AXIOMTEK PICO820 Series User manual

PICO820 Series
IntelAtom™All-In-One
Pico ITX CPU Board
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain
accurate information. AXIOMTEK Co., Ltd. assumes no responsibility
for any infringements of patents or any third party’s rights, and any
liability arising from such use.
AXIOMTEK does not warrant or assume any legal liability or
responsibility for the accuracy, completeness or usefulness of any
information in this document. AXIOMTEK does not make any
commitment to update the information in this manual.
AXIOMTEK reserves the right to change or revise this document
and/or product at any time without notice.
No part of this document may be reproduced, stored in a retrieval
system, or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise, without the prior
written permission of AXIOMTEK Co., Ltd.
Caution
If you replace wrong batteries, it causes the danger of explosion. It is
recommended by the manufacturer that you follow the manufacturer’s
instructions to only replace the same or equivalent type of battery, and
dispose of used ones.
Copyright 2010 AXIOMTEK Co., Ltd.
All Rights Reserved
February 2010, Version A4
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity.
To prevent chipsets from electrostatic discharge damage, please take
care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static
packaging until you are ready to install them.
Before holding the board or integrated circuit, touch an unpainted
portion of the system unit chassis for a few seconds. It
discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic
component stores, when handling boards and components.
Trademarks Acknowledgments
AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.
Windows®is a trademark of Microsoft Corporation.
Phoenix & AWARD are trademarks of Phoenix Technology Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International Business
Machines Corporation.
Intel®and Pentium®are trademarks of Intel Corporation.
Winbond is a trademark of Winbond Electronics Corp.
Other brand names and trademarks are the properties and registered
brands of their respective owners.

iv
Table of Contents
Disclaimers.........................................................................................................ii
ESD Precautions...............................................................................................iii
CHAPTER 1 INTRODUCTION...................................................................................1
1.1 Specifications........................................................................................2
1.2 Utilities Supported.................................................................................4
CHAPTER 2 JUMPERS AND CONNECTORS ..........................................................5
2.1 Board Dimensions and Fixing Holes......................................................5
2.2 Board Layout.........................................................................................7
2.3 Jumper Settings ....................................................................................9
2.3.1 Flat Panel Connector Voltage Selection Jumper (JP1)..................9
2.3.2 AUTO BUTTON Mode Selection Jumper (JP3)............................ 10
2.3.3 CompactFlash™ Power Selection Jumper (JP4) .......................... 10
2.3.4 CMOS Clear Jumpers (JP5)......................................................... 11
2.4 Connectors.......................................................................................... 12
2.4.1 VGA Connector (CN1)..................................................................13
2.4.2 DC POWER JACK Connector (CN2)............................................14
2.4.3 DC POWER Connector (CN3) (Optional) .....................................14
2.4.4 LPC Interface Connector (CN4)....................................................14
2.4.5 LVDS Flat Panel Connector (CN5)............................................... 15
2.4.6 Serial ATA Power Connector (CN6)..............................................16
2.4.7 Flat Panel Bezel Connector (CN7)................................................16
2.4.8 Digital I/O Connector (CN8).......................................................... 17
2.4.9 LVDS Backlight Connector (CN9)................................................. 18
2.4.10 Thru Front I/O Connector 1 (CN10) ..............................................19
2.4.11 Thru Front I/O Connector 2 (CN11) ..............................................19
2.4.12 SMBUS Connector (CN12)........................................................... 20
2.4.13 CPLD JTAG Interface Connector (JP2)........................................20
2.4.14 Ethernet Connector (LAN1) ..........................................................20
2.4.15 Serial ATA Power Connector (SATA1) .........................................21
2.4.16 DDRII SODIMM Connector (SCN1).............................................. 21
2.4.17 CompactFlash™ Socket (SCN2) ..................................................22
CHAPTER 3 HARDWARE DESCRIPTION.............................................................. 25
3.1 Microprocessors..................................................................................25
3.2 BIOS ...................................................................................................25
3.3 System Memory..................................................................................25
3.4 I/O Port Address Map..........................................................................26
3.4 I/O Port Address Map..........................................................................26
3.5 Interrupt Controller ..............................................................................27
CHAPTER 4 PHOENIX-AWARD BIOS UTILITY......................................................29
4.1 Entering Setup ....................................................................................29
4.2 Control Keys........................................................................................ 30
4.3 Getting Help........................................................................................ 30
4.4 The Main Menu ...................................................................................31
4.5 Standard CMOS Setup Menu..............................................................32

v
4.6 Advanced BIOS Features....................................................................34
4.7 Advanced Chipset Features ................................................................37
4.8 Integrated Peripherals.........................................................................39
4.9 Power Management Setup..................................................................42
4.10 PnP/PCI Configuration Setup..............................................................45
4.11 PC Health Status................................................................................. 47
4.12 Load Optimized Defaults..................................................................... 48
4.13 Set Supervisor/User Password............................................................ 49
4.14 Save & Exit Setup ...............................................................................50
4.15 Exit Without Saving.............................................................................51
CHAPTER 5 INSTALLATION OF DRIVERS............................................................ 53
5.1 Installing Chipset Driver.......................................................................53
5.2 Installing VGA Driver...........................................................................56
5.3 Installing LAN Driver............................................................................60
5.4 Installing Audio Driver..........................................................................62
APPENDIX A WATCHDOG TIMER .........................................................................65
APPENDIX B DIGITAL I/O ......................................................................................67

vi
MEMO

PICO820 Series All-In-One PICO ITX Board User’s Manual
Introduction
1
CHAPTER 1
INTRODUCTION
The PICO820 is a Pico-ITX board with support for Intel® ATOM™
processor Z500 Series, and integrates chipset Intel®System
Controller Hub US15W that deliver outstanding system performance
through high-bandwidth interfaces, multiple I/O functions for interactive
applications and various embedded computing solutions. The board
has one 200-pin unbuffered SODIMM sockets for DDR2 400/533 MHz
SO-DIMM memory, maximum memory capacity up to 2GB. It also
features Gigabit/Fast Ethernet, one serial ATA port, four USB 2.0 high
speed compliant, built-in high definition audio codec that can achieve
the best stability and reliability for industrial applications. It provides
you with unique embedded features, such as two serial ports (2x RS-
232) and Pico-ITX form factor that applies an extensive array of PC
peripherals. The board can be enhanced by its built-in watchdog timer,
a special industrial feature not commonly seen on other motherboards.

PICO820 Series All-In-One PICO ITX Board User’s Manual
Introduction
2
1.1 Specifications
CPU
Intel®ATOMTM processor Z500 Series
System Chipset
Intel®System Controller Hub US15W
BIOS
Phoenix-Award BIOS, Y2K compliant
8Mbit FWH Flash, DMI, Plug and Play
SmartView for multiple LCD type selection, display
mode option and application extension features
“Load Optimized Default” to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
System Memory
One x 200-pin unbuffered DDR2 SODIMM socket
Maximum to 2GB DDR2 400/533 MHz memory
Onboard Multi I/O
Controller: Winbond W83627HG
Serial Ports: two ports for RS-232
CompactFlash™Socket
One CompactFlash™Type II low profile slot
USB Interface
Four USB ports with fuse protection and complies with USB
Spec. Rev. 2.0
Display
One 2 x 20 LVDS connector, one 7-pin wafer connector for
inverter control
One D-sub 15-pin slim type connector
Watchdog Timer
1~255 seconds; up to 255 levels

PICO820 Series All-In-One PICO ITX Board User’s Manual
Introduction
3
Ethernet
One port with RTL8111B for Gigabit/Fast Ethernet
One RJ-45 connector
Audio
HD Audio compliant (with Speaker/line-out & MIC-in) via
ALC888
Supports multi-channel audio stream, 32-bit sample depth,
and sample rate up to 192KHz
Lin-in/Line-out/MIC-in
SDIO
One SDIO port support SDIO1.1 specification.
Power Management
ACPI (Advanced Configuration and Power Interface)
Form Factor
Pico-ITX form factor
NOTE All specifications and images are subject to change
without notice.

PICO820 Series All-In-One PICO ITX Board User’s Manual
Introduction
4
1.2 Utilities Supported
Chipset Driver
Ethernet Driver
Graphic Drivers
Audio Drivers

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
5
CHAPTER 2
JUMPERS AND CONNECTORS
2.1 Board Dimensions and Fixing Holes
Component Side
NOTE The height of Component Side is 18mm.

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
6
Solder Side
NOTE The height of Solder Side is 9mm.

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
7
2.2 Board Layout
Component Side

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
8
Solder Side

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
9
2.3 Jumper Settings
Proper jumper settings configure the PICO820 to meet your application
purpose. We are herewith listing a summary table of all jumpers and
default settings for onboard devices, respectively.
Jumper
Default Setting
Jumper Setting
JP1
Flat Panel Power Selection:
Optional or Default : 3.3V
Short 1-2
JP3
AUTO BUTTON Mode Selection
Optional or Default : OFF
Short 2-3
JP4
CompactFlash Voltage Selection
Optional or Default : 3.3V
Short 1-2
JP5
Clear CMOS Setting: Normal
Short 1-2
2.3.1 Flat Panel Connector Voltage Selection Jumper
(JP1)
The board supports +3.3V or +5V flat panel displays. Configure the
jumper JP1 to the appropriate voltage of the flat panel (CN5).
Description
Function
Jumper Setting
Flat Panel
Connector (CN5)
Voltage Selection
3.3V (Default)
5V

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
10
2.3.2 AUTO BUTTON Mode Selection Jumper (JP3)
The jumper selects the AUTO BUTTON Mode.
Description
Function
Jumper Setting
AUTO BUTTON
Mode Selection
ON
OFF
(Default)
2.3.3 CompactFlash™Power Selection Jumper (JP4)
This jumper is to select the voltage for CompactFlash™interface.
Description
Function
Jumper Setting
CompactFlash™
Power Select
3.3V (Default)
5V

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
11
2.3.4 CMOS Clear Jumpers (JP5)
You may need to use this jumper is to clear the CMOS memory if
incorrect settings in the Setup Utility.
Description
Function
Jumper Setting
CMOS Clear
Normal
(Default)
Clear CMOS

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
12
2.4 Connectors
Connectors connect the board with other parts of the system. Loose or
improper connection might cause problems. Make sure all connectors
are properly and firmly connected. Here is a summary table shows you
all connectors on the PICO820 Series.
Connectors
Label
VGA Connector
CN1
DC Power Jack Connector
CN2
DC Power Connector(Optional)
CN3
LPC Interface Connector
CN4
LVDS Connector
CN5
Serial ATA Power Connector
CN6
Flat Panel Bezel Connector
CN7
DIO Port Connector
CN8
Inverter Connector
CN9
Thru Front I/O Connector 1
CN10
Thru Front I/O Connector 2
CN11
SMBUS Connector
CN12
CPLD JTAG Interface Connector
JP2
LAN Connector
LAN1
Serial ATA Connector
SATA1
DDRII SODIMM Connector
SCN1
Compact Flash Connector
SCN2

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
13
2.4.1 VGA Connector (CN1)
CN1 is a standard 15-pin DB15 connector commonly for the CRT VGA
display.
Pin
Signal
1
Red
2
Green
3
Blue
4
N.C
5
Ground (GND)
6
AnalogGround（AGND）
7
AnalogGround（AGND）
8
AnalogGround（AGND）
9
N.C
10
Ground (GND)
11
N.C
12
DDC DATA
13
Horizontal Sync
14
Vertical Sync
15
DDC CLK
1
10 11
15
5
6

PICO820 Series All-In-One PICO ITX Board User’s Manual
Jumpers and Connectors
14
2.4.2 DC POWER JACK Connector (CN2)
The CN2 is a DC Power JACK connector for DC 5V input.
Pin
Signal
1
GND
2
GND
3
+5V
4
+5V
2.4.3 DC POWER Connector (CN3) (Optional)
The CN3 (co-lay with CN2) is a 3.96mm wafer DC Power connector
for DC 5V input.
Pin
Signal
1
+5V
2
GND
2.4.4 LPC Interface Connector (CN4)
The CN4is a LPC Interface Connector.
Pin
Signal
Pin
Signal
9
8
7
6
5
4
3
2
1
1
LPC_PCLK
2
BUF_RST#
3
LPC_FRAME#
4
LPC_AD0
5
LPC_AD1
6
LPC_AD2
7
LPC_AD3
8
+3.3V
9
GND
10
GND
