Axor Uno2 38040XX1 Installation guide

03/2005 9.05405.01
Installation Instructions / Warranty
Uno2
38040XX1
38222XX1

2
Uno2Lavatory Faucet
38040XX1
Uno2Bidet Faucet
38222XX1
Technical Specification
Maximum water pressure 145 psi
Recommended water pressure 14.5 - 72 psi
Maximum hot water temp. 176o*
Recommended hot water temp 120o- 140o*
Max. flow rate @ 45 psi 2.2 gpm
Max. deck thickness 1 5/8”
Hole size in deck 1 3/8”
*Many municipalities require that the water heater be set no
higher than 120o. Please know and follow all applicable
plumbing codes when setting the temperature on the water
heater.
Installation considerations:
•Hansgrohe recommends that this faucet be installed by a licensed professional
plumber.
•The supply hoses installed on this unit connect to the supply stops with standard 3/
8" compression fittings. Supply stops and 3/8" compression fittings are not
included.
•The 38222XX1 bidet faucet is not for use on a vertical spray bidet.

3
Installation Instructions
•Sit the faucet with black sealing ring in the faucet hole on top of the
mounting surface.
•From beneath, install the friction washer, metal washer, and mounting nut.
Tighten the mounting nut, taking care not to overtighten.
•Check the position of the faucet. When satisfied, use a slot-headed
screwdriver to tighten the tensioning screws.
•Feed the pull rod through the hole in the back of the faucet body.
•Attach the supply lines to the supply stops with standard 3/8" compression
fittings (not included)
sealing ring
friction washer
metal
washer
mounting nut
tensioning screws

4
Install the pop-up drain
•Remove the plunger assembly.
•Unscrew the drain outlet flange from the tee.
•Unscrew the tailpiece from the tee. Wrap the threads with plumbers’ thread
tape and replace.
•Install the white, flexible sealing gasket to the flange. Sit it in the sink outlet.
•From under the sink, install the black mack gasket, white friction ring , and
retainer nut to the flange. Do not tighten the nut against the bottom of the
sink at this time.
•Thread the tee and tailpiece to the flange. The pivot must face the faucet. If
necessary, turn the drain assembly.
•Tighten the retainer nut.
•Sit the plunger assembly in the drain.
•Install the horizontal rod so that the end goes through the loop in the bottom
of the height adjuster.
•Install and hand tighten the pivot ball nut.
•Attach the swivel connector to the end of the horizontal rod.
•Attach the swivel connector to the end of the vertical rod. Position as
desired, and tighten with a small, flathead screwdriver.

5
Service Parts
User Instructions
•Turn the right handle to obtain cold water, the left handle to obtain hot
water.
•The 38040XX1 spout will swivel 70o to the right and 70oto the left.
•The 38222XX1 spout does not swivel.
1 handle 38093XXX
2 color ring 96319000
3 snap connector 94184000
4 cold cartridge 94008000
5 hot cartridge 94009000
6 spout 97363XXX
7 aerator 96911XXX
8 mounting hardware13961000
9 pull rod 94083X X X
10 spout 97364XXX
11 bidet pivot 97362X X X
12 aerator 97360X XX
13 suppy line 94071001
2 mm
13

6
Cleaning Recommendation for Hansgrohe Products
Modern faucetry and shower products utilize a combination of materials to comply with
the needs of the market with regard to design and functionality.
To avoid damage, it is necessary to use some caution when cleaning. Damage caused by
improper treatment is not covered under the Hansgrohe warranty.
Cleaning Materials for Faucets and Showers
•To remove lime scale, use only products made specifically for that purpose. Always
follow the manufacturer’s instructions when using.
•Do not use cleaners that contain hydrochloric, formic, acetic, or phosphoric acids,
as these will cause considerable damage to finishes and to plastic components.
•Never mix cleaning materials.
•Never use cleaners containing abrasives. Do not use abrasive cleaning cloths,
pads, or sponges.
Cleaning Procedures
•Clean your faucets and shower products as and when required. Regular cleaning
will prevent scale buildup and water spotting.
•Follow the label instructions. Do not allow any cleaner to remain on the product for
longer than necessary.
•When using spray cleaners, spray first onto a sponge or cloth – do not spray
directly onto the product.
•After cleaning, rinse thoroughly with clear water to remove any cleaner residue.
Important
•Soap and shampoo residue can also cause damage to the product. Rinse well with
clean water after use.
•If the surface is already damaged, harsh cleaning materials will cause further
damage.
Limited Lifetime Consumer Warranty
