AXIST814460WIndustrialMidspan
Troubleshooting
Troubleshooting
SymptomCorrectiveaction
Verifythatthepowersourceoltageisbetween20–60VDC,andthatit’sworking.
Verifythattheterminalblockconnectorisproperlyconnected.
Themidspandoesnotpowerup
Verifythatthepowerinletcableisintact/functional.
VerifythattheremotedeiceisdesignedforPoEoperation.
Verifythattheremotedeiceisconnectedtothemidspan’sDATA&PWROUTportusing
astandardSTPCAT5orhigher,straight-wirednetworkcablewithfourpairs.
Ifanexternalpowersplitterisinuse,erifythatitworks.
VerifythatthereisnoshortcircuitonanyofthetwistedpaircablesorRJ45connectors.
Theremotedeiceconnectedtothe
midspandoesnotpowerup
Ifpossible,connecttheremotedeicetoadifferentmidspan.
Verifythattheremotedeiceisconnectedtothemidspan’sDATAINportusinga
standardSTPCAT5orhigher,straight-wirednetworkcablewithfourpairs.
IfusinganEthernetRJ45cable,erifythatitslengthbetweenthenetworkswitchand
theremotedeiceislessthan100m(330ft).
Theremotedeiceconnectedtothe
midspanpowersupbutthereisno
datalink
Ifpossibleconnecttheremotedeicetoadifferentmidspan.
7
