ZENEC Z-E3150 User manual

Z-E3150
DEVICE INSTALLATION MANUAL
EN

2
COMPATIBILITY LIST
Model Type Model Year
AUDI A3 (1st Gen) 8P 2006 – 2008**
AUDI A3 (Facelift > 2nd Gen) 8P 2008 – 2012
AUDI A3 (Sportback > 1st Gen) 8PA 2008 – 2010
AUDI A3 (Sportback > 2nd Gen) 8PA 2010 – 2012
AUDI A3 Convertible 8P 2008 – 2013
AUDI S3 8P 2006 – 2008**
AUDI RS3 8PA 2011 – 2012
** 1st Gen vehicle models lack various integration functions due to missing CAN data.
No. Article Qty
1 ZENEC system 1
2 GPS antenna 1
3 Double-sided adhesive pad 1
4 Main connection cable Quadlock II 1
5CAN bus interface 1
THE KIT INCLUDES
No. Article Qty
6DAB antenna adapter (Fakra – SMB) 1
7USB extension cable 2
824-pin connection cable (4.2, Cam, Mic) 1
9FM antenna adapter (Single to twin Fakra) 1
10 Unlock tool 4
●Insulating tape
TOOLS REQUIRED
●ZENEC ZE-NC-ANT3 (antenna interface)
●DAB antenna with SMB plug
(e.g. Z-EACC-DAB1 or Z-EACC-DAB2)
●External microphone (N-ZENC-MIC)
ADDITIONAL MOUNTING ACCESSORIES
● The installation of the ZENEC system should be carried out by an authorized installer. Specic
knowledge and tools are required to do the installation. Incorrect installation can cause damage to the
vehicle and the ZENEC system.
●Correct functioning can only be guaranteed when you use the ZENEC original accessories included
in the kit or those optionally available. The ZENEC system and the original accessories must under no
circumstances be modied or altered in any way. Inappropriate actions can cause damage to the
vehicle and the ZENEC system.
CAUTION
●The target vehicle must factory congured with a OE radio or navigation systems. The ZENEC
system is not compatible with vehicles, which are equipped with a hybrid or electro drive ex factory.
●This device installation manual applies to vehicle platforms appearing in the compatibility list on the
previous page, and in a condition as offered by the respective vehicle manufacturer. Other differing
congurations and installations may result in complications and malfunctions.
●The ZENEC system is equipped with an integrated DAB+ receiver. To make use of this you will need
a suitable DAB antenna (not included in kit) that must be connected to the ZENEC system.
●If the target vehicle is already equipped with an original DAB antenna, it is still possible to use it in
combination with the ZENEC system. Please use the DAB antenna connector (No. 6), which is part of
the kit, for connection.
●The Z-E3150 comes with an adaptor interface, which ts to the double FM antenna plug from the
vehicle. If this solution is not sufcient, e.g. the FM radio reception is deemed to be poor, the
ZE-NC-ANT3 phantom power adaptor which is separately available, may help to improve FM signal
level.
●Software updates to the ZENEC system are installed with a USB memory device. Therefore when
tting the system make sure that the USB connection of the ZENEC system will still be accessible
later (installation of USB extension cable or USB hub).
●If you have questions or problems relating to the ZENEC system, please contact the dealer from
whom you purchased it.
●Additional questions about the compatibility could be answered by using the ZENEC online
congurator:
www.zenec.com/congurator
NOTE

1
3
3
2
EXAMPLE OF INSTALLATION AUDI A3
REMOVAL WORK AND PREPARATION:
3. To completely remove the factory radio, all the
cables (i.e. main wire harness, antenna cable
etc.) must be unplugged on the backside of the
device. Put the radio aside in a safe place, to
protect it from damage.
1. Unlock the OE factory radio with the unlock tool
(No. 10) contained in the set. You need to insert
all four keys.
2. It should be possible to pull out the radio without
applying brute force.
1. Remove the ignition key and keep it outside the car until the installation is finished.
2. Please wait for about 10 minutes until the CAN bus system is completely shut down, before you start
with the uninstallation of the original device.
3. Now you can start with the uninstallation of the original device.
4. Please switch on the ignition only, once all installation steps are completed and the ZENEC system
is firmly mounted.
NOTE

4
8
7
INSTALLATION: 4. (No picture)
Install the GPS antenna (No. 2) in a suitable
position, making sure that the GPS reception is
not adversely affected by unwanted shielding
of metallic vehicle parts (thermal insulation
glazing, etc.). Then route the connection cable
into the radio bay.
5. (No picture)
If you have purchased the optional external
Bluetooth microphone (N-ZENC-MIC), install
it now and route the connection cable into
the radio bay. Depending on your preference,
and whether you select an internal or external
microphone, the microphone source for
Bluetooth mode must be set accordingly in the
unit menu.
6. (No picture)
Route the USB extension cable´s (No. 7) from
the radio bay to your preferred position.
7. Connect one of the main connection cables
(No. 4) of the ZENEC system (No. 1) to the
Quadlock connector of the car and close its
locking mechanism. Following this, connect the
CAN bus interface (No. 5) to the main connec-
tion cable.
8. Before installing the ZENEC system (No. 1)
remove the two transport securing screws.

5
9
10
11
COMMISSIONING
Finally carry out a general functional test and perform the basic and car specific settings (AC, OPS etc.).
Also ensure that no fault warnings appear on the vehicle side.
11. The installation of your Z-E3150 is now
complete.
●Make sure that all connectors at the rear of the ZENEC system have sufficient room and are not bent.
● Connectors without a retaining mechanism must be additionally secured with insulating tape.
10. Neatly arrange the wires to the side, making
room for the ZENEC system. Carefully slide
it into the radio slot. Push back the Z-E3150
until you hear the clicking sound of the latching
mechanism.
9. Connect all the cables to the ZENEC system
(No. 1) those previously run in the radio slot,
and the original antenna cables.
NOTE

Technical modifications excepted. No liability granted for printing errors. © Copyright 2018 · RevA / copy deadline: Q3-2018 · English
ZENEC · Bohrturmweg 1 · CH-5330 Bad Zurzach · Schweiz/Switzerland · Mail: [e-mail] · www.zenec.com
CONNECTION DIAGRAM
A20 PIN CONNECTOR
(DEVICE BACKSIDE)
A1
A11
A10
A20
A11 CAN TX
A12 P. ANT +12V** (Antenna)
A13 P. CNTR +12V** (Amplifier)
A14 Parking
A15 KL 31 / Power GND
A16 KL 30 / Permanent +12V PWR
A17 Speaker Rear Right (-)
A18 Speaker Rear Right (+)
A19 Speaker Front Right (-)
A20 Speaker Front Right (+)
A1 CAN RX
A2 Reverse
A3 KL 15 / Switched +12V PWR
A4 Illumination
A5 Analog Wheel KEY 2
A6 Analog Wheel KEY 1
A7 Speaker Rear Left (-)
A8 Speaker Rear Left (+)
A9 Speaker Front Left (-)
A10 Speaker Front Left (+)
** 300mA max current
AC
DAB
USB 1
USB 2
HDMI
B
CAN Box
Rear Monitor Out Camera IN
P.CONT (max 300mA) P.ANT (max 300mA)
Video IN Aux IN L Aux IN R Line Out Rear L Line Out Rear R Line Out Front L Line Out Front R Line Out Woofer Line Out Woofer
MIC
IR / IN GND Camera +12V (max 300mA)
P. A N T
GND
GND
P. A N T
Z-E3150
DAB HDMI
USB 2
USB1:
• Apple MFI
• USB Media Playback, -Smartlink Direct, -Software Updates
USB2:
• Apple MFI
• USB Media Playback, -Smartlink Direct, -Software Updates
A
GPS
UKW/
FM
USB 1
C
C1 Rear Monitor Out
C2 N.A.
C3 Camera IN
C4 Video IN
C5 AUX IN L
C6 AUX IN R
C7 Line Out Rear L
C8 Line Out Rear R
C9 Line Out Front L
C10 Line Out Front R
C11 Line Out Sub Woofer
C12 Line Out Sub Woofer
C13 MIC
C14 N.A.
C15 IR/IN
C16 GND
C17 N.A.
C18 Camera +12V (max 300mA)
C19 N.A.
C20 N.A.
C21 N.A.
C22 N.A.
C23 N.A.
C24 N.A.
B1 Speaker Rear Right (+)
B2 Speaker Front Right (+)
B3 Speaker Front Left (+)
B4 Speaker Rear Left (+)
B5 Speaker Rear Right (-)
B6 Speaker Front Right (-)
B7 Speaker Front Left (-)
B8 Speaker Rear Left (-)
B9 CAN High
B10 CAN Low
B12 GND
B15 B+
B25 Line Out Front L
B27 Line Out Rear L
B36 GND
B37 Line Out Front R
B39 Line Out Rear R
BQUADLOCK II
CONNECTOR
C
C24 C2
C23 C1
24 PIN CONNECTOR
Line Out Front L Line Out Front R Line Out Rear L Line Out Rear R
