AXISQ60–ENetworkDomeCameraSeries
RepaintingInstructions

AXISQ60–ENetworkDomeCameraSeries
Impactonwarranty
Impactonwarranty
ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat
www.axis.com/warranty-implication-when-repainting
Riskswithrepainting
ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training
ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:
ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD
damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.
Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.
Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.
Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems
withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe
parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.
2

AXISQ60–ENetworkDomeCameraSeries
Howtorepainttheprouct
Howtorepainttheprouct
Preparations
•Ifapplicable,disassembletheeuipmentaccordingtotheinstructionsinthisdocument.
•Removegaskets,screws,electricalcomponents,connectorsandplugs,windows,anddomesfromthepartstoberepainted.
•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.
•Toensurereassemblyandfunctionalityoftheproduct,maskopeningsforscrews,LEDindicators,ormicrophonesbefore
painting.
Pretreatmentofparts
Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto
adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.
Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetatwww.axis.com
Powdercoatedparts-Usingnesandpaper,removetheoriginalpowdercoatingdowntothebasematerialandcleantheparts
beforepainting,oruseaprimer.
Anodisedandchromatedparts-Useaprimer.
Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.
Plastic-Useaprimer.
3

AXISQ60–ENetworkDomeCameraSeries
Howtorepainttheprouct
Disassemly
1.Removethedomemoduleassembly(4screws).
2.Removethefourscrewsandseparatethedomemodulebracket,domewithdomemodulesealinganddomecoverring
fromeachother.
4

AXISQ60–ENetworkDomeCameraSeries
Howtorepainttheprouct
3.Loosentheunitassembly(3screws).
4.LifttheunitassemblyupwardsandremovetheconnectorfromthePCBassemblypowerbypullingtheconnectorupwards.
5

AXISQ60–ENetworkDomeCameraSeries
Howtorepainttheprouct
5.Removethepush-pullconnectorhousing(2screws).
6.Removethechassishook(3screws).
7.Removethethreebayonetscrews.
6

AXISQ60–ENetworkDomeCameraSeries
Howtorepainttheprouct
Repainting
1.Maskthetopsurfaceofthechassis.Makesureallscrewholesandtheconnectorareproperlymasked.
2.Masktheentireopeninginthebottomofthechassis.Makesurethatthemaskinglineisclosetotheoriginalpaintborderso
thatnopaintparticlescanreachtheinsideofthecamera.Outlinedrawingoftheopeningcanbefoundonwww.axis.com.
3.Masktheplasticcompassring.
4.Maskthefourthreadedscrewholesonthedomecoverring.
5.Makesureallnecessarypreparationsofthechassisandthedomecoverringhavebeenmade.SeePreparationsonpage3.
7

AXISQ60–ENetworkDomeCameraSeries
Howtorepainttheprouct
6.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.
7.Letthepaintdry.
8.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.
9.Whenthepaintisdry,removethemasking.
8

AXISQ60–ENetworkDomeCameraSeries
Howtorepainttheprouct
Reassemly
1.Attachthethreebayonetscrews(1.8Nm).
2.Reassemblethechassishook(3screws,2.4Nm).
3.Reassemblethepush-pullconnectorhousing(3screws,0.3Nm).Makesuretheorientationofthepush-pullconnector
housingiscorrect.Thetwotabsontheinsidecornersshouldbeonthesamesideasthechassishook.
9

AXISQ60–ENetworkDomeCameraSeries
Howtorepainttheprouct
4.AttachtheconnectorfromthePCBassemblypower.
5.Reassembletheunitassembly(3screws,4Nm).
6.Assemblethedomemodulebracket,domewithdomemodulesealinganddomecoverring(4screws,1.2Nm).
10

AXISQ60–ENetworkDomeCameraSeries
Howtorepainttheprouct
7.Reassemblethedomemoduleassembly(4screws,4Nm).Makesuretheorientationofthedomemoduleiscorrect.The
openingofthedomeshouldbeplacedontopoftheheaterassembly.
11

RepaintingInstructionsVer.M1.3
AXISQ60–ENetworkDomeCameraSeriesDate:October2018
©AxisCommunicationsAB,2018PartNo.T10131153
