Ayra ITA3D 710 User manual

1
ITA3D 710
RGB DMX laser with 3D effect
User manual

2
Safety precautions
WARNING: This unit may cause serious injury to eyesight when used incorrect. It therefore is strongly
advised to read this user manual carefully, to get familiar with the functions of this laser device.
WARNING: This unit must be operated by, or under the supervision of an adult. This device is not
suitable for children.
WARNING: Do not look directly into the beam coming out of the lens, from short distance or when a
solid beam is projected. This may cause serious injury to eyesight. Ayra is not responsible for any
injuries caused by incorrect use of this device.
WARNING: Do not project the beam of this unit on to reflective surfaces, as the shattering beam may
cause injury to eyesight.
Installation requirements:
- Always check the voltage settings on the unit and the power supply you want to connect the device
to. If the voltage requirements do not meet, do not connect the device as this may cause serious
damage.
- This device must be installed by a professional technician, in a standing or hanging position. Always
pay attention to the positioning of the unit, as the beams may project directly into your audience.
- It is strongly advised to NOT project the beams directly into your audience. Ayra strongly
recommends a minimum distance of 1.5 meters in height between the lowest projected laser beam
and your audience, for optimal safety. If there is no other option, keep a minimum distance of 5 meters
from the beam exit to the first beam that hits your audience.
- When installed in a standing position, a safety cable is recommended to secure the unit.
- When installed in a hanging position, this unit MUST be secured by using a safety cable, capable of
holding 10x the weight of this device.
- When installed in a hanging position, this unit must be mounted to a proper surface, e.g. a truss
system. When using a truss system, Ayra recommends the use of a proper hook or halfcoupler.
- Make sure there are no flammable objects in the direct environment of the device (such as
decorative objects). Keep a minimum distance of 1.5 meter.
- Do not block the beam-exit and fan
- Keep a minimum distance of 0.5 meter from any walls to provide sufficient cooling
- Make sure the beam-exit and fan are not blocked by any objects in the near environment
- This unit must be connected to a grounded power supply that meets the voltage requirements of the
device.
Maintenance and protection
- Keep the unit away from dusty environments, as this may have negative effect on the fan-cooling
system and laser optics. Ayra recommends using a flightcase for storage of this device. Clean the
optics and fan of the laser with a small, soft brush and vacuum cleaner when needed. Clean the
housing of the unit with a damp cloth. WARNING: Always disconnect the unit from the power supply
when cleaning the unit. Reconnect the unit only if any moist on the fixture disappeared completely.
- This laser device is a lighting effect, designed to support visual entertainment while playing music.
Continuous use is not recommended. Do not use the device longer than 3 hours subsequently, so the
unit can cool down. This will provide a longer lifespan for the diodes. Apply a cooling-down time of 25
minutes before re-activating the laser.
- Do not switch the power on and off too often, as this may cause serious damage to the unit.

3
- Avoid heavy shocks and collision during transport and use, as this might cause damage to the laser
diodes, electronic circuit, optics and housing.
- Keep the device away from moisture, rain, water or any liquids as this may cause a short circuit
and/or electric shocks. If any liquid enters the unit, power supply or housing of the unit, disconnect the
unit immediately and do not reconnect the power supply. Contact your local dealer or technician to
inspect the unit for any damage.

4
Box contents
Box contents
1x ITA3D 710 laser device
1x user manual
1x IEC to Schuko power cable
1x XLR –XLR DMX signal cable
Unit and accessory inspection
- Always use the supplied power cable to connect the unit to a power supply. If the cable appears
broken or has visible damage, do not use it. The supplied cable can be replaced with a regular IEC to
Schuko cable, with a minimum cable diameter of 0.75m².
- If the unit will not be used for a longer period of time, disconnect it from the power supply and store it
in a dust-free environment.
- Always check the unit for possible damage before use. If you suspect that something is wrong with
the unit, do not connect it to a power source! When you suspect that your unit is broken or damaged,
contact your local dealer or a certified technician to inspect the unit.
- When your device does not generate any laser beams, do not look directly into the lens. When the
laser suddenly produces a beam, it may cause severe eye damage, possibly resulting in permanent
visual loss.

5
Device overview
1. Beam output
2. Power status LED-indicator (red)
3. Microphone sensitivity LED indicator (blue)
4. Built-in microphone (used for sound-active mode)
5. DMX input
6. DMX output
7. DMX dipswitch setting (also used for activation of auto/sound active mode
8. Microphone sensitivity knob (low-high)
9. Pattern size adjustment (small-large)
10. Cooling fan
11. IEC power inlet
12. ON/OFF switch

6
Setting up the device
Setting up the device
- When the power supply is connected, the unit will first calibrate the stepping motors of the unit. It is
normal that this may cause any noise. When the calibration is done, the unit is ready to be used (in the
selected DMX, automatic or music controlled mode)
- It is possible that the unit may shut off the beam projection when no music or sound is detected. This
will avoid the projection of a solid, static beam, which may cause injury to eyesight.
- This unit uses stepping motors to create variable movements to the laser beam. This way, figures
and patterns can be made. The unit uses high-speed stepping motors to create the moving beams of
the laser. It is normal that the laser beam and projection may appear ‘flickering’ when projecting large
or complex patterns.
- The projected beams of the unit may appear shivering when projecting complex or large patterns on
surfaces as a wall, ceiling or decorative cloth.
Selecting a working mode
This laser device has three working modes, which are automatic, music-controlled and DMX. To
select the right operating mode for your situation, use the dipswitch panel on the rear of the unit.
A DMX-dipswitch panel works with a binary character. It sends a 0 or 1 message to the electrical
circuit. To select a working mode, pay close attention to the information scheduled below. Every DMX
dipswitch stands for a certain value, which is on or off. The values are stated as below:
1 –1
2 –2
3 –4
4 –8
5 –16
6 –32
7 –64
8 –128
9 –256
10 –mode switch (DMX ON/OFF)
To select the different working modes, pay close attention to the setting of DMX dipswitches below:
NOTE: value “X” = not used or not active for this mode
DIPSWITCH CHART
FUNCTION
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
0
0
0
X
X
X
X
X
X
0
SOUND ACTIVE
1
0
0
X
X
X
X
X
X
0
AUTO-BEAM
1
1
0
X
X
X
X
X
X
0
AUTO-ANIMATION
0
0
1
X
X
X
X
X
X
0
SLAVE MODE
SET DMX ADDRESS
1
DMX MODE

7
Working mode explanation:
Sound active:
The unit uses its internal microphone to sense music (the beat of the music) and will change patterns
according to the beat of the music. The microphone is situated at the front of the laser device. On the
rear of the laser, there is an adjustable microphone sensitivity knob.
Please note that the sound-activated mode will not function properly when the music source is not loud
enough or when only high-pitched sounds are played.
Auto-beam:
The laser device will activate a pre-defined lasershow on a solid speed setting. The patterns are
mainly beam-effects.
Auto-animation:
The laser device will activate a pre-defined lasershow on a solid speed setting. The patterns are
mainly animations and graphics.
Slave mode:
It is possible to link several ITA3D 710 fixtures for a synchronized lasershow, without the use of a
DMX controller.
Connect your devices with standard XLR-XLR cables. The first device in the chain needs to be set to a
basic function, such as sound-active or one of the auto shows.
Select the slave mode on all other connected device in the chain. You will notice that these devices
will mimic the actions of the first device.
DMX mode:
With an external DMX-controller (or DMX-software) it is possible to control every feature of the laser
device. It is possible to adjust the built-in patterns and to add several effects, such as zoom-effects or
pattern rotation.
NOTE: When the DMX-signal or master/slave signal is lost (due to a failure in the DMX-connection or
any other reason), the laser will shut off the output due to safety issues. This prevents the projection of
static images and/or patterns.

8
DMX operating mode
While in the DMX mode, it is possible to select the working mode of the laser. That way, you can either
choose to use your own programmed presets of your DMX controller, or to activate the music
activated/automatic working mode of the laser to have a fully-automatic lasershow. Depending on the
starting address you selected earlier, the laser responds to the following commands. In this example,
we use DMX starting address 1. When you use a different DMX-starting value, for example 29, the unit
will respond from channel 29, 30, 31.. and so on.
For more information about DMX, consult the manual of your DMX controller or software.
Channel
Function
Value
Description
1
Mode
0-49
Sound active mode
50-99
Auto beam mode
100-149
Auto animation mode
150-199
Manual mode auto run
200-255
Manual mode sound-active run
2
Color/shutter
0-255
Closed, single color, flashing color, multi-color and moving
multicolor effects
3
Pattern
selection
0-255
256 patterns to be selected
4
Movement Y
0-127
Manual up/down movement
128-191
Auto down-movement
192-255
Auto up-movement
5
Movement X
0-127
Manual left/right movement
128-191
Auto right-movement
192-255
Auto left-movement
6
Rolling X
0-127
Manual rolling (position)
128-255
Auto rolling (movement)
7
Rolling Y
0-127
Manual rolling (position)
128-255
Auto rolling (movement)
8
Rotation
0-127
Manual rotation (position)
128-191
Auto clockwise rotation (movement)
192-255
Auto counter-clockwise rotation (movement)
9
Zoom
0-85
Auto zoom (+)
86-170
Auto zoom (-)
171-255
Manual zoom (+/-)
10
Pattern size
0-255
0 is standard, 1-255 is small to large
11
Display dot
0-255
Variable adjustment, 0 is dot-display, 255 is best brightness
12
Drawing
0-127
Auto drawing mode 1
128-255
Auto drawing mode 2

9
Technical specifications
TYPE: ITA3D 710
Laser diodes
Type ITA3D 710:
- 60mW green laser (wavelength: 532nm)
- 150mW red laser (wavelength: 650nm)
- 500mW blue laser (wavelength: 450nm)
Tech specs:
- scanset: 15 kpps high-speed optical scanner with big angle capacities
- working modes: auto, sound-active, master/slave, DMX-512
- graphics and effects: 128 beam show and animated graphic show patterns with 3D animation
- high-efficiency 3D optical grating system for unique 3D lighting effects
- hanging bracket, for use with a lighting stand or truss system
- built-in microphone with adjustable microphone sensitivity
- adjustable pattern size (small-large)
- DMX-control with 3-pin XLR connectors
- DMX-control: 12 channels
- Power supply: 100-250V AC, 50/60 Hz
- Power consumption: 20 Watt
- dimensions: 300 x 185 x 100 mm
- weight: 2.5 kg
