AXIS T8051 Power Converter AC/DC

Electromagnetic Compatibility
(EMC)
This equipment has been designed and
tested to fulfill applicable standards
for:
• Radio frequency emission when
installed according to the
instructions and used in its intended
environment.
• Immunity to electrical and
electromagnetic phenomena when
installed according to the
instructions and used in its intended
environment.
USA - This equipment has been
tested using a shielded network cable
(STP) and found to comply with the
limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Canada - This Class B digital
apparatus complies with Canadian
ICES-003.
Europe - This digital equipment
fulfills the requirements for RF
emission according to the Class B limit
of EN 55022.
This product fulfills the requirements
for emission and immunity
according to EN 50121-4 and IEC
62236-4 railway applications.
This product fulfills the requirements
for immunity according to EN 61000-
6-1 residential, commercial and light-
industrial environments.
This product fulfills the requirements
for immunity according to EN 61000-
6-2 industrial environments.
This product fulfills the requirements
for immunity according to EN 55024
residential and commercial
environments.
Australia/New Zealand
This digital equipment fulfills the
requirements for RF emission
according to the Class B limit of AS/
NZS CISPR 22.
Safety
This product complies with IEC/EN/UL
60950-22, Safety of
Information Technology Equipment.
Korea - ࢇЕɼࢽࡈ%ࢷ࢕ળࢶଢԻ۰
࣯Իɼࢽ߾۰یࡈଜЕʨࡶּࢶࡳԻଜֲֻҘ
ࠇ߾۰یࡈଟܹ࢑ݡТЬ
Japan - この装置は、クラスB 情報技術装置です。
この装置は、家庭環境で使用することを目 的として
いますが、この装置がラジオやテレビジョン受信機
に近接して使用されると、 受信障害を引き起こすこ
とがあります。 取扱説明書に従って正しい取り扱い
をして下さい。

The power supply used with this
product shall fulfill the requirements
for Safety Extra Low Voltage (SELV)
and Limited Power Source (LPS)
according to EN/IEC/UL 60950-22.
Equipment Modifications
This equipment must be installed and
used in strict accordance with the
instructions given in the user
documentation. This equipment
contains no user-serviceable
components. Unauthorized equipment
changes or modifications will
invalidate all applicable regulatory
certifications and approvals.
Liability
Every care has been taken in the
preparation of this document. Please
inform your local Axis office of any
inaccuracies or omissions. Axis
Communications AB cannot be held
responsible for any technical or
typographical errors and reserves the
right to make changes to the product
and documentation without prior
notice. Axis Communications AB
makes no warranty of any kind with
regard to the material contained
within this document, including, but
not limited to, the implied warranties
of merchantability and fitness for a
particular purpose. Axis
Communications AB shall not be liable
nor responsible for incidental or
consequential damages in connection
with the furnishing, performance or
use of this material. This product is
only to be used for its intended
purpose.
Disposal and Recycling
When this product has reached the
end of its useful life, dispose of it
according to local raws and
regulations. For information about
your nearest designated collection
point, contact your local authority
responsible for waste disposal.
In accordance with local legislation,
penalties may be applicable for
incorrect disposal of this waste.
Europe
This symbol means that the
product shall not be
disposed of together with
household or commercial
waste.
Directive 2012/19/EU on waste
electrical and electronic
equipment (WEEE) is applicable in the
European Union member states. To
prevent potential harm to human
health and the environment, the
product must be disposed of in
an approved and environmentally safe
recycling process. For information
about your nearest designated
collection point, contact your local
authority responsible for waste
disposal. Businesses should contact
the product supplier for information
about how to dispose of this product
correctly.
This product complies with the
requirements of Directive 2011/65/EU
on the restriction of the use of certain
hazardous substances in electrical and
electronic equipment (RoHS).
China
This product complies with the
requirements of the
legislative act Administration
on the Control of Pollution
Caused by Electronic Information
Products (ACPEIP).
Support
Should you require any technical
assistance, please contact your Axis

reseller. If your questions cannot be
answered immediately, your reseller
will forward your queries through the
appropriate channels to ensure a rapid
response. If you are connected to the
Internet, you can:
• download user documentation and
firmware updates
• find answers to resolved problems in
the FAQ database. Search by
product, category, or phrases
• report problems to Axis support by
logging in to your private support
area.
Safeguards
Please read through this Installation
Guide carefully before installing the
Axis product. Keep the
Installation Guide for further
reference.
• Store the Axis product in a dry and
ventilated environment.
• Avoid exposing the Axis product to
vibration, shocks or heavy pressure.
• Do not install the product on
unstable brackets, unstable or
vibrating surfaces or walls, since this
could cause damage to the product.
• Only use applicable tools when
installing the Axis product; excessive
force could cause damage to the
product.
• Do not use chemicals, caustic agents,
or aerosol cleaners. Use a damp cloth
for cleaning.
• Use only accessories that comply
with technical specification of the
product. These can be provided by
Axis or a third party.
• Use only spare parts provided by or
recommended by Axis.
• Do not attempt to repair the product
by yourself, contact Axis or your Axis
reseller for service matters.
• This Axis product shall be used in
compliance with local laws and
regulations.
• Conservez le produit Axis dans un
environnement sec et aéré.
• Évitez d'exposer le produit Axis aux
vibrations, aux chocs ou à une forte
pression. N'installez pas le produit
sur un support instable, ou des
surfaces ou des murs instables ou
vibrants, car cela pourrait
l'endommager.
• N'utilisez que les outils applicables
pour installer le produit Axis ; une
force excessive pourrait
endommager le produit.
• Pour le nettoyage, n’utilisez ni
produits chimiques, ni substances
caustiques ou aérosols. Utilisez un
chiffon humide pour le nettoyage.
• N’utilisez que des accessoires
conformes aux caractéristiques
techniques du produit. Ceuxci
peuvent être fournis par Axis ou par
un fournisseur tiers.
• Utilisez uniquement des pièces de
rechange fournies ou recommandées
par Axis.
• Ne tentez pas de réparer le produit
vous-même, contactez Axis ou votre
revendeur Axis pour toute
réparation.

• Ce produit Axis doit être utilisé
conformément aux lois et
réglementations locales en vigueur.
• Lagern Sie das Axis-Produkt in einer
trockenen und belüfteten
Umgebung.
• Setzen Sie das Axis Produkt keinen
Vibrationen, Erschütterungen oder
starkem Druck aus. Installieren Sie
das Produkt nicht an instabilen
Halterungen oder instabilen oder
vibrierenden Oberflächen oder
Mauern, da dadurch das Produkt
beschädigt werden könnte.
• Verwenden Sie bei der Installation
des Axis Produkts nur geeignetes
Werkzeug; zu hoher Kraftaufwand
kann das Produkt beschädigen.
• Verwenden Sie keine chemischen,
ätzenden oder aerosolhaltigen
Reinigungsmittel.
• Verwenden Sie zur Reinigung ein
feuchtes Tuch.
• Verwenden Sie nur Zubehör, das den
technischen Spezifikationen des
Produkts entspricht. Dieses ist von
Axis oder Drittanbietern erhältlich.
• Verwenden Sie nur Ersatzteile, die
von Axis empfohlen bzw.
bereitgestellt wurden.
• Versuchen Sie nicht, das Produkt
selbst zu reparieren. Wenden Sie sich
bei Service- Angelegenheiten an Axis
oder an Ihren Axis-Händler.
Verwenden Sie dieses Axis-Produkt
unter Beachtung der vor Ort geltenden
rechtlichen Bestimmungen.
• Conservare il prodotto Axis in un
ambiente asciutto e ben ventilato.
• Evitare di esporre il prodotto Axis
alle vibrazioni, agli urti o a forte
pressione. Non installare il prodotto
su staffe instabili, superfici o pareti
instabili o vibranti, poiché ciò
potrebbe danneggiare il prodotto.
• Utilizzare solo strumenti idonei
quando si installa il prodotto Axis.
Una forza eccessiva potrebbe
danneggiare il prodotto.
• Non utilizzare sostanze chimiche,
agenti caustici o detergenti spray.
Utilizzare un panno umido per la
pulizia.
• Utilizzare solo accessori conformi
con le specifiche tecniche del
prodotto. Queste possono essere
fornite da Axis o da terze parti.
• Utilizzare solo parti di ricambio
fornite o raccomandate da Axis.
• Non tentare di riparare il prodotto da
soli, contattare Axis o il rivenditore
di zona Axis per assistenza.
• Questo prodotto Axis deve essere
utilizzato in conformità alle leggi e
alle disposizioni locali.
• Guarde el producto Axis en un
entorno seco y ventilado.
• Evite exponer el producto Axis a
vibraciones, golpes o presiones
excesivas. No instale el producto en
soportes inestables ni en superficies
o paredes inestables o con
vibraciones, ya que esto podría

dañarlo.
• Utilice solo las herramientas
apropiadas para instalar el producto
Axis; una fuerza excesiva podría
dañarlo.
• No utilice productos químicos,
agentes cáusticos ni limpiadores en
aerosol. Límpielo con un paño
húmedo.
• Utilice solo accesorios que cumplan
las especificaciones técnicas del
producto. Puede obtenerlos de Axis o
de un tercero.
• Utilice solo piezas de recambio
suministradas o recomendadas por
Axis.
• No intente reparar el producto usted
mismo, póngase en contacto con
Axis o con el distribuidor de Axis
para los temas de servicio técnico.
• Este producto Axis se utilizará de
conformidad con la legislación y
normativas locales.
• 本製品は、乾燥した通気のよい
環境に保管してください。
• 本製品に衝撃または強い圧力を
加えないでください。
• 本製品を不安定なブラケット、
場所または壁に設置しないでく
ださい。
• 本製品を設置する際には、適切
な工具のみを使用してくださ
い。不適切な工具を使用する
と、製品に過剰な力がかかり、
損傷することがあります。
• 化学薬品、腐食剤、噴霧式クリ
ーナーは使用しないでくださ
い。清掃はきれいな水に浸した
清潔な布を使用して行ってくだ
さい。
• 製品の技術仕様に準拠したアク
セサリーのみを使用してくださ
い。Axis またはサードパーティ
から入手することができます。
• Axis が提供または推奨する交換
部品のみを使用してください。
• 製品を自分で修理しないでくだ
さい。修理に関しては、Axis ま
たは Axis の販売代理店にお問い
合わせください。
• 本製品は、お使いになる国、地
域の法律、規制にしたがって使
用してください。
Contact Information
Axis Communications AB
Emdalavägen 14
223 69 Lund
Sweden
Tel: [phone]
Fax: [phone]
www.axis.com
Warranty
www.axis.com/warranty

AXIS T8051 Power Converter AC/DC Page 7
ENGLISH
Note:
For further information about the network camera and its parts, refer to
the Axis camera’s installation guide.
Separate the mounting bracket from the unit casing and use the
extended mounting bracket.
Remove the two plugs from the holes in the unit casing.
1
1x 1x
1x1x 1x
AXIS Q3505-VE
21.3VA@24 V AC
15W@12 V DC
Power Information

Page 8 AXIS T8051 Power Converter AC/DC
Route the two cables in the AC/DC module through the two holes in
back of the unit casing. The cable with the connector goes into the hole
on the right.
Attach the AC/DC module onto the unit casing with the four supplied
screws.
2
3
4x
T20

AXIS T8051 Power Converter AC/DC Page 9
ENGLISH
Draw the cables along the grooves and press the supplied cable guides in
the holes to keep them in place.
4

Page 10 AXIS T8051 Power Converter AC/DC
Connect the DC cable to the power connector in the camera unit. Attach
the camera to the unit casing.
5
6

AXIS T8051 Power Converter AC/DC Page 11
ENGLISH
Using the drill template mark the holes for attaching the mounting
bracket on the wall.
7

Page 12 AXIS T8051 Power Converter AC/DC
Drill holes for attaching the mounting bracket to the wall, and holes for
cables if cables are to be drawn through the wall.
8
9

AXIS T8051 Power Converter AC/DC Page 13
ENGLISH
Draw the cables through the hole or holes in the mounting bracket and
through the gaskets in the unit casing.
Connect the AC/DC cables coming from the wall and from the AC/DC
module according to the table below.
Wires Specifications
Red + DC or AC
Black – DC or AC
10
11

Page 14 AXIS T8051 Power Converter AC/DC
Push the network cable through the black cable gasket in one of the
holes in the unit casing, using the connector guard provided. Pull the
network cable back slightly so that the cable gasket adjusts itself on the
cable.
12
13

AXIS T8051 Power Converter AC/DC Page 15
ENGLISH
Draw the AC/DC cable through the 3mm cable gasket. Connect the AC/
DC cable to the power connector.
14
15
4x
T20

Page 16 AXIS T8051 Power Converter AC/DC
Connect the network cable to the camera and put the dome cover in
place.
4x
T20
16

Convertisseur électrique CA/CC AXIS T8051 Page 17
FRAN
Ç
AIS
Remarque :
Pour plus d'informations concernant la caméra réseau et ses pièces,
reportez-vous à son guide d’installation.
Séparez le support de montage du boîtier de l’unité et utilisez le support
de montage rallongé.
Retirez les deux caches obturant les trous du boîtier de l’unité.
1
1x 1x
1x1x 1x
AXIS Q3505-VE
21,3 VA à 24 V CA
15 W à 12 V CC
Informations sur l'alimentation

Page 18 Convertisseur électrique CA/CC AXIS T8051
Faites passer les deux câbles dans le module CA/CC par les deux trous
situés à l'arrière du boîtier de l’unité. Le câble équipé du connecteur
passe par le trou situé à droite.
Fixez le module CA/CC au boîtier de l’unité à l'aide des quatre vis
fournies.
2
3
4x
T20

Convertisseur électrique CA/CC AXIS T8051 Page 19
FRAN
Ç
AIS
Faites passer les câbles dans les rainures et appuyez sur les guides de
câbles fournis pour les maintenir en place dans les trous.
4

Page 20 Convertisseur électrique CA/CC AXIS T8051
Connectez le câble CC au connecteur d'alimentation de la caméra. Fixez
la caméra au boîtier de l'unité.
5
6
