Axxera AVM101LH Operating instructions

INSTALLATION/OWNER’S MANUAL
Multimedia Receiver with Bluetooth
featuring a 10.1" Touch Screen Display
AVM101LH

Copyright Notes
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Operating system updates from Apple and Android may cause your receiver not to function properly. This can usually be fixed
by doing a software/firmware update to the receiver itself. To see if your receiver has the latest firmware, contact customer
service at 1-866-382-5476 to see if your radio needs an update.
Other trademarks and trade names are those of their respective owners.

2
AVM101LH PREPARATION
Safety Information
Please read all instructions carefully before attempting to install or operate.
Due to its technical nature, it is highly recommended that your Axxera AVM101LH is installed by a professional
installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.
To prevent damage or injury:
• Make sure to ground the unit securely to the vehicle chassis ground.
• Do not remove the top or bottom covers of the unit.
• Do not install the unit in a spot exposed to direct sunlight or excessive heat or the possibility of water splashing.
• Do not subject the unit to excessive shock.
• When replacing a fuse, only use a new one with the prescribed rating. Using a fuse with the wrong rating may
cause the unit to malfunction.
• To prevent short circuits when replacing a fuse, disconnect the wiring harness first.
• Use only the provided hardware and wire harness.
• You cannot view video while the vehicle is moving. Find a safe place to park and engage the parking brake.
• If you experience problems during installation, consult your nearest Axxera dealer.
• If the unit malfunctions, reset the unit as described on page 10 first. If the problem still persists, consult your
nearest Axxera dealer or call tech assistance @ 1-866-382-5476.
• To clean the monitor, wipe only with a dry silicone cloth or soft cloth. Do not use a stiff cloth, or volatile solvents
such as paint thinner and alcohol. They can scratch the surface of the panel and/or remove the printing.
• When the temperature of the unit falls (as in winter), the liquid crystal inside the screen will become darker than
usual. Normal brightness will return after using the monitor for a while.
• When extending the ignition, battery or ground cables, make sure to use automotive-grade cables or other cables
with an area of 0.75mm (AWG 18) or more to prevent voltage drops.
• Do not touch the liquid crystal fluid if the LCD is damaged or broken. The liquid crystal fluid may be hazardous to
your health or fatal. If the liquid crystal fluid from the LCD contacts your body or clothing, wash it off with soap
immediately.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

3
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Insert the supplied keys into the slots as shown.
• Connect wiring harness as shown on page 6. Consult a qualified technician if you are
unsure.
• Certain vehicles may require an installation kit and/or wiring harness adapter (sold
separately).
• Reconnect negative battery terminal, and test for correct operation.
• Snap trim ring into place (if required).
AVM101LH INSTALLATION
Preparation
TYPICAL FRONT-LOAD DIN MOUNTING METHOD

4
Wiring Diagram - Inputs/Outputs
AVM101LH INSTALLATION
Note:
When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause
damage. The unit uses (1) 10 amp blade-style fuse located on the power connector.
Wiring Notes:
Rear camera input
A rear view camera (not included) can be used with the Camera input.
SWC-IR
USB CHARGE
HDMI INPU T
USB INPUT
CAMERAAUDIOINPUT
BT ANTENNA
HDMI

5
Control Locations
Power
Mode
Play / Pause
Mute
Title
Subtitle
Setup
Angle
Eject
Volume Up
Zoom
Select
Tune/Track Up
Volume Down
1
2
3
4
5
6
7
8
9
10
11
12
13
15
16
17
18
19
20
21
22
23
24
25
Audio
Go To / * Key
Loudness / Bluetooth Talk
Number Keys
Root
OSD (On Screen Display)
Local / Random
Tune/Track Down
AS/PS / Repeat
Stereo
Stop
Enter
Band
Mircophone
Power / Mode
Volume Down
1
2
3
Volume Up
Camera
Reset
4
5
6
14
26
27
1 2 3 4
5
6
7
8
9
10
11
12
13
14
15
27
26
25
24
23
22
21
20
19
18
16
17
AVM101LH OPERATION
8
MicroSD Card
IR Sensor
7
8
3 4 5 6 7
21

6
Notes:
• The remote control uses one 3 volt
Lithium CR2025 battery. Remove the
battery if the remote will not be used
for a month or longer.
• Remove and dispose of battery
properly.
• Do not store battery with metallic
objects or materials.
Remove battery insulation tape .
To insert or replace the battery,
remove the battery holder.
Remove the battery from the
battery holder.
Install the new battery.
Make sure to keep the (+) side
up.
Insert the battery holder.
Remote Control Preparation
AVM101LH OPERATION

7
Power On/Off
Volume
USB Port
Main Menu
Mute
Mode
Press to turn the unit on. Press and hold to turn the unit off.
Press Volume Up or Volume Down to increase or decrease the
volume level.
Connect a USB device to the USB port on the front panel to play MP3
files or view JPG photos.
From any operational mode, press the house icon in the top left corner
to access the Main Menu screen.
1. Adjust screen brightness or put the monitor into standby mode.
2. Access audio setting such as EQ, Surround Sound Settings and Field
Settings (Balance and Fader).
From the Main Menu, select the desired mode of operation to
immediately access that mode.
Press Volume Up or Volume Down, and the menu with volume level
will pop up. Press the speaker icon to mute or unmute the sound.
General Operation
21
1 2
AVM101LH OPERATION
DualMirror
™
Operation
See insert for DualMirror Operation Guide.
Note:
Operating system updates from Apple and Android
may cause issues with your receiver not to function
properly. This can usually be fixed by doing a
software/firmware update to the receiver itself.
To see if your receiver has the latest firmware,
contact customer service at 1-866-382-5476 to
see if your radio needs an update.

8
From the Main Menu screen, press Settings in the bottom right corner to
access the Setup Menu and select from the following categories: General,
Audio, Video and Bluetooth.
General:
• OSD Language - Select English only.
• Wallpaper - Select between three available wallpaper options.
• Panel Adust - Select to calibrate the touch screen.
• Radio Area - Select your current geographic area: Europe, USA, South
America, Russian and Asia.
• Time Setting - Adjust the current time (hours and minutes) and choose
between a 12-hour and 24-hour clock.
• SWC - Select to program steering wheel controls.
• Beep - Select to turn the audible beep On or Off.
• Camera - Select to turn the rear camera On or Off.
• Version- Select to view information about the unit.
• Restore Default- Select to restore the unit to default settings.
Audio:
•Sound Effect - Select to access the three sound effect sub-menus.
- EQ - Select from any preset equalization curve (Classic, Rock, Pop,
Jazz, Beat, Flat) or use custom settings (User).
- Surround Sound - Select one of the following surround sound
configurations: Concert, Church, Passive, Wide, Live or None.
- Field - Select to adjust Balance and Fader settings.
Video:
• Aspect Ratio - Select the desired aspect ratio: 4:3PS, 4:3LB or 16:9.
• Adjust - Select to adjust levels of Brghtness, Contrast, Hue, Saturation
and Sharpness.
• Panel - Select to choose backlight settings: 10s, 20s, 30s or Off.
Bluetooth:
• Auto Connect - Turn auto connect feature On or Off.
• Auto Answer - Turn auto answer feature On or Off.
General Operation
Setup Menu
AVM101LH OPERATION

9
Select the Radio icon from the Main Menu screen.
Press to return to Main Menu screen.
Displays current mode of operation.
Press momentarily to tune the unit down one step at a time. Press
and hold to tune down by seeking the next strong station.
To store a preset station, tune unit to desired station, then press
and hold the desired preset button to store the current station in
that preset spot. Up to 18 FM and 12 AM stations can be stored in
memory. Momentarily press any preset station to play it instantly.
Press to adjust screen brightness or put the monitor into standby
mode.
Press to select between three FM and two AM bands.
Press to toggle between LOCAL and DX (distance) tuning.
Press to access audio setting such as EQ, Surround Sound Settings
and Field Settings (Balance and Fader).
Press to toggle between Stereo and Mono tuning.
Radio Operation
Main Menu 1
Current Mode Indicator 2
Tune Frequency Down 3
Preset Stations 4
Screen 5
Band 6
Local / Distance 7
Audio 8
Stereo / Mono 9
1
4
3
2
5 6
AM/FM Tuner Operation
AVM101LH OPERATION
87 9

10
AVM101LH OPERATION
Press and hold to automatically store the six strongest stations in the
current band as presets. Press briefly for a preset scan, which will
scan all preset stations and play 10 seconds of each. Press again to
cancel the scan and continue playing the current station.
Press to access the Setting Menu.
Press momentarily to tune the unit up one step at a time. Press and
hold to tune up by seeking the next strong station.
AS/PS 10
Settings 11
Tune Frequency Up 12
AM/FM Tuner Operation
12
1110

11
USB Operation
CD/MP3
or JPG Operation
Main Menu 1
Current Mode Indicator 2
File Information 3
Screen 4
Tune / Track Down 5
Play / Pause 6
Audio 7
Tune / Track Up 8
To play MP3 files from a USB device, insert device into the USB
slot on the front of the unit and playback will begin automatically. To
return to USB playback from another mode of operation, select the
corresponding icon from the Main Menu.
Press to return to Main Menu screen.
Displays current mode of operation.
Displays information about the current file.
Press to adjust screen brightness or put the monitor into standby
mode.
Press momentarily to tune the unit down one step at a time. Press
and hold to tune down by seeking the next strong station.
Press to play or pause playback.
Press to access audio setting such as EQ, Surround Sound Settings
and Field Settings (Balance and Fader).
Press momentarily to tune the unit up one step at a time. Press and
hold to tune up by seeking the next strong station.
12
3
65 8
AVM101LH OPERATION
4 7

12
USB Operation
Folder Search 9
Settings 10
Repeat 11
Random 12
Press to access the directory of folders and files. Use the up/down
arrows to scroll through the folder list, then press on the name of the
desired folder to access it. Use the up/down arrows to scroll through
the file list, then press on the name of the desired file to access it.
Press to access the Settings Menu.
Press to turn Repeat feature on.
Press to turn Random feature on.
AVM101LH OPERATION
12
11
910

13
Bluetooth Operation
Before you can use a Bluetooth device, it must be paired and
connected. Make sure that Bluetooth is activated on your device
before you begin the pairing process.
The unit broadcasts the pairing signal constantly when no
devices are currently connected. Complete the pairing sequence
from your Bluetooth device. Refer to the owner's manual for
your device for more details. The device name is "Axxera
AVM101LH". The Bluetooth passcode "0000". The unit can
be in any mode of operation when pairing is performed.
Note: On certain phones, pairing may need to be done more than
once if there are connectivity issues.
Most Bluetooth devices support the auto-connect feature and
will connect automatically if the device is in range when the unit
is powered-on. If your device was previously paired but does not
connect, enter the Bluetooth setup menu and ensure that Auto
Connect is On.
To access the phone, select Bluetooth Phone from the Main
Menu.
Press to return to the Main Menu screen.
Displays current mode of operation.
Use the phone keypad to dial the desired phone number.
Alternately, numbers can be dialed directly from the phone.
Press to display keypad and dial a number.
Press to play music using the Bluetooth connection.
Preparation
Pairing a New Device
Connecting a
Paired Device
Bluetooth Phone
Main Menu 1
Current Mode Indicator 2
Phone Keypad 3
Phone 4
Music 5
12
4
5
3
AVM101LH OPERATION

14
Bluetooth Operation
Screen 6
Audio 7
Settings 8
End Call 9
Make a Call 10
Bluetooth Music 11
Previous File/Track 12
Play / Pause 13
Next File/Track 14
Press to adjust screen brightness or put the monitor into standby
mode.
Press to access audio setting such as EQ, Surround Sound Settings
and Field Settings (Balance and Fader).
Press to access the Settings Menu.
Press the end the current call.
Press to connect or answer a call.
To use your Bluetooth connection to play music from your device,
press #5 or select Bluetooth Music from the Main Menu.
Press to go back to the previous file or track.
Press to pause or resume playback.
Press to advance to the next file or track.
68
71312 14
AVM101LH OPERATION
9
11
10

15
Rear RCA A/V Input
Rear Camera Operation - (Optional)
Connect an optional audio/video source to the rear auxiliary input (Red/White/
Yellow RCA connectors). Refer to page 6 for details.
Select AV Input from the Main Menu to listen to audio.
Engage parking brake to watch video.
Connect an optional rear camera to the Camera Input (Black RCA connector).
Refer to the wiring diagram for details.
Manual selection - Touch CAMERA icon from the Main Menu or from any
operational mode (when enabled) to select camera mode. Touch the top left area
on the screen to exit camera mode.
Note: The manual mode is for dedicated cameras that are ALWAYS on while
driving, it is not meant for cameras that are connected to the vehicle's reverse
light.
The unit will automatically select camera mode when connected to the reverse
lamp circuitry.
Note: The external video output is not active when using the rear camera input.
Using AV Input
Using Rear Camera
Auto Selection
AVM101LH OPERATION

16
Limited One Year Warranty
This warranty gives you specific legal rights. You
may also have other rights which vary from state to
state.
Dual Electronics Corp. warrants this product to the
original purchaser to be free from defects in material
and workmanship for a period of one year from the
date of the original purchase.
Dual Electronics Corp. agrees, at our option, during
the warranty period, to repair any defect in material
or workmanship or to furnish an equal new, renewed
or comparable product (whichever is deemed
necessary) in exchange without charges, subject to
verification of the defect or malfunction and proof
of the date of purchase. Subsequent replacement
products are warranted for the balance of the
original warranty period.
Who is covered? This warranty is extended to the
original retail purchaser for products purchased from
an authorized Dual dealer and used in the U.S.A.
What is covered? This warranty covers all defects
in material and workmanship in this product. The
following are not covered: software, installation/
removal costs, damage resulting from accident,
misuse, abuse, neglect, product modification,
improper installation, incorrect line voltage,
unauthorized repair or failure to follow instructions
supplied with the product, or damage occurring
during return shipment of the product. Specific
license conditions and copyright notices for the
software can be found via www.dualav.com.
What to do?
1. Before you call for service, check the
troubleshooting guide in your owner’s manual. A
slight adjustment of any custom controls may save
you a service call.
2. If you require service during the warranty period,
you must carefully pack the product (preferably
in the original package) and ship it by prepaid
transportation with a copy of the original receipt
from the retailer to an
authorized service center.
3. Please describe your problem in writing and
include your name, a return UPS shipping address
(P.O. Box not acceptable), and a daytime phone
number with your shipment.
4. For more information and for the location of the
nearest authorized service center please contact
us by one of the following methods:
• Call us toll-free at 1-866-382-5476
• E-mail us at [e-mail]
Exclusion of Certain Damages: This warranty is
exclusive and in lieu of any and all other warranties,
expressed or implied, including without limitation the
implied warranties of merchantability and fitness for
a particular purpose and any obligation, liability, right,
claim or remedy in contract or tort, whether or not
arising from the company’s negligence, actual or
imputed. No person or representative is authorized
to assume for the company any other liability in
connection with the sale of this product. In no event
shall the company be liable for indirect, incidental or
consequential damages.
AVM101LH OPERATION

17
Specifications
FM Tuner
AM Tuner
Front USB
Monitor
General
Tuning range: 87.5MHz-107.9MHz
Usable sensitivity: 10dBf
50dB quieting sensitivity: 20dBf
Stereo separation @ 1kHz: 38dB
Frequency response: 30Hz-13kHz
Tuning range: 530kHz-1710kHz
Usable sensitivity: 24uV
Frequency response: 30Hz-2.3kHz
Compatibility: High Speed USB 2.0
USB Class: Mass storage class
Panel size: 10.1” diagonal measurement
View angle (up/down/left/right): 50/70/70/70
Resolution: 800 (H) x 480 (V)
Brightness (cd/m2): 250
Contrast ratio: 450:1
Pixels: 1,152,000
Speaker output impedance: 4 ohms
Line output voltage: 4 volt RMS
Line output impedance: 200 ohms
Chassis dimensions: 7" x 7" x 4" (W x D x H)
Design and specifications subject to change without notice.
AVM101LH OPERATION
Part Name Part Number Pieces
Trim Ring 40-040101-0001 1
Remote control 74-010101-1001 1
Removal key 44-042218-0100 1
SWI Guide 60-C16169-01-01 1
QSG 60-C16170-01-02 1
Parts List
CEA-2006 Power Standard Specifications
(reference: 14.4VDC +/- 0.2V, 20Hz~20kHz)
Power Output: 16 Watts RMS x 4 channels at 4 ohms and <1%
THD+N
Signal to Noise Ratio: 80dBA (reference: 1 watt into 4 ohms)

18
Troubleshooting
General
Problem Cause Action
Unit will not turn on
(no power)
Yellow wire not connected or incorrect voltage
Red wire not connected or incorrect voltage Check connections for proper voltage (11~16VDC)
Black wire not connected Check connection to ground
Fuse blown Replace fuse(s)
Unit has power
(but no sound)
Speaker wires not connected Check connections at speakers
One or more speaker wires touching each
other or touching chassis ground
Insulate all bare speaker wires from each other and
chassis ground
Unit blows fuse(s)
Yellow or red wire touching chassis ground Check for pinched wire
Speaker wires touching chassis ground Check for pinched wire
Incorrect fuse rating Use fuses with correct rating
Unit has audio
(but no video)
Parking brake safety circuit not connected
Parking brake not applied
Check connections at parking brake
Apply parking brake as described on page 26
No video display
(when in reverse)
Reverse circuit not connected
Vehicle is not in reverse
Check connections at reverse lamp
Select reverse gear
IR remote does not work Dead battery Replace battery
Please keep your original sales receipt and be prepared to provide this receipt in
the event you require service, as your original receipt is considered the best proof of
purchase and indicates the date you purchased your Axxera product.
Dealer Name
Dealer Phone
Purchase Date
Register your product online at www.dualav.com.
For Your Records
Register Your Product
AVM101LH OPERATION

Dual Electronics Corp.
Toll Free: 1-866-382-5476
Monday-Friday, 9AM-5PM EST
www.axxeraaudio.com
©2018 Dual Electronics Corp. All rights reserved.
NSA0418-V02
Printed in China
