which you can find on the back of the motherboard, is usually
used for pin 1.
2.3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on
2 jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MANO560 Series, please make sure all the jumpers are in factory
default position. Below you can find a summary table of all jumpers and onboard default settings.
Note
Once the default jumper setting needs to be changed, please do it under power-
off condition.

MANO560 Mini ITX Motherboard
Board and Pin Assignments 9
2.3.1 COM1 Data/Power Select (JP1)
This is a 3x2-pin (pitch=2.00mm) jumper. The COM1 port has +5V power capability on
DCD and +12V on RI by setting JP1.
2.3.2 Clear CMOS (JP3)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear
the CMOS memory of date, time, and system setup parameters by erasing the CMOS
RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which
includes system setup information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the onboard battery.
3. Move the jumper clip from pins 1-2 (default) to pins 2-3. Keep the clip-on pins 2-3
for about 5~10 seconds, then move the clip back to pins 1-2.
4. Re-install the battery.
5. Plug the power cord and turn ON the computer.
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter
data.
Jumper
Description
Setting
JP1
COM Data/Power Select
Default: RS-232 Data
3-5 Close
4-6 Close
JP3
Clear CMOS
Default: Normal Operation
1-2 Close
JP4
LVDS VDD Select
Default: +3.3V Level
1-2 Close
JP5
AT/ATX Power Mode Select
Default: ATX Mode
1-2 Close
Function
Setting
Power: Set COM1 pin 1 to +5V
1-3 close
Data: Set COM1 pin 1 to DCD (Default)
3-5 close
Power: Set COM1 pin 9 to +12V
2-4 close
Data: Set COM1 pin 9 to RI (Default)
4-6 close
Function
Setting
Normal operation (Default)
1-2 close
Clear CMOS
2-3 close

MANO560 Mini ITX Motherboard
10 Board and Pin Assignments
2.3.3 LVDS VDD Select (JP4)
The motherboard supports voltage selection for flat panel displays. Use this 2x3-pin
(pitch=2.0mm) jumper to set up VDD power of the LVDS connector. To prevent hardware
damage, before connecting please make sure that the input voltage of LVDS panel is
correct.
2.3.4 AT/ATX Power Mode Select (JP5)
This 3-pin (pitch=2.0mm) jumper allows you to select AT or ATX power mode.
Function
Setting
+3.3V level (Default)
1-2 close
+5V level
2-4 close
+12V level
5-6 close
Function
Setting
ATX mode (Default)
1-2 close
AT mode
2-3 close

MANO560 Mini ITX Motherboard
Board and Pin Assignments 11
2.4 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection might
cause problems, please make sure all connectors are properly and firmly connected. Here is a
summary table showing connectors on the hardware.
Connector
Description
CN1
COM1 and COM2 D-Sub Connector
CN3~CN4
COM3~COM4 Headers
CN7
SATA 3.0 Connector
CN10
USB 3.2 GEN1 Stack Port
CN11, CN19
LAN and USB 2.0 Connectors
CN20
PCI-Express x16 Slot
CN21
PCI-Express Mini Card Connector
CN22
M.2 Key E Socket
CN26
Digital I/O Connector
CN29
LVDS Signal Header
CN30, CN70
ATX Power Input Connectors
CN32
DisplayPort Connector
CN33
HDMI1.4 Connector
CN34
VGA Connector
CN50
eDP Connector
CN52
Audio Header
CN55
LVDS Backlight Control Header
CN60, CN61
Fan Headers
CN62
USB 2.0 Header
CN80
Front Panel Header
CN81
SPI Header
CN82
Audio Jack
SCN1
M.2 Key B Socket
SCN2
SIM Card Slot

MANO560 Mini ITX Motherboard
12 Board and Pin Assignments
2.4.1 COM1 and COM2 D-Sub Connector (CN1)
The CN1 is a double 9-pin D-Sub connector for COM1 and COM2 serial port interfaces
on the rear I/O. Only COM1 supports RS-232/422/485 mode. The pin assignments of RS-
232/422/485 are listed in table below.
COM1: COM2
COM1
Note
[*]: Pin 1 of COM1 can be DCD/+5V and pin 9 of COM1 can be RI/+12V by
selecting JP1 (see section 2.3.1).
COM2:
2.4.2 COM3~COM4 Headers (CN3~CN4)
The motherboard comes with two 2x5-pin (pitch=2.00mm) headers for COM3~COM4
serial port interfaces.
Pin
RS-232
(3T/5R)
RS-422
(1T/1R Full
Duplex)
RS-485
(1T/1R TX Enable
Low Active)
1
COM1C_DCD [*]
TX (-)
(R (-) / T (-))
2
COM1C_RXD
TX (+)
(R (+) / T (+))
3
COM1C_TXD
RX (+)
NC
4
COM1C_DTR
RX (-)
NC
5
GND
GND
GND
6
COM1C_DSR
NC
NC
7
COM1C_RTS
NC
NC
8
COM1C_CTS
NC
NC
9
COM1C_RI [*]
NC
NC
Pin
Signal
Pin
Signal
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
Pin
Signal
Pin
Signal
1
DCD
2
DSR
3
RX
4
RTS
5
TX
6
CTS
7
DTR
8
RI
9
GND
10
NC

MANO560 Mini ITX Motherboard
Board and Pin Assignments 13
2.4.3 SATA 3.0 Connectors (CN7)
This connector supports the thin Serial ATA cable for primary internal storage device.
2.4.4 USB 3.2 GEN1 Stack Port (CN10)
The motherboard comes with one stacked Universal Serial Bus (compliant with USB 3.2
GEN1) connector on the rear I/O for installing USB peripherals such as a keyboard,
mouse, scanner, etc.
Pin
Signal
1
GND
2
TX+
3
TX-
4
GND
5
RX-
6
RX+
7
GND
Pin
Signal
Pin
Signal
1
USB_PWR
10
USB_PWR
2
USB#1_D-
11
USB#2_D-
3
USB#1_D+
12
USB#2_D+
4
GND
13
GND
5
SSRX1-
14
SSRX2-
6
SSRX1+
15
SSRX2+
7
GND
16
GND
8
SSTX1-
17
SSTX2-
9
SSTX1+
18
SSTX2+

MANO560 Mini ITX Motherboard
14 Board and Pin Assignments
2.4.5 LAN and USB 2.0 Connectors (CN11 and CN19)
The motherboard supports two Ethernet ports (CN11, CN19): two RJ45 connectors with
CN11: Intel® i225-V controller support 10/100/1000/2500Mbps.
CN19: Intel® i219-V controller support 10/100/1000 Mbps.
The Universal Serial Bus (compliant with USB 2.0) connectors on the rear I/O are for
installing USB peripherals such as keyboard, mouse, scanner, etc.
Note
⚫CN11/CN19 supports Wake-on-LAN.
Pin
LAN Signal
Pin
LAN Signal
L1
Tx+ (Data transmission positive)
L2
Tx- (Data transmission negative)
L3
Rx+ (Data reception positive)
L4
RJ-1 (For 1000 Base-T only)
L5
RJ-1 (For 1000 Base-T only)
L6
Rx- (Data reception negative)
L7
RJ-1 (For 1000 Base-T only)
L8
RJ-1 (For 1000 Base-T only)
A
Speed LED
LAN1: Intel® i219-V
OFF: 10Mbps data rate
Green: 100Mbps data rate
Orange: 1Gbps data rate
LAN2: Intel® i225-V
OFF: 10/100Mbps data rate
Green: 1Gbps data rate
Orange: 2.5Gbps data rate
B
Active LED(Yellow)
OFF: No link
Blinking: Link established; data
activity detected
Pin
USB Signal
Pin
USB Signal
1
USB VCC (+5V level)
5
USB VCC (+5V level)
2
USB _D-
6
USB _D-
3
USB _D+
7
USB _D+
4
GND
8
GND
