Ayra Flash FX LED User manual

Flash FX LED
LED Strobe Effect with Segments
User Manual
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Introduction
Thank you for purchasing the Ayra Flash FX LED. This unique LED stroboscope is divided into segments so
that it is capable of producing one of a kind effects. This manual provides all the information you need to
know about the product before you start using it.
We advise that you read this user manual in its entirety before unpacking the contents of the box, so that you
are familiar with all of the functionality that this product has to offer. Please be sure to check that all of the
parts and accessories listed below under 'Box Contents' are included in the package. In the event that the
Flash FX LED does not function properly, or if you have any issues while operating it, please remove the
plug from the power socket and contact your retailer for assistance.
Box Contents
Ayra Flash FX LED Fixture
Double suspension bracket
Hardware (2x tightening knobs, 2x rubber rings)
Connection cable from IEC C13 to Schuko, 1.5 mm²
Please inspect the device and included accessories.
Should you discover that either the device or one or more of the included parts have been damaged or
rendered defective while in transit, please contact your dealer directly.
Please note that the pictures in this user manual serve illustrative purposes only and may differ from the
actual product.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Safety Instructions
Everyone involved with the installation, operation and maintenance of this device must:
Be qualified.
Be skilled.
Have read the instructions included in this user manual.
Be sure that neither the device nor the included accessories are damaged. Should the device or the
included accessories be damaged, please contact your retailer for more information.
Ensure that the device is in good working condition and is safe to operate. Please follow the advice and
instructions as they are described in this user manual.
Damage caused by misuse and/or modifications made to the device are not covered by the warranty.
This device does not contain any parts that can be repaired or replaced by the user. Should maintenance or
repairs be necessary, they must be handled by a qualified technician.
The light source of this device is not replaceable. If the light source no longer functions, the entire device
needs to be replaced.
Important information regarding health and safety
Do not remove any labels or stickers from this device.
Do not leave any cables lying around.
The device should not be opened up and any hardware or software that may be present should not be
modified.
To achieve optimal performance, any inputs on the device should not be fed with a signal higher than
necessary.
The device should only be used indoors; contact with water, rain and moisture should always be avoided.
Do not place any objects containing liquid on top of the device.
Remove the device from any nearby flames or heat sources; do not place it near flammable fluids, gasses
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
WARNING!
Keep this device away from moisture, water and rain to avoid the chance of electric shocks!
WARNING!
Only connect this device to a suitable power socket. This device functions on a specific power
voltage. If it is plugged into a power socket with a different voltage, it could result in permanent
damage and even dangerous situations such as fire or electric shocks.
WARNING!
Be careful when operating this device. Touching the wires that are connected to the mains,
inside or outside the device, could result in electric shocks!

or objects.
Disconnect this device from a power source if it is not being used for a long period of time; if maintenance is
necessary, or if it needs to be cleaned.
– Do not pull or tug on the cable to remove a connector as this may cause damage.
Do not use any cables other than the ones described in this manual. Do not use defective cables. Please
contact your retailer if the included or necessary cables do not function properly with this device.
Only use this device with a stable AC power supply.
Only use this device with power from a grounded power source.
In the event that the device is exposed to extreme temperature changes (e.g. transported from a cold
outdoor environment into a warm indoor environment), it should not be turned on until it has reached room
temperature. This is necessary to prevent moisture (condensation) from forming inside the device, which
could lead to electric shocks.
Guidelines and operation of this device
This device is intended for use by professionals on stage, in theatres, in clubs and in similar entertainment
locations.
This device is not suitable for use by children and should always be operated by an adult.
This device is designed to create light effects for entertainment purposes. It is not suitable for household
illumination.
This device may only be used in a suitable environment where no damage to the device can occur. Do not
use the device in moist or dusty environments such as:
indoor swimming pools where chlorine is used
beaches or any location where sand and/or salt is present
outdoors
indoors in spaces where intense heat sources are present, or where it can reach temperature levels
that would be considered uncomfortable for a person
Avoid impact and collisions during use and transport. Do not move or transport the device while it is in use.
Avoid using excessive force when installing and operating the device.
Any user must become familiar with the functions of this device before using it.
Should the device not be used in the manner described in this user manual, damages or even injuries could
occur. Ayra cannot be held responsible for any injuries or damages that occur as a result of improper use of
this product.
Storage and transport
This product was designed for mobile use. Please only transport the device in the original packaging, or in
a flight case with a suitable foam inlay.
This device was not designed for permanent (24/7) use. The expected lifespan of the device will not be
affected by occasionally turning the device off. Disconnect the device or turn off the power when it is not
actively in use.
If the device is not in use for a long period of time, it should be disconnected and stored in a dust free
environment.
Do not expose the device to extreme temperature differences.
Housing
Inspect the device's housing frequently and always just before use. Avoid operating the device if there are
any large dents or cracks, or if screws are missing. Do not use the device if the housing is not in good
condition.
Contact your dealer or a qualified technician if you are unsure about the state of the device.
Check the device and the screws for corrosion. Corrosion must not be present on this device. Contact your
dealer or a qualified technician if you find any corrosion on the screws.
Every power and signal connector should be securely attached. Do not use the device if the connectors are
not secure.
- Avoid dust and dirt build up. Clean the device once a month by disconnecting it from the power supply and
wiping it down with a dry or slightly moist cloth. If the device is used frequently, the cleaning intervals should
increase.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Symbol Explanation
WEEE Ensure that this device is disposed of properly. This product falls under the WEEE
(Waste Electrical and Electronic Equipment) directive. The requirements of this directive apply
to all manufacturers and producers of electronic devices in the EU. Do not throw this product
away with regular rubbish. Please contact your local authority for more information about how
to recycle and dispose of these products in your region. By recycling this product in the proper
manner, we can work together to ensure that we can continue to enjoy these kinds of
products and still protect the environment as much as possible from pollution.
CE The CE logo indicates that this product meets the European norms and requirements to
which it must legally conform.
Suitable for indoor use only this product was only designed for indoor use. The maximum
environmental temperature must not exceed 40 degrees Celsius (104 degrees Fahrenheit).
Contact
Ayra professional lighting products
Verrijn Stuartweg 18
4462 GE Goes
The Netherlands
Please do not send any products to this correspondence address.
Should you wish to send in a product for repairs or for a refund, please contact your dealer for an RMA
re uest (Return Merchandise Authorisation).
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Operation Guidelines for this Device
1. Light output
2. Suspension bracket with tightening knobs
3. Power output via IEC C13
4. Power unput via IEC C14 with fuse holder
5. LED display with Menu buttons
6. Microphone
7. Safety cable attachment point
8. DMX input and output via 3 pin XLR
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
2
5
6
7
8
9
1
3
4

Operation and Mounting
To activate the device, plug it into a mains socket. Once it's connected to an active power source, it will turn
on automatically.
The device cannot be operated while it is still starting up and displays the ‘AYRA’ logo. Once the device has
fully started up, it will automatically jump to the last mode and setting. Operation modes and other settings
shown on the display can now be adjusted or changed via the menu buttons.
If a DMX signal is detected, the device shall automatically switch to DMX mode and the DMX address that
was last used. For a new device, this is usually DMX address 001. The DMX address can of course be
changed via the display and menu buttons.
The functions, modes and settings can be changed by using the display and menu buttons. Push ‘Enter’ to
select a function or to confirm a change. Push ‘Up’ and ‘Down’ to change any values and push the ‘Menu’
button to return to the main menu. A few seconds after confirming a setting by pressing ‘Enter’, the device
shall automatically return to the main menu and perform the set actions. This can be sped up by holding the
‘Menu’ button down for 2 seconds after confirming a setting by pressing ‘Enter’. This is usually necessary
after adjusting the operation mode or DMX address.
The Menu includes the following options and fuctions:
Display Mode Function
ADDR / A001 DMX Address Configuration Address A001 … A510
CHND Channel Mode Selection 3CH/13CH
SLND Slave Mode Master
Slave 1
Slave 2
SHND Automatic Show Mode SH 0 15 Show selection (0 = random) + OFF
S001 S099 Speed selection (slow to fast)
SOUND Sound controlled Mode Mode: ON / OFF
SENS Sensitivity 0 100: Sensitivity in %
MANU Manual Mode STRO 000 255 LED fast on / strobe
DIMM 000 255 Dimmer 0 100%
LED LED Display On / Off when
unused for long periods
ON/OFF
DISP Display Inversion Display Invert, disp dslp
TEST Test Mode Test programme to check the operation of each
LED by illuminating every LED one by one
INFO HOUR = Usage in hours
VER = Firmware version
0000 – 9999 Hours of use
Displays firmware version. Cannot be adjusted
or changed.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

An explanation of all available functions can be found below
ADDR With this function, you can determine the DMX start address of the device. Set it channel 001, and
the device will respond to DMX channel 1. Set it to channel 003, then the device will respond to DMX
channel 3 and so on.
CHND DMX channel mode allows the selection of ‘X’ number of channels with which certain functions of the
device can be operated. For certain functions, a simple, limited channel mode can be used while others will
require more extensive modes for optimum functionality.
SLND Using the Master / Slave Mode, it’s possible to connect several devices of the same type with one
another, via DMX 3 pin XLR cables so that they perform exactly the same movements and functions at the
same time. Therefore, single devices do not respond individually (or chaotically) and this results in a
completely coordinated show. In the Master / Slave function, the first device in the circuit does not receive
DMX signal.
PLEASE NOTE: When Slave mode is activated, the device shall wait for a signal from the designated Master
device. Selecting a automatic or sound controlled mode is then not possible! To cancel the Slave mode,
enter the ‘SLND’ menu and select ‘NAST’. This then sets the device to Master mode and the stand alone
functions can then be activated once more.
SHND Within this mode, a number of automatic programs can be selected, the settings of which you have
full control over. There are 15 programmes to choose from (where programme ‘0’ is a random show) and the
speed of each show can be adjusted. In this mode, the Sound Controlled function must be switched off. If it
is switched on, the unit will only respond to sound registered via the in built microphone.
SOUN Here, the in built microphone can be set to On or Off.
SENS This mode allows you to set the sensitivity of the in built microphone. The further the device is
installed from the sound source, the higher the sensitivity of the microphone needs to be so that the sound is
registered and the device responds accordingly and in time to the music. The microphone is able to
withstand high sound pressure. However, if the sound is loud and the sensitivity is high, the microphone will
find it more difficult to register the beat. Experiment with the sensitivity and distance from the positioning of
the device to make sure you’re getting the best possible signal and optimum performance.
MANU In this mode, the device can be used as a standard stroboscope. Both the strobe speed and
dimming levels can be set manually. In this mode, it’s also possible to illuminate the device continually and
without flashes.
PLEASE NOTE: In order to use this function, all automatic shows in the SHND menu must be set to ‘Off’. If
the SHND is set to ‘On’, the device shall automatically switch to that mode.
LED When the LED display is not in use, it can be switched off. By setting ‘LED’ to ‘Off’, this will prevent red
symbols from illuminating when the device is being used in dark spaces. If you press of the menu buttons,
the display shall immediately light up and show all necessary information. If the display is not used, it shall
automatically switch off again within 30 seconds.
DISP This function is useful when the device is suspended and the display screen is upside down. Use this
function to flip the screen so that it can be easily read when the device is suspended.
TEST When the device needs to be checked, use the ‘TEST’ function to test one or more devices at the
same time. The device(s) shall continuously runs through a programme within which the LEDs are tested so
that any deviations or defects can be easily detected. The device shall continue to repeat the programme
until it is manually interrupted (when you switch the device to sound control, for example).
INFO When the device is used professionally, or has been rented, it is important to carry out general
maintenance on a regular basis and the device is inspected before and after use. The ‘HOUR’ function
shows the number of hours that the device has been active. This number counts the usage automatically and
cannot be adjusted or manipulated. There is also a ‘VER’ function which displays the current firmware
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

version of the device.
Operation Modes
Please find a clear explanation of the differences between all available Operation Modes below and how they
are affected by the menu functions listed above.
Auto
In Auto Mode, you can select one of the Operation Modes in which the device is not dependent on external
factors such as DMX signals, master signals or sound. Here, one of the basic programmes can be selected
such as setting the alternating speed or correcting the intensity.
Sound
The sound controlled mode or ‘sound mode’ uses an in built microphone that registers the beat of music and
a runs a program based on this. For example, the device can move in virtual synchronisation with any music,
providing an automatic light show.
When no music is detected or only highs are present in the music due to a break, the device will continue its
program at a slower pace. As such, the light show does not appear to come to a stand still. As soon as sound
is registered by the microphone once more, the device shall continue its program in synchronisation with the
beat.
Slave
In Slave Mode, it is possible to connect several devices of the same type with one another so that they
perform exactly the same movements and functions at the same time. Therefore, single devices do not
respond individually (or chaotically) and this results in a completely coordinated show. In theory, by adding a
DMX booster, an unlimited number of Slave devices can be linked to one Master device. Initially, no problem
would occur if 4 devices were linked and no DMX booster were added.
Please note: If you link devices of a different type or brand (even if they appear to have the same function),
chaotic or strange behaviour can occur. This is often because certain functions are linked to the incorrect
channels. This applies to DMX lighting of all types and brands.
DMX
The DMX Mode is the most comprehensive mode for optimum control over all functions of this device. Via
DMX, it is possible to control either a limited or large amount of functions via a DMX controller or DMX
software.
The device can be set to different channel modes so the channel layout (included below) is in alignment with
the layout of your DMX circuit and with the functions you want to use.
3CH mode
CH Function Value
1 Dimmer 0 100% 000 255
2 Effect 000 015 No function
016 030 Effect 1
031 045 Effect 2
046 060 Effect 3
061 075 Effect 4
076 090 Effect 5
091 105 Effect 6
106 120 Effect 7
121 135 Effect 8
136 150 Effect 9
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

151 165 Effect 10
166 180 Effect 11
181 195 Effect 12
196 210 Effect 13
211 225 Effect 14
226 240 Effect 15
241 255 Random effect
3 Effect speed / Sound controlled 000 249 Effect speed, slow to fast
250 255 Sound controlled
13CH mode
CH Function Value
1 Dimmer 0 100% 000 255
2 Shutter effects 000 007 LED Off
008 015 LED On
016 131 Stroboscope speed, slow to
fast
132 139 LED On
140 181 Fast off, slow on pulse effect,
slow to fast
182 189 LED On
190 231 Fast on, slow off, pulse effect,
slow to fast
232 239 LED On
240 247 Random Strobe
248 255 LED On
3 Strobe length duration 000 255 Quick flash slow flash
4 LED Dimmer segment 1 0 100% 000 255 0 100%
5 LED Dimmer segment 2 0 100% 000 255 0 100%
6 LED Dimmer segment 3 0 100% 000 255 0 100%
7 LED Dimmer segment 4 0 100% 000 255 0 100%
8 LED Dimmer segment 5 0 100% 000 255 0 100%
9 LED Dimmer segment 6 0 100% 000 255 0 100%
10 LED Dimmer segment 7 0 100% 000 255 0 100%
11 LED Dimmer segment 8 0 100% 000 255 0 100%
12 Effect 000 015 No function
016 030 Effect 1
031 045 Effect 2
046 060 Effect 3
061 075 Effect 4
076 090 Effect 5
091 105 Effect 6
106 120 Effect 7
121 135 Effect 8
136 150 Effect 9
151 165 Effect 10
166 180 Effect 11
181 195 Effect 12
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

196 210 Effect 13
211 225 Effect 14
226 240 Effect 15
241 255 Random effect
13 Effect speed / Sound controlled 000 249 Effect speed, slow to fast
250 255 Sound controlled
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Installation and Connection Instructions
Now you know how the Flash FX LED works. So that the device is used in the correct and safest way, please
make sure to follow the installation and connection instructions.
Make sure that children do not have access to the device or any connecting cables. If there are children
present, make sure that they are supervised. Since the device can be placed upright or be suspended, it is
possible for children to pull on any connecting cables and cause the device to fall. To prevent any accidents
or injury, this must be taken into account whenever the device is being positioned and/or installed.
Upright use
When you want to place the Flash FX LED in an upright position, make sure that the device is placed on a
stable surface such as a table, DJ booth or bar. The Flash FX LED is fitted with feet to ensure that it sits
stable where it is placed and without danger of shifting or slipping while in use.
Suspended use (brackets)
Should you want to suspend the Flash FX LED, use the suspension brackets, tightening knobs and rubber
rings included.
Place the rubber rings between the bracket and the fixture. Then tighten the knobs on both sides to make
sure that the bracket is secure.
If you want to suspend the device with a half coupler or G hook, this can be done by using the pre drilled
holes in the bracket. Standard hooks and/or brackets for 35 or 50 mm tubes (trusses or light stands) are
available from your local retailer.
Hardware for mounting the Flash FX LED to the wall, ceiling, or beam is not included. Contact a specialist if
you're not sure what hardware is required for your situation. A wooden beam and stone wall require different
mounting methods.
When the Flash FX LED is installed so that it is suspended, you will need to attach a safety cable to the
armature. This is not included, but is available at your local retailer. The device is fitted with an attachment
point for hooking a safety cable. Once hooked on, the cable can be wrapped around the truss or light stand
and attached once more to the same hook. This ensures the device is secure and prevents it from falling,
even if one or both of the brackets should come loose and fail.
Ensure that the safety cable has a load capacity of 10x the weight of the armature and that the device can
not fall farther than 30cm. You can wrap the safety cable around the truss or light stand several times to
ensure the fall is as short as possible. The shorter the fall, the less chance of damage or injury.
Light source
The Flash FX LED uses powerful LED modules that are made even more powerful by a special lens that
combines and focuses these beams, much like a magnifying glass. Since the human eye cannot adjust
quickly enough to sudden and intense exposure to the level of brightness this device produces, never look
directly into the lens at close range. While it won't result in permanent damage, it can cause temporary blind
spots which may cause disorientation and discomfort.
Cooling
De Flash FX LED is cooled by fans fitted in the housing. These are activated whenever the device is
switched on. Make sure the fans and vents are not blocked and regularly check that they are functioning
normally. Be aware that should the fans becomes clogged with substances like dust, smoke and moisture,
this may impair operation and shorten the life span of the device.
Parts and repairs
This product does not include spare parts and can not be repaired by the user. Any inspections and overall
maintenance should be carried out by a specialist only.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Cleaning and maintenance
Clean the exterior of this device on a monthly basis with a dry, or slightly damp microfibre cloth. Ensure that
the device is unplugged before cleaning it.
Check that all screws are intact and secured and tighten or replace them where needed. Check all metal
parts of the device for any signs of corrosion. If corrosion is found, the device needs to be checked
thoroughly.
Power Output
The Flash FX LED is fitted with an IEC C14 power input and an IEC C13 power output. This makes it
possible to link multiple devices with one single power supply, wall socket or power block.
The fuse fitted in this device is intended to protect that single device only. The input and output of the power
supply are directly wired to each other.
Since a standard 230 V group can handle a maximum load of 16A, and each Flash LX LED consumes
energy itself, the output can only handle 9A worth of external devices. This also includes a calculated safety
margin.
DMX Terminator
When using the device in DMX mode, it is common for a ‘terminator’ to be used at the end of the DMX
circuit. A DMX terminator is a terminal resistor, consisting of a 120 Ohm resistor placed between the second
and third pins to eliminate any data reflections. Data reflections can cause strange behaviour in DMX
controlled devices.
DMX terminators are sold read made but it is possible to solder a 120 Ohm resistor between the second and
third pins of a standard, male XLR connector.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

DMX Lighting Troubleshooting
If you have a problem with your DMX light effect, please consult the troubleshooting section for possible
solutions. If, after consulting this section, the problem remains unresolved, please contact your retailer for
more information and/or help.
This troubleshooting section contains information on how to solve the most common DMX light effect
problems, but it does not and cannot cover every eventuality. It is possible that you won't find your problem,
cause and solution in this section due to differences between various connecting devices.
Problem Possible Cause Solution
The device can not be turned on The fuse is blown Check the fuse to rule out if it is
blown or not. If it is blown, replace
it with a new fuse of the same type
and class.
Power cable not plugged in Check if the power cable is
properly connected to the device
and plugged into an active power
socket.
The device is not reacting to DMX
signals
Incorrect DMX start address Check if the device has been set
to the correct DMX start address
DMX controller is set to ‘Blackout’ Make sure the ‘Blackout’ function
on the DMX controller is not
activated
Make sure the polarity switch on
the DMX controller is set correctly
Try to reverse the DMX polarity
switch on the DMX controller.
The device is not reacting, there is
no DMX signal indication
Make sure the XLR cables are
connected properly and are not
defective. Replace if necessary.
The device does not react to
sound/music
Incorrect operation mode Make sure the sound activated
mode has been selected.
The internal microphone sensitivity
is too low
Check the microphone sensitivity
level and increase it if necessary.
The speaker is too far away, or is
not producing enough low tones
Place the light effect closer to a
speaker (or vice versa) and/or
increase the low frequency level.
The built in microphone is not
triggered by high tones.
The amount of projected light is
minimal
Dirty or dusty optics Clean the lens and/or other optics.
Dimmer is not completely open Check if the dimmers on the
spotlights themselves and/or if the
master dimmer is completely open.
Also, check the colour balance
settings.
The DMX signal appears to be
interrupted and some devices are
flashing or behaving strangely
Damaged/defective cables Check and replace the DMX
cables if necessary.
Power interference on the DMX
signal
Avoid connecting signal cables
parallel to power cables.
DMX terminator missing Close the DMX circuit with a DMX
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

terminator
Signal loss or interference in the
DMX circuit
Close the DMX circuit with a
terminator or connect a booster
after maximum 32 fixtures.
The device is not reacting properly
to DMX commands
Incorrect DMX channel mode Check that the correct DMX
channel mode is set
The operation mode can not be
changed
The device is in Slave mode If the device is in Slave mode, it
will wait for a master signal unless
there is a DMX signal present. Set
the device to Master to activate the
sound controlled or automated
operation modes.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Technical Specifications
Specifications
Powerful LED stroboscope with compact housing
LEDs divided into 8 separate an independently operated segments
Diverse interactive and varied programmes due to LED segments
Light source: 168x 0,5W white SMD LEDs
Diverse operation modes, such as static on, built in programmes that can be automatically played or sound
controlled, DMX, Master / Slave etc.
DMX Channels: 3 or 13 Channel mode
DMX input and output via 3 pin XLR
Power input via IEC C14, power output via IEC C13
Expected LED lifespan: 30.000 hours
Integrated attachment point for safety cable (built into housing)
Fuse: F3AL 250V
Power supply: 100 240V AC, 50/60 Hz
Power factor: 0.69 at 110V / 0.544 at 220V
Maximum power consumption: 112 W
Dimensions: 279 x 262 x 102 mm
Weight: 1.7 kg
Light projection:
Beam angle: 155 Degrees
Light output: 2860 Lux at 1m
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
