AXIOMTEK wm5201 User manual

MANO881 Series
Intel®Socket 1150 CoreTM i7/ i5/ i3/
Celeron®Processor Mini ITX Board
with HDMI/ VGA/ LVDS
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2016 Axiomtek Co., Ltd.
All Rights Reserved
July 2016, Version A2
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®CoreTM i7/ /i5 /i3, Celeron®are trademarks of Intel Corporation.
Winbond is a trademark of Winbond Electronics Corp.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers ......................................................................................................ii
ESD Precautions............................................................................................. iii
Chapter 1 Introduction............................................. 1
1.1 Features................................................................................................2
1.2 Specifications........................................................................................2
1.3 Utilities Supported.................................................................................3
Chapter 2 Board and Pin Assignments.................... 5
2.1 Board Layout.........................................................................................5
2.2 Rear Panel I/O ......................................................................................7
2.3 Jumper Settings....................................................................................7
2.3.1 Restore BIOS Optimal Defaults (CLRCMOS1)........................................... 8
2.3.2 Panel Power Selection (PNL_PWR1)......................................................... 8
2.3.3 Backlight Power Selection (BKT_PWR1).................................................... 8
2.3.4 AT/ATX Power Mode Jumper (PWR_JP1).................................................. 8
2.3.5 PWM Level Selection (BLT_PWM1) ........................................................... 8
2.4 Headers and Connectors ......................................................................9
2.4.1 Rear Panel Connectors............................................................................. 10
2.4.2 Backlight Power Connector (BLT_PWR1)..................................................11
2.4.3 Backlight Volume Control Connector (BLT_VOL1) ....................................11
2.4.4 ATX Power Input Connectors (ATXPWR1 and CON1)............................. 12
2.4.5 PS/2 Keyboard and Mouse Connector (PS2_KB_MS1)........................... 13
2.4.6 RS-232 Port Wafers (COM4~COM6)........................................................ 13
2.4.7 Fan Connectors (CPU_FAN1 and CHA_FAN1)........................................ 13
2.4.8 Chassis Intrusion Headers (CI1~CI2) ....................................................... 14
2.4.9 System Panel Header (PANEL1) .............................................................. 15
2.4.10 Audio AMP Output Wafer (SPEAKER1).................................................... 15
2.4.11 Digital I/O Header (JGPIO1) ..................................................................... 16
2.4.12 SATA Connectors (SATA_0~SATA_1 and SATA_4~SATA_5)................... 16
2.4.13 Front Panel Audio Header (HD_AUDIO1)................................................. 16
2.4.14 USB 2.0 Headers (USB4_5, USB8_9 and USB10_11)............................. 17
2.4.15 LVDS Panel Connector (LVDS1)............................................................... 17
Chapter 3 Hardware Installation ........................... 19
3.1 Screw Holes........................................................................................19
3.2 Pre-installation Precautions.................................................................19
3.3 Installing Memory Modules (SO-DIMM) ..............................................20

v
3.4 Expansion Slots (PCI-Express and mSATA Slots)...............................21
3.5 Installing an Expansion Card...............................................................21
Chapter 4 Hardware Description ........................... 23
4.1 Microprocessors..................................................................................23
4.2 BIOS....................................................................................................23
4.3 System Memory..................................................................................23
4.4 I/O Port Address Map..........................................................................24
4.5 Interrupt Controller (IRQ) Map.............................................................26
4.6 Memory Map .......................................................................................30
Chapter 5 AMI BIOS Setup Utility .......................... 31
5.1 Starting................................................................................................31
5.2 Menu Bar.............................................................................................32
5.3 Navigation Keys..................................................................................32
5.4 Main Menu ..........................................................................................34
5.5 Advanced Menu..................................................................................35
5.6 H/W Monitor Menu ..............................................................................47
5.7 Boot Menu...........................................................................................48
5.8 Security Menu .....................................................................................50
5.9 Exit Menu............................................................................................51

vi
This page is intentionally left blank.

MANO881 Series All-In-One Mini ITX Board
Introduction 1
Chapter 1
Introduction
The MANO881 is a Mini ITX board based on the 4th Generation Intel®CoreTM i7 / i5 / i3 /
Celeron®processors (codename: Haswell) in LGA1150 socket. This motherboard integrates
Intel®H81 chipset that delivers outstanding system performance through high-bandwidth
interfaces, multiple I/O functions for interactive applications and various embedded computing
solutions. There are two 204-pin DDR3 SO-DIMM for dual channel DDR3 1600/1333MHz
memory with maximum capacity up to 16GB; assuming dual channel mode of two 8GB
double-sided unbuffered, non-ECC SO-DIMM memory configuration. It also features two
Gigabit Ethernet ports, two SATA 3.0 ports with maximum transfer rate up to 6Gb/s, two SATA
2.0 ports with maximum transfer rate up to 3Gb/s, two USB 3.0 and eight USB 2.0 high speed
compliant ports that can achieve the best stability and reliability for industrial applications.

MANO881 Series All-In-One Mini ITX Board
2 Introduction
1.1 Features
LGA1150 Socket 4th Generation Intel®Core™ i7/ i5/ i3/ Celeron®processors (codename:
Haswell)
2 DDR3 1600/1333MHz max. up to 16GB memory capacity
PCI-Express x16 Gen. 2 supported
1 mSATA supported
2 SATA-600 and 2 SATA-300 supported
2 USB 3.0 and 8 USB 2.0 ports
Dual view display
Display: HDMI/VGA/LVDS
1.2 Specifications
CPU
Intel®CoreTM i7/ i5/ i3/ Celeron®processors.
System Chipset
Intel®H81.
CPU Socket
LGA1150 socket.
BIOS
AMI BIOS via SPI interface with socket.
System Memory
Two 204-pin SO-DIMM sockets.
Maximum up to 16GB DDR3 memory.
Support 1600/1333MHz memory.
L3 Cache
Varies with CPU.
Onboard Multi I/O
One PS/2 keyboard and mouse in internal box header.
Serial ports: Three ports for RS-232/422/485 (COM1/2/3) on the rear I/O. Three ports
for RS-232 (COM4/5/6) in internal box headers.
USB Interface
Two USB 3.0 ports.
Eight USB 2.0 ports (2 on the rear I/O and 6 in box headers).
Onboard Graphics
Intel®HD 5000 Integrated Graphics (depends on CPU).
Display memory: Max. shared system memory up to 1759MB.
One HDMI: Resolution max. up to 4096x2304 @ 75Hz.
One VGA: Resolution max. up to 1920x1200 @ 60Hz.
One LVDS: Resolution max. up to 1920x1080 dual channel.
Ethernet
LAN1: Intel®i210AT, supports 1000/100/10 Base-T Gigabit Ethernet with
Wake-on-LAN and PXE Boot ROM.
LAN2: Intel®i217V supports 1000/100/10 Base-T Gigabit Ethernet with
Wake-on-LAN and PXE Boot ROM.

MANO881 Series All-In-One Mini ITX Board
Introduction 3
Serial ATA
Two SATA 3.0 ports (6Gb/s).
Two SATA 2.0 ports (3Gb/s).
Audio
HD codec audio as MIC-in/line-out with Realtek ALC662.
Expansion Slot
One PCI-Express x16 Gen. 2.
One mSATA.
Watchdog Timer
1~255 seconds or minutes; up to 255 levels.
Note
All specifications and images are subject to change without notice.
1.3 Utilities Supported
Intel®chipset drivers
Intel®graphics drivers
Ethernet utility and drivers
Intel®USB 3.0 drivers
HD audio drivers
RAID utility
iAMT utility and drivers

MANO881 Series All-In-One Mini ITX Board
4 Introduction
This page is intentionally left blank.

MANO881 Series All-In-One Mini ITX Board
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Layout
Top View

MANO881 Series All-In-One Mini ITX Board
6 Board and Pin Assignments
1 : Backlight Power Connector (BLT_PWR1)
2 : Backlight Volume Control Connector (BLT_VOL1)
3 : 24-pin ATX Power Input Connector (ATXPWR1)
4 : Panel Power Selection (PNL_PWR1)
5 : Backlight Power Selection (BKT_PWR1)
6 : PWM Level Selection (BLT_PWM1)
7 : PS/2 Keyboard and Mouse Connector (PS2_KB_MS1)
8 : RS-232 Port Headers (COM4, COM5, COM6)
9 : 4-pin +12V CPU Fan Connector (CPU_FAN1)
10 : Chassis Intrusion Headers (CI1, CI2)
11 : 4-pin ATX Power Input Connector (CON1)
13 : System Panel Header (PANEL1)
14 : 3W Audio AMP Output Wafer (SPEAKER1)
15 : Digital Input/Output Header (JGPIO1)
16 : 4-pin +12V Chassis Fan Connector (CHA_FAN1)
17 : Restore BIOS Optimal Defaults Jumper (CLRCMOS1)
18 : ATX/AT Power Mode Jumper (PWR_JP1)
19 : SATA 3.0 Connectors (SATA_0, SATA_1)
SATA 2.0 Connectors (SATA_4, SATA_5)
20 : Front Panel Audio Header (HD_AUDIO1)
21 : USB 2.0 Headers (USB4_5, USB8_9, USB10_11)
22 : LVDS Panel Connector (LVDS1)

MANO881 Series All-In-One Mini ITX Board
Board and Pin Assignments 7
2.2 Rear Panel I/O
2.3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MANO881 Series, please make sure all of the jumpers are in factory
default position. Below you can find a summary table of all jumpers and onboard default
settings.
Jumper
Description
Setting
CLRCMOS1
Restore BIOS Optimal Defaults
Default: Normal Operation
1-2 Close
PNL_PWR1
Panel Power Selection
Default: +3V
1-2 Close
BKT_PWR1
Backlight Power Selection
Default: +5V
1-2 Close
PWR_JP1
ATX/AT Power Mode Jumper
Default: ATX Mode
2-3 Close
BLT_PWM1
PWM Level Selection
Default: +5V
2-3 Close

MANO881 Series All-In-One Mini ITX Board
8 Board and Pin Assignments
2.3.1 Restore BIOS Optimal Defaults (CLRCMOS1)
CLRCMOS1 allows you to clear the data in CMOS. To clear and reset the system
parameters to default setup, please turn off the computer and unplug the power cord
from the power supply. After waiting for 15 seconds, use a jumper clip to short pin 2 and
pin 3 on CLRCMOS1 for 5 seconds. However, please do not clear the CMOS right after
you update the BIOS. If you need to clear the CMOS when you just finish updating the
BIOS, you must boot up the system first, and then shut it down before you do the
clear-CMOS action. Please be noted that the password, date, time, user default profile
and MAC address will be cleared only if the CMOS battery is removed.
2.3.2 Panel Power Selection (PNL_PWR1)
This motherboard supports voltage selection for flat panel displays. Use this jumper to
set power of LVDS panel to +3V, +5V or +12V. To prevent hardware damage, before
connecting please make sure that the input voltage of LVDS panel is correct.
2.3.3 Backlight Power Selection (BKT_PWR1)
This jumper allows you to select backlight power for LVDS panel.
2.3.4 AT/ATX Power Mode Jumper (PWR_JP1)
This jumper allows you to select ATX power or AT power mode.
2.3.5 PWM Level Selection (BLT_PWM1)
This jumper allows you to select PWM level.
Function
Setting
Normal (Default)
1-2 close
Restore BIOS optimal defaults
2-3 close
Function
Setting
+3V (Default)
1-2 close
+5V
2-3 close
+12V
4-5 close
Function
Setting
+5V (Default)
1-2 close
+12V
2-3 close
Function
Setting
AT mode
1-2 close
ATX mode (Default)
2-3 close
Function
Setting
+3V level
1-2 close
+5V level (Default)
2-3 close

MANO881 Series All-In-One Mini ITX Board
Board and Pin Assignments 9
2.4 Headers and Connectors
Signals go to other parts of the system through headers and connectors. Loose or improper
connection might cause problems, please make sure all headers and connectors are properly
and firmly connected. Here is a summary table showing headers and connectors on the
hardware.
Note
Onboard headers and connectors are NOT jumpers. Do NOT place jumper clips
over these headers and connectors. Placing jumper clips over the headers and
connectors will cause permanent damage of the motherboard!
Header and Connector
Description
BLT_PWR1
Backlight Power Connector
BLT_VOL1
Backlight Volume Control Connector
ATXPWR1
24-pin ATX Power Input Connector
PS2_KB_MS1
PS/2 Keyboard and Mouse Connector
COM4~COM6
RS-232 Port Headers
CPU_FAN1
4-pin +12V CPU Fan Connector
CI1~CI2
Chassis Intrusion Headers
CON1
4-pin ATX Power Input Connector
PANEL1
System Panel Header
SPEAKER1
3W Audio AMP Output Wafer
JGPIO1
Digital I/O Header
CHA_FAN1
4-pin +12V Chassis Fan Connector
SATA_0~SATA_1
SATA 3.0 Connectors
SATA_4~SATA_5
SATA 2.0 Connectors
HD_AUDIO1
Front Panel Audio Header
USB4_5, USB8_9, USB10_11
USB 2.0 Headers
LVDS1
LVDS Panel Connector
PCIE1
PCI-Express x16 Slot
mini-SATA
mSATA Slot
DDR3_A1
204-pin DDR3 SO-DIMM Socket A1
DDR3_B1
204-pin DDR3 SO-DIMM Socket B1

MANO881 Series All-In-One Mini ITX Board
10 Board and Pin Assignments
2.4.1 Rear Panel Connectors
1
COM Port (COM1)*
7
USB 2.0 Ports (T:USB3, B:USB2)
2
COM Port (COM3)*
8
USB 3.0 Ports (T:USB1, B:USB0)
3
LAN RJ-45 Port (LAN1)**
9
D-Sub VGA Port (VGA1)
4
LAN RJ-45 Port (LAN2)**
10
COM Port (COM2)*
5
Line-out (Lime)
11
HDMI Port (HDMI1)
6
Microphone (Pink)
* This motherboard supports RS-232/422/485 on COM1~COM3 ports. The pin
assignments are listed in table below. If you need to adjust these COM ports to work as
RS-232/422/485, please refer to BIOS setting in section 5.4.
** There are two LEDs next to the LAN port. Please refer to the table below for the LAN
port LED indications.
LAN Port LED Indications
Pin
RS-232
RS-422
RS-485
1
DCD, Data Carrier Detect
TX-
RTX-
2
RXD, Receive Data
RX+
N/A
3
TXD, Transmit Data
TX+
RTX+
4
DTR, Data Terminal Ready
RX-
N/A
5
GND
GND
GND
6
DSR, Data Set Ready
N/A
N/A
7
RTS, Request To Send
N/A
N/A
8
CTS, Clear To Send
N/A
N/A
9
No Power/+5V/+12V
N/A
N/A
Activity/Link LED
SPEED LED
Status
Description
Status
Description
OFF
No link
OFF
10Mbps connection
Blinking
Data activity
Orange
100Mbps connection
ON
Link
Green
1Gbps connection

MANO881 Series All-In-One Mini ITX Board
Board and Pin Assignments 11
2.4.2 Backlight Power Connector (BLT_PWR1)
The backlight power interface is available through this connector.
2.4.3 Backlight Volume Control Connector (BLT_VOL1)
The backlight volume control interface is available through this connector.
Pin
Signal
1
GND
2
GND
3
BL CTL
4
BL EN
5
LCD_BLT_VCC
6
LCD_BLT_VCC
Pin
Signal
1
GPIO_VOL_UP
2
GPIO_VOL_DW
3
PWRDN
4
LVDS1 BLUP
5
LVDS1 BLDW
6
GND
7
GND

MANO881 Series All-In-One Mini ITX Board
12 Board and Pin Assignments
2.4.4 ATX Power Input Connectors (ATXPWR1 and CON1)
Steady and sufficient power can be supplied to all components on the motherboard by
connecting power connector. Please make sure all components and devices are
properly installed before connecting the power connector. External power supply plug fits
into this connector in only one orientation. Properly press down power supply plug until it
completely and firmly fits into this connector. Loose connection may cause system
instability.
The ATXPWR1 is a 24-pin ATX power connector. Please connect an ATX power supply
to this connector.
Note
Though this motherboard provides 24-pin
ATX power connector, it can still work if you
adopt a traditional 20-pin ATX power supply.
To use the 20-pin ATX power supply, please
plug your power supply along with pin 1 and
pin 13.
24 13
12 1
20-pin ATX power supply
installation
The CON1 is a 4-pin ATX power connector. Please connect a 12V ATX power supply to
this connector.
Pin
Signal
Pin
Signal
1
3.3V
13
3.3V
2
3.3V
14
-12V
3
GND
15
GND
4
+5V
16
PS_ON
5
GND
17
GND
6
+5V
18
GND
7
GND
19
GND
8
PWR OK
20
-5V
9
5VSB
21
+5V
10
+12V
22
+5V
11
+12V
23
+5V
12
3.3V
24
GND
Pin
Signal
Pin
Signal
1
GND
3
+12V
2
GND
4
+12V
3
1

MANO881 Series All-In-One Mini ITX Board
Board and Pin Assignments 13
2.4.5 PS/2 Keyboard and Mouse Connector (PS2_KB_MS1)
This is an interface for PS/2 keyboard and mouse.
2.4.6 RS-232 Port Wafers (COM4~COM6)
COM4/COM5/COM6:
2.4.7 Fan Connectors (CPU_FAN1 and CHA_FAN1)
Fans are always needed for cooling down CPU and system temperature. This
motherboard has two fan connectors.
The CPU_FAN1 is for CPU fan interface. Please connect the CPU fan cable to the
connector and match the black wire to the ground pin.
Note
Though this motherboard provides 4-pin CPU
fan (Quiet Fan) support, the 3-pin CPU fan still
can work successfully even without the fan
speed control function. If you plan to connect
the 3-pin CPU fan to the CPU fan connector on
this motherboard, please connect it to pin 1~3.
Pin
Signal
1
KBCLK
2
+5V
3
KBDATA
4
+5V
5
MSDATA
6
GND
7
MSCLK
8
GND
Pin
Signal
Pin
Signal
1
DCD
6
DSR
2
RXD
7
RTS
3
TXD
8
CTS
4
DTR
9
No Power/+5V/+12V
5
GND
10
NC
Pin
Signal
1
GND
2
+12V
3
CPU_FAN_SPEED
4
FAN_SPEED_CONTROL

MANO881 Series All-In-One Mini ITX Board
14 Board and Pin Assignments
The CHA_FAN1 is for chassis fan interface. Please connect the fan cable to the fan
connector and match the black wire to the ground pin.
1 4
2.4.8 Chassis Intrusion Headers (CI1~CI2)
This motherboard supports CASE OPEN detection feature that detects if the chassis
cover has been removed. This feature requires a chassis with chassis intrusion
detection design.
Note
CI1:
- Close: Active case open.
- Open : Normal.
CI2:
- Close: Normal.
- Open: Active case open.
Pin
Signal
1
GND
2
+12V
3
CHA_FAN_SPEED
4
FAN_SPEED_CONTROL
Pin
Signal
1
Signal
2
GND
