Axis AX ONE User manual

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
1
AX ONE
AX ONE ELD, GPS Tracking, Diagnostics, Wi-Fi Hotspot All-In-One Device
SUMMARY
AX-ONE is an all-in-one device Real-Time 4G LTE Gateway with Wi-Fi
Hotspot. The device is dedicated to connecting your vehicle to the
Axis TMS system. The AX ONE has multi-functionalities such as ELD
Compliance, GPS Tracking, Diagnostics and Tablet Mobile App
Connectivity for Driver Daily Operations.
WARRANTY
3-Year Manufacturer Warranty
REQUIREMENTS
Requires License and plug-n-play self-installation. Please visit
www.axistms.com for pricing details. License includes cellular data
connectivity, cloud software, mobile apps, ongoing firmware updates,
maintenance, and support. Available in 1, 3, and month to month
terms.
HIGHLIGHTS
•Wi-Fi Hotspot for in-vehicle devices (Tablet, Smartphone etc.)
•Secured with WPA2 Encryption
•Real-Time Data:
oOdometer Reading to Axis Truck Monitor
oSpeedometer Reading to Axis Truck Monitor
oFault Codes & Diagnostics to Axis Truck Monitor
oGPS Location Updates to Axis Truck Monitor
•Over-the-air Updates

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
2
TECHNICAL SPECS
CELLULAR
ELECTRICAL
AT&T
LTE FDD Cat.1
Operating Voltage
Vehicle 12V / 24V system
B2 (1900), B4 (AWS1700),
Current Consumption
Operating: 45-180mA @ 12V
B5 (850), B12 (700)
Deep Sleep: 1.4mA @ 12V
WCDMA B2 (1900), B5 (850)
Backup Battery (Optional)
3.7V 920mAh
Verizon
LTE FDD Cat.1
B2 (1900), B4 (AWS1700), B13 (700)
MEMORY
Sprint
LTE FDD Cat.1
Internal Flash Memory
64 Megabit
B2 / B25 (1900), B4 (AWS1700)
Up to 120,000 logs
B5 / B26 (850), B12 (700)
Up to 21,000 queues
Telstra
LTE FDD Cat.1
B1 (2100), B3 (1800), B5 (850), B8 (900),
SENSORS
B28 (700)
Accelerometer
3-axis ±16g
WCDMA B1 (2100), B5 (850), B8 (900)
Data Support
UDP / IP, TCP / IP, SMS over IMS
ENVIRONMENTAL
Antenna
Embedded cellular antenna
Operating Temperature
−40 to +70 °C (without battery)
−20 to +60 °C (with battery)
GPS
Humidity
95%RH @ 50° C non-condensing
Receiver Type
72 channel engine
Vibration/Shock
MIL-STD-810G
Location Technology
GPS & GLONASS
SBAS Support
WAAS, EGNOS, GAGAN, MSAS
PHYSICAL
Tracking Sensitivity
-167dBm
Dimension
152mm × 98mm × 30mm
Acquisition Sensitivity
-148dBm
(5.98" x 3.86" x 1.18")
Location Accuracy
2.5m CEP 50%
Weight
229g (0.50 lb)

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
3
Antenna
Internal (Optional external antenna)
Enclosure
Flame Retardant ABS+PC
Mounting Method
Screw Mounting Bracket, Adhesive
INPUTS/OUTPUTS
Vehicle BUS Protocols
ISO 15765-4 (CAN)
CONNECTORS
ISO 14230-4 (KWP2000)
I/O Connection
Molex 14 Pin Connector
ISO 9141-2
SIM Card Socket
Mini SIM(2FF)
SAE J1850 VPW / PWM
PC/Accessory Interface
4 Pin RS232 with 5V (±5%) Power
SAE J1939 / J1587 / J1708
External GPS
SMA
Digital Ignition Input
1 Positive Input
Configuration Interface
Mini USB Port
Digital Inputs
Up to 8 (Configurable)
Vehicle BUS Interface
Molex 12 Pin Connector
Digital Outputs
Up to 5 (Configurable)
Optional Wire Harness for OBD-II,
Max. sink current 300mA
DEUTSCH 6Pin/9Pin Connector
Analog Inputs
Up to 3 (Configurable)
DC 0~5V, DC 0~40V (12bits resolution)
DEVICE MANAGEMENT
1-Wire® Interface
1 (Driver ID, Temperature sensors)
Configuration
ADM, SMS, USB Cable
LED Indicators
5 LEDs (Power, GPS, Cellular, Wi-Fi, BT)
Firmware Update
ADM, FOTA, USB Cable
Buzzer
>80dB @ 10cm
Bluetooth (Optional)
Bluetooth BLE 4.1
CERTIFICATIONS
Wi-Fi (Optional)
2.4GHz IEEE 802.11b/g/n AP Mode
Standards
FCC, IC, PTCRB, NCC
Data rate DL: 3Mbps UL: 1.5Mbps

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
4
WHAT’S INCLUDED
Here’s what’s included out of the box:
•AX ONE Device
•2x Double Sided Adhesive
•4x Mounting Brackets and Screws
•1x Truck Cable

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
5
INSTALLATION
The AX ONE can be installed on most trucks in just minutes, you can use the double-sided adhesive or the mounting bracket on the sides:

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
6
POWER I/O CONNECTION
The following describes the function of each bare wire:
WARNING: Connecting of the input wires can be hazardous to both the installer and your vehicle’s electrical system if done by an inexperienced installer. This
document assumes you are aware of the inherent dangers of working in and around a vehicle and have qualified understanding of electrical behaviors.

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
7
POWER I/O CONNECTION CONTINUED
The following table describes the function of each bare wire:

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
8
DLC CONNECTION
The following table describes the function of each bare wire:

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
9
DLC CONNECTION CONTINUED
The following table describes the function of each pin:

Axis TMS Corp –780 W. Maple Rd. Troy, MI 48084 | tel: [phone] | fax: [phone]
10
LED INDICATORS
The following figure shows the LED statuses
